2A7Z4-TLASelfie Monitor Screen

RF EXPOSURE EVALUATION EUT Specification EUT Selfie Monitor Screen Model Number TLA Series Model TLAW0-149, TLAW0-149-CN, TLAW0-44 Model Difference All models are the same except for the model names. FCC ID 2A7Z4-TLA Antenna gain (Max) BR+EDR: 1.95 dBi 5G WIFI: 3.74 dBi Operation Frequency BT: 2.402GHz ~ 2.480GHz WIFI: 5.180GHz ~ 5.240GHz WIFI: 5.745GHz ~ 5.825GHz Power Supply DC 5V Battery 3.7V Classification Per Stipulated Test Standard §15.247(i), §2.1093 Max. output power BR+EDR BR+EDR:1.76 dBm 5G WIFI U-NII-1 IEEE 802.11a: 8.29 dBm IEEE 802.11n HT20: 7.31 dBm IEEE 802.11n HT40: 7.14 dBm U-NII-3 IEEE 802.11a: 8.64 dBm IEEE 802.11n HT20: 8.36 dBm IEEE 802.11n HT40: 8.13 dBm Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio Page 2 of 3 frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. Two antenna is available for the EUT. The minimum separation distance is 5mm. Page 3 of 3 Measurement Result BT: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power (dBm) Calculation Result 1-g SAR 2480 3-DH5 1.76 6±1 2 0.49918 7.5 5G WIFI: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power (dBm) Calculation Result 1-g SAR 5785 IEEE 802.11a 8.64 8±1 9 6.05594 7.5 Maximum Simultaneous transmission 1-g SAR for Bluetooth & 5G WIFI Maximum 1-g SAR (Bluetooth) Maximum 1-g SAR (5G WIFI) ∑1-g SAR Limit Results 0.49918 6.05594 0.87402 1.000 Pass No need to test SAR. Signature: Alan He Date: 2026-08-03

Setup Photographs Radiated Band edge and Spurious Emission Page 2 of 2 Conducted emissions

TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC330BX ProductName:Antenna Page 1 SpecificationFor Approval Date:2025.3.14 Version:1.0 客 户 名 称 Customer：先智 客 户 料 号 CustomerP/N： 腾 祥 料 号 T X P/N：AN2450-FPC330BX 规 格 描 述 Description : 2.4G/5G FPC 天线1.13mm 黑色线 L=50mm +IPEX TengxiangCheckedBy: 腾 祥 审 核 CustomerApprovedBy: 客 户 审 核 DRAWN 制 作 路婷 TESTEDBY 检 测 CHECKEDBY 审 核 胡超 CHECKEDBY 审 核 Q.C.DEPT. 品 管 周志红 Q.C.DEPT. 品 管 APPROVEDBY 核 准 韦佳 APPROVEDBY 核 准 NO. 53 ShatouSha ChongRoad,ChangAn Town,Guangdongprovince,China 中国广东省东莞市长安镇沙头区沙涌路53号 TEL:86-769-81873082FAX:86-769-82663788 http://www.tenxiang.cn TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC330BX ProductName:Antenna Page2 Index: 1.Specification(规格) 2.CharacteristicsandReliabilityTest(产品特性和可靠性测试标准) 3.Antenna-SParameterTestData(样品测试数据) 4.Antenna-RadiationPatternTestData(辐射模式测试数据) 5.MechanicalandPackingDrawing(图纸包装规范) RevisionHistory（变更履历） RevisionDateChangeNotificationDescription 1.02025.3.14 初版 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC330BX ProductName:Antenna Page3 1.Specification SamplePhoto A.ElectricalCharacteristics Frequency频率2400-2500MHz/5150-5850MHz S.W.R.驻波比<=2.0 AntennaGain增益3.42dBi/3.74dBi Polarization 极化方式Linear Impedance 阻抗50Ohm B.Material&MechanicalCharacteristics CableType线材规格OD1.13mm,BIack ConnectorType连接器规格I-PEX C.Environmental StorageTemperature 存储温度 -40 ̊C~+80 ̊C OperationTemperature 工作温度 -40 ̊C~+80 ̊C TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC330BX ProductName:Antenna Page4 2.CharacteristicsandReliabilityTest TestItems 测试 项目 TestConditionandProcedure 测试方法 Requirements 要求Result 结果 1V.S.W.R. 电压驻波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 2Insertion Loss插入损 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest设置网络分析仪参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 3Antenna Gain 天线增益 SetDUTonAntennaChamber;makeindividual calibrationtotest设置天线暗室参数进行测试 DirectiveDUTspecification 符合待测物规范 PASS 4Solderability 可焊性 GB/T2423.28-2005 Temp:260±5°C;Duration:5seconds温度260± 5°C;持续5秒 Tinevenlyonfull 上锡均匀饱满 PASS 5PullTest 拉力 Holdingwithindividualspecification;force appliedtoaxisofterminal.单独定义产品端子拉力 1.DirectiveDUTspecification 2.FrequencyTol.≤5% 符合待测物规范;频率偏移≤5% PASS 6Dimension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面处理 DirectiveDUTspecification 符合待测物规范 PASS 7RoHSWithReferencetoIEC62321:2008withflowchart 参考IEC62321测试流程 DirectiveRoHS2015/863/EU 符合RoHS2015/863/EU标准 PASS TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC330BX ProductName:Antenna Page5 3.Antenna-SParameterTestData 4.Antenna-RadiationPatternTestData Frequency(MHz)2400.02450.02500.05150.05500.05850.0 Efficiency(%)58.0065.8062.1067.2061.1063.50 Gain(dBi)3.383.423.293.713.743.52 TengxiangTechnology.Inc 东莞市腾祥电子有限公司 ProductNumber:AN2450-FPC330BX ProductName:Antenna Page6 5.MechanicalDrawingSeeattachedfiles B C D AN2450-FPC330BX / Antenna 1/1 ±0.5±0.2±1 OD1.13 Part Number Name CB-113BS Coaxial Cable 1 No. 2 1 Q'ty 1 Material Finish A SYY 2025.03.13 DES BY Note: 1.Mark is important dimension;"Cpk "Identify for process control(CpK 1.33). 2.Tolerance:Unmarked tolerance refer to the standard tolerance please. 3.Pay attention to the direction of the connector. APPROVER DATE SIGN DESCRIPTION SCALE: APP BY Tolerance X.XX X.X X° TITLE: PART NO.: CUSTOMER P/N: CHK BY RF BY UNITS: mm REVISION: HFREACHRoHS2.0 CONFIDENTIAL AN2450-FPC0640 FPC Black Black 1 CR-113-ZP-A 3 Cu I-PEX Au Plated AN2450-FPC0640 1 2 3 端子朝向如图所示 WJ 2025.03.13 HC 2025.03.13 YCX 2025.03.13 100pcs/ PE bag Revision : A Customer : ALL APPROVED BY CHECKED BY DESIGNED BY Name: Page: 1 of 1 Date: Part Number : 产品包装规范 PACKING CRITERION 8000pcs/Carton 3. SEALING 。 MEAS G W: KGS N W: KGS QTY: PCS ITEM NO: C/NO MADE IN CHINA SIDE FRONT 2.PACKING 1 . Enter PE bag。 2025.03.13 AN2450-FPC330BX Antenna AN2450-FPC0640

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART E TEST REPORT For Selfie Monitor Screen MODEL NUMBER: TLA, TLAW0-149, TLAW0-149-CN, TLAW0-44 REPORT NUMBER: E04A26050950F00502 ISSUE DATE: August 3, 2026 FCC ID: 2A7Z4-TLA Prepared for Ningbo Fulman Communication Technology Co., Ltd No.98, Yuanzhong Road, Economic Development Zone, Xiang shan County, Zhejiang, China Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A26050950F00502 Page 2 of 58 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 August 3, 2026 Initial Issue REPORT NO.: E04A26050950F00502 Page 3 of 58 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result ON TIME AND DUTY CYCLE ANSI C63.10-2020, Clause 12.2 None; for reporting purposes only. Pass 6dB AND 26dB EMISSION BANDWIDTH AND 99% OCCUPIED BANDWIDTH KDB 789033 D02 v02r01 Section C.1 FCC Part 15.407 (a)/(e), Pass CONDUCTED OUTPUT POWER KDB 789033 D02 v02r01 Section E.3.a (Method PM)/KDB 789033 D02 v02r01 Section E.3.b (Method PM) Section E.2.d (Method SA-2) FCC 15.407 (a) Pass POWER SPECTRAL DENSITY KDB 789033 D02 v02r01 Section F FCC 15.407 (a) Pass AC POWER LINE CONDUCTION EMISSION ANSI C63.10-2020, Clause 6.2 FCC 15.207, Pass RADIATED EMISSIONS AND BAND EDGE MEASUREMENT KDB 789033 D02 v02r01 Section G.3, G.4, G.5, and G.6 FCC 15.407 (b) FCC 15.209 FCC 15.205 Pass FREQUENCY STABILITY ANSI C63.10-2020, Clause 6.8 FCC 15.407 (g) Pass DYNAMIC FREQUENCY SELECTION (SLAVE) KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 FCC Part 15.407 (h), N/A DYNAMIC FREQUENCY SELECTION (MASTER) KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 FCC Part 15.407 (h), N/A ANTENNA REQUIREMENT N/A FCC 47 CFR Part 15.203/ 15.407(a)(1) (2), Pass ADDITIONAL REQUIREMENTS N/A FCC Part 15.407 (c), Pass Note: 1. N/A: In this whole report not applicable. 2. For ISED, this report is also performed according to ANSI C63.10-2020 + Cor.1-2023 + C63.10a-2024 + Errata to C63.10a-2024 standards. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART E. REPORT NO.: E04A26050950F00502 Page 4 of 58 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. CHANNEL LIST ........................................................................................................ 8 5.3. MAXIMUM EIRP ....................................................................................................... 9 5.4. THE WORSE CASE POWER SETTING PARAMETER ............................................ 9 5.5. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 10 5.6. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 11 5.7. SETUP DIAGRAM .................................................................................................. 11 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 12 7. ANTENNA PORT TEST RESULTS ..................................................................................... 14 7.1. ON TIME AND DUTY CYCLE ................................................................................. 14 7.2. 6dB AND 26dB EMISSION BANDWIDTH AND 99% OCCUPIED BANDWIDTH..... 15 7.3. CONDUCTED OUTPUT POWER ........................................................................... 17 7.4. POWER SPECTRAL DENSITY .............................................................................. 20 7.5. FREQUENCY STABILITY ....................................................................................... 22 7.6. DYNAMIC FREQUENCY SELECTION (SLAVE) .................................................... 24 7.7. DYNAMIC FREQUENCY SELECTION (MASTER) ................................................. 28 8. RADIATED TEST RESULTS ............................................................................................... 32 8.1. RADIATED EMISSIONS AND BAND EDGE MEASUREMENT .............................. 38 9. AC POWER LINE CONDUCTION EMISSION ..................................................................... 51 10. ANTENNA REQUIREMENT ................................................................................... 54 11. ADDITIONAL REQUIREMENTS ......................................................................…

Text truncated - open the document above for the full version.

100 / 131 Freq. Stability 20C 3.7V n20 5825MHz Ant1 Freq. Stability 20C 4.2V n20 5825MHz Ant1 101 / 131 Freq. Stability -20C 4V n20 5825MHz Ant1 Freq. Stability -10C 4V n20 5825MHz Ant1 102 / 131 Freq. Stability 0C 4V n20 5825MHz Ant1 Freq. Stability 10C 4V n20 5825MHz Ant1 103 / 131 Freq. Stability 20C 4V n20 5825MHz Ant1 Freq. Stability 30C 4V n20 5825MHz Ant1 104 / 131 Freq. Stability 40C 4V n20 5825MHz Ant1 Freq. Stability 50C 4V n20 5825MHz Ant1 105 / 131 Freq. Stability 20C 3.3V n40 5190MHz Ant1 Freq. Stability 20C 3.7V n40 5190MHz Ant1 106 / 131 Freq. Stability 20C 4.2V n40 5190MHz Ant1 Freq. Stability -20C 4V n40 5190MHz Ant1 107 / 131 Freq. Stability -10C 4V n40 5190MHz Ant1 Freq. Stability 0C 4V n40 5190MHz Ant1 108 / 131 Freq. Stability 10C 4V n40 5190MHz Ant1 Freq. Stability 20C 4V n40 5190MHz Ant1 109 / 131 Freq. Stability 30C 4V n40 5190MHz Ant1 Freq. Stability 40C 4V n40 5190MHz Ant1 110 / 131 Freq. Stability 50C 4V n40 5190MHz Ant1 Freq. Stability 20C 3.3V n40 5230MHz Ant1 111 / 131 Freq. Stability 20C 3.7V n40 5230MHz Ant1 Freq. Stability 20C 4.2V n40 5230MHz Ant1 112 / 131 Freq. Stability -20C 4V n40 5230MHz Ant1 Freq. Stability -10C 4V n40 5230MHz Ant1 113 / 131 Freq. Stability 0C 4V n40 5230MHz Ant1 Freq. Stability 10C 4V n40 5230MHz Ant1 114 / 131 Freq. Stability 20C 4V n40 5230MHz Ant1 Freq. Stability 30C 4V n40 5230MHz Ant1 115 / 131 Freq. Stability 40C 4V n40 5230MHz Ant1 Freq. Stability 50C 4V n40 5230MHz Ant1 116 / 131 Freq. Stability 20C 3.3V n40 5755MHz Ant1 Freq. Stability 20C 3.7V n40 5755MHz Ant1 117 / 131 Freq. Stability 20C 4.2V n40 5755MHz Ant1 Freq. Stability -20C 4V n40 5755MHz Ant1 118 / 131 Freq. Stability -10C 4V n40 5755MHz Ant1 Freq. Stability 0C 4V n40 5755MHz Ant1 119 / 131 Freq. Stability 10C 4V n40 5755MHz Ant1 Freq. Stability 20C 4V n40 5755MHz Ant1 120 / 131 Freq. Stability 30C 4V n40 5755MHz Ant1 Freq. Stability 40C 4V n40 5755MHz Ant1 121 / 131 Freq. Stability 50C 4V n40 5755MHz Ant1 Freq. Stability 20C 3.3V n40 5795MHz Ant1 122 / 131 Freq. Stability 20C 3.7V n40 5795MHz Ant1 Freq. Stability 20C 4.2V n40 5795MHz Ant1 123 / 131 Freq. Stability -20C 4V n40 5795MHz Ant1 Freq. Stability -10C 4V n40 5795MHz Ant1 124 / 131 Freq. Stability 0C 4V n40 5795MHz Ant1 Freq. Stability 10C 4V n40 5795MHz Ant1 125 / 131 Freq. Stability 20C 4V n40 5795MHz Ant1 Freq. Stability 30C 4V n40 5795MHz Ant1 126 / 131 Freq. Stability 40C 4V n40 5795MHz Ant1 Freq. Stability 50C 4V n40 5795MHz Ant1 127 / 131 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT a 5745 Ant1 14.442 0.5 Pass NVNT a 5785 Ant1 15.084 0.5 Pass NVNT a 5825 Ant1 15.072 0.5 Pass NVNT n20 5745 Ant1 15.069 0.5 Pass NVNT n20 5785 Ant1 12.549 0.5 Pass NVNT n20 5825 Ant1 13.518 0.5 Pass NVNT n40 5755 Ant1 33.834 0.5 Pass NVNT n40 5795 Ant1 35.028 0.5 Pass 128 / 131 -6dB Bandwidth NVNT a 5745MHz Ant1 -6dB Bandwidth NVNT a 5785MHz Ant1 129 / 131 -6dB Bandwidth NVNT a 5825MHz Ant1 -6dB Bandwidth NVNT n20 5745MHz Ant1 130 / 131 -6dB Bandwidth NVNT n20 5785MHz Ant1 -6dB Bandwidth NVNT n20 5825MHz Ant1 131 / 131 -6dB Bandwidth NVNT n40 5755MHz Ant1 -6dB Bandwidth NVNT n40 5795MHz Ant1

67 / 131 Freq. Stability 20C 3.7V a 5825MHz Ant1 Freq. Stability 20C 4.2V a 5825MHz Ant1 68 / 131 Freq. Stability -20C 4V a 5825MHz Ant1 Freq. Stability -10C 4V a 5825MHz Ant1 69 / 131 Freq. Stability 0C 4V a 5825MHz Ant1 Freq. Stability 10C 4V a 5825MHz Ant1 70 / 131 Freq. Stability 20C 4V a 5825MHz Ant1 Freq. Stability 30C 4V a 5825MHz Ant1 71 / 131 Freq. Stability 40C 4V a 5825MHz Ant1 Freq. Stability 50C 4V a 5825MHz Ant1 72 / 131 Freq. Stability 20C 3.3V n20 5180MHz Ant1 Freq. Stability 20C 3.7V n20 5180MHz Ant1 73 / 131 Freq. Stability 20C 4.2V n20 5180MHz Ant1 Freq. Stability -20C 4V n20 5180MHz Ant1 74 / 131 Freq. Stability -10C 4V n20 5180MHz Ant1 Freq. Stability 0C 4V n20 5180MHz Ant1 75 / 131 Freq. Stability 10C 4V n20 5180MHz Ant1 Freq. Stability 20C 4V n20 5180MHz Ant1 76 / 131 Freq. Stability 30C 4V n20 5180MHz Ant1 Freq. Stability 40C 4V n20 5180MHz Ant1 77 / 131 Freq. Stability 50C 4V n20 5180MHz Ant1 Freq. Stability 20C 3.3V n20 5200MHz Ant1 78 / 131 Freq. Stability 20C 3.7V n20 5200MHz Ant1 Freq. Stability 20C 4.2V n20 5200MHz Ant1 79 / 131 Freq. Stability -20C 4V n20 5200MHz Ant1 Freq. Stability -10C 4V n20 5200MHz Ant1 80 / 131 Freq. Stability 0C 4V n20 5200MHz Ant1 Freq. Stability 10C 4V n20 5200MHz Ant1 81 / 131 Freq. Stability 20C 4V n20 5200MHz Ant1 Freq. Stability 30C 4V n20 5200MHz Ant1 82 / 131 Freq. Stability 40C 4V n20 5200MHz Ant1 Freq. Stability 50C 4V n20 5200MHz Ant1 83 / 131 Freq. Stability 20C 3.3V n20 5240MHz Ant1 Freq. Stability 20C 3.7V n20 5240MHz Ant1 84 / 131 Freq. Stability 20C 4.2V n20 5240MHz Ant1 Freq. Stability -20C 4V n20 5240MHz Ant1 85 / 131 Freq. Stability -10C 4V n20 5240MHz Ant1 Freq. Stability 0C 4V n20 5240MHz Ant1 86 / 131 Freq. Stability 10C 4V n20 5240MHz Ant1 Freq. Stability 20C 4V n20 5240MHz Ant1 87 / 131 Freq. Stability 30C 4V n20 5240MHz Ant1 Freq. Stability 40C 4V n20 5240MHz Ant1 88 / 131 Freq. Stability 50C 4V n20 5240MHz Ant1 Freq. Stability 20C 3.3V n20 5745MHz Ant1 89 / 131 Freq. Stability 20C 3.7V n20 5745MHz Ant1 Freq. Stability 20C 4.2V n20 5745MHz Ant1 90 / 131 Freq. Stability -20C 4V n20 5745MHz Ant1 Freq. Stability -10C 4V n20 5745MHz Ant1 91 / 131 Freq. Stability 0C 4V n20 5745MHz Ant1 Freq. Stability 10C 4V n20 5745MHz Ant1 92 / 131 Freq. Stability 20C 4V n20 5745MHz Ant1 Freq. Stability 30C 4V n20 5745MHz Ant1 93 / 131 Freq. Stability 40C 4V n20 5745MHz Ant1 Freq. Stability 50C 4V n20 5745MHz Ant1 94 / 131 Freq. Stability 20C 3.3V n20 5785MHz Ant1 Freq. Stability 20C 3.7V n20 5785MHz Ant1 95 / 131 Freq. Stability 20C 4.2V n20 5785MHz Ant1 Freq. Stability -20C 4V n20 5785MHz Ant1 96 / 131 Freq. Stability -10C 4V n20 5785MHz Ant1 Freq. Stability 0C 4V n20 5785MHz Ant1 97 / 131 Freq. Stability 10C 4V n20 5785MHz Ant1 Freq. Stability 20C 4V n20 5785MHz Ant1 98 / 131 Freq. Stability 30C 4V n20 5785MHz Ant1 Freq. Stability 40C 4V n20 5785MHz Ant1 99 / 131 Freq. Stability 50C 4V n20 5785MHz Ant1 Freq. Stability 20C 3.3V n20 5825MHz Ant1

34 / 131 Frequency Stability Condition Mode Frequency (MHz) Antenna Measured Frequency (MHz) Frequency Error (Hz) Deviation (ppm) Limit (MHz) Verdict 20C 3.3V a 5180 Ant1 5179.94 -60000 -11.58 5150-5250 Pass 20C 3.7V a 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass 20C 4.2V a 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass -20C 4V a 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass -10C 4V a 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass 0C 4V a 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass 10C 4V a 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass 20C 4V a 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass 30C 4V a 5180 Ant1 5179.92 -80000 -15.44 5150-5250 Pass 40C 4V a 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass 50C 4V a 5180 Ant1 5180 0 0 5150-5250 Pass 20C 3.3V a 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 20C 3.7V a 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 20C 4.2V a 5200 Ant1 5199.96 -40000 -7.69 5150-5250 Pass -20C 4V a 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass -10C 4V a 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 0C 4V a 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 10C 4V a 5200 Ant1 5200 0 0 5150-5250 Pass 20C 4V a 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 30C 4V a 5200 Ant1 5200.02 20000 3.85 5150-5250 Pass 40C 4V a 5200 Ant1 5199.88 -120000 -23.08 5150-5250 Pass 50C 4V a 5200 Ant1 5200 0 0 5150-5250 Pass 20C 3.3V a 5240 Ant1 5239.98 -20000 -3.82 5150-5250 Pass 20C 3.7V a 5240 Ant1 5239.98 -20000 -3.82 5150-5250 Pass 20C 4.2V a 5240 Ant1 5239.98 -20000 -3.82 5150-5250 Pass -20C 4V a 5240 Ant1 5239.96 -40000 -7.63 5150-5250 Pass -10C 4V a 5240 Ant1 5239.92 -80000 -15.27 5150-5250 Pass 0C 4V a 5240 Ant1 5239.94 -60000 -11.45 5150-5250 Pass 10C 4V a 5240 Ant1 5240 0 0 5150-5250 Pass 20C 4V a 5240 Ant1 5240 0 0 5150-5250 Pass 30C 4V a 5240 Ant1 5239.94 -60000 -11.45 5150-5250 Pass 40C 4V a 5240 Ant1 5240.02 20000 3.82 5150-5250 Pass 50C 4V a 5240 Ant1 5239.96 -40000 -7.63 5150-5250 Pass 20C 3.3V a 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass 20C 3.7V a 5745 Ant1 5745 0 0 5725-5850 Pass 20C 4.2V a 5745 Ant1 5744.94 -60000 -10.44 5725-5850 Pass -20C 4V a 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass -10C 4V a 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass 0C 4V a 5745 Ant1 5744.96 -40000 -6.96 5725-5850 Pass 10C 4V a 5745 Ant1 5745 0 0 5725-5850 Pass 35 / 131 20C 4V a 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass 30C 4V a 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass 40C 4V a 5745 Ant1 5745 0 0 5725-5850 Pass 50C 4V a 5745 Ant1 5744.96 -40000 -6.96 5725-5850 Pass 20C 3.3V a 5785 Ant1 5784.94 -60000 -10.37 5725-5850 Pass 20C 3.7V a 5785 Ant1 5784.98 -20000 -3.46 5725-5850 Pass 20C 4.2V a 5785 Ant1 5784.98 -20000 -3.46 5725-5850 Pass -20C 4V a 5785 Ant1 5784.98 -20000 -3.46 5725-5850 Pass -10C 4V a 5785 Ant1 5784.96 -40000 -6.91 5725-5850 Pass 0C 4V a 5785 Ant1 5784.98 -20000 -3.46 5725-5850 Pass 10C 4V a 5785 Ant1 5785 0 0 5725-5850 Pass 20C 4V a 5785 Ant1 5785 0 0 5725-5850 Pass 30C 4V a 5785 Ant1 5785.02 20000 3.46 5725-5850 Pass 40C 4V a 5785 Ant1 5784.98 -20000 -3.46 5725-5850 Pass 50C 4V a 5785 Ant1 5784.96 -40000 -6.91 5725-5850 Pass 20C 3.3V a 5825 Ant1 5824.96 -40000 -6.87 5725-5850 Pass 20C 3.7V a 5825 Ant1 5824.98 -20000 -3.43 5725-5850 Pass 20C 4.2V a 5825 Ant1 5824.98 -20000 -3.43 5725-5850 Pass -20C 4V a 5825 Ant1 5824.98 -20000 -3.43 5725-5850 Pass -10C 4V a 5825 Ant1 5824.96 -40000 -6.87 5725-5850 Pass 0C 4V a 5825 Ant1 5825 0 0 5725-5850 Pass 10C 4V a 5825 Ant1 5825 0 0 5725-5850 Pass 20C 4V a 5825 Ant1 5825.02 20000 3.43 5725-5850 Pass 30C 4V a 5825 Ant1 5825 0 0 5725-5850 Pass 40C 4V a 5825 Ant1 5824.96 -40000 -6.87 5725-5850 Pass 50C 4V a 5825 Ant1 5825 0 0 5725-5850 Pass 20C 3.3V n20 5180 Ant1 5180 0 0 5150-5250 Pass 20C 3.7V n20 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass 20C 4.2V n20 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass -20C 4V n20 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass -10C 4V n20 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass 0C 4V n20 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass 10C 4V n20 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass 20C 4V n20 5180 Ant1 5180 0 0 5150-5250 Pass 30C 4V n20 5180 Ant1 5179.98 -20000 -3.86 5150-5250 Pass 40C 4V n20 5180 Ant1 5179.96 -40000 -7.72 5150-5250 Pass 50C 4V n20 5180 Ant1 5180 0 0 5150-5250 Pass 20C 3.3V n20 5200 Ant1 5199.92 -80000 -15.38 5150-5250 Pass 20C 3.7V n20 5200 Ant1 5200.08 80000 15.38 5150-5250 Pass 20C 4.2V n20 5200 Ant1 5199.96 -40000 -7.69 5150-5250 Pass -20C 4V n20 5200 Ant1 5199.96 -40000 -7.69 5150-5250 Pass -10C 4V n20 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 0C 4V n20 5200 Ant1 5200.04 40000 7.69 5150-5250 Pass 10C 4V n20 5200 Ant1 5200.04 40000 7.69 5150-5250 Pass 36 / 131 20C 4V n20 5200 Ant1 5200.02 20000 3.85 5150-5250 Pass 30C 4V n20 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 40C 4V n20 5200 Ant1 5199.98 -20000 -3.85 5150-5250 Pass 50C 4V n20 5200 Ant1 5200.02 20000 3.85 5150-5250 Pass 20C 3.3V n20 5240 Ant1 5240.04 40000 7.63 5150-5250 Pass 20C 3.7V n20 5240 Ant1 5239.96 -40000 -7.63 5150-5250 Pass 20C 4.2V n20 5240 Ant1 5239.96 -40000 -7.63 5150-5250 Pass -20C 4V n20 5240 Ant1 5240.16 160000 30.53 5150-5250 Pass -10C 4V n20 5240 Ant1 5240.02 20000 3.82 5150-5250 Pass 0C 4V n20 5240 Ant1 5240 0 0 5150-5250 Pass 10C 4V n20 5240 Ant1 5239.96 -40000 -7.63 5150-5250 Pass 20C 4V n20 5240 Ant1 5239.86 -140000 -26.72 5150-5250 Pass 30C 4V n20 5240 Ant1 5240.14 140000 26.72 5150-5250 Pass 40C 4V n20 5240 Ant1 5239.96 -40000 -7.63 5150-5250 Pass 50C 4V n20 5240 Ant1 5239.98 -20000 -3.82 5150-5250 Pass 20C 3.3V n20 5745 Ant1 5745 0 0 5725-5850 Pass 20C 3.7V n20 5745 Ant1 5744.96 -40000 -6.96 5725-5850 Pass 20C 4.2V n20 5745 Ant1 5744.96 -40000 -6.96 5725-5850 Pass -20C 4V n20 5745 Ant1 5744.82 -180000 -31.33 5725-5850 Pass -10C 4V n20 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass 0C 4V n20 5745 Ant1 5744.98 -20000 -3.48 5725-5850 Pass 10C 4V n20 5745 Ant1 5745 0 0 5725-5850 Pass 20C 4V n20 5745 Ant1 5745.12 120000 20.89 5725-5850 Pass 30C 4V n20 5745 Ant1 5744.96 -40000 -6.96 …

Text truncated - open the document above for the full version.

Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT a 5180 Ant1 33.33 4.77 0.71 NVNT a 5200 Ant1 38.21 4.18 0.71 NVNT a 5240 Ant1 36.29 4.4 0.71 NVNT a 5745 Ant1 36.15 4.42 0.71 NVNT a 5785 Ant1 42.53 3.71 0.71 NVNT a 5825 Ant1 37.01 4.32 0.71 NVNT n20 5180 Ant1 34.92 4.57 0.76 NVNT n20 5200 Ant1 30.77 5.12 0.76 NVNT n20 5240 Ant1 33.72 4.72 0.76 NVNT n20 5745 Ant1 44.67 3.5 0.76 NVNT n20 5785 Ant1 31.43 5.03 0.76 NVNT n20 5825 Ant1 34.24 4.65 0.76 NVNT n40 5190 Ant1 15.87 8 1.55 NVNT n40 5230 Ant1 17.74 7.51 1.52 NVNT n40 5755 Ant1 14.81 8.29 1.52 NVNT n40 5795 Ant1 17.41 7.59 1.55 2 / 131 Duty Cycle NVNT a 5180MHz Ant1 Duty Cycle NVNT a 5200MHz Ant1 3 / 131 Duty Cycle NVNT a 5240MHz Ant1 Duty Cycle NVNT a 5745MHz Ant1 4 / 131 Duty Cycle NVNT a 5785MHz Ant1 Duty Cycle NVNT a 5825MHz Ant1 5 / 131 Duty Cycle NVNT n20 5180MHz Ant1 Duty Cycle NVNT n20 5200MHz Ant1 6 / 131 Duty Cycle NVNT n20 5240MHz Ant1 Duty Cycle NVNT n20 5745MHz Ant1 7 / 131 Duty Cycle NVNT n20 5785MHz Ant1 Duty Cycle NVNT n20 5825MHz Ant1 8 / 131 Duty Cycle NVNT n40 5190MHz Ant1 Duty Cycle NVNT n40 5230MHz Ant1 9 / 131 Duty Cycle NVNT n40 5755MHz Ant1 Duty Cycle NVNT n40 5795MHz Ant1 10 / 131 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Conducted Power (dBm) Total Conducted Power (W) Limit Conducted(dBm) Verdict NVNT a 5180 Ant1 8.29 0.00675 24 Pass NVNT a 5200 Ant1 7.92 0.00619 24 Pass NVNT a 5240 Ant1 7.6 0.00575 24 Pass NVNT a 5745 Ant1 8.51 0.0071 30 Pass NVNT a 5785 Ant1 8.64 0.00731 30 Pass NVNT a 5825 Ant1 8.57 0.00719 30 Pass NVNT n20 5180 Ant1 7.23 0.00528 24 Pass NVNT n20 5200 Ant1 7.19 0.00524 24 Pass NVNT n20 5240 Ant1 7.31 0.00538 24 Pass NVNT n20 5745 Ant1 7.96 0.00625 30 Pass NVNT n20 5785 Ant1 8.36 0.00685 30 Pass NVNT n20 5825 Ant1 8.11 0.00647 30 Pass NVNT n40 5190 Ant1 7.12 0.00515 24 Pass NVNT n40 5230 Ant1 7.14 0.00518 24 Pass NVNT n40 5755 Ant1 8.13 0.0065 30 Pass NVNT n40 5795 Ant1 8.12 0.00649 30 Pass 11 / 131 -26dB Bandwidth Condition Mode Frequency (MHz) Antenna -26 dB Bandwidth (MHz) NVNT a 5180 Ant1 18.162 NVNT a 5200 Ant1 18.285 NVNT a 5240 Ant1 18.501 NVNT n20 5180 Ant1 19.431 NVNT n20 5200 Ant1 19.515 NVNT n20 5240 Ant1 19.5 NVNT n40 5190 Ant1 38.4 NVNT n40 5230 Ant1 38.58 12 / 131 -26dB Bandwidth NVNT a 5180MHz Ant1 -26dB Bandwidth NVNT a 5200MHz Ant1 13 / 131 -26dB Bandwidth NVNT a 5240MHz Ant1 -26dB Bandwidth NVNT n20 5180MHz Ant1 14 / 131 -26dB Bandwidth NVNT n20 5200MHz Ant1 -26dB Bandwidth NVNT n20 5240MHz Ant1 15 / 131 -26dB Bandwidth NVNT n40 5190MHz Ant1 -26dB Bandwidth NVNT n40 5230MHz Ant1 16 / 131 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT a 5180 Ant1 16.201 NVNT a 5200 Ant1 16.195 NVNT a 5240 Ant1 16.234 NVNT a 5745 Ant1 16.186 NVNT a 5785 Ant1 16.237 NVNT a 5825 Ant1 16.267 NVNT n20 5180 Ant1 17.413 NVNT n20 5200 Ant1 17.407 NVNT n20 5240 Ant1 17.329 NVNT n20 5745 Ant1 17.365 NVNT n20 5785 Ant1 17.422 NVNT n20 5825 Ant1 17.416 NVNT n40 5190 Ant1 35.282 NVNT n40 5230 Ant1 35.228 NVNT n40 5755 Ant1 35.252 NVNT n40 5795 Ant1 34.929 17 / 131 OBW NVNT a 5180MHz Ant1 OBW NVNT a 5200MHz Ant1 18 / 131 OBW NVNT a 5240MHz Ant1 OBW NVNT a 5745MHz Ant1 19 / 131 OBW NVNT a 5785MHz Ant1 OBW NVNT a 5825MHz Ant1 20 / 131 OBW NVNT n20 5180MHz Ant1 OBW NVNT n20 5200MHz Ant1 21 / 131 OBW NVNT n20 5240MHz Ant1 OBW NVNT n20 5745MHz Ant1 22 / 131 OBW NVNT n20 5785MHz Ant1 OBW NVNT n20 5825MHz Ant1 23 / 131 OBW NVNT n40 5190MHz Ant1 OBW NVNT n40 5230MHz Ant1 24 / 131 OBW NVNT n40 5755MHz Ant1 OBW NVNT n40 5795MHz Ant1 25 / 131 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm) Duty Factor (dB) Total Conducted PSD (dBm) Limit Conducted(dBm) Verdict NVNT a 5180 Ant1 -5.97 4.77 -1.2 11 Pass NVNT a 5200 Ant1 -6.49 4.18 -2.31 11 Pass NVNT a 5240 Ant1 -7.72 4.4 -3.32 11 Pass NVNT a 5745 Ant1 -6.17 4.42 -1.75 30 Pass NVNT a 5785 Ant1 -6.8 3.71 -3.09 30 Pass NVNT a 5825 Ant1 -5.92 4.32 -1.6 30 Pass NVNT n20 5180 Ant1 -7.48 4.57 -2.91 11 Pass NVNT n20 5200 Ant1 -7.79 5.12 -2.67 11 Pass NVNT n20 5240 Ant1 -7.26 4.72 -2.54 11 Pass NVNT n20 5745 Ant1 -6.21 3.5 -2.71 30 Pass NVNT n20 5785 Ant1 -6.55 5.03 -1.52 30 Pass NVNT n20 5825 Ant1 -7.15 4.65 -2.5 30 Pass NVNT n40 5190 Ant1 -12.57 8 -4.57 11 Pass NVNT n40 5230 Ant1 -15.48 7.51 -7.97 11 Pass NVNT n40 5755 Ant1 -12.28 8.29 -3.99 30 Pass NVNT n40 5795 Ant1 -12.61 7.59 -5.02 30 Pass 26 / 131 PSD NVNT a 5180MHz Ant1 PSD NVNT a 5200MHz Ant1 27 / 131 PSD NVNT a 5240MHz Ant1 PSD NVNT a 5745MHz Ant1 28 / 131 PSD NVNT a 5785MHz Ant1 PSD NVNT a 5825MHz Ant1 29 / 131 PSD NVNT n20 5180MHz Ant1 PSD NVNT n20 5200MHz Ant1 30 / 131 PSD NVNT n20 5240MHz Ant1 PSD NVNT n20 5745MHz Ant1 31 / 131 PSD NVNT n20 5785MHz Ant1 PSD NVNT n20 5825MHz Ant1 32 / 131 PSD NVNT n40 5190MHz Ant1 PSD NVNT n40 5230MHz Ant1 33 / 131 PSD NVNT n40 5755MHz Ant1 PSD NVNT n40 5795MHz Ant1

Ningbo Fulman Communication Technology Co., Ltd 2026-07-10 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A7Z4-TLA) [ Ningbo Fulman Communication Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Lingyun Shen General manager Ningbo Fulman Communication Technology Co., Ltd Ningbo Fulman Communication Technology Co., Ltd 2026-07-10 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation St…
