2A9OS-YW-AHD06282.4G wireless backup camera

IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. We recommend doing a benchmark test before installation to ensure that all components are working properly.      AHD 1080P Wireless Rear View Camera System QUAD VIEW (4) CAMERA INSTRUCTION MANUAL Please read this manual before using the product. It may be different from how it is described in the manual depending on the software version Wireless camera x 1 7" wireless monitor x 1 Mount Bracket x 1 Monitor sunshade x 1 Antenna x 2 Screw Kit for Camera Installation x 1 Camera Power Cable x 1 Package contents Before drilling, please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. Step 1: Choose the monitor and camera locations. Step 2: Install all cabels in vehicle, when necessary a 0.8 (20mm) hole should be drilled for passing camera cable through vehicles walls. Install split grommets where applicable. Step 3: Once all cables and wiring have been properly routed, perform a system function test by temporarily connecting the system. If the system seems to not be operating properly see troubleshooting. Camera Installation 1. Attach camera bracket close to rear marker lights, centered on vehicle. 2. Camera: drill a 20mm (0.8in) diameter hole into vehicle body near the camera and bracket. Insert camera cable into vehicle not to kink cable) and fit grommet into hole. Apply sealant around grommet to increase resistance to water penetration. connect camera to the camera extension cable which runs inside the vehicle. Before Beginning Installation Installation Guide Troubleshooting Monitor Displays Blue Screen & Displays No Signal Do a hard reset, unplug all cables and power cables and leave them out for 2 minuteS and then re-connect them. Check to ensure that the connection to the camera is tight. Monitor Will Not Power-Up ( no backlight no power button ) Check fuse Check 12v+ to monitor No Image On Screen Verify camera is connected with antenna Verify camera is connected to cable 110 3. Feed as much cable as possible into vehicle with clamp securely. This reduces the possibility of cable being hooked or snagged. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather conditions. 4. Attach camera to bracket using screws and adjust the angle. 5. Wiring camera connect the POWER (red) to 12V and the GROUND (black). 1. To attach the pedestal mount to the dashboard or to the headliner use self-tapping screws and/or the adhesive pad. 2. Attach monitor to mount, and adjust mounting angle to allow optimum driver viewing comfort. Infrared technology built into camera IRs are activated automatically according to the lighting conditions. Grid lines function can be turned on/off by manually from menu. (Note: if connecting power directly to battery, the camera is always ON and therefore can drain battery. Therefore it is recommended to connect power to an ignition switchedaccessory power source.) Monitor Installation Guide Install the monitor Antenna Mounting Position Adjustment Wheel Thumb Screw SD Card slot Remove the screw and detach the cover of SD card slot. Then insert the SD card and attach its cover by tightening the screw. Cameras Pairing Record Playback View mode Setting Press " Menu" button Press " +" or "-" scroll to “ PLAYBACK" Press "OK" Press " +" or "-" scroll to the footage you want to playback Press " OK", playback starts Press " Menu" button Press " +" or "-" scroll to “ View mode" Choose desired view mode when you have two or more cameras installed, Press "OK" If you hope to see each camera in loop viewing automatically, choose and " SCAN" appears on the screen in this mode How to playback the recordings saved How to choose display view mode 9 Cameras Pairing Record Playback View mode Setting Installation Diagram Connect to cigarette lighter socket in the car Red ( power+) DC 12-32V Black ( Ground ) DC 12-32V Cameras Pairing Record Playback View mode Setting When you use one camera mode, press " MENU" > 2S to turn on Record Press " MENU" > 2S again to turn off Record How to set up Record on/off Postitioning Monitor Camera FULL AHD Wireless Monitor Screen Size 7" ( diagnal length) Technology 2.4GHz Digital Wireless Transmission Distance 330ft / 100m Frequency 2400 -2483.5 MHz Camera Max support 4 cameras Resolution 1024 x 600 ( RGB) Display Format 16:9 /500:1 Display Brightness 400cd/M² Viewing Angle U: 50 ̊ / D: 50 ̊ / R: 70 ̊ Video Source 1Vp-p, 75Ώ Power Source DC 12-32V Display Mode Single, Split view, Quad view Power Consumption < 500mA Operating Temperature -30 +80 Video System Auto NTSC / PAL Overall Dimension 19.5cm (L) x 3cm (D) x13cm (H) Weight 0.4kg Sync System Internal Note: this monitor can recording video footage DVR Storage SD card supports up to 128GB ( up level 4) SD card is NOT included in the package Feature Overview Preview / Recording / Playback Monitor Specifications Cameras Pairing Record Playback View mode Setting PAIR>3s This system is default being paired, it displays camera image as soon as power connection finished. Camera pairing is needed to use when you need to repair camera and monitor if it looses signals or when you need to add more cameras to this system. Press " Menu", press "+" or " - " scroll to Pairing Press "OK", it appears countdown "20 seconds" on the monitor Press " Pair" button > 3s in the back of camera Monitor displays camera image when pairing complete This monitor has built-in DVR, it can record video footage if you like to. Note: SD card support…

Text truncated - open the document above for the full version.

Forsafe Co.Ltd Model Difference Model: YW-AHD0628，YW-AHD0668, YW-AHD0658, YW-AHD0688 All the models are the same circuit and RF module, except the model name. Regards Sincerely, Client’s signature: Client’s name / title : Owen Meng/ PM Contact information / address: 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800

Forsafe Co.Ltd 12/11/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (2.4G wireless backup camera / # AND FCC ID: 2A9OS-YW-AHD0628 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Owen Meng/ PM Contact information / address: 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800

Forsafe Co.Ltd 12/11/2022 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTA Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Owen Meng/ PM Contact information / address: 6F NO.1 Xing Long Four Street, DaHua, HuaCheng, HuaDu District, Guangzhou, Guangdong CHINA 510800

FCC ID: 2A9OS-YW-AHD0628 YW-AHD0628 External Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9OS-YW-AHD0628 Photo 4 Photo 5 Photo 6 FCC ID: 2A9OS-YW-AHD0628 Photo 7

0.3*1.7cm

FCC ID: 2A9OS-YW-AHD0628 YW-AHD0628 Internal Photos of the EUT Photo 1 Photo 2 Photo 3 FCC ID: 2A9OS-YW-AHD0628 Photo 4 Photo 5 Photo 6 2.4G External antenna FCC ID: 2A9OS-YW-AHD0628 Photo 7 Photo 8 Photo 9 FCC ID: 2A9OS-YW-AHD0628 Photo 10 Photo 11

1. Antenna Description: Antenna type External antenna Model YW-AHD0628 Frequency range 2400-2500MHz Manufacturer Forsafe Co.Ltd ANT Peak Gain 1.93 dBi 2. Antenna Photo: Length :20.50Cm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

FORSAFE CO., LTDDV2631 V1.0 Page 1 QR-RD-004-A FORSAFE CO., LTD Product: 2.4GHz Digital Wireless AV Transceiver RF Module Model NO.:DV2631_ V1.0 Image Prepared By: Date: Checked By:Date: Approved By:Date: Customer Approval:Date: (Please return to us one copy of“Specification for approval”with your Approved signatures.) FORSAFE CO., LTD DV2631 V1.0 Page 2 QR-RD-004-A 1、Features ■2.4GHz ISM band HDR (high data rate) FH (frequency hopping) transceiver; ■Provides three types of digital modulation 16QAM/QPSK/BPSK; ■Data rate support 12Mbps/6Mbps/3Mbps; ■Support plugins and half-hole mount. 2 、 Specification General Power Supply+5.0V Current Consumption 550mA±20mA @TX Power = 26dBm±1dBm) 65mA(Typ.) @12MHz RX Mode Standby Mode10mA Transmission range>600m (line of sight) Size27.65mm(L) X 20.4mm(W) X 3.3mm(H) Interface10Pin x 2.0mm (10Pin 2.0mm header or SMD) WeightApprox.:3.2g Operating Temperature-40~+85ºC Storing Temperature-65~+100ºC Operating humidity85%RH RF Operating frequency range Cover2400 ~ 2483MHz RF Impedance50Ω, Typ. Output Power27dBm @ Maximum Power Setting Max. Emission <-30dBm@2nd Harmonic <-50dBm@3rd Harmonic RX Sensitivity -81dBm(Typ.) @12MHz,16QAM BER<1E-3 -86dBm(Typ.) @12MHz QPSK BER<1E-3 RF Bit Rate 3MHz/6MHz/12MHz BER<1E-3（Optional） Modulation / Demodulation16QAM/QPSK/BPSK Spread SpectrumFHSS MAX. Hope Rate1200hops/S RF Band Width1MHz RF Overlapping Hopping Channel19 LO Frequency stabilization±30kHz LO Frequency Precision±50kHz SPI SpeedSPI: 0~30MHz Data Error Check16CRC FORSAFE CO., LTD DV2631 V1.0 Page 3 QR-RD-004-A 3 、 Function introduce (TOP View) Pin NO.FunctionComment 1+3.3V~+5VRF module supply voltage input DC 5.0V 2GNDGround 3CLK12MNC 4IRQ_NOutput (Interrupt indication for external MCU) 5CS_NInput (Chip selection for SPI interface) 6SDOData Output 7SDIData Input 8SCKClock Input 9RST_NReset Input 10CLK32K32kHz Crystal Output 11GNDGround 12GNDGround 13GNDGround 14GNDGround 15ANT2.4GHz Antenna Port 16GNDGround 4 、 Dimension （Unit: mm)
