2A9FO-CD86Desktop CD Player

Reference No.: WTX25X11303610W001/002 Page 1 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2A9FO-CD86 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: ZHUHAI MEDING TECHNOLOGY CO.,LTD Address of applicant: Floor 2, Building 6A, ZHIZAO DAJIE, JINHE ROAD, HONGQI TOWN, JINWAN DISTRICT, ZHUHAI, GUANGDONG, 519000, China Manufacturer: ZHUHAI MEDING TECHNOLOGY CO.,LTD Address of manufacturer: Floor 2, Building 6A, ZHIZAO DAJIE, JINHE ROAD, HONGQI TOWN, JINWAN DISTRICT, ZHUHAI, GUANGDONG, 519000, China General Description of EUT: Product Name: Desktop CD Player Trade Name / Model No.: CD86 Adding Model(s): CD01, CD02, CD03, CD03P, CD40 Rated Voltage: Type-C 5V Battery Capacity: / Adapter Model: / FCC ID: 2A9FO-CD86 Equipment Type: Portable device Technical Characteristics of EUT: Bluetooth(BR/EDR mode) Bluetooth Version: V5.0 (BR/EDR mode) Frequency Range: 2402-2480MHz RF Output Power: 3.105dBm (Conducted) Data Rate: 1Mbps, 2Mbps, 3Mbps Modulation: GFSK, π/4 DQPSK, 8DPSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: PCB Antenna Antenna Gain: -0.58dBi Bluetooth(LE mode) Bluetooth Version: V5.0 (LE mode) Frequency Range: 2402-2480MHz RF Output Power: -0.113dBm (Conducted) Data Rate: 1Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: PCB Antenna Antenna Gain: -0.58dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 3.105 -0.58 100 4.00 1.27 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 B 0.5 4.00 2.51 2.788 0.90 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Result: Pass

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 39 TEST REPORT Reference No. ....................: WTX25X11303610W002 FCC ID ............................... .: 2A9FO-CD86 Applicant .......................... .: ZHUHAI MEDING TECHNOLOGY CO.,LTD Address ............................ .: Floor 2, Building 6A, ZHIZAO DAJIE, JINHE ROAD, HONGQI TOWN, JINWAN DISTRICT, ZHUHAI, GUANGDONG, 519000, China Manufacturer .................... .: ZHUHAI MEDING TECHNOLOGY CO.,LTD Address ............................ .: Floor 2, Building 6A, ZHIZAO DAJIE, JINHE ROAD, HONGQI TOWN, JINWAN DISTRICT, ZHUHAI, GUANGDONG, 519000, China Product Name .................. .: Desktop CD Player Model No.. ......................... .: CD86 Standards ......................... .: FCC Part 15.247 Date of Receipt sample ... .: 2025-11-18 Date of Test....................... .: 2025-11-21 to 2025-12-13 Date of Issue .................... .: 2025-12-16 Test Report Form No. ...... . : WTX_Part 15_247W Test Result ........................ .: Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Gala Wang/Project Engineer Jason Su/Manager Reference No.: WTX25X11303610W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 39 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ......................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................. 5 1.3 TEST METHODOLOGY ........................................................................................................................................... 5 1.4 TEST FACILITY ...................................................................................................................................................... 5 1.5 EUT SETUP AND TEST MODE .............................................................................................................................. 6 1.6 MEASUREMENT UNCERTAINTY ............................................................................................................................. 7 1.7 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 12 3. ANTENNA REQUIREMENT ................................................................................................................................. 13 3.1 STANDARD APPLICABLE ..................................................................................................................................... 13 3.2 EVALUATION INFORMATION ................................................................................................................................ 13 4. POWER SPECTRAL DENSITY ........................................................................................................................... 14 4.1 STANDARD APPLICABLE ..................................................................................................................................... 14 4.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 14 4.3 TEST PROCEDURE .............................................................................................................................................. 14 4.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 14 5. DTS BANDWIDTH ................................................................................................................................................. 15 5.1 STANDARD APPLICABLE ..................................................................................................................................... 15 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 15 5.3 TEST PROCEDURE .............................................................................................................................................. 15 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 15 6. RF OUTPUT POWER ............................................................................................................................................ 16 6.1 STANDARD APPLICABLE ..................................................................................................................................... 16 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 16 6.3 TEST PROCEDURE .............................................................................................................................................. 16 6.4 SUMMARY OF TEST RESULTS/PLOTS ..........................................................…

Text truncated - open the document above for the full version.

InvertedFAntennaSpecification Summary ITEMANTSPEC ModelName 2.4GANT Center Frequency HorizontalVertical 2400MHz2500MH2450MHzz2400MHz2500MH2450MHzz -1.26-0.76-0.58 -5.25 -2.46-1.86 MAX.Gain -0.58dBi PolarizationHorizontalandVertical AzimuthBeam Pattern Omni-directional Impedance 50Ohm TypeofAntennaPCBAntenna AntennaLength 38.20mm Manufacture ShenzhenWinodaTechnologyCo.,LTD Manufactureaddress 1421ZhihuiBuilding,WestCitygate,ShajingStreet,BaoanDistrict,Shenzhen AntennaPhoto&Length(mm) Horizontal:2400MHz2450MHz2500MHz Power(dBm) Max:0Min:-40Scale:5/div Frequency (MHz) Gain(dBi) Max Min Avg 2400 -1.26174 -30.0801-7.18716 2450-0.765802-36.5604-7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical:2400MHz2450MHz2500MHz Power(dBm) Max:0Min:-30Scale:5/div Frequency (MHz) Gain(dBi) Max Min Avg 2400-5.2537 -22.1424-12.4294 2450-2.4652-24.5837-10.4702 2500 -1.86120 -29.5214-9.20432 ANTTestLabs ： AttestationofGlobalComplianceCo.,Ltd.
