2A9OS-YW-06292.4G wireless backup camera

USER MANUAL Digital Wireless Camera System SPLIT VIEW FOR ( 2) CAMERA Congratulations on purchasing our Backup Camera System! Normally you do not need to pair the camera and monitor, we defaulted and paired them well to the first channel before delivery. What you need to do are as follow: 1. Find out the installation place of the camera and the power of reversing light( or ACC). 2. Install the monitor to a suitable place and connect it to the cigarette lighter. We recommend doing a benchmark test before installa�on to ensure that all components are working properly. IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. 16 1. The device may be powered by a 12/32 volt ba�ery or the vehicle's electrical system. 2. Make sure all cables are connected properly. Improper cable connec�ons may damage the monitor. Remove the power cable connec�ons when not using the device. Operating Precautions Wireless camera x 1 5" wireless monitor x 1 Mount Bracket x 1 Antenna x 2 Screw Kit for Camera Installa�on x 1 Camera Power Cable x 1 Package contents Electric shock or product malfunc�on may occur if this product is installed incorrectly. Use this product within the voltage range specified. Failure to do so can cause electronic shock or product malfunc�on. Take special care when cleaning the monitor, no wet hands touch during installa�on. Make sure to firmly affix the product before use. If smoke or a burning smell is detected, disconnect the system immediately. Where the power cable may touch a metal case, cover the cable with fric�on tape. A short circuit or disconnected wire may cause a fire. While installing the System be careful with the wire posi�oning in order to avoid wire damage. Do not watch movies or operate the monitor while driving; as it may cause an accident. Do not install the monitor where it may obstruct drivers view or obstruct an air bag device. Dropping the unit may cause possible mechanical failure. Do not hard press on the camera lens. Do not crush or damage the power cable. Do not use the device during a lightning storm. Installation 1. Is the signal between the camera and the receiver encrypted? Yes. 2. How many cameras does the system support? 2 cameras. 3. Why does the frame rate some�mes drop when I am driving? When driving the signal recep�on might drop some�mes. This occurs as the signal to the receiver is constantly transmi�ed from different angles. This is considered normal when transmi�ng wirelessly. 4. Is the camera water resistant? The camera is Ip69k classed. This means that the camera is well protected from both dust and humidity. It can be placed outside and can be cleaned using a pressure washer. 5. Can I hear sound from the camera? No, the camera does not have a microphone. 6. I am using the camera for reversing, how do I mirror the image? Please see the instruc�ons in the “Opera�on” sec�on. 7. What do I do if I have bad recep�on on the LCD-monitor? Start by reading through the troubleshoo�ng. If troubleshoo�ng doesn’t help, welcome to contact us: 8. Will the camera break at very low temperatures? No, at very low temperatures the picture might tone red. At extremely low temperatures the camera might turn off. However, when the temperature gets higher again the camera will regain its func�onality. FAQ 5 Mir-flip Screen Rota�on Se�ngs PAIRINGPICTUREMIR-FLIPSYSTEM CH1 NORMAL MIRROR FLIP MIR-FLIP Rota�on Op�ons (Ver�cal + Horizontal) There are many advantages to rota�ng a screen ver�cally or horizontally. Different views include : Normal Standard Display Display in classic view Mirror Horizontal Reverse Display flipped horizontally Flip Ver�cal Reverse Display flipped ver�cally Mir Flip Hand V Revers Display flipped ver�cally + horizontally The image can be modified to the driver's specifica�ons. Easily adjust the Brightness, Contrast, and Color to create the op�mal brightness. 1) Press “ Menu” 2) Press “ / ” & “OK ” to Select “ Picture “ 3) Press “ OK” & “ / ” to adjust picture image se�ngs Picture-Image Se�ngs PAIRINGPICTUREMIR-FLIPSYSTEM CH1 6 6 6 BRIGHTNESS CONTRAST HUE System - Se�ngs 1. Press “ Menu ”, Choose“SYSTEM” Press “ OK” 2. Press “ ”, “ ” to adjust 3. Press “ OK ” to select Language: Language Selec�on Delay�me: Interval Time when reversing camera displays Scan�me: Interval �me when autoscan is on Autoscan: Auto displays CH1 & CH2 on/off Autoscan means system displays CH1 & CH2 by turns PAIRINGPICTUREMIR-FLIPSYSTEM CH1 LANGUAGE ENGLISH SCANTIME 45 20 5 AUTOSCAN DELAYTIME ON OFF Technical Specification 97mm 57mm 92mm 150mm 90mm Monitor Camera Monitor Panel Size 5" LED Digital Panel Video System PAL/NTSC auto Resolu�on 800 x 3(RGB) x 480 Brightness 500cd/m2 Contrast Ra�o 500:1 Screen Mode 16:9 Field of View Top: 50°, Bo�om 70°, L/R 70° Audio NO Dot Pitch 0.077(W) x 0.231(H)mm Ac�ve Area 110.000(W) x 62.832(H)mm Power Input DC 10V-32V Opera�ng Temperature -4F to approx. 176F Frequency 2400-2483.5 MHz Transmission Type Digital Wireless Video Input 2 Channel Video Source 1vp-p75Ω Pairing CH1 Camera Paired Power Cosump�on About 4W Transmission Distance 328 � Display Mode Single / Autoscan / Split View Sensor 1/3' CCD Effec�ve Pixel Array 512x492 Sync. System 700 TV LINES Minumina�on 0.1 LUX Working Current 260mA Op�cal Format 1/3 inch Camera Correc�on R-0.45-1.0 Lens F=3.6 mm Viewing Angle 110° Waterproof Ra�ng IP69K Power Consump�on About 3.5W (IR on) Power Input DC12 -32V Opera�ng Temperature -4F to approx. 176F Frequency 2400-2483.5 MHz Transmission Type Digital Wireless Transmission Distance 328 � S/N Ra�o More than 48dB White Balance Auto IR Control Auto 34 System has been paired, connect power and it works. Use pairing unless you need to add more cameras or replace a camera. Pairing Main Menu PAIRING START 20 (RED) ACC DC 12-32V (BLACK) Ground PAIRINGPICTUREMIR-FLIPSYSTEM Camera Pairing: 1. Un-plug camera's power connec�o…

Text truncated - open the document above for the full version.

Forsafe Co.Ltd Model Difference Model: YW-0629，YW-0669, YW-0659, YW-088, YW-0689 All the models are the same circuit and RF module, except the model name. Regards Sincerely, Client’s signature: Client’s name / title : Owen Meng/ PM Contact information / address: 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800

Forsafe Co.Ltd 12/11/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (2.4G wireless backup camera / # AND FCC ID: 2A9OS-YW-0629 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Owen Meng/ PM Contact information / address: 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800

Forsafe Co.Ltd 12/11/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTA Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Owen Meng/ PM Contact information / address: 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800

FCC ID: 2A9OS-YW-0629 YW-0629 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9OS-YW-0629 Photo 4 Photo 5 Photo 6 FCC ID: 2A9OS-YW-0629 Photo 7

0.3*1.7cm

FCC ID: 2A9OS-YW-0629 YW-0629 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9OS-YW-0629 Photo 4 Photo 5 Photo 6 2.4G WiFi External antenna FCC ID: 2A9OS-YW-0629 Photo 7 Photo 8 Photo 9 FCC ID: 2A9OS-YW-0629 Photo 10

RF Exposure evaluation FCC ID: 2A9OS-YW-0629 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information Briller can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: WIFI / External antenna 1.94dBi for 2400-2500MHz; 5. Manufacturing Tolerance [2.4GHz WLAN] IEEE 802.11b (Average) Frequency (MHz) 2412 2437 2462 Target (dBm) 16.0 16.0 16.0 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11g (Average) Frequency (MHz) 2412 2437 2462 Target (dBm) 15.0 15.0 15.0 Tolerance ± (dB) 1.0 1.0 1.0 IEEE 802.11n HT20 (Average) Frequency (MHz) 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 1.94dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW 2.4GWIFI ANT1 16.0 39.81 1.94 1.56 0.012 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

1. Antenna Description: Antenna type External antenna Model YW-0629 Frequency range 2400-2500MHz Manufacturer Forsafe Co.Ltd ANT Peak Gain 1.94 dBi 2. Antenna Photo: 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. Length :29.52Cm 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : CTA22110400801 2A9OS-YW-0629 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Amy Wen Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Nov. 16, 2022 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : Forsafe Co.Ltd Address ............................................ : 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800 Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : 2.4G wireless backup camera Trade Mark ....................................... : YUWEI Manufacturer .................................... : Forsafe Co.Ltd Model/Type reference ...................... : YW-0629 Listed Models .................................. : YW-0669, YW-0659, YW-088, YW-0689 Modulation Type ............................... : CCK/DSSS/OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 12.0V From Battery Result ............................................... : PASS Report No.: CTA22110400801 Page 2 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : 2.4G wireless backup camera Model /Type : YW-0629 Series Model No. YW-0669, YW-0659, YW-088, YW-0689 Model Declaration : The PCB board is exactly the same, only the color is different. Applicant : Forsafe Co.Ltd Address : 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800 Manufacturer : Forsafe Co.Ltd Address : 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800 Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA22110400801 Page 3 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S .................................................................. 4 2 S U M M A R Y ............................................................................. 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T ............................................................... 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................ 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 11 4.3 Maximum Peak Conducted Output Power 17 4.4 Power Spectral Density 18 4.5 6dB Bandwidth 21 4.6 Out-of-band Emissions 24 4.7 Antenna Requirement 31 5 T E S T S E T U P P H O T O S O F T H E E U T .......................................... 32 6 P H O T O S O F T H E E U T ............................................................. 33 Report No.: CTA22110400801 Page 4 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: CTA22110400801 Page 5 of 38 Shenzhen CTA Testing Technology…

Text truncated - open the document above for the full version.

Report No.: CTA22110400801 Page 26 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 802.11b 802.11g Reference Reference CH011 CH01 30MHz-3GHz 30MHz-3GHz 3GHz -25GHz 3GHz -25GHz Report No.: CTA22110400801 Page 27 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 802.11g Reference Reference CH06 CH11 30MHz-3GHz 30MHz-3GHz 3GHz -25GHz 3GHz -25GHz Report No.: CTA22110400801 Page 28 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 802.11n20 Reference Reference CH01 CH06 30MHz-3GHz 30MHz-3GHz 3GHz -25GHz 3GHz -25GHz Report No.: CTA22110400801 Page 29 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 802.11n20 / Reference CH11 / 30MHz-3GHz / 3GHz -25GHz Report No.: CTA22110400801 Page 30 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Band-edge Measurements for RF Conducted Emissions: 802.11b Left bandedge Right bandedge 802.11g Left bandedge Right bandedge 802.11n(HT20) Left bandedge Right bandedge Report No.: CTA22110400801 Page 31 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 4.7 Antenna Requirement Standard Applicable For intentional device, according to FCC 47 CFR Section 15.203: An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited FCC CFR Title 47 Part 15 Subpart C Section 15.247(c) (1) (I): (i) Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point operations may employ transmitting antennas with directional gain greater than 6dBi provided the maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the directional gain of the antenna exceeds 6dBi. Test Result: The maximum gain of antenna was 1.94 dBi. Remark:The antenna gain is provided by the customer , if the data provided by the customer is not accurate, Shenzhen CTA Testing Technology Co., Ltd. does not assume any responsibility. Report No.: CTA22110400801 Page 32 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 5 T e s t S e t u p P h o t o s o f t h e E U T Report No.: CTA22110400801 Page 33 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 6 P h o t o s o f t h e E U T Report No.: CTA22110400801 Page 34 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA22110400801 Page 35 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA22110400801 Page 36 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Antenna Report No.: CTA22110400801 Page 37 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Report No.: CTA22110400801 Page 38 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn ********************** End of Report **********************

FORSAFE CO., LtdYW-0629 MANUAL V1.0 Page 1QR-RD-004-A FORSAFE CO., Ltd Product:2.4GHz WiFi Module Model NO.:YW-0629 Image Prepared By: Date: Checked By:Date: Approved By:Date: CUSTOMER APPROVAL:DATE: (Please return to us one copy of“Specification for approval”with your Approved signatures.) FORSAFE CO., LtdYW-0629 MANUAL V1.0 Page 2QR-RD-004-A 1、Overview YW-0629 is a WLAN 11n USB module, which fully supports the features and Functional compliance of IEEE 802.11n,e and i standards. It supports up to 150Mbps high-speed wireless network connections. It is designed to provide excellent performance with low power Consumption and enhance the advantages of robust system and cost-effective. It is targeted at competitive superior performance, better power Management applications. 2 、 Features 1) General ■7 -pin Stamp hole; ■CMOS MAC, Baseband PHY, and RF in a single chip for IEEE 802.11b/g/n compatible WLAN; ■Complete 802.11n solution for 2.4GHz band; ■72.2Mbps receive PHY rate and 72.2Mbps transmit PHY rate using 20MHz bandwidth; ■150Mbps receive PHY rate and 150Mbps transmit PHY rate using 40MHz bandwidth; ■Compatible with 802.11n specification; ■Backward compatible with 802.11b/g devices while operating in 802.11n mode 2) Interface ■Complies with USB 1.0/1.1/2.0 for WLANStandards Supported; ■IEEE 802.11b/g/n compatible WLAN; ■IEEE 802.11e QoS Enhancement (WMM); ■802.11i (WPA, WPA2). Open, shared key,and pair-wise key authentication services 3) WLAN MAC Features ■Frame aggregation for increased MAC efficiency (A-MSDU, A-MPDU); ■Low latency immediate High-Throughput Block Acknowledgement (HT-BA); ■PHY-level spoofing to enhance legacy compatibility; ■Power saving mechanism; ■Channel management and co-existence; ■Transmit Opportunity (TXOP) Short Inter-Frame Space (SIFS) bursting for higher multimedia bandwidth 4) WLAN PHY Features IEEE 802.11n OFDM ■One Transmit and one Receive path (1T1R); FORSAFE, LtdYW-0629 MANUAL V1.0 Page 3QR-RD-004-A ■20MHz and 40MHz bandwidth transmission; ■Short Guard Interval (400ns); ■DSSS with DBPSK and DQPSK, CCK modulation with long and short preamble; ■OFDM with BPSK, QPSK, 16QAM, and 64QAM modulation. Convolutional Coding Rate: 1/2, 2/3, 3/4,and 5/6; ■Maximum data rate 54Mbps in 802.11g and 150Mbps in 802.11n; ■Hardware antenna diversity in per packet base; ■Selectable receiver FIR filters; ■Programmable scaling in transmitter and receiver to trade quantization noise against increased probability of clipping; ■Fast receiver Automatic Gain Control(AGC); ■On-chip ADC and DAC; 3 、 Specification Product Model YW-0629 Product Name WLAN 11n USB 1T1R module General Power ConsumptionDC3.3V Maximum power dissipation in 80mA Size18.5mm(L)X15.4mm(W)X3.0mm(H) WeightApprox.:1.5 g Operating Temperature-20~ +70°C ambient temperature Storing Temperature-40 ~ 125°C ambient temperature Operating humidity5 to 90 % maximum (non-condensing) Standard802.11b/g/n, 802.3, 802.3u Data Transfer Rate 1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,90,120 and maximum of 150Mbps Modulation MethodBPSK/ QPSK/ 16-QAM/ 64-QAM Frequency Band2.412~2.4835 GHz ISM Band Spread Spectrum IEEE 802.11b: DSSS (Direct Sequence Spread Spectrum)； IEEE 802.11g/n:OFDM (Orthogonal Frequency Division Multiplexing) RF Output Power< 14dBm@11n，< 15dBm@11g，< 19dBm@11b Operation ModeAd hoc, Infrastructure Receiver Sensitivity11Mbps-86dBm@8%,54Mbps-73dBm@10%,130Mbps，-66dBm@10% Operation RangeUp to 180 meters in open space LEDNO OS Support Windows 2000, XP32-64, Vista 32/64, Win7 32/64,Linux,Mac, Android， WIN CE SecurityWEP, TKIP, AES, WPA, WPA2 InterfaceUSB 2.0 FORSAFE CO., LtdYW-0629 MANUAL V1.0 Page 4QR-RD-004-A 4、DC Characteristics Description Performance TypUnit Sleep mode1.1mA RX Active, HT40, MCS7151mA RX Power saving, DTIM=115mA RX Listen6mA TX HT40, MCS7 @ 15dBm210mA TX CCK, 11Mpbs @ 19dBm242mA Note: All result is measured at the antenna port and VDD33 is 3.3V. Power Consumption ParametersConditionsTypUnit Receiving Tests the biggest receive 11MBPS90mA 54MBPS90mA 65MBPS90mA 135MBPS90mA Transmission Biggest transmission test 11MBPS120mA 54MBPS110mA 65MBPS110mA 135MBPS105mA The depth waits for an opportunity5mA Deep sleep5mA Browse the web current90mA High-definition current100mA FORSAFE CO., LtdYW-0629 MANUAL V1.0 Page 5QR-RD-004-A 5 、 Pin Description 6、Application circuit 7、sequence chart 8 、 Dimension Pin NO.Function 1Power: DC 3.3V 2D- 3D+ 4GND 5REST 6IPX: Antenna Port

FCC ID: 2A9OS-YW-0629 YW-0629 Test Setup Photos of the EUT
