2A7ZK-LBLFF01Lumos Firefly

*For optimal charging, charge in ambient temperatures of <=30°C. If charging gets too hot, Firefly will temporarily stop charging to protect itself from overheating. Charging will automatically resume once it has cooled down sufficiently. The Lumos Firefly has a small LED indicator to convey different information. Please note the colours below and the corresponding message. Red LED light - Firefly is charging. Green LED light - Firefly is fully charged. Yellow LED light - Firefly has temporarily paused charging to allow it to charge within acceptable operating temperatures*. FIREFLY CHARGING INDICATORS LED indicator Rear of Firefly Sticker CHARGING FIREFLY For more information, visit firefly.lumoshelmet.co Syncing all of your Firefly lights is as simple as double-tapping the power button. Any surrounding Firefly lights will then sync to the same pattern. When the battery is low, place your Firefly into the Charging Cradle and connect it to a power source. A red LED light should appear indicating it’s charging. Firefly is fully charged when the red LED light on Firefly turns green. It takes roughly 5 hours for a full charge. Note: Firefly is Qi-compatible and can also be charged with other Qi wireless chargers. Lumos SYNCING FIREFLY PAIRING FIREFLY For more information, visit firefly.lumoshelmet.co Press and hold the Firefly power button for a few seconds until it enters 'pairing mode'. In 'pairing mode', Firefly lights will breathe on and off. Download the Lumos App via the Apple App Store or Google Play Store and head to the pairing screen in the app. Click “Pair”. Your Firefly should pair within a few seconds. If it is not, repeat steps process. The full text of the UK declaration of conformity is available at the following internet address: https://lumoshelmet.co/UK_DOC LUMOS FIREFLY USER GUIDE FIREFLY QUICK START GUIDE For more information, visit firefly.lumoshelmet.co Power button - Single press: Powers on Firefly, and cycles through flash patterns. Power button - Double press: Sync flash patterns with other Firefly. Power button - Long press: While Firefly is off, enters pairing mode. While Firefly is on, turns off the device. FIREFLY KEY COMMANDS For more information, visit firefly.lumoshelmet.co DISCOVER MORE FEATURES For more information, visit firefly.lumoshelmet.co Seatpost padding allows you to mount Firefly at an angle. It is most suited for use on seatposts or other positions that require angled mounting, like forks. Low profile padding is flat and suited for most other mounting positions (ie: handlebar) Slot the protruding ends into the designated holes located below the universal mount When riding with Firefly, it is important to get the right angle to ensure the most optimal riding position. That's why we've included multiple sets of padding to suit different needs. MOUNTING PADDING For more information, visit firefly.lumoshelmet.co Download the Lumos App to unlock the full potential of Firefly UNLOCK YOUR ECOSYSTEM For more information, visit firefly.lumoshelmet.coFor more information, visit firefly.lumoshelmet.co All Lumos Firefly come with a set of navigational stickers to tell all your Firefly lights apart. When using multiple Firefly lights in your setup, place the sticker corresponding to its profile in the indentation on the rear of Firefly. IDENTIFY YOUR FIREFLY AT A GLANCE For more information, visit firefly.lumoshelmet.co Silicone strap Velcro strap The velcro strap provided can be used to mount the Firefly in more unusual places that cannot be achieved with the silicone straps, such as around an arm or a non-smart helmet. Attach the appropriate padding to the mount. To mount the Universal Mount, secure the silicone strap into one of the hooks on the mount. Pull it around your desired mounting surface and secure the strap in the opposite hook. To use the velcro strap, feed it through the two slots in the base of the Universal Mount as shown. Ensure that the Lumos logo is facing down when you feed the velcro through the hole. Wrap the velcro around the mounting feature you are trying to mount to. In some instances, you may need to wrap the velcro around multiple times. Ensure a tight fit to reduce unwanted vibrations. SILICONE STRAP MOUNTING VELCRO STRAP MOUNTING For more information, visit firefly.lumoshelmet.coFor more information, visit firefly.lumoshelmet.co Align to opening Push Push To use the mount clips, simply insert them into the side of the Universal Mount as shown. You'll need to install both clips for this to work as intended. Now when you place a Firefly into the Universal Mount, you should be able to feel the clips engage. You may need to push the Firefly in to secure it fully. To remove Firefly, press both clips at the same time. Feel free to keep the clips attached if you prefer to do so. The Universal Mount was designed to work both with and without the clips. For more information, visit firefly.lumoshelmet.co We've designed mounting clips specifically to give extra peace of mind to prevent Firefly from falling out of its base. Note: under normal cycling conditions and even fairly rough terrain, we never encountered an issue with Firefly falling out. WORRIED THAT FIREFLY WILL FALL OUT EVEN WITH THE STRONG MAGNETS? For more information, visit firefly.lumoshelmet.co 1 Download Lumos App and Pair Devices 2 Setup Sync Grid and Remote 3 Double Tap to Sync F IC Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic DevelopmentCanada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil contient des émetteurs/récepteurs exemptés de licence qui sont conformes aux flux RSS exemptés de licence de Innovation, Science et développement économique Canada. L’exploitation est soumise aux deux con…

Text truncated - open the document above for the full version.

Lumos Labs International Pte Ltd U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Feb 22, 2023 Signed by (Printed Name/Title): Kenneth Young/ Manager The Applicant acknowledges that they mus t maintain an agent for no les s tha n one yea r afte r terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges thei r responsibility to infor m the FC C whenever the Designated U.S . Agent information above changes. Applicant Company name: Lumos Labs International Pte Ltd Grantee Code: 2A7ZK FCC ID: 2A7ZK-LBLFF01 C ontact Name: Bilal Raja Street Address: 11 Collyer Qua y, #17- 00, The Arcade, City/Province/Zip: Singapore 049317, Singapore Tele phone No: +60 11-2110 9192 Email: [email protected] Applicant Signature: Date: 2023/02/22 Signed by (Printed Name/Title): Bilal Raja / Head of Product

(Lumos Labs International Pte Ltd) (2023.2.23) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2A7ZK-LBLFF01 [Lumos Labs International Pte Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Client’s signature: Client’s name / title : Bilal Raja / Head of Product (Lumos Labs International Pte Ltd) (2023.2.23) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2A7ZK-LBLFF01 [Lumos Labs International Pte Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Client’s signature: Client’s name / title : Bilal Raja / Head of Product

Lumos Labs International Pte Ltd 2023.01.04 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Lumos Firefly Trademark: LUMOS MODEL : LBLFF FCC ID: 2A7ZK-LBLFF01 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Bilal Raja / Head of Product Contact information / address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore

Lumos Labs International Pte Ltd 2023.01.04 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION EUT NAME: Lumos Firefly Trademark: LUMOS MODEL : LBLFF FCC ID: 2A7ZK-LBLFF01 To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Bilal Raja / Head of Product Contact information / address: 11 Collyer Quay, #17-00, The Arcade, Singapore 049317, Singapore

External Photos

Size:20*20mm Model : LBLFF FCC ID: 2A7ZK-LBLFF01 IC: 28829-LBLFF01 Label location

Internal Photos Wireless charge receiving antenna Antenna BT

FCC ID: 2A7ZK-LBLFF01 RF exposure evaluation §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  GFSK Modulation Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR GFSK(2M) 2.480 1.69 1±1 2 1.58 5 0.50 3.0 Conclusion: For the max result : 0.50W/Kg ≤ FCC Limit 3.0 for 1g SAR. The Product unsupported at the same time to Transmitting.
