2A97G-8A0018A series

8A SЕRIES Programmable Logic Relays Control panels for pumps Control and management of water Packaging machines Panels for electrical distribution Air Conditioner Building automation Forced-air ventilators FINDER reserves the right to alter characteristics at any time without notice. FINDER assumes no liability for damage to persons or property, caused as a result of the incorrect use or application of its products. H Programmable Logic Relays (PLRs) with 8 input and 4 output relays Type 8A.04-8300 - Lite version with USB (type C port), ETH Type 8A.04-8310 - Plus version with USB (type C port), ETH and Modbus RS485 Type 8A.04-8320 - Advanced version with USB (type C port), ETH, Modbus RS485, Wi-Fi and BLE • 8 digital or analog (0...10V) input • 4 relay output 10 A • USB (type C port) port for programming, data logging and powering during configuration • RJ45 port • Connectivity (*according to type): - USB - 1 Gbit Ethernet TCP/IP or Modbus TCP/IP - Modbus RS485* - Wi-Fi + BLE* • LED status indicator for each output • Programmable USER button • Programming language via IDE as an option IEC-61131-3 (LD - SFC - FBD - ST - IL) • 70 mm wide • 35 mm rail (EN 60715) mount 8A.04 Screw terminal 8A.04-83008A.04-83108A.04-8320 • Lite version • USB Port • RJ45 Port for ETH and Modbus TCP/IP • Plus version • USB Port • RJ45 Port for ETH and Modbus TCP/IP • Modbus RS485 Port • Advanced version • USB Port • RJ45 Port for ETH and Modbus TCP/IP • Modbus RS485 Port • Wi-Fi/BLE internal module Partnership with For outline drawing see page 7 Output specification Contact configuration4 NO (SPST) Rated current/Maximum peak current A10/15 Rated voltage/ Maximum switching voltage V AC250/400 Rated load AC1 VA 2500 Rated load AC15 (230 V AC) VA 500 Breaking capacity DC1: 24/110/220 V A 10/0.3/0.12 Minimum switching load mW(V/mA) 300 (5/5) Output operate/release time ms 6/4 Standard contact material AgNi Supply specification Nominal voltage (U N ) V DC12...24 Rated power W0.6...2.2 (according to type) Operating range V DC10.2...27.6 Input circuit Number of input 8 (configurable) TypeDigital/Analog Analog input type V0...10 Analog input resolution16 to 12 bit user configurable Input frequency kHz4.5 Input voltage signal 0/signal 1<4 VDC / > 5.9 VDC Input compatibilityNPN/Sink Reverse polarity protectionYES Technical data Programm languageArduino via IDE , as option IEC-61131-3 (LD - SFC - FBD - ST - IL) Minimum input signal ms0.2 Electrical life at rated load in AC1 cycles100 · 10 3 Ambient temperature range °C–20...+55 Protection categoryIP 20 Approvals (according to type) 3 I-2023, www.findernet.com 8A SERIES 8A SERIES Programmable Logic Relays H Ordering information Example: 8A series, Lite PLR version, 4 NO (SPST) - 10 A, 8 digital/analog input, 12...24 V DC. 8A.04.9.024.8300 Series Type 0 = Control Relay No. of poles 4 = 4 NO (SPST) Supply version 9 = DC Supply voltage 024 = (12...24) V DC N° of input 8 = 8 digital/ analog input Options 0 = Standard Versions 0 = Lite version, RJ45, USB (type C port) 1 = Plus version, RJ45, USB (type C port), Modbus RS485 port 2 = Advanced version, RJ45, USB (type C port), Modbus RS485 port, Wi-Fi/BLE module Type of output 3 = EMR NO contact (SPST) 4 I-2023, www.findernet.com 8A SERIES Programmable Logic Relays 8A SERIES H Technical data Insulation between input and output circuit V AC4000 between open contacts V AC1000 Insulation (1.2/50 μs) between input and output kV6 EMC specifications Type of testReference standard Electrostatic dischargecontact dischargeEN 61000-4-24 kV air dischargeEN 61000-4-28 kV Radio-frequency electromagnetic field (80 ÷ 1000 MHz)EN 61000-4-310 V/m Fast transients (burst) (5-50 ns, 5 kHz) on Supply terminalsEN 61000-4-44 kV Surges (1.2/50 μs) on Supply terminalscommon modeEN 61000-4-54 kV differential modeEN 61000-4-54 kV on input terminalscommon modeEN 61000-4-54 kV differential modeEN 61000-4-54 kV Radio-frequency common mode (0.15 ÷ 80 MHz) on Supply terminalsEN 61000-4-610 V Radiated and conducted emissionEN 55022class B Other data Power lost to the environmentwithout contact current W1.4 with rated current W3.2 PLC to PLC communication and PLC to network communication (Ethernet) Ethernet: –For Modbus TCP communication –As standard TCP/IP – RJ45 connector CAT5 cable, 2X LAN status led indicators RS485: –For Modbus RTU communication –For custom serial communication Wireless connectivityWi-Fi and Bluetooth® Low Energy Maximum program memory1 MB internal External memory moduleUSB-C pendrive Data LoggingUSB-C Stick + internal flash memory Flash memory2MB int + 16MB Flash QSPI RESET buttonYES USER buttonPush button configurable for user purposes MCUSTMicroelectronics STM32H747XI Dual ARM® Cortex® M7/M4 IC: 1x ARM® Cortex® -M7 core up to 480 MHz 1x ARM® Cortex® -M4 core up to 240 MHz Secure elementATECC608B Programming interfaceUSB-C + OTA via Web Editor (Cloud) + Ethernet RTC power reserve10 days at 25 °C RTC accuracy10 min/year @25 °C 37.5 min/year @ –10...+70 °C Cloud supportArduino Cloud via Wi-Fi and Ethernet or the Cloud services Response time ON/OFF ms6/4 Bounce time NO/NC ms3/6 TerminalsScrew terminals Wire strip length mm10 Screw torque Nm0.8 Min. wire sizesolid cablestranded cable mm 2 0.50.5 AWG2020 Max. wire sizesolid cablestranded cable mm 2 1 x 6 / 2 x 41 x 4 / 2 x 2.5 AWG1 x 10 / 2 x 121 x 12 / 2 x 14 5 I-2023, www.findernet.com 8A SERIES 8A SERIES Programmable Logic Relays H Front view 1 2 3 4 5 6 7 8 1 Supply terminals 12...24 V DC, Split terminals to facilitate wiring. 2 Input terminals I1...I8 digital/analog (0...10 V) input configurable via IDE. 3 Output terminals 1...4 Output relay, 10 A 250 V AC, NO contact. 4 LED Status 1...4 LED Status configurable via IDE. For exemple for 1...4 output relay LED ON = Contact CLOSE. 5 LED Ethernet port status Status of ETH connection. 6 Modbus RS485 Port Terminals for Modbus over RS485 protocol. 7 HARDWARE RESET Button for hardware reset. BE CAREFUL. Press the 'RESET' button with the tip of a sm…

Text truncated - open the document above for the full version.

8A.04.9.024.83xx U N (12...24) V DC + –15% Class 2 source I < 200 mA OUTPUT 4 NO (SPST) 10 A, 250 V AC1 4 A, 24 V DC1 1/2 HP 240 V AC 1/4 HP 120 V AC INPUT 8 digital/analog (0...10 V) STM32H747XI Dual ARM R Cortex R M7/M4 IC: 1x ARM R Cortex R -M7 core up to 480 MHz 1x ARM R Cortex R -M4 core up to 240 MHz USB Type C 10/100 Ethernet RS485 (8A-8310 + 8A-8320) Wi-Fi + BLE (8A-8320) Secure element integrated (–20...+50)°C Open type, EN 60715 rail mounting Environmental Conditions: Extended Humidity 5-95 RH% Altitude 2000 m IP20 1 ~ M 8A.04.9.024.8300 Versione Lite 8A.04.9.024.8310 Versione Plus 8A.04.9.024.8320 Versione Advanced DIMENSIONI SCHEMA DI COLLEGAMENTO 2a Solo per tipi 8A.04 - 8310 e 8A.04 - 8320 QUADRO FRONTALE 3a Morsetti alimentazione 12...24 V DC 3b I1....I8 morsetti ingressi digitali / analogici (0...10 V) configurabili via IDE 3c Pulsante di RESET: Imposto il dispositivo in modalità bootloader. Premendolo due volte riavvia il dispositivo. (Premerlo con un utensile appuntito isolato) 3d Pulsante USER programmabile 3e LED di stato del contatto 1...4 3f Morsetti 1...4 di uscita a relè, contatto NO (SPST) 10 A 250 V AC 3g Morsetto di terra funzionale (ETH) 3h LED stato della porta Ethernet 3i Porta targhette 060.48 3j Morsetti per collegamento MODBUS RS485 (solo per versioni 8A.04-8310 / 8320) 3k USB-C per la programmazione e il data logging 3m Porta Ethernet 3n Porta per comunicazione e collegamento moduli ausiliari INFORMAZIONI PER INIZIARE: IDE Per la programmazione di Finder OPTA 8A.04 è necessaria l’installazione di Arduino Desktop IDE. Per collegare l’8A.04 al computer, è necessario un cavo USB di tipo C. Questo collegamento fornisce anche alimentazione alla scheda, i LED potranno essere pilotati https://www.arduino.cc/en/Main/Software ARDUINO WEB EDITOR Finder OPTA può funzionare anche con Arduino Web Editor, semplicemente installando un plug-in. Arduino Web Editor è utilizzabile online, quindi sarà sempre aggiornato con le ultime funzionalità. https://create.arduino.cc/editor https://create.arduino.cc/projecthub/Arduino_Genuino/getting-started- with-arduino-web-editor-4b3e4a ARDUINO IOT CLOUD Finder OPTA è supportato su Arduino IoT Cloud il che consente di registrare, rappresentare graficamente e analizzare i dati dei sensori, oppure attivare eventi e automatismi NOTA Se il dispositivo viene utilizzato in un modo non specificato dal produttore, la protezione fornita dal dispositivo potrebbe essere compromessa. 1 2 3 8A.04.9.024.8300 Lite Version 8A.04.9.024.8310 Plus Version 8A.04.9.024.8320 Advanced Version DIMENSIONS WIRING DIAGRAM 2a Only for 8A.04 - 8310 and 8A.04 - 8320 FRONT VIEW 3a Power supply terminals 12...24 V DC 3b I1....I8 digital / analog input terminals (0...10 V) configurable via IDE 3c Reset button: puts the device in bootloader mode. Pressing it twice will restart the device. (Press with pointed tool isolated) 3d User programmable button 3e Contact status LED 1...4 3f Relay output terminals 1...4, NO contact (SPST) 10 A 250 V AC 3g Functional Earth 3h Ethernet port status LED 3i Label holder 060.48 3j Terminals for MODBUS RS485 connection (only for versions 8A.04 - 8310 / 8320) 3k USB Type C for programming and data logging 3m Ethernet port 3n Port for communication and connection of auxiliary modules GETTING STARTED GUIDE Getting started - IDE If you want to program your 8A.04 while offline you need to install the Arduino Desktop IDE. To connect the 8A.04 to your computer, you’ll need a Type C - USB cable. This also provides power to the board, as indicated by the LED. https://www.arduino.cc/en/Main/Software GETTING STARTED - ARDUINO WEB EDITOR All Arduino boards, including this one, work out-of-the-box on the Arduino Web Editor, by just installing a simple plugin. The Arduino Web Editor is hosted online, therefore it will always be up-to-date with the latest features and support for all boards. Follow to start coding on the browser and upload your sketches onto your board. https://create.arduino.cc/editor https://create.arduino.cc/projecthub/Arduino_Genuino/getting-started- with-arduino-web-editor-4b3e4a GETTING STARTED - ARDUINO IOT CLOUD All Arduino IoT enabled products are supported on Arduino IoT Cloud which allows you to Log, graph and analyze sensor data, trigger events, and automate your home or business. NOTE If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. 1 2 3 2 3 41 ITALIANOENGLISHFRANCAISDEUTSCH Utility Model - IB8A04VXX - 04/23 - Finder S.p.A. con unico socio - 10040 ALMESE (TO) - ITALY ITALIANO 1 ENGLISH 2 FRANCAIS 3 DEUTSCH 4 8A.04 0.8 Nm 9mm (1x6/2x4) mm 2 (1x10/2x12) AWG 9mm (1x4/2x2.5) mm 2 (1x12/2x14) AWG 1 3 3c 3d 3e 3g 3f 3h 3k 3n 3m 3a 3b 3j 3i 8A.04.9.024.8300 Lite Version 8A.04.9.024.8310 Plus Version 8A.04.9.024.8320 Advanced Version DIMENSIONS SCHÉMA DE RACCORDEMENT 2a Uniquement pour 8A.04 - 8310 et 8A.04 - 8320 FACADE 3a Bornes d’alimentation 12...24 V DC 3b I1....I8 entrées digitales/analogiques (0...10 V) paramétrable via IDE 3c Bouton Reset: met l’appareil en mode bootloader. Appuyer deux fois dessus pour redémarrer l’appareil. (Appuyer avec l’outil pointu isolé) 3d Bouton utilisateur programmable 3e LED d’état du contact 1...4 3f Sorties relais 1...4, contacts NO 10 A 250 V AC 3g Bornes de terre 3h LED d’état du port Ethernet 3i Porte étiquette 060.48 3j Borne de raccordement pour MODBUS RS485 (Uniquement pour les versions 8A.04 - 8310 / 8320) 3k Port USB Type C pour la programmation et l’enregistrement des données 3m port Ethernet 3n Port de communication et raccordement de modules auxiliaires GUIDE DE DEMARRAGE Commencer avec IDE hors ligne Si vous souhaitez programmer votre 8A.04 hors ligne, vous devez installer le Arduino Desktop IDE. Pour connecter le 8A.04 à votre ordinateur, vous aurez besoin d’un câble Type C - USB qui fournira également l’alimentation de la carte, comme indiqué par la LED. https://www.arduino.cc/en/Main/Software C…

Text truncated - open the document above for the full version.
