2A8SQ-IST-5Tablet computer

ShenZhen ZhiWei Technology Co., Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 01, 2024
Application Purpose: Original Equipment
Date of Application: Aug 01, 2024
Equipment Note: Tablet computer
Frequency Range: 2412.00000000 - 2462.00000000
Company: ShenZhen ZhiWei Technology Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CONTROL INTERFACES, IST-5 1 www.rticontrol.com IST-5 5.5” Intelligent Surface Touchpanel Reference Guide The IST-5 touchpanel elevates system control in all commercial and residential settings. It starts with a hi-resolution 5” capacitive-touch screen with a 854x480 resolution with true-black display filter for exceptional clarity. With an ultra-thin bezel, near-flush mount (just 0.4”/ 12mm off the wall), and elegantly compact form-factor, the IST-5 makes an elegant statement in landscape or portrait mount. Built-in 10/100 Base-T Ethernet with PoE enables seamless two-way system control, video, and remote programming. Version 1.1 Key Features • Hi-resolution 5” capacitive-touch screen (854x480) with ultra-thin bezel. • Near-flush mount (less than 0.4”/11mm off wall). • Ethernet and Wi-Fi options for control and communication. • PoE or 12V DC power options. • Exceptional video streaming and two-way intercom at H.264 or H.265 format. • Dual speakers and far-field microphone array (with mute button). • Proximity and ambient light sensors. • Portrait or landscape. Product Contents • IST-5 • Metal Wall Mounting Bracket (1) • Mounting Bracket Screws (2) PMN: Tablet computer CONTROL INTERFACES, IST-5 Technical Support: [email protected] - Customer Service: [email protected] Overview Mounting Bracket Installation The IST-5 is designed to be wall mounted in either Portrait or Landscape orientation. Mounting Depth The IST-5 requires a minimum mounting depth of 1.34” (34mm) from the wall surface. Leave space to account for the RJ-45 or 12V barrel connector. Mounting Height The recommended mounting height for the IST-5 is 57”- 65” (145 cm -165 cm) from the finished floor to the center of the unit. Mounting Bracket The IST-5 is designed to be mounted to a US standard single gang wall box or a single gang low voltage bracket. The IST-5 mounting bracket, included in the box, should be attached to the single gang low voltage bracket with the supplied screws, then the IST-5 unit is secured on the metal rear mounting bracket with a captive screw located at the bottom of the IST-5. Light Sensor Proximity Sensor Microphone Ethernet w/ PoE Microphone Mute Butto n Mute Indicator DC In USB-C (not used) Speakers Power Button Captive Screw Tunnel Hook Hole Hook Hole Screw Slot Metal Mounting Bracket CONTROL INTERFACES, IST-5 3 www.rticontrol.com Portrait/ Landscape Mounting • Portrait orientation: Install the single gang low-voltage bracket on a wall in its normal position • Landscape orientation: Install the single gang low-voltage bracket on wall after rotating it 90 degrees in a clockwise direction. Install the IST-5 Mounting Bracket • The IST-5 package includes a mounting bracket that MUST be used for installation. • Use the included screws to mount the bracket onto a single gang low-voltage bracket. • Verify that the bracket is level before tightening the captive screw on the IST-5. Single Gang low voltage bracket IST-5 Mounting Bracket (included) Power the IST-5 The IST-5 is designed to be powered over an Ethernet connection with PoE or by connecting a 12VDC power supply (not included), but not both. PoE Connection • PoE connection requires IEEE 802.3at standard. Utilize a network switch or PoE injector that meets this standard. • Connect the IST-5 using a standard T568A or T568B Ethernet cable from the network switch to the LAN/ PoE jack on the rear enclosure of the IST-5. 12VDC Power Supply • You can provide power to the IST-5 by utilizing a 12VDC/2A power supply (available separately). • Plug the connector into the DC jack on the rear enclosure of the IST-5. CONTROL INTERFACES, IST-5 Technical Support: [email protected] - Customer Service: [email protected] Power Up The IST-5 • The IST-5 will automatically power on when power is applied. PoE Network Switch Cabling12VDC Power Supply CablingPoE Injector Cabling Install the IST-5 • Use a Philips #1 head screw driver to loosen the captive screw of the unit to the level indicated below in the diagram. Screw should not be removed from the unit. • Align the mounting frame hooks with the IST-5 mounting slots and gently pull the IST-5 unit down the mounting bracket. Make sure the mounting hooks are properly engaged. • To complete the installation, tighten the captive screw on the bottom part of unit, to secure the IST-5 on the mounting bracket. • For Landscape orientation, rotate mounting bracket and IST-5 90 degrees in clockwise direction before installation. Tighten the captive screw to secure the IST-5 to the mount- ing bracket. Loosen captive screw Align mounting frame hooks Gently pull IST-5 down Network Switch PoE Injector To IST-5 PoE Network Switch Line in wall 12VDC 2.1mm Coaxial Plu g Loosen Tighten CONTROL INTERFACES, IST-5 5 www.rticontrol.com Remove the IST-5 • Use a Philips #1 head screw driver to loosen the captive screw of the IST-5, then gently pull straight up from the mounting frame to disengage the unit. Loosen captive screw Gently push IST-5 upwards Dimensions Ethernet Communication • When the IST-5 is connected to a network switch by Ethernet cable, the unit will acquire a network address via DHCP and automatically connect to the LAN. Programming Touchscreen Display The IST-5 touchscreen display is programmed using the RTI Integration Designer Programming Software. Normally, it is organized into a series of pages containing objects (buttons, text, graphics, etc.) that are related to each other. Updating the Software RTI’s Integration Designer data files can be downloaded to the IST-5 via Ethernet network. Loosen 84.5mm 3.33” 44.9mm 1.77” 133.0mm 5.24” 51.0mm 2.01” 61.0mm 2.40” 35.7mm 1.41” 16.5mm 0.65” 10.9mm 0.43” CONTROL INTERFACES, IST-5 Technical Support: [email protected] - Customer Service: [email protected] Safety Suggestions Read and Follow Instructions Read all safety and operating instructions before operating the unit. Retain Instructions Keep the safety and operating instructions for future re…

Text truncated - open the document above for the full version.

External Photos

Page 1 of 5 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 5 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 5 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 5 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 5 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10

ID Label/Location Info

FCCID:2A8SQ-IST-5IC:32614-IST5 ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BuildingAand301BuildingC,JujiIndustrialPark,YabianxueziweiShajingStreet,Baoan District,Shenzhen,518000,P.R.C. Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity LABELANDLOCATION Material:tagboard Gule:adhesivesticker Fontcolor:white Labelcolor:black&silverpolyester (Size:L4.0cmxW2.0cm) LabelLocation Tabletcomputer Model:IST-5 HVIN:IST-5 IC:32614-IST5 FCCID:2A8SQ-IST-5 L W

Internal Photos

RF Exposure Info

Page 1 of 12 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information EUT : Tablet computer Test Model : IST-5 Additional Model No. : IST-5-W, IST-5-B Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: 12.0V2.0A For AC Adapter Input: 100-240V~, 50/60Hz, 1.0A Adapter Output: 12.0V2.0A, 24.0W Hardware Version : ZW-A5R/A10R-V200 Software Version : update_rk3566-r165-p5-v2-lp4x-v10-12.0 Bluetooth: Frequency Range : 2402MHz~2480MHz Channel Number : 79 channels for Bluetooth V4.2(DSS) Channel Spacing : 1MHz for Bluetooth V4.2 (DSS) Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V4.2(DSS) Bluetooth Version : V4.2 Antenna Description : FPC Antenna, 2.74dBi(Max.) WIFI(2.4G Band): Frequency Range : 2412MHz~2462MHz Channel Spacing : 5MHz Channel Number : 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) Modulation Type : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Description : FPC Antenna, 2.74dBi(Max.) WIFI(5.2G Band): Frequency Range : 5180MHz~5240MHz Channel Number : 4 Channels for 20MHz bandwidth(5180MHz~5240MHz) 2 channels for 40MHz bandwidth(5190MHz~5230MHz) 1 channels for 80MHz bandwidth(5210MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : FPC Antenna, 3.45dBi(Max.) WIFI(5.3G Band): Frequency Range : 5260MHz~5320MHz Page 2 of 12 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Channel Number : 4 Channels for 20MHz bandwidth(5260MHz~5320MHz) 2 channels for 40MHz bandwidth(5270MHz~5310MHz) 1 channels for 80MHz bandwidth(5290MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : FPC Antenna, 3.45dBi(Max.) WIFI(5.5G Band): Frequency Range : 5500MHz~5700MHz Channel Number : 11 Channels for 20MHz bandwidth(5500MHz~5700MHz) 5 Channels for 40MHz bandwidth(5510MHz~5670MHz) 2 Channels for 80MHz bandwidth(5530MHz, 5610MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : FPC Antenna, 3.78dBi(Max.) WIFI(5.8G Band) Frequency Range : 5745MHz~5825MHz Channel Number : 5 channels for 20MHz bandwidth(5745MHz~5825MHz) 2 channels for 40MHz bandwidth(5755MHz~5795MHz) 1 channels for 80MHz bandwidth(5775MHz) Modulation Type : IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Antenna Description : FPC Antenna, 3.83dBi(Max.) GPS function : Support and only RX Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Device 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum Page 3 of 12 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Li…

Text truncated - open the document above for the full version.

Test Report

DATE DATE APPROVED BY Edition/Part number ENGINEER R&D DEPT BUSSINESS DEPT R&D DEPT ENGINEER R&D DEPT APPROVAL LEJIN Shenzhen Lejin radio frequency technology Co., LTD SPECIFICATIONS FOR APPROVAL ZW A5R WIFI/BT ANT LJF02-240510003-R0A 李明进 2024/5/10 CUSTOMER Customer Name: Product Name: Product Model: Part Number: Write By : Issued Date: All data in this report only represent the data when the sample antenna is correctly installed in the designated test object. Replacing the test object or changing the installation method and position of the antenna will render the data in the report invalid. Antenna manufacturer：Shenzhen Lejin radio frequency technology Co., LTD Company Address: 3rd Floor, Building A4, No. 176 Chongqing Road, Fuhai Street, Bao'an District, Shenzhen, Guangdong Province.（Phone number: 13603098741） Edition/Part number ECN/ECR Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. Shenzhen Lejin radio frequency technology Co., LTD 目录 Index 1、封面（Cover） 2、目录（Index） 3、规格（Product Specification） 4、测试设备（Test Equipment & Conditions） 5、性能测试报告（Test Report） 6、天线图片（Antenna Picture ） Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. 0.81 L:50 Black Linear Linear ≥0,<2.0 Shenzhen Lejin radio frequency technology Co., LTD Polarization 5.15GHZ-5.85GHZ <2.5>50%50 Ohm Electrical Characteristics FrequencyVSWRGain（dB) ≥0,<2.0 Material & Mechanical CharacteristicsEnvironmental Storage Temperature - 30 ̊C ~ + 80 ̊C Material of Radiator Connector Type KCC232 Operation Temperature BL- 20 ̊C ~ + 50 ̊C Cable Type Dimension Test Equipment & Conditions 1． Network Analyzers :Agilent 5071C 2． Communications Test Set:Agilent E5515C/CMW500/AT8826 3. 3D Chamber Test System(ETS743)/STM23+1 EfficiencyImpedance 2.4GHZ-2.5GHZ>35%<1.850 Ohm Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. Frequency (MHz) 2400241024202430244024502460247024802490 2500 2.15 2.36 2.27 2.45 1.98 2.47 2.52 2.12 2.74 1.93 2.23 39.84 40.25 43.36 41.25 42.78 45.5947.22 45.53 43.89 44.71 44.22 5150520052505300535054005450550055505600 5750 5800 3.33 3.32 3.45 3.15 3.35 3.11 3.59 3.64 3.78 3.45 3.11 3.83 48.84 50.59 50.11 52.12 55.65 57.1251.21 49.12 52.17 48.84 44.33 49.78 13.55 -77.66 11.69 -67.63 14.37 -70.18 802.1 1B Channe l No. Freq. (MHz) TRP (dBm) TIS (dBm) 802.11 G Channel No. Freq. (MHz) TRP (dBm) TIS (dBm) 802.11 A Channel No. Freq. (MHz) TRP (dBm) TIS (dBm) 1 2412 13.77 -77.961 2412 11.78 -67.5436 5180 14.11 -70.78 6 2437 13.25 -78.256 2437 11.36 -67.25149 5745 14.78 -70.23 11 2462 13.64 -76.7811 2462 11.94 -68.11165 5825 14.23 -69.54 5550.0MHz H+V, Eff: 52.17% / Gain：2.155800.0MHz H+V, Eff: 49.78% / Gain：2.15 2400.0MHz H+V, Eff:39.84% / Gain：2.152450.0MHz H+V, Eff: 45.59% / Gain：2.472500.0MHz H+V, Eff: 44.22% / Gain：2.15 5150.0MHz H+V, Eff: 48.84% / Gain：2.15 Antenna Impedance: WIFI ANT M: TRP /TIS(dBm) Tx_11M / Rx_11M TRP /TIS(dBm) Tx_6M / Rx_54M TRP /TIS(dBm) Tx_6M / Rx_54M Shenzhen Lejin radio frequency technology Co., LTD Gain (dBi) Efficiency (%) Frequency (MHz) Gain (dBi) Efficiency (%) Antenna Performance Table Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. Antenna installation method 天线工程图：打胶固定射频线防止射频外移到天线辐射臂上（重点管控）天线金手指上加导电海绵与主板金手指接地 Shenzhen Lejin radio frequency technology Co., LTD Lejin radio frequency Proprietary Confidential © 2017 Lejin radio frequency Corporation. All rights reserved. 由 Autodesk 教育版产品制作由 Autodesk 教育版产品制作由 Autodesk 教育版产品制作由 Autodesk 教育版产品制作

Test Report

Page 1 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B RF Test Data for 2.4GWIFI (Conducted Measurement) Product Name: Tablet computer Test Model: IST-5 Environmental Conditions Temperature: 23.1 C Relative Humidity: 53.4% ATM Pressure: 100.0 kPa Test Engineer: Jerry Chu Supervised by: Nick Peng Page 2 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT b 2412 Ant1 8.04 >=0.5 Pass NVNT b 2437 Ant1 8.121 >=0.5 Pass NVNT b 2462 Ant1 7.827 >=0.5 Pass NVNT g 2412 Ant1 16.302 >=0.5 Pass NVNT g 2437 Ant1 16.354 >=0.5 Pass NVNT g 2462 Ant1 16.32 >=0.5 Pass NVNT n20 2412 Ant1 16.826 >=0.5 Pass NVNT n20 2437 Ant1 17.414 >=0.5 Pass NVNT n20 2462 Ant1 17.078 >=0.5 Pass NVNT n40 2422 Ant1 35.511 >=0.5 Pass NVNT n40 2437 Ant1 35.57 >=0.5 Pass NVNT n40 2452 Ant1 35.83 >=0.5 Pass Page 3 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -6dB Bandwidth NVNT b 2412MHz Ant1 -6dB Bandwidth NVNT b 2437MHz Ant1 Page 4 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT b 2462MHz Ant1 -6dB Bandwidth NVNT g 2412MHz Ant1 Page 5 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT g 2437MHz Ant1 -6dB Bandwidth NVNT g 2462MHz Ant1 Page 6 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT n20 2412MHz Ant1 -6dB Bandwidth NVNT n20 2437MHz Ant1 Page 7 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT n20 2462MHz Ant1 -6dB Bandwidth NVNT n40 2422MHz Ant1 Page 8 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT n40 2437MHz Ant1 -6dB Bandwidth NVNT n40 2452MHz Ant1 Page 9 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.2 Maximum Peak Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 15.40 30 Pass NVNT b 2437 Ant1 15.39 30 Pass NVNT b 2462 Ant1 15.97 30 Pass NVNT g 2412 Ant1 14.50 30 Pass NVNT g 2437 Ant1 14.96 30 Pass NVNT g 2462 Ant1 14.83 30 Pass NVNT n20 2412 Ant1 13.82 30 Pass NVNT n20 2437 Ant1 12.99 30 Pass NVNT n20 2462 Ant1 13.55 30 Pass NVNT n40 2422 Ant1 12.32 30 Pass NVNT n40 2437 Ant1 12.45 30 Pass NVNT n40 2452 Ant1 12.61 30 Pass Page 10 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT b 2412 Ant1 -8.66 8 Pass NVNT b 2437 Ant1 -8.87 8 Pass NVNT b 2462 Ant1 -8.31 8 Pass NVNT g 2412 Ant1 -15.07 8 Pass NVNT g 2437 Ant1 -15.87 8 Pass NVNT g 2462 Ant1 -15.62 8 Pass NVNT n20 2412 Ant1 -15.78 8 Pass NVNT n20 2437 Ant1 -17.61 8 Pass NVNT n20 2462 Ant1 -16.73 8 Pass NVNT n40 2422 Ant1 -20.88 8 Pass NVNT n40 2437 Ant1 -21.24 8 Pass NVNT n40 2452 Ant1 -21.01 8 Pass Page 11 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs PSD NVNT b 2412MHz Ant1 PSD NVNT b 2437MHz Ant1 Page 12 of 55 FCC ID: 2A8SQ-IST-5 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial P…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 39 FCC ID: 2A8SQ-IST-5 Report No.: LCSA06064146EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For ShenZhen ZhiWei Technology Co., LTD Tablet computer Test Model: IST-5 Additional Model No.: Please Refer to Page 6 Prepared for : ShenZhen ZhiWei Technology Co., LTD Address : 6th Floor, Bld 8, 4th&5th Floor, Bld 6 Lijincheng Industrial Park, The East of Gongye Road, Longhua, Shenzhen, China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : June 11, 2024 Number of tested samples : 2 Sample number : A240606068-1, A240606068-2 Serial number : Prototype Date of Test : June 11, 2024 ~ June 28, 2024 Date of Report : June 28, 2024 Page 2 of 39 FCC ID: 2A8SQ-IST-5 Report No.: LCSA06064146EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSA06064146EB Date of Issue .................................. : June 28, 2024 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Par…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Qiang Zhou(General Manager)

[email protected]+86-131 1386 5258Fax: +86-755-2220 0906

Test Firm

Shenzhen LCS Compliance Testing Laboratory Ltd.Gavin Liang

[email protected]0755-82591330Fax: 0755-82591132

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	39.50 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
