2A84DMAXSTRPLUSSTROKE MASTER PLUS

USER MANUAL THE MOST REALISTIC LIFE-LIKE PENETRATION EXPERIENCE STROKER #engineered4pleasure Congratulations on your purchase of Stroke Master+, the world’s elite pleasure stroker equipped with hyper powerful motor offering almost unlimited torque and unparallel stroke depth. Please take a moment to read through this user manual before using the stroker. YOUR STROKE MASTER+ On/Off Button • Plus Button • Minus Button • • Charging Port • Housing Case Inner Sleeve • Detachable Cap • Sleeve Removing Handle • • Quality Check Seal Make sure to charge your STROKE MASTER+ together with the remote before the first use. In case the battery is getting low, the LED around button area starts flashing fast. Insert the DC plug into the DC port. LED will start flashing slowly indicating charging. Once fully charged LED stops flashing. Charge at least once every 6 months to protect and extend battery lifetime. IMPORTANT: Use only original USB charging cable provided with your MAXTASY product. USB adapter must not have higher charging current than 1A (one amper). CHARGING Charing time Stroke Master+: 120min Running time Stroke Master+: 120min Charing time Remote: 60min Running time Remote: 12hrs REMOTE CONTROL On/Off Button • Turbo Button • • Charging Port • Plus Button • Minus Button HOW TO USE 1. Remove the cap and the sleeve inner support 2. Wash the inner sleeve in warm soapy water before the first use 3. Lube up inner sleeve 4. Lube up your penis 5. Insert penis 6. Enjoy 7. Clean immediately after use, following cleaning instructions IMPORTANT: For the most pleasurable sensation, always apply a generous amount, at least 15ml/0.5oz, of water-based lubricant to the penis and the inner side of the sleeve prior to use. BUTTONS’ CONTROL WITHOUT THE REMOTE Press and hold On/Off Button until it lights up = product in stand-by mode Press On/Off Button shortly = stroking starts Press Plus Button shortly once = stroking speed increases (total of 10 stroking speed levels) Press Minus Button shortly once = stroking speed decreases Press and hold On/Off Button = stroking stops and light turns off TIP: For more details visit www.maxtasy.com/howtouse On/Off Button • Plus Button • Minus Button • BUTTONS’ CONTROL WITH THE REMOTE Press and hold On/Off Button on the main unit until it lights up = product is stand-by mode Press and hold On/Off Button on the remote until it lights up = remote control is activated Press On/Off Button or Plus Button on the remote = stroking starts Press Plus Button on the remote shortly once = stroking speed increases (total of 10 stroking speed levels) Press Minus Button on the remote shortly once = stroking speed decreases Press Turbo Button on the remote shortly once = stroking speed increases to the maximum level Press On/Off Button on the remote shortly = stroking stops Press and hold On/Off Button on the remote = remote control is de-activated and light turns off TIP: The remote-control range is 5meters On/Off Button • Turbo Button • • Plus Button • Minus Button Clean the outer case with a damp cloth or tissue and dry after use. IMPORTANT: Never let water come inside the main housing case. TIP: For more details visit www.maxtasy.com/cleaning Wash the inner sleeve in soapy water before and after every use, including the first. CLEANING twist the sleeve to release itremove the sleeve with handle wash the inner sleeve in soapy water dry the sleeve with a towel insert the sleeve back, follow the position mark put back the cap and inner support magnets on the sleeve bottom connect to the inner housing twist the sleeve to fix it 1 567 8 23 4 STROKING SPEEDS 1 2 3 4 5 6 7 8 9 10 1 9 5 1 8 0 2 1 0 2 2 5 2 4 0 M A X 1 5 0 1 6 5 1 4 0 1 3 0 1 2 0 Strokes per minute 10 speeds TROUBLESHOOTING Product does not turn on Product is not charging/light is not flashing Stroking is noisy LED is flashing but product works Remote does not work Charge the product fully Disconnect the charging cable Turn on the product with On/Off Button Plug the DC cable in the DC port on your toy Plug the USB cable in the USB adaptor Ensure the sleeve is inserted correctly Low battery indicator, charge the product fully Make sure the main unit as well as the remote are in stand-by mode, both On/Off buttons are light up Read BUTTON’S CONTROL WITH THE REMOTE Material: Dimensions: Weight: Battery: Noise Level: Charging Time Stroke Master+: Running Time Stroke Master+: Charging Time Remote: Running Time Remote: Remote Range: Remote Frequency: Housing and buttons ABS, inner sleeve TPE Height 10” (255mm) Outer Diameter 3” (85mm) Max insertable depth 5“ (128mm standard version) Max insertable depth 4¾“ (124mm realistic version) 600 g (Standard version) 600 g (Realistic version) Li-Ion 1800 mAh 3.7V < 45dB 120min 120min 60min 12hr 5meters 433MHz SPECIFICATIONWARRANTY Your product is covered by one year warranty valid from the date of purchase. Please note the warranty is rendered void if: 1) Quality Checked Seal was removed 2) There is no valid proof of purchase 3) The damage was caused by dropping, stepping on or any other accidental damage after purchase 4) The product was modified or dismantled 5) The outer housing case was submerged in liquid For detailed warranty policy and/or to make a claim visit www.maxtasy.com/warranty SAFETY & WARNINGS Keep away from direct sunlight and humidity. Those who use a pacemaker and/or have diabetes, phlebitis, thrombosis or any other health conditions, should consult with a medical professional regarding the risk of blood clots before using the product. If you notice any visible damage, turn the product off and stop using it immediately. Do not share the product with others. This is an adult novelty product and children should not play with it. This product is for novelty use only. The manufacturer holds no liability. Do not use alcohol-, acid- or alkali-based cleaners. Always clean the inner sleeve with warm soapy water and the outer housing case with a damp cloth or tissue. Ensure that the …

Text truncated - open the document above for the full version.

Atta�tatlon St�t(gm@nts 27 th Feb. 2023 TO: Federal Communications Cemmisslon Authorlzatlen and Evaluation Division 74S5 OG!kland Mills Road Colljmbla, MD 21046, USA RE: A ttestation Statements Part 2J)11(d)(i) request for 2A84D I nnovation Street PTE. LTD, the undersigned, hereby authorl%e Michelle Liss LLC to act as oyr designated LJ .S, agent for service of process, Innovation Street PTE. LTD accepts to maintain an agen-t for no less than one year after the grantee has terminated all marketing and Importation or the conclusion of any Commls:ilon-related proceeding Involving the equipment. Michelle Liss LLC accepts the responsibility t o act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and Importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information: Company name: Innovation Street PTE. LTD Contact Name: Mark T. Address: 141 Cecil Street #08-07, Singapore 069541 Tel ephone No: Email: [email protected] u.s, Agent Information: Company Name: Michelle Liss LLC Address: 850 Bluebell Ct Carlsbad, CA 92011 FRN: 0033507237 Contact Name: Marty Gozdzik Telephone No: Email: ma [email protected] Applicant Signature: Applicant printed na Agent Signature: {if the agent Is different from the applicant) A gent printed name: Marty Gozdzik

Page 1 of 4 Report No.: LGT22J052 Appendix - External Photographs of EUT Constructional Details FCC ID: 2A84DMAXSTRPLUS Model Name: MAXSTRPLUS Photo 1 Photo 2 Receiver Transmitter Page 2 of 4 Report No.: LGT22J052 Photo 3 Photo 4 Page 3 of 4 Report No.: LGT22J052 Photo 5 Photo 6 Page 4 of 4 Report No.: LGT22J052 Photo 7 Photo 8

Label MAXSTRPLUS Model name:Maxtasy Stroke FCC ID: 2A84DMAXSTRPLUS INNOVATION STREET PTE.LTD. 141 CECIL STREET #08-07 TUNG ANN ASSOCIATION BUILDING SINGAPORE 069541 Importer:XXXXXXXXX Address:XXXXXXXXXX

Page 1 of 2 Report No.: LGT22J052 Appendix - Internal Photographs of EUT Constructional Details FCC ID: 2A84DMAXSTRPLUS Model Name: MAXSTRPLUS Photo 1 Photo 2 ANT Page 2 of 2 Report No.: LGT22J052 Photo 3 Photo 4

FCC ID:2A84DMAXSTRPLUS RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID:2A84DMAXSTRPLUS The Worst Case Mode 433.925MHz Detector PEAK field strength 61.66dBuV/m(-33.54dBm) Remark: The worst case gain of the antenna is -20dBi. -20dBi logarithmic terms convert to numeric result is nearly 0.01 0.4339 -33.54 -33 0.000501187 0.0001 3 Limit Maximum Peak Conducted Output Power (dBm) frequency (GHz) Tune up Power (dBm) Tune up Power (mW) Result Threshold at which no SAR required is 0.0001≤ 3.0 for 1-g SAR, Separation distance is 5mm.

Antenna Type: PCB Antenna Antenna Gain: -20dBi All measurements were performed radiated and therefore additional antenna gain documentation is not required 1mm 8.2mm 27mm 17mm

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: STROKE MASTER PLUS Model Name: MAXSTRPLUS FCC ID: 2A84DMAXSTRPLUS Issued For : INNOVATION STREET PTE.LTD. 141 CECIL STREET #08-07 TUNG ANN ASSOCIATION BUILDING SINGAPORE 069541 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT22J052RF03 Sample Received Date: Nov. 23, 2022 Date of Tested: Nov. 23, 2022 – Dec. 26, 2022 Date of Issue: Dec. 26, 2022 Report No.: LGT22J052RF03 Page 2 of 33 TEST REPORT CERTIFICATION Applicant INNOVATION STREET PTE.LTD. Address 141 CECIL STREET #08-07 TUNG ANN ASSOCIATION BUILDING SINGAPORE 069541 Manufacturer INNOVATION STREET PTE.LTD. Address 141 CECIL STREET #08-07 TUNG ANN ASSOCIATION BUILDING SINGAPORE 069541 Product Name STROKE MASTER PLUS Trademark N/A Model Name MAXSTRPLUS Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.231, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT22J052RF03 Page 3 of 33 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.4 EQUIPMENTS LIST 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 15 4.1 RADIATED EMISSION LIMITS 15 4.2 TEST PROCEDURE 17 4.3 DEVIATION FROM TEST STANDARD 17 4.4 TEST SETUP 18 4.5 EUT OPERATING CONDITIONS 19 4.6 TEST RESULTS 19 4.7 FIELD STRENGTH CALCULATION 20 5. BANDWIDTH TEST 25 5.1 LIMIT 25 5.2 TEST REQUIREMENTS 25 5.3 TEST PROCEDURE 25 5.4 TEST SETUP 25 5.5 EUT OPERATION CONDITIONS 25 5.6 TEST RESULTS 25 6. DUTY CYCLE 27 6.1 TEST PROCEDURE 27 6.2 TEST SETUP 27 6.3 EUT OPERATION CONDITIONS 27 6.4 TEST RESULTS 28 Report No.: LGT22J052RF03 Page 4 of 33 TABLE OF CONTENTS Page 7. AUTOMATICALLY DEACTIVATE 30 7.1 STANDARD REQUIREMENT 30 7.2 TEST PROCEDURE 30 8. ANTENNA REQUIREMENT 32 8.1 STANDARD REQUIREMENT 32 8.2 EUT ANTENNA 32 APPENDIX I - PHOTOS OF TEST SETUP 33 Report No.: LGT22J052RF03 Page 5 of 33 Revision History Rev. Issue Date Contents 00 Dec. 26, 2022 Initial Issue Report No.: LGT22J052RF03 Page 6 of 33 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.205(a)/15.209/ 15.231.(b) Radiated Spurious Emission PASS -- 15.231(a)(1)/ 15.231(b)(2) Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT22J052RF03 Page 7 of 33 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. Parameter Uncertainty RF Output Power, Conducted ±0.71dB Unwanted Emission, Conducted ±0.63dB Conducted emission ±2.80dB All Emissions, Radiated (0.009-30MHz) ±2.16dB All Emissions, Radiated (30MHz-1GHz) ±4.40dB All Emissions, Radiated (1GHz-18GHz) ±5.49dB Report No.: LGT22J052RF03 Page 8 of 33 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name STROKE MASTER PLUS Trademark N/A Model Name MAXSTRPLUS Series Model N/A Model Difference N/A Frequency band 433.925MHz Power Rating N/A Modulation Type ASK Hardware version number V1.0 Software version number V1.1 Connecting I/O Port(s) N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. Table for filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna N/A -20 Antenna Note: The antenna information refer the manufacturer provide report, applicable only to the tested sample identified in the report. Report No.: LGT22J052RF03 Page 9 of 33 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mode Mode 1 Charging + TX Mode For Conducted Emission Final Test Mode Description Mode 2 Charging + TX Mode For Radiated Emission Final Test Mode Description Mode 1 TX Mode 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Accessories Equipment Description Manufacturer Model S/N …
