2A839-PEM202Remote Control

Product introduction Technical data • Power ： 3V（CR2032） • Frequency ： 433.92MHz • Working current ： ≤20mA Warning • Keep away from moisture and impact to extend the service life. • Check whether the battery needs to be replaced,when it becomes less sensitive. • Press any button for more than 10 seconds, the wall switch will stop sending wireless signals. • Please dispose of used batteries properly. Packing list Poyal PEM 201 wall switch is a 86-type single-button curtain control product. Users do not need wiring in the wall, and can stall it at a distance or in a dark box. It can control the Poyal curtain system with one button. PEM201 Remote Control Manual Switch*1 • Working temperature: -20°C ~ +60°C • Product size： 86 * 86 * 16.8mm • Battery specification： CR2032*1 PE bag*1Rear base*1 Instruction*1 Open Stop Close Indicator light Code button Warning PEM202 Remote Control Manual Product introduction Packing list Switch*1PE bag*1Rear base*1 Instruction*1 Code button Open Stop Close Indicator light Indicator light Open Stop Close Indicator light Indicator light Technical data • Power ： 3V（CR2032） • Frequency ： 433.92MHz • Working current ： ≤20mA • Working temperature ：-20°C ~ +60°C • Product size： 86 * 86 * 16.8mm • Battery specification： CR2032*1 • Keep away from moisture and impact to extend the service life. • Check whether the battery needs to be replaced,when it becomes less sensitive. • Press any button for more than 10 seconds, the wall switch will stop sending wireless signals. • Please dispose of used batteries properly. Poyal PEM 202 wall switch is a 86-type dual-button curtain control product. Users do not need wiring in the wall, and can stall it at a distance or in a dark box. It can control the Poyal curtain system with one button. Zhejiang General Light Curtain Co.,LTD. EU DECLARATION OF CONFORMITY in accordance with Annex VI of Directive 2014/53/EU of the European Parliament and of the Council 1. For the following Radio equipment: Product name / Number (s): Remote Control / PEM202, PEM201 Trade name or Brand: POYAL Software / Hardware number: V4.0/V1.0 2. Name and address of the manufacturer: Zhejiang General Light Curtain Co.,LTD. Manufacturer: Xin Tang Tou Village, Xin Jie Town, Xiao Shan District,HangZhou City, Zhe Jiang Province, China 3. This declaration of conformity is issued under the sole responsibility of the Manufacturer. 4. Object of the declaration (identification of the radio equipment allowing traceability; it may include a colour image of sufficient clarity where necessary for the identification of the radio equipment): 5. The object of the declaration described above is in conformity with the relevant Union harmonization legislation: Directive 2014/53/EU (RED) 6. References to the relevant harmonized standards used or references to the other technical specifications in relation to which conformity is declared: Article 3.3:N/A Article 3.2: ETSI EN 300 220-1 V3.1.1 (2017-02) ETSI EN 300 220-2 V3.2.1 (2018-06) Article 3.1b: ETSI EN 301 489-1 V2.2.3 (2019-11) ETSI EN 301 489-3 V2.1.2 (2021-03) Article 3.1a Health: EN 50663:2017 Article 3.1a Electrical Safety: EN IEC 62368-1:2020+A11:2020 IEC 62368-1: 2018 7. Notified Body Name: Eurofins Electrical and Electronic Testing NA, Inc. Notified Body Number: 0980 Notified Body Assessment Performed: Module B/C on Article 3.1a, 3.1b, 3.2 and 3.3 Technical File Identification Number: N/A 8. Where applicable, description of accessories and components, including software, which allow the radio equipment to operate as intended and covered by the EU declaration of conformity: User instructions are provided in the User Manual. The Software and Hardware versions are specified above. 9. Additional information: Referring to Article 10.2 of the Directive, this equipment is so constructed that it can be operated in all Member States, without infringing applicable requirements on the use of radio spectrum. Referring to Article 10.10 of the Directive, there are no restrictions on putting this equipment into service or of requirements for authorisation of use. Please refer to the User Manual for details. On behalf of: Date 2025-05-09 Signature Name: Lei guo Title: Manager Manufacturer: Zhejiang General Light Curtain Co.,LTD. Address: Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China CE Maintenance 1.EUT Operating temperature range: -20° C to 40° C . 2.Input: 3V（CR2032） 3.The device complies with RF specifications when the device used at 5mm from your body. 4. Operating frequency:433.92MHz Declaration of Conformity Zhejiang General Light Curtain Co.,LTD. hereby declares that this Remote Control is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.In accordance with Article 10(2) and Article 10(10),This product is allowed to be used in all EU member states. 5. Max. Transmitting Power:-14.22 dBm Importer:XXXXXX Importer Address:XXXXXX FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful in…

Text truncated - open the document above for the full version.

Zhejiang General Light Curtain Co.,LTD. Covered Equipment Certification Attestation Letter 5/9/2023 ATTN.: Reviewing Engineer FCC ID: 2A839-PEM202 Zhejiang General Light Curtain Co.,LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Zhejiang General Light Curtain Co.,LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signature: Date: 2022-05-09 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

AxiomInternational,Inc. * theapplicantmustdesignateacontactlocatedintheUnitedStatesforpurposesofactingasthe applicant’sagentforserviceofprocess,regardlessofwhethertheapplicantisadomesticorforeign entity.AnapplicantlocatedintheUnitedStatesmaydesignateitselfastheagentforserviceofprocess. U.S.AgentDesignationforServiceofProcess- CertificationAttestationLetter 4/27/2023 ATTN.:ReviewingEngineer FCCID:2A839-PEM202 Persection2.911(d)(7)oftheFCCrules, ZhejiangGeneralLightCurtainCo.,LTD. (“theapplicant”) certifiesthattheequipmentforwhichauthorizationissoughtisdesignatedtothefollowingU.S. agent*forserviceofprocess: CompanyName:AxiomInternational,Inc. PhysicalU.S.CompanyAddress:5522MainsailWayGainesville.GA30504 Agentcontactname/Title:JeffVolante/President AgentEmailAddress:[email protected] TelNo.:678-517-1325 Theabovecontactpersonacceptstheobligationforserviceofprocess. Theapplicantacceptstomaintainanagentfornolessthanoneyearafterthegranteehas terminatedallmarketingandimportationortheconclusionofanyCommission-related proceedinginvolvingtheequipment. ApplicantSigned:AgentSigned(ifdifferenttoApplicant): Signed:Signed: Printedname:GuoLeiPrintedname:JeffVolante Title:ManagerTitle: President CompanyName:ZhejiangGeneralLightCurtainCo.,LTD.CompanyName:AxiomInternational,Inc. Date:4/27/2023Date:4/27/2023

Differences Description We Zhejiang General Light Curtain Co.,LTD. state: Product： Remote Control Model Name： PEM202, PEM201 Trade Name: POYAL The electrical circuit design, layout, components used and internal wiring for above models are identical, only the model name is different. Signatory Signature: Date: 2022-05-09 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Zhejiang General Light Curtain Co.,LTD. 2023-05-09 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Remote Control / PEM202, PEM201 # FCC ID:2A839-PEM202) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the(Block diagram/Operational description/Schematic diagram) required to be submitted with this application be permanently withheld from public review. the above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Signature: Date: 2023-05-09 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Page 1 of 3 Report No.: STS2304003 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: PEM202 Photo 1 Photo 2 Page 2 of 3 Report No.: STS2304003 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2304003 Photo 5 Photo 6

Label 3*4cm CE Label 4*5cm

Page 1 of 2 Report No.: STS2304003 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: PEM202 Photo 1 Photo 2 Antenna Page 2 of 2 Report No.: STS2304003 Photo 3 Photo 4

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2304003H02 Issued for Zhejiang General Light Curtain Co.,LTD. Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China Product Name: Remote Control Brand: POYAL Model Number: PEM202 Series Model(s): PEM201 FCC ID: 2A839-PEM202 Test Standard: FCC 47CFR §2.1093 S T L A B S Page 2 of 9 Report No.: STS2304003H02 Test Report Certification Applicant’s Name ................. : Zhejiang General Light Curtain Co.,LTD. Address ................................. : Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China Manufacturer's Name .......... : Zhejiang General Light Curtain Co.,LTD. Address ................................. : Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China Product Description Product Name ........................ : Remote Control Brand ................................... : POYAL Model Number ....................... : ... : PEM202 Series Model(s) ...................... : PEM201 Standards ............................. : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 04 Apr. 2023 Date (s) of performance of tests ............. : 04 Apr. 2023 ~ 23 May 2023 Date of Issue ........................................... : 23 May 2023 Test Result ............................................... : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2304003H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2304003H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 23 May 2023 STS2304003H02 ALL Initial Issue Page 5 of 9 Report No.: STS2304003H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Remote Control Brand POYAL Model Number PEM202 Series Model(s) PEM201 Model Difference Only the model name is different. Product Description The EUT is Remote Control. Operation Frequency: 433.92 MHz Modulation Type: OOK Antenna gain: 0dBi Antenna Designation: PCB Antenna Rating Input: 3V（CR2032） Hardware version number V4.0 Software version number V1.0 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2304003H02 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2304003H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2304003H02 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating struc…

Text truncated - open the document above for the full version.

PAC50101 PAC50102 COC501 PAC50101 PAC50102 Model: PEM202 Brand:POYAL Antenna Type:PCB Zhejiang General Light Curtain Co.,LTD. Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TESTREPORT Report No.:STS2304003W02 Issued for Zhejiang General Light Curtain Co.,LTD. Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China Product Name: Remote Control Brand: POYAL Model Number: PEM202 Series Model(s): PEM201 FCC ID: 2A839-PEM202 Test Standard: FCC Part 15.231 S T L A B S Page 2 of 30 Report No.: STS2304003W02 TEST REPORT CERTIFICATION Applicant’s Name ........................ : Zhejiang General Light Curtain Co.,LTD. Address ...................................... : Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China Manufacturer's Name ................. : Zhejiang General Light Curtain Co.,LTD. Address ...................................... : Xin Tang Tou Village, Xin Jie Town, Xiao Shan District, HangZhou City, Zhe Jiang Province, China Product Description Product Name ............................. : Remote Control Brand .......................................... : POYAL Model Number ............................ : PEM202 Series Model(s) ........................... : PEM201 Test Standards .......................... : FCC Part 15.231 Test Procedure............................ : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : 04 Apr. 2023 Date of performance of tests ................ : 04 Apr. 2023 ~ 13 Apr. 2023 Date of Issue......................................... : 13 Apr. 2023 Test Result ............................................ : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 30 Report No.: STS2304003W02 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 8 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.5 EQUIPMENTS LIST 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 TEST RESULTS 12 4. RADIATED EMISSION MEASUREMENT 13 4.1 RADIATED EMISSION LIMITS 13 4.2 TEST PROCEDURE 15 4.3 DEVIATION FROM TEST STANDARD 15 4.4 TEST SETUP 16 4.5 EUT OPERATING CONDITIONS 17 4.6 TEST RESULTS 17 4.7 FIELD STRENGTH CALCULATION 18 5. BANDWIDTH TEST 22 5.1 LIMIT 22 5.2 TEST REQUIREMENTS 22 5.3 TEST PROCEDURE 22 5.4 TEST SETUP 22 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 23 6. DUTY CYCLE 24 6.1 TEST PROCEDURE 24 6.2 TEST SETUP 24 6.3 EUT OPERATION CONDITIONS 24 6.4 TEST RESULTS 25 Page 4 of 30 Report No.: STS2304003W02 TABLE OF CONTENTS Page 7. AUTOMATICALLY DEACTIVATE 27 7.1 STANDARD REQUIREMENT 27 7.2 TEST PROCEDURE 27 8. ANTENNA REQUIREMENT 29 8.1 STANDARD REQUIREMENT 29 8.2 EUT ANTENNA 29 APPENDIX 1-PHOTOS OF TEST SETUP 30 Page 5 of 30 Report No.: STS2304003W02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 13 Apr. 2023 STS2304003W02 ALL Initial Issue Page 6 of 30 Report No.: STS2304003W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a)/15.209/ 15.231.(b) Radiated Spurious Emission PASS -- 15.231(a)(1)/ 15.231(b)(2) Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) “N/A” denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated>6G ±5.22dB 7 Conducted Emission (9KHz-150KHz) ±2.14dB 8 Conducted Emission (150KHz-30MHz) ±2.54dB Page 7 of 30 Report No.: STS2304003W02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Remote Control Brand POYAL Model Number PEM202 Series Model(s) PEM201 Model Difference Only the model name is different. Frequency band 433.92 MHz Rating Input: 3V（CR2032） Modulation Type OOK Antenna Type PCB Antenna Antenna Gain 0dBi Hardware version number V4.0 Software version number V1.0 Connecting I/O Port(s) N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. The antenna information refer the manufacturer provide report, applicable only to the tested sample identified …

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID.: 2A839-PEM202 DSC Setup photo Model Number: PEM202 DSC radiation L DSC radiation H
