70x100mm PowerBank UserManual Tha nkyou for purcha singthi s pr oduct. Please careful ly read theins truc tionbe for e us e. At a Glance 1．Type -C -port out putline2．Lightning- port out putline 3．USB-C Port4．USB-A Port 5．LED Display6．Power But ton Charg ing the iPhone 12 Seri es or Later To activate wi reless chargi ng，pr ess the power button or pl ace yourde vice on the charger as illus trated be low and it wi ll beheld in pl ace magnetically. Note : When yourPowerCore exceedsthe tempe ratur e limit，the ba ttery level indi cator will tur n off. Let PowerCore cool downbe fore us e. •This wi reless charge r is not compatibl e wi th non-MagS afe phone cases, suc h as Otterbox Defende r cases. •Do not us e an ada pt er wi th an out putof 5V/1A (5W) or less. •Wireless charge rs make chargi ng more convenient than wi red charge rs, butconfined bycur rent wireless technology , their charging spe ed is slower than that of wi red charge r s •Hightempe ratur es wi ll reduce chargi ng spe ed and restrict power, which is something that happens to all wi reless charge rs. It is recommende d that you charge yourde vice in environments wi th tempe ratur es be low 25°C/77°F. •Both the pr otective phone case and the position of yourde vice on the wi reless charge r will affect the chargi ng spe ed. The farther it is pl aced fromthe center of the wi reless charge r, the slower the chargi ng spe ed wi ll be . IMPORTANT SAFETY INSTRUCTIONS When us ing this pr oduct, ba sic pr ecaut ions shoul d always befollowed, includi ng the followi ng: 1) Store the pr oduct in a cool, dr y pl ace. 2) Do not store the pr oduct in a hot or humid environment. 3) Use of a power supply or charge r not recommende d or sold bythe pr oduct manuf actur er may resul t in a risk of fire or injur y to pe rsons. 4) Ope rating tempe ratur e should bebe tween 0°C to 40°C/ 32°F to 104°F 5) Do not di sassemble the pr oduct. Take it to a qualified service pe rson when se rvice or repa ir is required. Incorrect reassembl y may resul t in a risk of fire or injury to pe rsons. 6) lf the pr oduct is not us ed for long pe riodsof time, you shoul d chargeand di schargeit once every three months 7) When chargi ng a device, the pr oduct may feel warm. This is a normal ope rating condition and shoul d not bea caus e for concern. 8) In normal conditions, the ba ttery pe rformance wi ll de cline over several years. 9) Do not di spose of the pr oduct in heat or fire. 10) Do not c lean the pr oduct with harmful chemicals or de terge nts. 11) Misuse, dr opping, or excessive force may caus e pr oduc t da mage . 12) When di sposing of secondary cells or ba tteries, keep cells or ba tteries of di fferent electrochemical systems sepa rate fromeach other. 13) Be aware that a di scharge d ba ttery may caus e fire or smoke. Tapethe terminals to insul ate them Speci fica tions Cell Capa city10000mAh（3.7V/37Wh） Type -C Input5V ⎓2.4A，9V⎓2A，12V⎓1.5A Type -C Port Out put5V⎓3A，9V⎓2.22A，12V⎓1.67A USB-A Out put5V ⎓ 3A，9V ⎓2.22A ， 12V⎓1.5A Type -C Cabl e Out put5V⎓3A，9V⎓2A，12V⎓1.5A Lightning Cabl e Out put5V⎓2A Wireless Out put5W，7.5W，10W，15W Model Number:Q5 Model Number Q5 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. "The FCC certification of this device refers to RF exposure testing performed in typical operating conditions, where a person is no closer than 0cm centimeters from the device surface at all times, except for non-repetitive patterns with transient time intervals in the order of a second. Only in the stated conditions, the device is shown to fully comply with the FCC RF Exposure requirements of KDB 447498."
