2A9IA-ST-16-02Wireless Remote Control

2.4cm 1.19cm 1.19cm1.15cm 1.19cm

Report No: 708882511476-00A EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 2 Rev. 23.00 RF Exposure Estimation 1. Introduction Applicant: Changzhou Yooksmart Innovation Co., Ltd. Address: Building 6C,Jintong International Industrial Park,Changzhou,Jiangsu,213167 China FCC ID: 2A9IA-ST-16-02 Product: Wireless Remote Control Model No.: ST-16-02 Reference RF report # 6128625069501, 6128625069601 2. 447498 D04 Interim General RF Exposure Guidance v01 B.2 Blanket 1 mW Blanket Exemption The 1 mW Blanket Exemption of § 1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power of no more than 1 mW, regardless of separation distance. The 1 mW blanket exemption applies at separation distances less than 0.5 cm, including where there is no separation. This exemption shall not be used in conjunction with other exemption criteria other than those for multiple RF sources in paragraph § 1.1307(b)(3)(ii)(A). The 1 mW exemption is independent of service type and covers the full range of 100 kHz to 100 GHz, but it shall not be used in conjunction with other exemption criteria or in devices with higher-power transmitters operating in the same time-averaging period. Exposure from such higher-power transmitters would invalidate the underlying assumption that exposure from the lower-power transmitter is the only contributor to SAR in the relevant volume of tissue. 3. RF Exposure Evaluation Per the test report included herein, for 433.92MHz According to C63.10-2020 Annex G EIRP = pt × gt =( E × d) 2 /30 (G.1) where pt is the transmitter output power in watts gt is the numeric gain of the transmitting antenna (dimensionless) E is the electric field strength in V/m d is the measurement distance in meters (m) ERP = EIRP /1.64 = (E x d) 2 / (30 x 1.64) = (E x d) 2 / 49.2 (G.2) Transmitter output power for 433.92MHz Function Field Strength (EMeas): 92.14(dBuV/m)=0.0405V/m (f=433.92 MHz) Measurement Distance(dMeas): 3 (m) ERP (W): 0.0003W ERP (mW): 0.3mW Report No: 708882511476-00A EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 2 Rev. 23.00 Per the test report included herein, for 2480MHz According to C63.10-2020 Annex G EIRP = pt × gt =( E × d) 2 /30 (G.1) where pt is the transmitter output power in watts gt is the numeric gain of the transmitting antenna (dimensionless) E is the electric field strength in V/m d is the measurement distance in meters (m) ERP = EIRP /1.64 = (E x d) 2 / (30 x 1.64) = (E x d) 2 / 49.2 (G.2) Transmitter output power for 2480MHz Function Field Strength (EMeas): 80.22(dBuV/m)=0.0103V/m (f=2480 MHz) Measurement Distance(dMeas): 3 (m) ERP (W): 0.000019W ERP (mW): 0.019mW We used the maximum ERP/EIRP to perform RF exposure exemption evaluation. Evaluation method Exempt Limit (mW) Verdict ◼ Blanket 1 mW Blanket Exemption 1mW Yes  MPE-based Exemption (ERP) 7mW (ERP) N/A  SAR-based Exemption (Pth) 3060mW N/A Remark: The device does not support simultaneous. So, the device is qualified for SAR test exemption, the exemption report is in lieu of the SAR report. -TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch Reviewed by: Prepared by: _____________________ ______________________ Hui TONG Jiaxi XU Reviewer Engineer Test Engineer Date: 2025-12-25 Date: 2025-12-25 -------------------------------------------------------End of Test Report----------------------------------------------------------

TÜ V SÜ D Asia Ltd., Taiwan Branch 7F., No. 37, Sec. 2, Zhongyang S. Rd., Beitou District, Taipei City, 11270, Taiwan (R.O.C.) Phone: + 886 2 2898-6818 Fax: + 886 2 2895-1598 Revision: 1.0 Effective: 2024-06-07 Page 1 of 34 RF Test Report Report Number : 6128625069602 Applicant : Changzhou Yooksmart Innovation Product : Wireless Remote Control Model : ST-16-02 FCC ID : 2A9IA-ST-16-02 IC : 32635-ST1602 In accordance with FCC rule part §15.231 ISED RSS-210 RESPONSIBLE FOR NAME SIGNATURE DATE Approved By Jack Chang 2025.12.30 Prepared By Ariel Hsu 2025.12.30 Signatures in this approval box have checked this document in line with the requirements of TÜ V SÜ D Product Service control rules. EXECUTIVE SUMMARY TÜ V SÜ D Asia Ltd., reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜ V SÜ D Asia Ltd. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜ V SÜD Asia Ltd. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 6128625069602 Page 2 of 34 Contents 1 General Information ....................................................................................................................3 1.1 Report Modification Record ...........................................................................................................3 1.2 Introduction ....................................................................................................................................3 1.3 Applied Standard ...........................................................................................................................4 1.4 Deviation from standards ..............................................................................................................4 1.5 List of applied test(s) of the EUT ...................................................................................................4 2 General EUT Information ............................................................................................................5 2.1 Variation of family model(s) ...........................................................................................................5 2.2 Technical Specification of EUT .....................................................................................................5 2.3 Antenna List ..................................................................................................................................5 2.4 Accessory of EUT ..........................................................................................................................5 3 Configuration of Equipment .......................................................................................................6 3.1 Equipment used ............................................................................................................................6 3.2 Cable(s) used ................................................................................................................................6 3.3 System configuration .....................................................................................................................7 4 General Test Configurations ......................................................................................................8 4.1 Description of test mode ...............................................................................................................8 4.2 Test Condition ...............................................................................................................................9 5 Test Result ................................................................................................................................ 10 5.1 Transmitter Requirement & Test Suites ..................................................................................... 10 5.2 Field Strength of Fundamental Emissions ................................................................................. 10 5.3 Radiated Spurious Emissions .................................................................................................... 13 5.4 Emission Bandwidth ................................................................................................................... 16 5.5 Time for Ceasing Tranmission（Optional for manually Transmitter） ...................................... 17 5.6 Duty cycle ................................................................................................................................... 18 5.7 AC Mains Conducted Emission .................................................................................................. 19 6 Measurement Uncertainty ....................................................................................................... 20 7 Photographs of the Test Set-Up ............................................................................................. 21 Appendix A. Test Equipment ................................................................................................................... 23 Appendix B. Duty cycle ............................................................................................................................. 24 Appendix C. Emission Bandwidth ............................................................................................................ …
