2A8DL-KEILERThermal Imaging camera

BEDIENUNGSANLEITUNG • OPERATING MANUAL • MANUAL DE INSTRUCCIONES • MODE D‘EMPLOI • ISTRUZIONE PER L‘USO • INSTRUKCJA OBSŁUGI KEILER-1 / KEILER-2 2 FASZINATION WÄRMEBILDTECHNIK Liebe Kunden, aus unserem Anspruch heraus, Ihnen stets technisch und qualitativ führende optische Wärmebildgeräte anzubieten, finden Sie in unserem neuen Programm Produkte mit modernster Technologie und herausragenden Leistungsparametern. Mit unserem Leistungsversprechen, Ihnen Ihre optischen Geräte im Falle einer Einsen- dung innerhalb von zehn Werktagen zurückzusenden, sowie einer Garantie auf unsere Produkte von bis zu drei Jahren bedanken wir uns für Ihr Vertrauen und grüßen Sie mit einem kräftigen Waidmannsheil! Ihr LIEMKE-Team KEILER−1 / KEILER−2 · Bedienungsanleitung 01 / 2023 – 3 D E INHALT 2 2 01. KOMPONENTEN UND BEDIENELEMENTE 4 02. LIEFERUMFANG 6 03. TECHNISCHE DATEN 6 04. SICHERHEITSHINWEISE 8 05. AUFBAU UND VERWENDUNG 11 06. STROMVERSORGUNG 17 0 7. AKKU LADEN 18 08. EINGABEMODI 20 0 9. ZOOMFUNKTION 21 10. MENÜFUNKTIONEN 22 11. FOTO- UND VIDEOAUFNAHME 29 12. INTERNER SPEICHER 30 13. WIFI-VERBINDUNG 30 14. REINIGUNG UND PFLEGE 31 15. STÖRUNGSBESEITIGUNG 32 16. ENTSORGUNG 34 17. KONFORMITÄTSERKLÄRUNG 35 4 01. KOMPONENTEN UND BEDIENELEMENTE 01 02 03 04 05 06 17 18 09 10 14 15 KEILER−1 / KEILER−2 · Bedienungsanleitung 01 / 2023 – 5 D E 4 01. Objektiv mit Fokusring 02. Status-LED 03. Bedienfeld 04. Drei-Positionen-Schalter (ON/ Standby/OFF) 05. Dioptrienausgleich 06. Augenmuschel, drehbar 07. Aufnahme für Stativadapter 08. USB-C-Anschluss mit Gummi- abdeckung 09. LIEMKE BP-K Li-Ion-Akku mit Bajonettverschluss 10. Ösen (vier) zur Befestigung der Handschlaufe 11. Stativ-Adapterplatte 12. Befestigungsschrauben (zwei) für Adapterplatte 13. Winkelschlüssel 14. Handschlaufe 15. Leiterschnalle 16. Adapter für LIEMKE Tragerie- men 17. Neopren-Cover 18. Befestigungsschlaufe für Trage- riemen 19. Trageriemen 20. Karabiner 21. Fixierschnalle 22. Oberer und unterer Anschlag 13 12 11 21 22 08 07 20 18 09 19 22 16 6 02. LIEFERUMFANG • LIEMKE KEILER-1 / KEILER-2 Wärmebild- kamera, mit: • Handschlaufe • 1 LIEMKE BP-K Li-Ion-Akku • Trageriemen Slim • Neopren-Cover • Stativ-Adapterplatte mit Schrauben und Winkelschlüssel • Netzteil mit USB-C-Anschluss und 4 Ste- ckeradaptern • Kabel USB-C auf USB-A • Optik-Reinigungstuch • Bedienungsanleitung • Adapter für LIEMKE Trageriemen (Art. Nr. 80409753; nicht im Lieferumfang enthalten) 03. TECHNISCHE DATEN Modell KEILER -1KEILER -2 Artikelnummer 8 01115 5 680113545 Detektor und Optik Auflösung und Typ 640×512 VOx Mikrobolometer, ungekühlt Pitch-Detektor 12 μm Pixel-Sichtfeld 0.34 mrad0.19 mrad Detektions- reichweite 1750 m2500 m Spektralbereich 8–14 μm Bildwieder- holrate 50 Hz NETD 50 mK Objektivlinse 35 mm f/1.050 mm f/1.1 Sehfeld 22.0×17.6 m / 100 m – 12.5°×10.0° 15.4×12.3 m / 100 m – 8.8×7.0° Vergrößerung 1.9× bi s 10×2.7× bis 14.0× Display 1024x768 OLED Nahbereich <1 m Dioptrien- verstellung ±5 dpt Funktionen und Medien Entfernungs- bewertung stadiametrisch, zoombar Farbmodi White Hot, Black Hot, Extra Dunkel, Red Hot, Rainbow WiFi-Frequenz- bereich 2400 bis 2483.5 MHz KEILER−1 / KEILER−2 · Bedienungsanleitung 01 / 2023 – 7 D E 6 Modell KEILER -1KEILER -2 WiFi-Übertra- gungs leistung ≤20 dBm WiFi-Signal- reichweite 5 m Interner Speicher 32 GB Medienformat JPG/MP4 Physische Merkmale und Umweltmerkmale Gewicht inkl. Akku 465 g510 g Größe 158×72×47 mm163×75×47 mm Wasserdich- tigkeit IP67 Betriebs-/Aufbe- wah rungs tem- pe ratur −20 °C bis +50 °C/ −40 °C bis +70 °C Stromversorgung Externe Strom- versorgung USB-C, 5 V / max. 4 A Akkulaufzeit bis 9 h* * in Abhängigkeit von den Umweltbedin- gungen, Einstellungen und Medienfunk- tionen. Das Design, die Software und die tech- nischen Parameter des Produkts können Änderungen unterliegen, ohne dass im Vorfeld eine entsprechende Benachrichti- gung erfolgt. Akku BP-K ModellBP-K Artikel-Nr.80412223 TypWechselbarer geschützter Lithium- Ionen-Akku Leistung3,7 V; 4800 mAh Lebensdauer ca. 800 Ladezyklen* Gewicht 90 g Größe 30x95 mm Betriebsbedingun- gen −5 °C bis +50 °C, Feuchte nicht-kon- densierend Ladebedingungenoptimal: 15 °C bis 25 °C; zulässig: 0 °C bis 37 °C MaterialienElektronische Bau- teile, Kunststoff, Gummi, Lithium-Ionen-Akku * Richtwert. Die tatsächliche Zyklenlebens- dauer ist maßgeblich von den Verwen- dungsbedingungen abhängig. Die verfügbare Leistung hängt von der Umgebungstemperatur ab. 8 04. SICHERHEITSHINWEISE > Lesen und beachten Sie diese Bedienungsanleitung und insbesondere die Sicherheitshinweise, bevor Sie das Gerät verwenden. Die empfohlene Betriebstemperatur liegt bei −10 °C bis +50 °C. Wenn die Temperatur zu hoch ist, geht die Wärmebildkamera KEILER-1 / KEILER-2 in den Hochtemperatur-Schutz- status über und schaltet sich automatisch ab. > Verwenden Sie das Gerät nicht für längere Zeit in einer Umgebung mit hohen Tempe- raturen. Schäden am Gerät durch eindringende Feuchtigkeit! Das Gerät ist nur bei korrekt eingesetztem Akku und fest verschlossener USB-C-Gummi- abdeckung gegen äußere Feuchtigkeit geschützt. > Stellen Sie sicher, dass die Gummiabdeckung des USB-C-Anschlusses am Gerät bei der Verwendung in feuchten Umgebungen, z. B. an Regentagen, fest verschlossen ist. > Stellen Sie sicher, dass der Akku korrekt eingesetzt und der Bajonettverschluss ver- riegelt ist. Beschädigung der elektronischen Komponenten des Geräts bei Ausrichtung auf inten- sive Energiequellen! Ein Schaden, der infolge einer Nichtbeachtung der Bedienungsanweisungen entsteht, fällt nicht unter die Gewährleistungsansprüche. > Richten Sie das Objektiv des Geräts nicht auf intensive Energiequellen aus (z.B. Laser- geräte, Sonne). Sichere Handhabung des Akkus Der Akku ist kein Spielzeug. > Halten Sie den Akku von Kindern fern. Die nicht sachgemäße Verwendung des Akkus kann zu erheblichen Schäden bis hin zu Explosionen führen. > Prüfen Sie den Akku vor jedem Verwenden und jedem Ladevorgang auf Schäden. KEILER−1 / KEILER−2 · Bedienungsanleitung 01 / 2023…

Text truncated - open the document above for the full version.

Blaser Group GmbH Ziegelstadel 1, 88316 Isny Germany The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-3-7 To whom it may concern: We, Blaser Group GmbH , hereby certify that the equipment for which authorization is sought (FCC ID: 2A8DL-KEILER) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). Sincerely, Signature Daniela koemm Purchaser Blaser Group GmbH 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V02

Blaser Group GmbH Add: Ziegelstadel 1, 88316 Isny Germany Date: 2023-3-7 FCC ID: 2A8DL-KEILER Dear Sir/Madam, We, Blaser Group GmbH Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Thermal Imaging camera Model no.: Keiler, Keiler-1, Keiler-2, Keiler-25.1 Sincerely, Name/Title： Daniela koemm /Purchaser Company: Blaser Group GmbH Address: Ziegelstadel 1, 88316 Isny Germany Phone: +49 6441 566 91 644 Fax: +49 6441 566 91 644 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2023-3-7> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2A8DL-KEILER Keiler For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Daniela koemm /Purchaser Company: Blaser Group GmbH Address: Ziegelstadel 1, 88316 Isny Germany Phone: +49 6441 566 91 644 Fax: +49 6441 566 91 644 E-Mail: [email protected]

Blaser Group GmbH Ziegelstadel 1, 88316 Isny Germany Date: 2023-3-7 FCC ID: 2A8DL -KEILER Model Number: Keiler To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Blaser Group GmbH , declare that this EUT (FCC ID: 2A8DL-KEILER) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Daniela koemm /Purchaser Company: Blaser Group GmbH Address: Ziegelstadel 1, 88316 Isny Germany Phone: +49 6441 566 91 644 Fax: +49 6441 566 91 644 E-Mail: [email protected]

Blaser Group GmbH Ziegelstadel 1, 88316 Isny Germany Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-3-7 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2A8DL-KEILER including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Daniela koemm /Purchaser Company: Blaser Group GmbH Address: Ziegelstadel 1, 88316 Isny Germany Phone: +49 6441 566 91 644 Fax: +49 6441 566 91 644 E-Mail: [email protected]

FCC ID: 2A8DL-KEILER External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A8DL-KEILER Photo 4 Photo 5 Photo 6

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2A8DL-KEILER

FCC ID: 2A8DL-KEILER Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A8DL-KEILER Photo 4 Photo 5 Photo 6 FCC ID: 2A8DL-KEILER Photo7 Photo 8 Photo 9 FCC ID: 2A8DL-KEILER Photo 10 Photo 11 Photo 12 FCC ID: 2A8DL-KEILER Photo 13 Photo 14 Photo 15 2.4G WiFi PIFA antenna FCC ID: 2A8DL-KEILER Photo 16 Photo 17 Photo 18 FCC ID: 2A8DL-KEILER Photo 19 Photo 20 Photo 21 FCC ID: 2A8DL-KEILER Photo 22 Photo 23 Photo 24

RF Exposure evaluation FCC ID: 2A8DL-KEILER 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance 802.11b (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 8.0 8.0 8.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11g (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 7.0 7.0 7.0 Tolerance ±(dB) 1.0 1.0 1.0 802.11n(HT20) (Peak) Channel Channel 01 Channel 06 Channel 11 Target (dBm) 7.0 7.0 7.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.450 5 9.0 7.9433 2.4866<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type Internal antenna Model Keiler Frequency range 2400-2500MHz Manufacturer Wuhan Cono Technology Co.,Ltd. ANT Peak Gain 1.48 dBi 2. Antenna Photo: Length :24.67mm Width:8.59mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Report No.: CTA23021300301 Page 31 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 802.11n20 Reference Reference CH01 CH06 30MHz-3GHz 30MHz-3GHz 3GHz -25GHz 3GHz -25GHz Report No.: CTA23021300301 Page 32 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 802.11n20 Reference CH11 30MHz-3GHz 3GHz -25GHz Report No.: CTA23021300301 Page 33 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Band-edge Measurements for RF Conducted Emissions: 802.11b Left bandedge Right bandedge 802.11g Left bandedge Right bandedge 802.11n(HT20) Left bandedge Right bandedge Report No.: CTA23021300301 Page 34 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 4.7 Antenna Requirement Standard Applicable For intentional device, according to FCC 47 CFR Section 15.203: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited FCC CFR Title 47 Part 15 Subpart C Section 15.247(c) (1) (I): (i) Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point operations may employ transmitting antennas with directional gain greater than 6dBi provided the maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the directional gain of the antenna exceeds 6dBi. Test Result: The maximum gain of antenna was 1.48 dBi. Remark:The antenna gain is provided by the customer , if the data provided by the customer is not accurate, Shenzhen CTA Testing Technology Co., Ltd. does not assume any responsibility. Report No.: CTA23021300301 Page 35 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 5 T e s t S e t u p P h o t o s o f t h e E U T Report No.: CTA23021300301 Page 36 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 6 P h o t o s o f t h e E U T Report No.: CTA23021300301 Page 37 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 38 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 39 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 40 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 41 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 42 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Antenna Report No.: CTA23021300301 Page 43 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 44 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA23021300301 Page 45 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn ********************** End of Report **********************

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA23021300301 2A8DL-KEILER Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Amy Wen Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Feb. 17, 2023 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Blaser Group GmbH Address ............................................ : Ziegelstadel 1, 88316 Isny Germany Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Thermal Imaging camera Trade Mark ....................................... : LIEMKE Manufacturer .................................... : Wuhan Cono Technology Co.,Ltd. Model/Type reference ...................... : Keiler Listed Models .................................. : Keiler-1, Keiler-2, Keiler-25.1 Modulation Type ............................... : CCK/DSSS/OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 3.7V From Battery and DC 5.0V From external circuit Result ............................................... : PASS Report No.: CTA23021300301 Page 2 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Thermal Imaging camera Model /Type : Keiler Series Model No. Keiler-1, Keiler-2, Keiler-25.1 Applicant : Blaser Group GmbH Address : Ziegelstadel 1, 88316 Isny Germany Manufacturer : Wuhan Cono Technology Co.,Ltd. Address : Room 210-218, Building 7 WISCO High-tech Industrial No.5 Maodianshan Middle Road, Wuhan City (Free Trade Zone, Wuhan Area) Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA23021300301 Page 3 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T CO N D ITI O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Maximum Peak Conducted Output Power 20 4.4 Power Spectral Density 21 4.5 6dB Bandwidth 24 4.6 Out-of-band Emissions 27 4.7 Antenna Requirement 34 5 T E S T S E T UP P H O T O S O F T H E E U T ......................................... 35 6 P H O T O S O F T H E E U T ........................................................... 36 Report No.: CTA23021300301 Page 4 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: CTA23021300301 Page 5 of 45 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322…

Text truncated - open the document above for the full version.

FCC ID: 2A8DL-KEILER Test Setup Photos of the EUT
