2A94K-V9-22Tablet

FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. FCC/IC RF Radiation Exposure and SAR Statements The Tablet ACER TAB V9-22 has been tested for body-worn Specific Absorption Rate(SAR) compliance. The FCC/IC has established detailed SAR requirements and has established that these requirements. RF Exposure Information The radio module has been evaluated under FCC Bulletin C95.1 and IEEE 1528 and found to be compliant to RF Exposure from radio frequency devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest reported SAR level for usage near the body (0mm) is 0.733 W/kg, Body Simultaneous transmission is 1.041W/kg.

Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 95 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 96 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 97 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 98 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 99 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 100 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 101 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 102 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 103 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 104 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 105 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 106 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 107 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 108 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 109 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 110 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 111 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 112 of 155 Edition：B.2 Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 113 of 155 Edition：B.2

Report No.:BCTC2411135403-1E No.：BCTC/RF-EMC-005 Page: 81 of 83 Edition：B.2 17. EUT Test Setup Photographs Conducted Emissions Photo Radiated Measurement Photos Report No.:BCTC2411135403-1E No.：BCTC/RF-EMC-005 Page: 82 of 83 Edition：B.2

Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 152 of 155 Edition：B.2 19. EUT Test Setup Photographs Front Back Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 153 of 155 Edition：B.2 Left Top Report No：BCTC2411029391E No.：BCTC/RF-EMC-005 Page 154 of 155 Edition：B.2 Bottom

No.：BCTC/RF-EMC-005 Page: 1 of 147 Edition：B.2 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2411135403-4E Applicant: Acer India PVT Limited Product Name: Tablet Test Model: ACER TAB V9-22 Tested Date: 2024-11-15 to 2024-12-17 Issued Date: 2024-12-17 Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 2 of 147 Edition：B.2 FCC ID: 2A94K-V9-22 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Tablet Trademark: Model/Type reference: ACER TAB V9-22 Prepared For: Acer India PVT Limited Address: Acer India PVT Limited, 6th Floor, Embassy Heights, No.13, Magrath Road, Bangalore, 560025, India Manufacturer: Acer India PVT Limited Address: Acer India PVT Limited, 6th Floor, Embassy Heights, No.13, Magrath Road, Bangalore, 560025, India Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2024-11-15 Sample tested Date: 2024-11-15 to 2024-12-17 Issue Date: 2024-12-17 Report No.: BCTC2411135403-4E Test Standards: FCC Part15 15.407 ANSI C63.10-2013 KDB 789033 D02 v02r01 Test Results: PASS Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 3 of 147 Edition：B.2 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 9 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List ........................................................................................................ 10 4.5 Test Mode ........................................................................................................... 11 5. Test Facility And Test Instrument Used ............................................................... 12 5.1 Test Facility ......................................................................................................... 12 5.2 Test Instrument Used .......................................................................................... 12 6. Conducted Emissions .......................................................................................... 14 6.1 Block Diagram Of Test Setup .............................................................................. 14 6.2 Limit .................................................................................................................... 14 6.3 Test Procedure ................................................................................................... 14 6.4 EUT Operating Conditions .................................................................................. 14 6.5 Test Result .......................................................................................................... 15 7. Radiated Emissions ............................................................................................. 17 7.1 Block Diagram Of Test Setup .............................................................................. 17 7.2 Limit .................................................................................................................... 18 7.3 Test Procedure ................................................................................................... 19 7.4 EUT Operating Conditions .................................................................................. 20 7.5 Test Result .......................................................................................................... 20 8. Power Spectral Density Test ............................................................................... 35 8.1 Block Diagram Of Test Setup .............................................................................. 35 8.2 Limit .................................................................................................................... 35 8.3 Test Procedure ................................................................................................... 36 8.4 EUT Operating Conditions .................................................................................. 36 8.5 Test Result .......................................................................................................... 37 9. 26dB & 6dB & 99% Emission Bandwidth ............................................................ 52 9.1 Block Diagram Of Test Setup .............................................................................. 52 9.2 Limit .................................................................................................................... 52 9.3 Test Procedure ................................................................................................... 52 9.4 EUT Operating Conditions .................................................................................. 53 9.5 Test Result .......................................................................................................... 53 10. Maximum…

Text truncated - open the document above for the full version.

Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 59 of 147 Edition：B.2 -26dB Bandwidth NVNT ac20 5240MHz -26dB Bandwidth NVNT ac40 5190MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 60 of 147 Edition：B.2 -26dB Bandwidth NVNT ac40 5230MHz -26dB Bandwidth NVNT ac80 5210MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 61 of 147 Edition：B.2 Test Graphs OBW NVNT a 5180MHz OBW NVNT a 5200MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 62 of 147 Edition：B.2 OBW NVNT a 5240MHz OBW NVNT n20 5180MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 63 of 147 Edition：B.2 OBW NVNT n20 5200MHz OBW NVNT n20 5240MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 64 of 147 Edition：B.2 OBW NVNT n40 5190MHz OBW NVNT n40 5230MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 65 of 147 Edition：B.2 OBW NVNT ac20 5180MHz OBW NVNT ac20 5200MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 66 of 147 Edition：B.2 OBW NVNT ac20 5240MHz OBW NVNT ac40 5190MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 67 of 147 Edition：B.2 OBW NVNT ac40 5230MHz OBW NVNT ac80 5210MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 68 of 147 Edition：B.2 Temperature: 26 °C Relative Humidity: 54% Pressure: 101kPa Test Voltage: DC 3.8V Test Mode : TX Frequency U-NII-3(5745-5825MHz) Condition Mode Frequency (MHz) 99% bandwidth (MHz) -6dB bandwidth (MHz) Limit -6dB bandwidth (MHz) Result NVNT a 5745 16.372 16.324 0.5 Pass NVNT a 5785 16.393 16.325 0.5 Pass NVNT a 5825 16.391 16.3 0.5 Pass NVNT n20 5745 17.521 17.578 0.5 Pass NVNT n20 5785 17.559 17.579 0.5 Pass NVNT n20 5825 17.551 17.568 0.5 Pass NVNT n40 5755 36.002 35.825 0.5 Pass NVNT n40 5795 35.917 35.639 0.5 Pass NVNT ac20 5745 17.541 17.563 0.5 Pass NVNT ac20 5785 17.548 17.563 0.5 Pass NVNT ac20 5825 17.537 17.597 0.5 Pass NVNT ac40 5755 35.949 36.303 0.5 Pass NVNT ac40 5795 35.976 36.052 0.5 Pass NVNT ac80 5775 75.106 75.915 0.5 Pass Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 69 of 147 Edition：B.2 Test Graphs -6dB Bandwidth NVNT a 5745MHz -6dB Bandwidth NVNT a 5785MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 70 of 147 Edition：B.2 -6dB Bandwidth NVNT a 5825MHz -6dB Bandwidth NVNT n20 5745MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 71 of 147 Edition：B.2 -6dB Bandwidth NVNT n20 5785MHz -6dB Bandwidth NVNT n20 5825MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 72 of 147 Edition：B.2 -6dB Bandwidth NVNT n40 5755MHz -6dB Bandwidth NVNT n40 5795MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 73 of 147 Edition：B.2 -6dB Bandwidth NVNT ac20 5745MHz -6dB Bandwidth NVNT ac20 5785MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 74 of 147 Edition：B.2 -6dB Bandwidth NVNT ac20 5825MHz -6dB Bandwidth NVNT ac40 5755MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 75 of 147 Edition：B.2 -6dB Bandwidth NVNT ac40 5795MHz -6dB Bandwidth NVNT ac80 5775MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 76 of 147 Edition：B.2 Test Graphs OBW NVNT a 5745MHz OBW NVNT a 5785MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 77 of 147 Edition：B.2 OBW NVNT a 5825MHz OBW NVNT n20 5745MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 78 of 147 Edition：B.2 OBW NVNT n20 5785MHz OBW NVNT n20 5825MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 79 of 147 Edition：B.2 OBW NVNT n40 5755MHz OBW NVNT n40 5795MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 80 of 147 Edition：B.2 OBW NVNT ac20 5745MHz OBW NVNT ac20 5785MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 81 of 147 Edition：B.2 OBW NVNT ac20 5825MHz OBW NVNT ac40 5755MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 82 of 147 Edition：B.2 OBW NVNT ac40 5795MHz OBW NVNT ac80 5775MHz Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 83 of 147 Edition：B.2 10. Maximum Conducted Output Power 10.1 Block Diagram Of Test Setup 10.2 Limit According to FCC §15.407 The maximum conduced output power should not exceed: Frequency Band(MHz) Limit 5150~5250 250mW 5725~5850 1W 10.3 Test Procedure Maximum conducted output power may be measured using a spectrum analyzer/EMI receiver or an RF power meter. 1. Device Configuration If possible, configure or modify the operation of the EUT so that it transmits continuously at its maximum power control level (see section II.B.). a) The intent is to test at 100 percent duty cycle; however a small reduction in duty cycle (to no lower than 98 percent) is permitted if required by the EUT for amplitude control purposes. Manufacturers are expected to provide software to the test lab to permit such continuous operation. b) If continuous transmission (or at least 98 percent duty cycle) cannot be achieved due to hardware limitations (e.g., overheating), the EUT shall be operated at its maximum power control level with the transmit duration as long as possible and the duty cycle as high as possible. 2. Measurement using a Spectrum Analyzer or EMI Receiver (SA) Measurement of maximum conducted output power using a spectrum analyzer requires integrating the spectrum across a frequency span that encompasses, at a minimum, either the EBW or the 99-percent occupied bandwidth of the signal.1 However, the EBW must be used to determine bandwidth dependent limits on maximum conducted output power in accordance with § 15.407(a). a) The test method shall be selected as follows: (i) Method SA-1 or SA-1 Alternative (averaging with the EUT transmitting at full power throughout each sweep) shall be applied if either of the following conditions can be satisfied: • The EUT transmits continuously (or with a duty cycle ≥ 98 percent). • Sweep triggering or gating can be implemented in a way that the device transmits at the maximum power control level throughout the duration of each of the instrument sweeps to be averaged. This condition can generally be achieved by triggering the instrument’s sweep if the du…

Text truncated - open the document above for the full version.

Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 104 of 147 Edition：B.2 Band Edge NVNT ac20 5180MHz Low Band Edge NVNT ac20 5240MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 105 of 147 Edition：B.2 Band Edge NVNT ac40 5190MHz Low Band Edge NVNT ac40 5230MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 106 of 147 Edition：B.2 Band Edge NVNT ac80 5210MHz High Band Edge NVNT ac80 5210MHz Low Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 107 of 147 Edition：B.2 Test Graphs Band Edge NVNT a 5745MHz Low Band Edge NVNT a 5825MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 108 of 147 Edition：B.2 Band Edge NVNT n20 5745MHz Low Band Edge NVNT n20 5825MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 109 of 147 Edition：B.2 Band Edge NVNT n40 5755MHz Low Band Edge NVNT n40 5795MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 110 of 147 Edition：B.2 Band Edge NVNT ac20 5745MHz Low Band Edge NVNT ac20 5825MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 111 of 147 Edition：B.2 Band Edge NVNT ac40 5755MHz Low Band Edge NVNT ac40 5795MHz High Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 112 of 147 Edition：B.2 Band Edge NVNT ac80 5775MHz High Band Edge NVNT ac80 5775MHz Low Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 113 of 147 Edition：B.2 12. Spurious RF Conducted Emissions 12.1 Block Diagram Of Test Setup 12.2 Limit Undesirable emission limits. Except as shown in paragraph (b)(7) of this section, the maximum emissions outside of the frequency bands of operation shall be attenuated in accordance with the following limits: (1)For transmitters operating in the 5.15-5.25 GHz band: All emissions outside of the 5.15-5.35 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (2)For transmitters operating in the 5.725-5.85 GHz band(i) All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the band edge, and from 25 MHz above or below the band edge increasing linearly to a level of 15.6 dBm/MHz at 5 MHz above or below the band edge, and from 5 MHz above or below the band edge increasing linearly to a level of 27 dBm/MHz at the band edge.. 12.3 Test Procedure 1. Check the calibration of the measuring instrument using either an internal calibrator or a known signal from an external generator. 2. Position the EUT without connection to measurement instrument. Turn on the EUT and connect its antenna terminal to measurement instrument via a low loss cable. Then set it to any one measured frequency within its operating range, and make sure the instrument is operated in its linear range. 3. Set RBW of spectrum analyzer to 1 MHz with a convenient frequency span. 4. Measure the highest amplitude appearing on spectral display and set it as a reference level. Plot the graph with marking the highest point and edge frequency. 5. Repeat above procedures until all measured frequencies were complete. 12.4 Test Result Remark: The measurement frequency range is from 9KHz to the 10th harmonic of the fundamental frequency. The lowest, middle and highest channels are tested to verify the spurious emissions and bandege measurement data. About:26.5GHz-40GHz, The amplitude of spurious emissions which are attenuated by more than 20dB below the permissible value has no need to be reported. Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 114 of 147 Edition：B.2 Test Graphs Tx. Spurious NVNT a 5180MHz Emission Tx. Spurious NVNT a 5200MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 115 of 147 Edition：B.2 Tx. Spurious NVNT a 5240MHz Emission Tx. Spurious NVNT n20 5180MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 116 of 147 Edition：B.2 Tx. Spurious NVNT n20 5200MHz Emission Tx. Spurious NVNT n20 5240MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 117 of 147 Edition：B.2 Tx. Spurious NVNT n40 5190MHz Emission Tx. Spurious NVNT n40 5230MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 118 of 147 Edition：B.2 Tx. Spurious NVNT ac20 5180MHz Emission Tx. Spurious NVNT ac20 5200MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 119 of 147 Edition：B.2 Tx. Spurious NVNT ac20 5240MHz Emission Tx. Spurious NVNT ac40 5190MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 120 of 147 Edition：B.2 Tx. Spurious NVNT ac40 5230MHz Emission Tx. Spurious NVNT ac80 5210MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 121 of 147 Edition：B.2 Test Graphs Tx. Spurious NVNT a 5745MHz Emission Tx. Spurious NVNT a 5785MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 122 of 147 Edition：B.2 Tx. Spurious NVNT a 5825MHz Emission Tx. Spurious NVNT n20 5745MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 123 of 147 Edition：B.2 Tx. Spurious NVNT n20 5785MHz Emission Tx. Spurious NVNT n20 5825MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 124 of 147 Edition：B.2 Tx. Spurious NVNT n40 5755MHz Emission Tx. Spurious NVNT n40 5795MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 125 of 147 Edition：B.2 Tx. Spurious NVNT ac20 5745MHz Emission Tx. Spurious NVNT ac20 5785MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 126 of 147 Edition：B.2 Tx. Spurious NVNT ac20 5825MHz Emission Tx. Spurious NVNT ac40 5755MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 127 of 147 Edition：B.2 Tx. Spurious NVNT ac40 5795MHz Emission Tx. Spurious NVNT ac80 5775MHz Emission Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 128 of 147 Edition：B.2 13. Frequency Stability Measurement 13.1 Block Diagram Of Test Setup 13.2 Limit Manufactures of U-NII devices are responsible for ensuring frequency stability such that an emission is maintained within the band of operation under all conditions of normal oper…

Text truncated - open the document above for the full version.

Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 144 of 147 Edition：B.2 16. EUT Photographs EUT Photo 1 EUT Photo 2 NOTE: Appendix-Photographs Of EUT Constructional Details. Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 145 of 147 Edition：B.2 17. EUT Test Setup Photographs Conducted Emissions Photo Radiated Measurement Photos Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 146 of 147 Edition：B.2 Report No.: BCTC2411135403-4E No.：BCTC/RF-EMC-005 Page: 147 of 147 Edition：B.2 STATEMENT 1. The equipment lists are traceable to the national reference standards. 2. The test report can not be partially copied unless prior written approval is issued from our lab. 3. The test report is invalid without the "special seal for inspection and testing". 4. The test report is invalid without the signature of the approver. 5. The test process and test result is only related to the Unit Under Test. 6. Sample information is provided by the client and the laboratory is not responsible for its authenticity. 7. The quality system of our laboratory is in accordance with ISO/IEC17025. 8. If there is any objection to this test report, the client should inform issuing laboratory within 15 days from the date of receiving test report. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China TEL: 400-788-9558 P. C.: 518103 FAX: 0755-33229357 Website: http://www.chnbctc.com Consultation E-mail: [email protected] Complaint/Advice E-mail: [email protected] ※※※※※ END ※※※※※

ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 AcknowledgmentLetter SPECIFICATIONFORAPPROVAL ApprovalustomerApproval PreparedByCheckedByApprovalByCheckedByApprovalBy Signature Huang Zongbao FuXuerongXiaChenglei Date2024.11.142024.11.142024.11.14 hangeLog VersionChangeDescriptionPersoninChargeApprovalByDate CustomerNameYuKe CustomerProject Name T87NProjectNameT87N AntennatypeFourinoneantennaSDCP/N WG6070B-A Band WiFi2.4G/5.8G/BT/GPS Version A0 DesignerInformation RFEngineerYangYongHuiR&DDiretorFuXuerong MEEngineerHuangZongBao ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 Catalogue No.ItemPageNo. 1DrawingorProductImage3 2DimensionsTestReport4 3RFPerformanceTestReport5-7 4ReliabilityTestReport18 5PackageDocument9 6RoHSControllistforSample10 7InstallWizardorOther10 ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 DrawingorProductImage D E S C R I P T I O N N O Q ' T Y 1 1 R E M A R K F P C 6 5 4 3 2 1 A B X X . X . . X X . X X X . X C H E C K E D ± 1 . 0 D R A W I N G ± 0 . 1 ± 0 . 5 A P P R O V E D ± 3 . 0 ± 5 F I L E : S H E E T : P A R T N A M E : R E V A 0 U N I T m / m C U S T O M E R : 2 / 3 6 5 4 C D E 3 2 2 0 2 4 . 1 1 . 1 4 A 0 F R E V D A T E N e w I s s u e G D E S C R I P T I O N 1 S D C P / N O : W G A n t e n n a ( T 8 7 N ) F P C ( S c r e e n p r i n t i n g S D C T 8 7 N W G )  W G 6 0 7 0 B - A S D C T 8 7 N W G S h e n z h e n C i t y s h u n r e a c h T e c h n o l o g y C o . , L T D . R e n t e k F u X u e r o n g L i Y o n a L i Y o n a A l l t h r o u g h h o l e s o b s e r v e d T e a r p o s i t i o n F P C - B l a c k o i l b l a c k c h a r a c t e r h a l f a n d h a l f b a s e m a t e r i a l , d o e l e c t r i c n i c k e l t r e a t m e n t 3 M 9 4 7 1 b a c k a d h e s i v e ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 SampleDimensionsTestReport TestDate2024.11.14SampleQty.3Inspector XuYanfang DimensionNo.StandardSample1Sample2Sample3Pass/NG ①length18.8±0.2mm18.818.918.8 Pass ②width11.1±0.2mm11.111.211.1 Pass ③ thickness 0.1±0.03mm0.10.10.1 Pass ConclusionPASS Inspector&Date XuYanfang2024.11.14 Approval&Date ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 RFPerformanceTestReport AntennaTestEquipmentIntroduction TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5062Avectornetwork analyzer;Theradiationpatternoftheantennaaretestedusingtheguangping3DnearfieldAnechoicChamber, andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthedarkroom areasfollows: 1. S11Parameter-VSWR MeasuringMethodisa50 Ω coaxialcableisconnectedtotheantenna.Thenthiscableisconnectedtoanetworkanalyzerto measuretheS11parameter,Keepingthisfixtureawayfrommetalatleast20cm. ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 S11Parameter-VSWR Frequency( MHz) 157015751580240024502500515057205850 VSWR1.541.531.572.121.101.981.521.361.59 2.AntennaMatchingNetwork ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 3.Electricalparameter ： 4.Gain&Efficiency Electricalparameter （Frequencyrange） 1575-5850Mhz PolarizationmodeHorizontalandverticalpolarization Measurementprogram Widescreen Testequipment Agilent(5071B）/Agilent（8960） /ROHDE&SCHWARZ(CMW500) TestSettings Insertthetestingwhitecard,fixtheentire machineonthetestingturntable,openthe testingsoftware,andselectthecorresponding testingfrequencyband TestinglocationOTAmicrowaveanechoicchamber AntennamanufacturerShenzhenShundachengTechnologyCo.,Ltd DebuggingmodePIFA AntennamaterialFPC+coaxialline ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 5.OTAdata 6.GPSmeasurementmap ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:0755-27211658FAX:0755-29485750 ReliabilityTestReport TestDate2024.11.14SampleQty.3Inspector XuYanfang TestItemRequirement testing equipment Sample1Sample2Sample3PASS/NG high temperature storage Exposeto+85°Cfor 24hours,recoverfor 2hours,andconduct testing Constant temperature andhumidity box OKOKOKPass low temperature storage Exposeto-40°Cfor 24hours,recoverfor 2hours,andperform testing Constant temperature andhumidity box OKOKOKPass High temperature operation Poweredonfor24 hoursat+60°C Constant temperature andhumidity box OKOKOKPass Low temperature operation Poweredonfor24 hoursat-20°C Constant temperature andhumidity box OKOKOKPass Saltspray test (5士0．5)%sodium chloride、pHValue is6.5～7.2， Temperatureof experimental chamber(35±2)°C □24H☑48H Saltspray testing machine OKOKOKPass Connector rivetingand pulling force 1.13Wirediameter≥ 10N 0.81Wirediameter≥ 8N RG174≥60N RG178≥50N Push-pull forcegauge ≥10N≥10N≥10NPass Conclusion Pass Inspector& Date XuYanfang2024.11.14 Approval&D ate ShenzhenShundachengTechnologyCo.,Ltd CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,Bao'anDistrict, Shenzhen TEL:…

Text truncated - open the document above for the full version.

No.：BCTC/RF-EMC-005 Page 1 of 155 Edition：B.2 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2411029391E Applicant: Acer India PVT Limited Product Name: Tablet Test Model: ACER TAB V9-22 Tested Date: 2024-11-15 to 2024-12-23 Issued Date: 20…
