2A8NV-ES29TWS Earbuds

Incoming call Charging a. Incoming call when there is an incoming call, the earbuds will prompt the user to call. b. Answering / hang up the phone When incoming call, long press the left or right MF button for 2 seconds to reject the phone call. short press the L or R MF button to answer the call. Use the type-c cable in the package to connect the adaptor and the tws charging case,the tws case will indicate the current power; after the case is fully charged , all 4 indicators will be blue. Single earbud mode: a Take out any earphone of the left or right from the charging case,the LED indicator will blinking alternately R LED indicator L LED indicator or The user can search for “Wave Buy” with a smart phone for pairing.The device will prompt "Connected",The pairing is successful, and the light will be turned off. Wave BuyConnect Bluetooth b smart phone for pairing After the earbuds is successfully connected to the terminal device, the next time the earbuds is turned on, it can automatically connect back to the terminal device that was connected last time. Automatic reconnection: Reset to factory default Earbuds will prompt out low battery voice alert once the battery level is too low. Put the L/R earbuds in the charging case and close the charging case cover, the earbuds will automatically enter the charging mode and the white light display. Earbuds full charge time: 1.5 hours, the white charging indicator light turns off after the earphone is fully charged. Charge the earbuds 1. 2. 3. You can reset earbuds to factory default if you encounter pairing problems.When the earbuds off , tap and hold for 10 seconds to reset them to factory default. Put them back to the charging case and take out again for pairing. 1. 1. Chipset: Actions 2. Input charging voltage and current: 5V/1A 3. Battery type: built-in rechargeable lithium battery 4. Battery capacity: earbuds 40mAh*2, charging case 300mAh 5. Frequency response range: 20HZ-20KHZ 6. Sensitivity: 99+- 3dB 7. Bluetooth version: V5.0 8. Working range: 10M 9. Working hours: Earbuds: 4H 1. Please store and use the product under normal temperature, do not expose this apparatus to the rain or moisture . 2. Do not throw away or disassemble for repair as it may cause safety problem 3. Built-in lithium battery, do not discard or put it into a fire 4. For your health and to extend the life of the product, better not to keep maximum volume on, to avoid injury of your hearing. 5. In any emergency, Cut off the power immediately 6. To always have a better performance, please charge in time once the battery is low. ATTENTION With the software and hardware updated, all the technical data and the mode of operation showed on the manual could be changed without prior notice. Technical Parameters Security warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction FCC Compliance Statement Note: The left and right earbuds will be turned on at the same time when the charging case is opened. When using the single earbud mode, the other earbud needs to be turned off (manually power off or put it in the charging case and close the top cover of the charging case). 10”10” next song This product supports automatic master-slave switching, the headset uses a touch structure design, and the key operation instructions are as following Button definition Short press on L earphone or R earphone: Short press three times on the left side earbud : Short press three times on the right side earbud : in the state of playing music, play/pause; Playcall Game mode on/ Game mode off Short press twice on the right side earbud: When incoming call, long press left /right side earbud for 2 seconds to reject the phone call Short press twice on the left side earbuds: long press left or right earbuds for 5 seconds activate voice assistant Previous song 2” Power on/offReject call 5” Operations Bluetooth connection TWS Mode: a Automatic boot, automatic pairing L R indicators b When the pairing is successful c Connect mobile phone Thank you very much for choosing the ES29 Bluetooth earphones. To have a great experience, please read this manual carefully before use. in the state of incoming call, answer/hang up Game mode Earbuds will automatically turn on and prompt out “power on” and try to connect each other, once they have been taken out from the charging case. LED indicators on the L earbuds will blinking alternately ,and LED indicators turned off on the R earbuds. User can turn on Blue…

Text truncated - open the document above for the full version.

Shenzhen E-Ran Technology Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen E-Ran Technology Co., Ltd. Address: Room 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen Product Name: TWS Earbuds FCC ID: 2A8NV-ES29 Model(s): ES29 2.911(d)(5)(i) Equipment Type We, [Shenzhen E-Ran Technology Co., Ltd. ] certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Robert Ruan Date: Feb.08,2023 Title and Company name: Product Manager / Shenzhen E-Ran Technology Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen E-Ran Technology Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen E-Ran Technology Co., Ltd. Address: Room 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen Product Name: TWS Earbuds FCC ID: 2A8NV-ES29 Model(s): ES29 2.911(d)(5)(ii) Applicant filing We, [Shenzhen E-Ran Technology Co., Ltd. ] certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Robert Ruan Date: Feb.08,2023 Title and Company name: Product Manager / Shenzhen E-Ran Technology Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen E-Ran Technology Co., Ltd. 2.911 (d)(7)USA Agent v1.2 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen E-Ran Technology Co., Ltd. Address: Room 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen Product Name: TWS Earbuds FCC ID: 2A8NV-ES29 Model(s): ES29 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen E-Ran Technology Co., Ltd. ] designate [PROMOTERK LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: PROMOTERK LLC Address: 1750 N Florida Mango Rd , Suite408 West Palm Beach, FL33408 FRN:0033505504 Contact Name: Kathy Telephone No: 909 516 3088 Email:[email protected] Applicant Company name: Shenzhen E-Ran Technology Co., Ltd. Address: oom 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen FCC Grantee Code: 2A8NV Contact Name: Robert Ruan Telephone No: 17302623056 Email: [email protected] Shenzhen E-Ran Technology Co., Ltd. 2.911 (d)(7)USA Agent v1.2 Signature: Title:General Manager Signature: Title: Product Manager Date:Feb.08,2023 Date: Feb.08,2023 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Shenzhen E-Ran Technology Co., Ltd. Agent Authorization Company: Shenzhen E-Ran Technology Co., Ltd. Address: Room 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen Product Name: TWS Earbuds Model Number(s): ES29 Product Description: TWS Earbuds We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.2.08 Name: Robert Ruan Title: Product Manager Company: Shenzhen E-Ran Technology Co., Ltd.

Shenzhen E-Ran Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 8, 2023 Subject; Request for Confidentiality FCC ID: 2A8NV-ES29 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Robert Ruan Title: Product Manager

- Page 1 of 4 - ET-23010033 Product Name: TWS Earbuds Model No.: ES29 Ext Photos - Page 2 of 4 - ET-23010033 - Page 3 of 4 - ET-23010033 - Page 4 of 4 - ET-23010033 -----END-----

Label location Label (Size:5*10mm) Label location FCC ID: 2A8NV-ES29

- Page 1 of 3 - ET-23010033 Product Name: TWS Earbuds Model No.: ES29 Internal photos - Page 2 of 3 - ET-23010033 RF ANT - Page 3 of 3 - ET-23010033 ------END-----

FCC ID: 2A8NV-ES29 RF Exposure Evaluation TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). FCC ID: 2A8NV-ES29 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(i)(A). (B) in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. Where: a = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(B) of Part 1.1307 for Pth, including existing exempt transmitters and those being added. b = number of fixed, mobile, or portable RF sources claiming exemption using paragraph (b)(3)(i)(C) of Part 1.1307 for Threshold ERP, including existing exempt transmitters and those being added. c = number of existing fixed, mobile, or portable RF sources with known evaluation for the specified minimum distance including existing evaluated transmitters. Pi = the available maximum time-averaged power or the ERP, whichever is greater, for fixed, mobile, or portable RF source i at a distance between 0.5 cm and 40 cm (inclusive). Pth,i = the exemption threshold power (Pth) according to paragraph (b)(3)(i)(B) of this section for fixed, mobile, or portable RF source i. FCC ID: 2A8NV-ES29 ERPj = the ERP of fixed, mobile, or portable RF source j. ERPth,j = exemption threshold ERP for fixed, mobile, or portable RF source j, at a distance of at least λ/2π according to the applicable formula of paragraph (b)(3)(i)(C) of Part 1.1307. Evaluatedk = the maximum reported SAR or MPE of fixed, mobile, or portable RF source k either in the device or at the transmitter site from an existing evaluation at the location of exposure. Exposure Limitk = either the general population/uncontrolled maximum permissible exposure (MPE) or specific absorption rate (SAR) limit for each fixed, mobile, or portable RF source k, as applicable from § 1.1310. Test Result of RF Exposure Evaluation Protocol Fre. (GHz) Output power (dBm) Tune-up power (dBm) Max tune-up power (dBm) ANT Gain ( dBi) Max EIRP (dBm) Max EIRP (mW) Separation distance (cm) Limit (mW) Result BT 2.402 -0.53 0±1 1 2.0 3.0 2.0 0.5 2.76 PASS Note: 1. This device is portable device. 2. The source of the evaluation data results is based on the test report ET-23010033E 3. The Maxinum power is less than the limit, complies with the exemption requirements.

Antenna specification 1. Project information 1.1 Appearance and Dimensions Symbol Dimension(mm) L 5.2±0.2 W 2.2±0.2 T 1.0±0.2 S 0.5±0.2 1.2 1.2 Matching circuit With the following recommended values of matching and tuning components the center frequencies will be about 2440MHz at our standard 30*40mm evaluation board. However,these are typical refenerce values. Which way need to be changed when circuit boards or part vendors are deffierent. System matching circuit component Location Description Tolerance 1 NC / 2 1.6nH ±0.2nH 3 0.75pF ±0.1 pF 2. Electrical characteristics 2.1 Elecrtical table Characteristics Specifications Unit Outline Dimensions 5.2*2.2*1.0 mm Working frequency 2400-2500 MHz VSWR <2 / Impdeance 50 ohm polarization Line / Gain peak 2 dBi Efficiency 50 % 2.2 VSWR& Return loss VSWR Return loss 2.3 Gain and Efficiency Frequency(MHz) Gain(dBi) Efficiency(%) 2400 1.34 45.88 2410 1.37 46.78 2420 1.09 47.67 2430 1.22 50.38 2440 1.45 50.78 2450 1.67 51.44 2460 1.87 51.34 2470 2.00 51.36 2480 1.75 51.24 2490 1.67 51.36 2500 1.89 51.24 2.4 Antenna radiation pattern 3D Plane @2440MHz 2D Plane XOY @2440MHz 2D Plane XOZ @2440MHz 2D Plane YOZ @2440MHz

Report No.: ET-23010033E This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen ETR Standard Technology Co., Ltd. TEST REPORT Applicant: Shenzhen E-Ran Technology Co., Ltd. Address of Applicant: Room 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen Manufacturer/Factory: Shenzhen Yinuo Digital Technology Co.,Ltd Address of Manufacturer/Factory: Room 201, Plant No.34, Zhangyi Residential Quarter, Junzibu Community, Guanlan Street, Longhua District, Shenzhen Product Name: TWS Earbuds Model No.: ES29 Trade Mark: N/A FCC ID: 2A8NV-ES29 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of Test: Jan.10, 2023- Jan.30, 2023 Date of report issued: Feb.08, 2023 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Remark: The results shown in this test report refer only to the sample(s) tested , this test report cannot be reproduced, except in full without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver Prepared By Shenzhen ETR Standard Technology Co., Ltd. Address: No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Compiled by: Reviewed by: Approved by: Project Engineer Project Manager Authorized Signature - Page 2 of 47 - Report No.: ET-23010033E Report Revision History Report No. Description Issue Date ET-23010033E Original Feb.08, 2023 - Page 3 of 47 - Report No.: ET-23010033E Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Contents Page 1 TEST SUMMARY ......................................................................................................................................4 2 GENERAL INFORMATION .......................................................................................................................5 2.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 2.2 TEST MODE .........................................................................................................................................7 2.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 2.4 DEVIATION FROM STANDARDS ..............................................................................................................7 2.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 2.6 TEST FACILITY.....................................................................................................................................7 2.7 TEST LOCATION...................................................................................................................................7 2.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 3 TEST INSTRUMENTS LIST ......................................................................................................................8 4 TEST RESULTS AND MEASUREMENT DATA .......................................................................................9 4.1 ANTENNA REQUIREMENT ......................................................................................................................9 4.2 CONDUCTED EMISSIONS ....................................................................................................................10 4.3 CONDUCTED PEAK OUTPUT POWER ...................................................................................................13 4.4 20DB EMISSION BANDWIDTH ..............................................................................................................14 4.5 CARRIER FREQUENCIES SEPARATION .................................................................................................18 4.6 HOPPING CHANNEL NUMBER .............................................................................................................22 4.7 DWELL TIME ......................................................................................................................................24 4.8 BAND EDGE.......................................................................................................................................29 4.8.1 Conducted Emission Method ......................................................................................................29 4.8.2 Radiated Emission Method .........................................................................................................33 4.9 SPURIOUS EMISSION .........................................................................................................................35 4.9.1 Conducted Emission Method ......................................................................................................35 4.9.2 Radiated Emission Method .........................................................................................................39 5 TEST SETUP PHOTO .............................................................................................................................47 6 EUT CONSTRUCTIONAL DETAILS .......................................................................................................47 - Page 4 of 47 - Report No.: ET-23010033E Tel:(86-755) 85259392 Email:[email protected] Web: www.etrlab.cn No.103, No.10, Phase I, Zone 3, Xinxing Industrial Park, Xinhe, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China 1 Test Summary Test Item Section in CFR 47 Result Te…

Text truncated - open the document above for the full version.

ET-23010033 Page 1 of 2 Product Name: TWS Earbuds Test Model No.: ES29 Test Setup Photo Radiated emissions 30MHz to1GHz Above 1GHz ET-23010033 Page 2 of 2 Conducted Emission ------End------
