Safety and Warranty information V3.5 Overseas Project Multimedia Domain Controller Host Manual Manufacturer: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone Product Description Product Name: Multimedia Control System Specification & Model: IN9.0-OS Installation Location: Behind the vehicle dashboard Hardware: AA Software: AA Product Features 1. This product can output video signals and play multimedia files on the display screen. It can also receive the touch signal input by the display screen to realize the user's control of this product. 2. This product can process the video input of the vehicle's Surround View camera and output it to the display screen. 3. This product can output audio signals to make the vehicle's speaker sound. 4. This product accepts microphone input signals, allowing users to make phone calls or use voice assistants. 5. This product can communicate with the user's mobile phone through Bluetooth, WIFI, USB, etc., and provide functions such as Bluetooth phone and mobile phone interconnection. 6. This product also supports many upper-layer applications, and can realize functions such as navigation, occupant monitoring, and OTA upgrade. Technical Parameters Dimensions: 190*55*160mm Safety and Warranty information Weight: 1.1kg Working voltage: 7V-18V Rated voltage: 12V Normal working temperature: -40°C-70°C (full performance and full function) 70°C-85°C (full function) Feature Description Schematic diagram of the back-end interface of the full-featured host: Safety and Warranty information Camera 4-in-1 connector port: It can connect up to four 2-megapixel cameras for inputting video data from DVR, DMS, and OMS cameras. Built-in 360 Surround View: It can connect up to four 2-megapixel cameras for inputting video data from the AVM Surround View camera. Passenger: The video data output port of the passenger display. HVAC: The video data output port of the air conditioning control panel. IVI: The video data output port of the central display. USB3.0: A data transmission interface that supports the USB3.0 protocol. HUD: The video data output port of the HUD display. Cluster: The video data output port of the instrument display. Main connector: integrated power input, speaker audio output, microphone audio input, CAN bus signal transmission port, display enable signal, and fuel sensor signal input. SXM: SDARS antenna signal input port. GNSS: GNSS antenna signal input port. FM2: FM sub-antenna signal input port. FM1/AM: FM/AM main antenna signal input port. RVC: RVC camera video data input port. Gigabit Ethernet: Gigabit Ethernet cable access port. Fast Ethernet: Fast Ethernet cable access port. USB2.0: A data transmission interface that supports the USB2.0 protocol. Installation method; Bracket mounting Safety and Warranty information WARNING: 1. When using the voice assistant to control the vehicle, pay attention to the surrounding environment and personal safety to prevent serious accidents such as pinching and bumping. 2. For driving safety, do not operate the Vehicle Settings while driving. FCC compliance statement FCC ID: 2A7V5-IN90-OS-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or Safety and Warranty information television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Human RF Exposure: This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter.

NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023/3/13 Ref: Attestation Statement Part 2.911(d)(7) Filing FCC ID: 2A7V5-IN90-OS-1 NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. certifies that, as of the dates of this application, Americas Compliance Consulting LLC dba iCertifi “iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission- related proceeding involving the equipment. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Americas Compliance consulting, LLC dba iCertifi Address: 1001 SW Disk Drive, Suite 250, Bend, Oregon 97702 Contact Person: Paul Preston Tel: 866-885-45575 Email: [email protected] Sincerely, NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Americas Compliance Consulting LLC dba iCertifi Wenjuan Dou Paul Preston Signature V02072023

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2A7V5-IN90-OS-1 IN9.0-OS We, applicant Company Name: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Phone: +86-512-80616208 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2023/3/13 Signature Date Printed Name of Signee: Wenjuan Dou Company: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Phone: +86-512-80616208 Fax: Email: [email protected]

NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No.668 caihong Road Zhangjiagang Economic and Technological Development Zone Model Declaration Letter Date: 2023/1/30 Model Number: IN9.0-OS To Whom It May Concern: We, NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD., hereby declare that the Two Configurations are identical with Testing products except the information in the below table. Notes: "×" indicates that the configuration is different from that of Full Testing Sample. "√" indicates that the configuration is the same as that of Full Testing Sample. Full Testing Sample(components include MAX96714F, MAX96722, MAX96718F, TJA1044, TJA1021, Marvel 88Q5030, MX25L3233FM1R-08Q, Marvel 88Q2112, 9472B-80Z57-TM, D4S20L-40MA5-A, D4S20L-40MA5-D, D4S20L-40MA5-C, E6S20A-40MT5-A, D4S20L- 40MA5-F, 59S2AQ-40MT5-D, AMS22D-40MZ5-A, AMS22D-40MZ5-E, 34861-1406, D4S20L-40MA5-B, 59S2AQ-40MT5-B, 59S2AQ-40MT5-H, 59S2AQ-40MT5-K, 59S2AQ- 40MT5-F, 2349217-1, 34826-X124, TPS25846 and 2349217-1) design covers all complete product functions and complete components. Other configurations are only based on Full Testing Sample remove/change related components, interfaces and functions, that do not affect RF performance. All configurations have the same PCB layout and RF parts.. *note1: Camera Processing Chip Specification include MAX96714F, MAX96722, MAX96718F *note2: Digital Communication Chip Specification include TJA1044, TJA1021, Marvel 88Q5030, MX25L3233FM1R-08Q, Marvel 88Q2112 *note3: Connector Interface include 9472B-80Z57-TM, D4S20L-40MA5-A, D4S20L- 40MA5-D, D4S20L-40MA5-C, E6S20A-40MT5-A, D4S20L-40MA5-F, 59S2AQ-40MT5-D, AMS22D-40MZ5-A, AMS22D-40MZ5-E, 34861-1406, D4S20L-40MA5-B, 59S2AQ- 40MT5-B, 59S2AQ-40MT5-H, 59S2AQ-40MT5-K, 59S2AQ-40MT5-F, 2349217-1, 34826- X124 *note4: USB chip and Interface include TPS25846 ConfigurationCamera *Note1 Communication Components *Note2 Connector *Note3USB *Note4 Full Testing Sample√√√√ Secondary configuration ×××× NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No.668 caihong Road Zhangjiagang Economic and Technological Development Zone Sincerely, Wenjuan Dou / PM NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD.: No.668 caihong Road Zhangjiagang Economic and Technological Development Zone Tel: 0512-80616208 Email: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2A7V5-IN90-OS-1 IN9.0-OS For the products listed above, we request permanent confidentiality for all applicable exhibits as there are:  the Operational Description  the Block Diagram  the Schematics  the Parts Lists  the Tune Up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2023/3/13 Signature Date Printed Name of Signee: Company: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Phone: +86-512-80616208 Fax: Email: [email protected]

TESTREPORT REPORTNUMBER:I23W00008-EMC ON TypeofEquipment:MultimediaControlSystem TypeofDesignation:IN9.0-OS BrandName： Manufacturer:NOBOAUTOMOTIVETECHNOLOGIESCO.,LTD. FCCID:2A7V5-IN90-OS-1 ACCORDINGTO SubpartB,PART15,RADIOFREQUENCEYDEVICES,ANSIC63.4-2014 ChongqingAcademyofInformationandCommunicationsTechnology Monthdate,year March24,2023 Signature XiangLuoyong Director Note: Thetestresultsinthistestreportrelateonlytothedevicesspecifiedinthisreport. Thisreportshallnotbereproducedexceptinfullwithoutthewrittenapprovalof ChongqingAcademyofInformationandCommunicationsTechnology. ReportNo.:I23W00008-EMC ChongqingAcademyofInformationandCommunicationTechnology Address：No.8,YumaRoad,ChayuanNewCity,Nan’anDistrict,Chongqing,P.R.China,401336 Tel:0086-23-88069965FAX:0086-23-88608777 Page2of21 RevisionVersion ReportNumberRevisionDateMemo I23W00008-EMC002023-3-24Initialcreationoftestreport ReportNo.:I23W00008-EMC ChongqingAcademyofInformationandCommunicationTechnology Address：No.8,YumaRoad,ChayuanNewCity,Nan’anDistrict,Chongqing,P.R.China,401336 Tel:0086-23-88069965FAX:0086-23-88608777 Page3of21 CONTENTS 1.TestLaboratory................................................................................................................4 1.1.TestingLocation...............................................................................................................4 1.2.TestingEnvironment........................................................................................................4 1.3.Projectdata.......................................................................................................................4 1.4.Signature...........................................................................................................................4 2.ClientInformation............................................................................................................5 2.1.ApplicantInformation......................................................................................................5 2.2.ManufacturerInformation................................................................................................5 3.EquipmentunderTest(EUT)andAncillaryEquipment(AE)........................................6 3.1.AboutEUT.......................................................................................................................6 3.2.InternalIdentificationofEUTusedduringthetest.........................................................6 3.3.InternalIdentificationofAEusedduringthetest............................................................6 4.ReferenceDocuments......................................................................................................8 4.1.ReferenceDocumentsfortesting.....................................................................................8 5.TestEquipmentUtilized...................................................................................................9 6.TestResults....................................................................................................................10 6.1.SummaryofTestResults...............................................................................................10 7.TestResults.....................................................................................................................11 7.1.RadiatedEmission..........................................................................................................11 7.2.ConductedEmission.......................................................................................................18 7.3.AntennaPowerConductionLimitsforReceiver...........................................................18 AnnexAEUTPhotos.......................................................................................................................20 ANNEXBDeviationsfromPrescribedTestMethods.....................................................................21 ReportNo.:I23W00008-EMC ChongqingAcademyofInformationandCommunicationTechnology Address：No.8,YumaRoad,ChayuanNewCity,Nan’anDistrict,Chongqing,P.R.China,401336 Tel:0086-23-88069965FAX:0086-23-88608777 Page4of21 1.TestLaboratory 1.1.TestingLocation Name: ChongqingAcademyofInformationandCommunications Technology FCCRegistration Number: CN1239 Address: BuildingC,TechnologyInnovationCenter,No.8,YumaRoad, ChayuanNewArea,Nan'anDistrict,Chongqing,People’s RepublicofChina PostalCode:401336 Telephone:0086-23-88069965 Fax:0086-23-88608777 1.2.TestingEnvironment NormalTemperature:18.0-19.1°C RelativeHumidity:55-58% 1.3.Projectdata TestingStartDate:2023-03-21 TestingEndDate:2023-03-24 1.4.Signature 2023-03-24 LiQuan (Preparedthistestreport) Date 2023-03-24 XiaoYu (Reviewedthistestreport) Date 2023-03-24 XiangLuoyongDirectorofthe laboratory(Approvedthistestreport) Date ReportNo.:I23W00008-EMC ChongqingAcademyofInformationandCommunicationTechnology Address：No.8,YumaRoad,ChayuanNewCity,Nan’anDistrict,Chongqing,P.R.China,401336 Tel:0086-23-88069965FAX:0086-23-88608777 Page5of21 2.ClientInformation 2.1.ApplicantInformation CompanyName:NOBOAUTOMOTIVETECHNOLOGIESCO.,LTD. Address/Post: No.668,CaihongRoad,ZhangjiagangEconomicandTechnological DevelopmentZone,Suzhou,Jiangsu,P.R.China City:Suzhou,Jiangsu Country:China Telephone:0512-80616208 Fax:N/A Email:[email protected] ContactPerson:WenjuanDou 2.2.ManufacturerInformation CompanyName:NOBOAUTOMOTIVETECHNOLOGIESCO.,LTD. Address/Post: No.668,CaihongRoad,ZhangjiagangEconomicandTechnological DevelopmentZone,Suzhou,Jiangsu,P.R.China City:Suzhou,Jiangsu Country:China Telephone:0512-80616208 Fax:N/A Email:[email protected] ContactPerson:WenjuanDou ReportNo.:I23W00008-EMC ChongqingAcademyofInformationandCommunicationTechnology Address：No.8,YumaRoad,ChayuanNewCity,Nan’anDistrict,Chongqing,P.R.China,401336 Tel:0086-23-88069965FAX:0086-23-88608777 Page6of21 3.EquipmentunderTest(EUT)andAncillaryEquipment(AE) 3.1.AboutEUT EUTDescriptionMultimediaControlSystem ModelnameIN9.0-OS Br…

Text truncated - open the document above for the full version.

Test Photograph Description: Front view of Radiated Emission Test Setup (Below 1GHz) Description: Back view of Radiated Emission Test Setup (Below 1GHz) Description: Front view of Radiated Emission Test Setup (Above 1GHz) Description: Back view of Radiated Emission Test Setup (Above 1GHz)
