2A839-PD28TEQTUBULAR MOTOR

0102 Option B：Copy programming Option A：Button programming Operating Instruction (Please complete the operations within 10s, except limit setting） Pairing Press the motor Head Button once. Press Pairing Button once. Programming success. The motor jogs once. 1 × The motor jogs once. 1 × 1 × Remote A (Paired) Press STOP Button 5 times. Remote B (Unpaired) Press Pairing Button once. Programming success. 5 × The motor jogs once. 1 × The motor jogs once. 1 × 1 × Change Direction 1 × Press UP Button once. The motor jogs once. 1 × The motor jogs once. 1 × Press Pairing Button once. 1 × Direction is changed. Set the First and Second Limits Before the limit position is set, the motor is in the jogging state. When the first and second limit positions are set, the motor turns to the interlocking state. After the limit has been set, short press UP/DOWN Button, and the motor will run up/down continuously. Press Pairing Button once again. Press Up/Down Button and move to the desired position. Press UP/DOWN Button and move to the desired position. The motor jogs twice and enters limit setting state. 2 × The motor jogs once. 1 × Until the motor jogs once The second limit is set. 1 × Until the motor jogs once. The first limit is set. 1 × Press and hold STOP Button. Press and hold STOP Button. Press Pairing Button once. 1 × 1 × 25/28 Tubular Motor and Finished Product Installation（TE） Instruction Manual Power： Refer to the nameplate for details Frequency： 433.92MHz Receiver Sensitivity： -112dBm IP Grade： IP20 Working Temperature： -20°C ~+60°C Technical Data -20°C 60°C Product Introduction Motor Head Working Temperature Head Button Power Supply Line Remote Pairing Button UP Button STOP Button DOWN Button 1 2 L N Brown Wire Blue Wire Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 05 04 Warranty Card User Name Contact Number Postal Address Product Name Model Purchase Date The following situations are out of free warranty: 1. Faults and damages caused by human factors, including failure to use according to the instructions or caused by the environment not in accordance with the instructions. 2.Without the authorization, the user is not allowed to disassemble the motor. Otherwise it will not be covered by the warranty. 3. Damage caused by other force majeure (such as flood, lightning strike, earthquake). 4. Failure to show valid shopping vouchers and warranty card, etc. 5. Products that do not belong to our company (such as counterfeit products). 6. Normal use, wear, tear and dipping. 03 Attention 1) Improper installation may result in serious personal injury. Please strictly follow all instructions. 2) Please place the motor and remotes out of the reach of children to avoid accidents caused by improper operations. 3) Before installing the motor, please make sure to remove all extraneous power cables. 4) During the setting process, it may fail because of signal interference. Please reset once. 5) The remote button time should keep short, otherwise it will affect the battery life; The button time should be about 0.5s, and the interval remote between each button is about 1s. When the battery power is too low, the transmitter does not work. The battery needs to be replaced. 6) Please operate strictly in accordance with the motor function manual. If there are any unfinished matters, please contact with our company. The third limit can only be set after the first and second limits are completed. After the third limit has been set, long press STOP Button to run to the third limit. Set the Third Limit Press UP/DOWN Button and move to the desired position. The motor jogs twice and enters limit setting state. The motor jogs once. 1 × Press Pairing Button once again. 1 × Press Pairing Button once. 1 × Until the motor jogs once. The third limit is set. 1 × Long press STOP Button. 2 × The motor jogs once. Delete the current operating remote/channel. 1 × The motor jogs once. 1 × 1 × Press Pairing Button once. 1 × Press DOWN Button once. For multi-channel remote, delete the channel of the currently operating remote. Delete All Limits Delete the Currently Operating Remote/Channel The motor jogs twice. Delete all limits. 2 × The motor jogs once. 1 × 1 × Press Pairing Button once. 1 × Press STOP Button once. The speed of motor is adjustable, which can switch among three levels. The initial factory setting defaults to maximum. Adjustable Speed 1 × Simultaneously press UP Button and STOP Button once. 1 × 2 × 3 × Motor jogs once represents the motor speed is at the first level. Motor jogs twice represents th…
