2A7ZK-LAXBLCCLumos Charging Cradle

The Charging Cradle comes with an additional set of feet to add some character. Watch it turn into an alien-sheep-thingy by attaching the set of feet supplied. *For optimal charging, charge in ambient temperatures of <=30°C. If charging gets too hot, Firefly will temporarily stop charging to protect itself from overheating. Charging will automatically resume once it has cooled down sufficiently. CHARGING CRADLE GUIDE The Lumos Firefly has a small LED indicator to convey different information. Please note the colours below and the corresponding message. Red LED light - Firefly is charging. Green LED light - Firefly is fully charged. Yellow LED light - Firefly has temporarily paused charging to allow it to charge within acceptable operating temperatures*. To attach, gently peel off the default flat rubber base from underneath. Remove the adhesive protector from the feet and carefully stick them to the base of the Charging Cradle. The feet were designed with the longer feet in front, but feel free to orient them however works best for you. FIREFLY CHARGING INDICATORS TURN YOUR CRADLE INTO A SHEEP ~ BAAA LED indicator For more information, visit firefly.lumoshelmet.coFor more information, visit firefly.lumoshelmet.co DISCOVER MORE FEATURES For more information, visit firefly.lumoshelmet.co The full text of the UK declaration of conformity is available at the following internet address: https://lumoshelmet.co/UK_DOC CHARGING FIREFLY When the battery is low, place your Firefly into the Charging Cradle and connect it to a power source. A red LED light should appear indicating it’s charging. Firefly is fully charged when the red LED light on Firefly turns green. It takes roughly 5 hours for a full charge. Note: Firefly is Qi-compatible and can also be charged with other Qi wireless chargers. ICet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences etDéveloppement économique Canada. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pasproduire de brouillage,et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme auxCNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) L'appareil ne doit pas produire de brouillage; (2) L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre lefonctionnement. This transmitter must not be co-located or operating in conjunction with any other antenna ortransmitter. This equipment should be installed and operated with a minimum distance of 20centimeters between the radiator and your body. Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ouémetteur. Cet équipementdevrait être installé et actionné avec une distance minimum de 20 centimètres entre le radiateur et votre corps. IC Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic DevelopmentCanada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. The term “IC: “ before the certification/registration number only signifies that the Industry Canada technical specifications were met. This product meets the applicable Industry Canada technical specifications. FCC - Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Product: Lumos Charging Cradle Model Number: LAXBL-CC Operating frequency: 115kHz - 205kHz Max. RF output power: 7.2dBμA/m Hereby, Lumos Labs International Pte Ltd. declares that the radio equipment type Lumos Charging Cradle is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: lumoshelmet.co/EU_DOC SPECIFICATION OF RADIO TRANSMISSION Importer in the Philippines: Liberty & Co. 20 Talisay Road Barangay Forbes Park Makati City 121…

Text truncated - open the document above for the full version.

Lumos Labs International Pte Ltd U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Feb 22, 2023 Signed by (Printed Name/Title): Kenneth Young/ Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of a ny Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Lumos Labs International Pte Ltd Grantee Code: 2A7ZK FCC ID: 2A7ZK-LAXBLCC Contact Name: Bilal Raja Street Address: 11 Collyer Quay, #17-00, The Arcade, City/Province/Zip: Singapore 049317, Singapore Telephone No: +60 11-2110 9192 Email: [email protected] Applicant Signature: Date: 2023/02/22 Signed by (Printed Name/Title): Bilal Raja / Head of Product

(Lumos Labs International Pte Ltd) (2023.2.23) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2A7ZK-LAXBLCC [Lumos Labs International Pte Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Client’s signature: Client’s name / title : Bilal Raja / Head of Product (Lumos Labs International Pte Ltd) (2023.2.23) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2A7ZK-LAXBLCC [Lumos Labs International Pte Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Client’s signature: Client’s name / title : Bilal Raja / Head of Product

Lumos Labs International Pte Ltd 2022.11.25 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION EUT NAME: Lumos Charging Cradle Trademark: LUMOS MODEL : LAXBL-CC FCC ID: 2A7ZK-LAXBLCC To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Bilal Raja / Head of Product Contact information / address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore

External Photos

Size:20*20mm Model : LAXBL-CC FCC ID: 2A7ZK-LAXBLCC IC: 28829-LAXBLCC Label location

Internal Photos Antenna

Lumos Charging Cradle 1. Product name: Lumos Charging Cradle 2. Product Model: LAXBL-CC 3. Product input and output parameters: a. Input: 10W: 5V, 2A b. Output: 5W: 5V, 1A 4. Wireless parameters (including maximum power) Output: 5W: 5V, 1A Maximum Output Voltage: +5 - +12V Maximum Output Current: 2A Test Criteria Rated Value Minimum Value Maximum Value Unit Standby Mode Power Consumption Vcc=5V 110 80 130 mW Operating Frequency / 113 125 KHz Wireless Coil Dimensions (Unit: mm) SHENZHEN LINRONG TECHNOLOGY CO.,LTD ADD：Floor 3, building 1, LianJian Industrial Park, Huarong Road, Dalang street, Longhua District, Shenzhen A B C D E F G 40±2 2.6±0.25 13.85±0.30 35.5±0.5 31±1 12±1 2.3MAX ELECTRICAL CHARACTERISTICS(电气特性) PARAMETERS UNIT LIMIT Inductance ls @100khz,1.0Vrms μH 6.6±10% Q @100khz,1.0Vrms ≥45 DCR mΩ ＜80 PCBA Structural Diagram unit:mm PCBA Specifications Wireless Coil Specifications 31.4mm*23.4mm*2.6mm Diameter :36mm* Height 2.3mm* Projected wire length 5mm 5. Applicable country US, Canada, EU, UK 6. Warning 7. DOC Affirmation Letter Link

No.：BCTC/RF-EMC-005 Page 1 of 26 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2208559134-1E Applicant: Lumos Labs International Pte Ltd Product Name: Lumos Charging Cradle Model/Type Ref.: LAXBL-CC Tested Date: 2022-08-10 to 2022-08-15 Issued Date: 2022-08-16 Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 2 of 26 Edition：A.5 FCC ID: 2A7ZK-LAXBLCC The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Lumos Charging Cradle Trademark: LUMOS Model/Type Ref.: LAXBL-CC Prepared For: Lumos Labs International Pte Ltd Address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore Manufacturer: Lumos Labs International Pte Ltd Address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-08-10 Sample tested Date: 2022-08-10 to 2022-08-15 Issue Date: 2022-08-16 Report No.: BCTC2208559134-1E Test Standards: FCC Part15.209 ANSI C63.10-2013 Test Results: PASS Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 3 of 26 Edition：A.5 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 4 2. Test Summary ....................................................................................................... 5 3. Measurement Uncertainty ..................................................................................... 6 4. Product Information And Test Setup ..................................................................... 7 4.1 Product Information ............................................................................................... 7 4.2 Support Equipment ............................................................................................... 7 4.3 Test Setup Configuration ...................................................................................... 7 4.4 Test Mode ............................................................................................................. 8 5. Test Facility And Test Instrument Used ................................................................. 9 5.1 Test Facility ........................................................................................................... 9 5.2 Test Instrument Used ............................................................................................ 9 6. Conducted Emissions .......................................................................................... 11 6.1 Block Diagram Of Test Setup .............................................................................. 11 6.2 Limit .................................................................................................................... 11 6.3 Test Procedure ................................................................................................... 11 6.4 EUT Operating Conditions .................................................................................. 11 6.5 Test Result .......................................................................................................... 12 7. Radiated Emissions ............................................................................................. 14 7.1 Block Diagram Of Test Setup .............................................................................. 14 7.2 Limit .................................................................................................................... 15 7.3 Test Procedure ................................................................................................... 15 7.4 Test Result .......................................................................................................... 16 8. Bandwidth Test .................................................................................................... 20 9. Antenna Requirements ........................................................................................ 22 10. EUT Photographs ................................................................................................ 23 11. EUT Test Setup Photographs.............................................................................. 24 (Note: N/A Means Not Applicable) Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 4 of 26 Edition：A.5 1. Version Report No. Issue Date Description Approved BCTC2208559134-1E 2022-08-16 Original Valid Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 5 of 26 Edition：A.5 2. Test Summary The Product has been tested according to the following specifications: No. Test Parameter Clause No Results 1 Conducted Emission 15.207 PASS 2 Radiated Emission 15.209 PASS 3 20dB Bandwidth 15.215 PASS 4 Antenna Requirement 15.203 PASS Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 6 of 26 Edition：A.5 3. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the Product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. No. Item Uncertainty 1 3m chamber Radiated spurious emission(9kHz-30MHz) U=3.7dB 2 3m chamber Radiated spurious emission(30MHz-1GHz) U=4.3dB 3 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 4 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 5 Conducted Emission(150kHz-30MHz) U=3.20dB 6 Conducted Adjacent chan…

Text truncated - open the document above for the full version.

No.：BCTC/RF-EMC-005 Page 1 of 12 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2208559134-2E Applicant: Lumos Labs International Pte Ltd Product Name: Lumos Charging Cradle Model/Type Ref.: LAXBL-CC Tested Date: 2022-08-10 to 2022-08-15 Issued Date: 2022-08-16 Report No.: BCTC2208559134-2E No.：BCTC/RF-EMC-005 Page 2 of 12 Edition：A.5 FCC ID: 2A7ZK-LAXBLCC The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Lumos Charging Cradle Trademark: LUMOS Model/Type Ref.: LAXBL-CC Prepared For: Lumos Labs International Pte Ltd Address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore Manufacturer: Lumos Labs International Pte Ltd Address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-08-10 Sample tested Date: 2022-08-10 to 2022-08-15 Issue Date: 2022-08-16 Report No.: BCTC2208559134-2E Test Standards: FCC CFR 47 part1, 1.1307(b), 1.1310 Test Results: PASS Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2208559134-2E No.：BCTC/RF-EMC-005 Page 3 of 12 Edition：A.5 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 4 2. Product Information ............................................................................................... 5 2.1 Product Information ............................................................................................... 5 2.2 Support Equipment ............................................................................................... 5 2.3 Test Mode ............................................................................................................. 5 3. Test Facility And Test Instrument Used ................................................................. 6 3.1 Test Facility ........................................................................................................... 6 3.2 Test Instrument Used ............................................................................................ 6 4. Method Of Measurement ....................................................................................... 7 4.1 Applicable Standard .............................................................................................. 7 4.2 Block Diagram Of Test Setup ................................................................................ 7 4.3 Limit ...................................................................................................................... 8 4.4 Test Procedure ..................................................................................................... 8 4.5 Equipment Approval Considerations ..................................................................... 9 4.6 E And H Field Strength ....................................................................................... 10 5. Photographs Of Test Set-Up ............................................................................... 11 (Note: N/A Means Not Applicable) Report No.: BCTC2208559134-2E No.：BCTC/RF-EMC-005 Page 4 of 12 Edition：A.5 1. Version Report No. Issue Date Description Approved BCTC2208559134-2E 2022-08-16 Original Valid Report No.: BCTC2208559134-2E No.：BCTC/RF-EMC-005 Page 5 of 12 Edition：A.5 2. Product Information 2.1 Product Information Model/Type Ref.: LAXBL-CC Model differences: N/A Product Description: Lumos Charging Cradle Operation Frequency: 115kHz-205kHz Antenna installation: loop coil antenna Ratings: USB-C Input:5V2A Wireless Output:5W Hardware Version: N/A Software Version: N/A Cable of Product No. Cable Type Quantity Provider Length (m) Shielded Note 1 -- -- Applicant --- Yes/No With a ferrite ring in mid Detachable 2 -- -- BCTC -- Yes/No -- 2.2 Support Equipment No. Device Type Brand Model Series No. Note 1. Lumos Firefly --- LBLFF --- --- 2. Adapter --- BCTC001 --- --- Notes: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 2.3 Test Mode Test Modes 1 Wireless Charging(5W) Report No.: BCTC2208559134-2E No.：BCTC/RF-EMC-005 Page 6 of 12 Edition：A.5 3. Test Facility And Test Instrument Used 3.1 Test Facility All measurement facilities used to collect the measurement data are located at Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China. The site and apparatus are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1-1 other equivalent standards. FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 3.2 Test Instrument Used EMF Test Equipment Manufacturer Model# Serial# Last Cal. Next Cal. Electromagnet -ic radiation tester Wavecontrol SMP160 19SN0980 May 26, 2022 May 25, 2023 Electromagne- tic field probe Wavecontrol WP400-3 20WP120082 Aug. 30, 2021 Aug. 29, 2022 Report No.: BCTC2208559134-2E No.：BCTC/RF-EMC-005 Page 7 of 12 Edition：A.5 4. Method Of Measurement 4.1 Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure is c…

Text truncated - open the document above for the full version.

Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 24 of 26 Edition：A.5 11.EUT Test Setup Photographs Conducted emissions Photo Radiated Measurement Photos Report No.: BCTC2208559134-1E No.：BCTC/RF-EMC-005 Page 25 of 26 Edition：A.5
