2A9QN-JLP60SMotion Space Home Gym

Product Manual JLP60S Home Gym 12 Product Introduction Home Gym Device Waist Band Connecting Buckle AnkleBand Folding Handle Folding Switch Wireless SwitchConnecting Buckle Power Switch Packing List Display Screen Universal Wheel AC Power Cord Product Manual Power Socket Control Panel Pole Bracket Speaker Handle 34 Safety Precautions Thank you for choosing the Home Gym. The correct use of the product is the guarantee of safe exercise. To protect the personal safety of you and yourfamily during exercise, please read this manual carefully before using the Home Gym,and strictly follow the precautions in the instructions when using. User-related 1 . Please wear appropriate sports shoes and clothes to use this equipment, and perform appropriate warm- up exercises first. 2 . If you feel any discomfort or any abnormalities in your body during using, please stop exercising immediately and consult a doctor. 3 . Elderly people over 6 5 years of age, pregnant women, pregnant women, breastfeeding mothers, who have undergone surgery within 6 months, sufferfrom heart disease, high blood pressure, asthma and o ther diseases that cannot engage in strenuous exercise, and other medical advice is not recommended. In the case of strenuous exercise, we do not recommend that you use the Home Gym, if you are using it, please stop using it immedi- ately. 4 . Before and after using, it is strictly prohibited to drinkalcoholic beverages and any excitement products prohibited by national laws and regulations. 5 . Fatigue, failure to use the operation method and excessive exercise may cause yo u to be injured. You should make accurate judgments about your physical condition and endurance before exercising, and ensure that the exercise, intensityand duration are appropriate. 6 . When using the Home Gym, please keep children and pets awayfrom the Home Gym to avoid danger. 7 . Minors must use this equipment under the supervision and guidance of their guardians, not alone. 8 . When the operator with long hair uses this machine, it is recommended to coil or tie up the hai r to prevent the hair from entering the gap of the equipment bymistake. 9 . Keep indoors with a certain humidity in winter to avoid static electricity. Static electricity may interfere with the operation of the equipment and even cause damage to the equipment. Chemical fiber fabrics are prone to static electricity. Avoid wearing chemical fiber clothing to use this equipment . Equipment and using environment 1 . The Home Gym is an indoor sports equipment, please do not place it outdoors. 2 . When using the Home Gym, make sure that the Home Gym is in a safe and open space in at least 2 square- meters. 3 . The location of the Home Gym should be far away from water, heat and flammable and explosive materials. 4 . The Home Gym is a special equipment for sports, please do not disassemble it at will, and do not modify it for other purposes at will to avoid potential safety hazards. 5 . Do not splash liquids on the Home Gym, and do not place any foreign objects on the Home Gym. 6 . Do not insert your fingers or any foreign objects into the gap of the Home Gym to avoid danger. 7 . Do not touch the power cord, power socket and power switch with wet hands. 8 . Please do not use the power cord or plug that is damaged or stuck with water. If the power cord of the Home Gym is damaged, please consult the after- sales service person- nel or personnel with relevant profe ssional qualifications to replace it, so as to avoid injury. 9 . After using, please turn off the Home Gym and unplug the Home Gym in time. 1 0 . When cleaning the machine, you must unplug the power cordand wipe it with a clean and soft towel that does not drip. 1 1 . The Home Gym should be placed on a clean, flat, and hard ground. Do not place soft cushions such as blankets or yoga mats under the equipment. 1 2 . The rollers of the Home Gym are only suitable for indoor wooden and tiled floors. Please do not use them on bumpy roads such as asphalt roads in outdoor scenes. 1 3 . The current product is only suitable for home use, commercial scenarios ( such as gyms, etc. ) are not applicable. 1 4 . Please cooperate with the Home Gym' s own power cord for use, do not use other power cords for power supply. 5 6 16. The power plug must be grounded reliably, and try to avoidusing other electrical appliances on the same power supply line. Please do not use the power cord or plug that is damaged or stuck with water. The power cord of the Home Gym is dedicated. If it is damaged, it must be replaced by the manufacturer, service center or personnel with relevant professional qualifications to avoid injury. 17. Do not plug the machine into a socket that is short-circuited to ground or leakag e, to avoid electric shock. Warning According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time infuture you need to dispose of this product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Operating Instructions Preparation before use A. When opening the folded Home Gym, please make sure to emptythe items in theHome Gym placement area and place the Home Gym slowly on the ground. Do not let go directly in the middle of unfolding to avoid pressing your feet. B. The Home Gym needs to be energized for use. Please do not pull out the rope before it is powered on, otherwise the rope will not be retracted, if you accidentally pull the rope out without power…

Text truncated - open the document above for the full version.

Declaration on model difference We, _ Hong Kong M Spacer Limited _ the undersigned hereby declare that the device's schematics ，PCB layout and all other electrical aspects of the device are identical. The only differences are model no. and colors for trading purpose. Product Name: Motion Space Home Gym Models: JLP60S-A1、JLP60S-A2、JLP60S-A3、JLP60S-A4、JLP60S-A5 Name：Wenjie Liu Company: Hong Kong M Spacer Limited

Date: 2023/01/03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Motion Space Home Gym / JLP60S - A1 、 JLP60S - A2 、 JLP60S - A3 、 JLP60S - A4 、 JLP60S - A5 / 2A9QN - JLP60S ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Signature: Name: wenjie liu Applicant: Hong Kong M Spacer Limited Address: UNIT 808,8/F WITTY COMM BLDG 1A - 1L TUNG CHOI ST HK TEL: 18566070767

date: 203/01/03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Eurofins Electrical Testing Service (Shenzhen) Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: wenjie liu Applicant: Hong Kong M Spacer Limited Address: UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK TEL: 18566070767

REVISIONS RECORD DESCRIPTIONREVISIONDATEREVISED BY GUANGZHOU SHIYUAN ELECTRONIC CO.,LTD. TOLERANCE UNLESS OTHERWISE SPECIFIED N/APART NAMESCALE SIZE SHEET 1:1NOTES: N/A 1/1 CHK'DAPP'D UNITmm MATERIALSEEDRAWING TECHNOLOGY SEEDRAWING DRAWN =CRITICAL DIMDRAWING No. MAT'L SEE NOTES: N/A NewV1.0 luo yanxia 2022/11/14 罗艳霞 刘雅静 铭牌贴纸 PS60-G03-R47101-V1.0 铭牌贴纸-英文-Motion Space Motion Space Home Gym Model No.: JLP60S-A1 Power: 1500W Maximum Weight: 150KG Voltage: 100-240V~ 50/60Hz Production Date: 2022/07/01 S/N: XXXXXXXXXXXXXXXXXX Hong Kong M Spacer Limited 工艺参数： 1. 材质： 75#哑银龙，背覆强粘胶，可打印雾膜 2. 尺寸： 100*30mm 3. 印刷颜色：来料空白，所有内容都为工厂打印， 卷装来料，长度方向为出纸方向 4. 所有材质及油墨需符合RoHS 5. 高温高湿环境下（60°C，相对湿度60%）无翘角、 起泡、脱落现象，粘贴测试24小时后无以上不良 现象出现。 1.打印字体为：Arial，5pt 2.二维码尺寸：6×6mm 内容为： 序列号,即： XXXXXXXXXXXX 序列号按照视睿最新编码规则打印，客户编码规则如下 图纸中所有条码仅供参考样式，请根据实际订单所对应的条码内容更新, 红色字体为变量，工厂根据实际订单打印。 CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE THE COVER OR SCREWS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. 100mm 30mm CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2A9QN-JLP60S Made in China

BT WIFI Antenna 2.4G receive Antenna

1 Safety Human Exposure 1.1 Radio Frequency Exposure Compliance 1.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test standard : CFR47 FCC Part 2: Section 2.1091 CFR47 FCC Part 1: Section 1.1310 FCC KDB Publication 447498 v06, section 7 FCC ID: 2A9QN-JLP60S  FCC requirements FCC requirement: Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 20cm normally can be maintained between the user and the device. MPE Calculation Method according to KDB 447498 v06 Power Density: S (Mw/cm 2 ) = PG/4Πr 2 or EIRP/4Πr 2 Where: S = power density (mW/cm 2 ) P = power input to the antenna (mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm) From the maximum conducted output power, the minimum mobile separation distance, d=20 cm, as well as the antenna gain, the RF power density can be calculated as below: S(Mw/cm2)= PG/4Πr2 1) EUT RF Exposure Evaluation operations, Worst Case mode Test Mode Measured Power (dBm) Antenna Gain (dBi) Measured e.i.r.p (dBm) S(Mw/cm 2 )= PG/4Πr 2 Limit (Mw/cm 2 ) 2.4GHz band Wi-Fi 11.21 4.52 15.73 0.0074 1.0 BLE 2.37 4.52 6.89 0.0010 1.0 BR+EDR 4.36 4.52 8.88 0.0015 1.0 The EUT power density for transmit simultaneously is 0.0099 mW/cm 2 it is less than the limit 1.0 mW/cm 2

表单编号：B&T-QR-EN-002版本：B3 第1页共16页 开发案号:Y202012071975 日期：2021.02.25 版本：A0-0225 承认书 客户名称：视源 调试机型： YD.R11 客户料号： 博安通料号： AG-041333-2166 规格描述： 2.4G 内置天线（ FPC31.2 × 12.9 ） - 灰色 1.13 线 - 端子， L=110mm 出厂签章： 编写审核批准 黄飞辉杨懂关宁 客户承认签章： 检查审核批准 博安通联系方式 业务联系人：张艳花手机：13510808863邮箱：[email protected] 技术联系人：关宁手机：18682108275邮箱：[email protected] 品质联系人：袁进军手机：18998784314邮箱：[email protected] 表单编号：B&T-QR-EN-002版本：B3 第2页共16页 文件制定 / 修订 / 废止履历表 版本日期制定/修订内容制定核准 A02021.01.12首次制定黄飞辉唐海林/易琳宇 A0-02252021.02.25更改线长黄飞辉唐海林/易琳宇 表单编号：B&T-QR-EN-002版本：B3 第3页共16页 目录 1 、封面 ·········································································1 2 、目录 ·········································································3 3 、产品图面 ···································································4 4 、性能参数表 ································································5 5 、电气性能测试报告 ·······················································6-8 6 、可靠性测试报告 ··························································9-12 6.1维持力······································································9 6.2恒温恒湿试验································································10 6.3高低温冷热冲击······························································11 6.4盐雾测试····································································12 7 、材料成份及有害物质表 ·················································13 8 、禁用物质保证 ·····························································14 9 、包装规范 ···································································15 10 、天线安装示意图 ·························································16 表单编号：B&T-QR-EN-002版本：B3 第4页共16页 3 、产品图面 表单编号：B&T-QR-EN-002版本：B3 第5页共16页 4 、性能参数 电气参数 频率范围2.4G-2.5G 输入阻抗 50 Ω 驻波比对照工程封样 功率容量 <10w 极化方式线极化 辐射方向全向 接头型号端子 机械参数 线长 110±3mm 端子维持力≥1KG 同轴电缆灰色 1.13 线 盐雾测试24H 环境参数 工作温度 -30 °C ~65 °C 表单编号：B&T-QR-EN-002版本：B3 第6页共16页 5 、电气性能测试报告（整机） 天线 S11 参数图天线 1 天线S11参数图天线2 表单编号：B&T-QR-EN-002版本：B3 第7页共16页 5.2 驻波比数据 天线 1 天线 2 5.3 天线暗室测试数据 天线 1 天线 2 Freq/GHz2.42.452.5 VSWR1.861.661.83 Freq/GHz2.42.452.5 VSWR1.751.481.66 频率/MHz 24002410242024302440245024602470248024902500 增益/dBi 3.333.423.853.453.573.473.373.503.793.323.39 效率/% 59.2659.2065.3760.8463.5562.7261.8164.1268.8663.5167.23 频率/MHz 24002410242024302440245024602470248024902500 增益/dBi 2.742.663.062.752.852.622.532.833.212.823.04 效率/% 58.9358.2963.7159.0661.4359.5158.1559.8563.7658.4562.21 表单编号：B&T-QR-EN-002版本：B3 第8页共16页 5.4天线方向图 天线1 天线2 表单编号：B&T-QR-EN-002版本：B3 第9页共16页 6 、可靠性试验报告 6．1．维持力 试验/试验项目 维持力 检验单号 产品名称/规格 2.4G内置天线（FPC31.2×12.9）-灰色 1.13线-端子，L=110mm 试验数量：5PCS 送检日期:2021-01-11完成日期：2021-01-12 试验/检验设备： 1.拉力测试计 试验/检验条件： 1.温度：18-25°C 2.湿度≤65％RH 试验/检验结果：合格 项目 条件 端子与线缆之间的维持力≥1kgf 测试次数12345 测试结果1.011.031.11.051.12 备注： 试验/检验判定：□合格□不合格□不作判定 测试：李银珂审核：蒋红英 表单编号：B&T-QR-EN-002版本：B3 第10页共16页 6 ． 2 ．恒温恒湿试验 试验/试验项目 恒温恒湿试验 检验单号 产品名称/规格 2.4G内置天线（FPC31.2×12.9）- 灰色1.13线-端子，L=110mm 试验数量：5PCS 送检日期:2021-01-11完成日期：2021-01-12 试验/检验设备： 1.可程式恒温恒湿实验箱 2.8753ES网络分析仪 试验/检验条件： 1.恒温-30°C下试验12H 2.+65°C65～70%RH试验12H，共24小时； 试验结果 判定标准： 1、金属表面镀层应无剥落，裂痕起皱，分离等；非金属部分不应发生变色，开裂，变形， 脱胶等不良； 2、电气测试符合标准要求：电压驻波比测试合格 检验项目恒温恒湿试验前恒温恒湿试验后缺陷描述判定结果 外观 外观无变色开裂、变 形、脱胶 外观无变色开裂、变形、 脱胶 无合格 电性能 天线电压驻波比测试 合格 天线电压驻波比测试合 格 无合格 试验/检验判定：□合格□不合格□不作判定 测试：李银珂审核：蒋红英 表单编号：B&T-QR-EN-002版本：B3 第11页共16页 6．3．高低温冷热冲击 试验/试验项目 高低温冷热冲击 检验单号 产品名称/规格 2.4G内置天线（FPC31.2×12.9）- 灰色1.13线-端子，L=110mm 试验数量：5PCS 送检日期:2021-01-11完成日期：2021-01-12 试验/检验设备： 1.高低温交变湿热箱 2.8753ES网络分析仪 试验/检验条件： -40°C（2H）---间隔80°C（2H），6次循环，共24小时 试验结果 判定标准： 1、 金属表面镀层应无剥落，裂痕起皱，分离等；非金属部分不应发生变色，开裂，变形， 脱胶等不良； 2、电气测试符合标准：电压驻波比测试合格。 检验项目高低温冷热冲击试验前高低温冷热冲击试验后缺陷描述判定结果 外观 外观无变色开裂、变形、 脱胶 外观无变色开裂、变形、 脱胶 无合格 电性能 天线电压驻波比测试合 格 天线电压驻波比测试合 格 无合格 试验/检验判定：□合格□不合格□不作判定 测试：李银珂审核：蒋红英 表单编号：B&T-QR-EN-002版本：B3 第12页共16页 6．4．盐雾测试 试验/试验项目 盐雾测试 检验单号 产品名称/规格 2.4G内置天线（FPC31.2×12.9）-灰 色1.13线-端子，L=110mm 试验数量：5PCS 送检日期:2021-01-11完成日期：2021-01-12 试验/检验设备： 1.HL-60-SS盐雾测试仪 试验/检验条件： 1.盐雾箱内温度为35±2°C；试验室温度22~30°C 2.盐雾沉降速度经24H喷雾后每80cm面积上为1-2ML/h氯化钠浓度为50±10g/L，PH值 为6.5/7.2 试验/检验结果：合格 样品编号评价等级缺陷描述 1合格 2合格 3合格 4合格 5合格 试验/检验判定：□合格□不合格□不作判定 测试：李银珂审核：蒋红英 表单编号：B&T-QR-EN-002版本：B3 第13页共16页 7 、材料成分及有害物质表 表单编号：B&T-QR-EN-002版本：B3 第14页共16页 8 、禁用物质保证 表单编号：B&T-QR-EN-002版本：B3 第15页共16页 产品包装规范 PACKINGCRITERION 产品料号：AG-041333-2166 产品规格：2.4G内置天线（FPC31.2×12.9）-灰色1.13线-端子，L=110mm 一、标签要求 内标签长10cm宽6cm左右外标签长10cm宽6cm左右 需方*************需方************* 供方中山市博安通通信技术有限公司供方中山市博安通通信技术有限公司 物料编码*************物料编码************* 生产单号*****************生产单号***************** 品名规格******** 检验员 **品名规格******** 检验员 ** 数量/单位*****日期****.**.*数量/单位*****日期****.**.* 追溯码********流水号**追溯码********流水号** 二、装箱要求 作业说明： 1．内包装： 产品50PCS/小袋, 200PCS/大袋. 2．外包装： 根据实际情况定数量/箱 注意事项： 1．是否要增设隔板、珍珠棉； 2．标签的贴附，如ROHS等； 表单编号：B&T-QR-EN-002版本：B3 第16页共16页 10 、天线安装示意图 天线1 天线2

Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Frequency[MHz] 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.933 2401.484 2402.417 --- --- 2441 0.954 2440.469 2441.423 --- --- 2480 0.945 2479.472 2480.417 --- --- 2DH5 Ant1 2402 1.293 2401.298 2402.591 --- --- 2441 1.308 2440.277 2441.585 --- --- 2480 1.317 2479.271 2480.588 --- --- 3DH5 Ant1 2402 1.317 2401.277 2402.594 --- --- 2441 1.314 2440.277 2441.591 --- --- 2480 1.317 2479.277 2480.594 --- --- Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.82272 2401.5182 2402.3409 --- --- 2441 0.83422 2440.5119 2441.3462 --- --- 2480 0.84124 2479.5086 2480.3498 --- --- 2DH5 Ant1 2402 1.1867 2401.3403 2402.5270 --- --- 2441 1.1774 2440.3435 2441.5209 --- --- 2480 1.1936 2479.3346 2480.5282 --- --- 3DH5 Ant1 2402 1.1881 2401.3397 2402.5278 --- --- 2441 1.1850 2440.3419 2441.5269 --- --- 2480 1.2016 2479.3277 2480.5293 --- --- Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix C: Maximum conducted output power Test Result Test Mode Antenna Frequency[MHz] Conducted Powert[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 1.19 ≤30 PASS 2441 2.07 ≤30 PASS 2480 1.39 ≤30 PASS 2DH5 Ant1 2402 3.12 ≤20.97 PASS 2441 4.15 ≤20.97 PASS 2480 3.33 ≤20.97 PASS 3DH5 Ant1 2402 3.48 ≤20.97 PASS 2441 4.36 ≤20.97 PASS 2480 3.66 ≤20.97 PASS Appendix D: Carrier frequency separation Test Result TestMode Antenna Frequency[MHz] Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.128 ≥0.954 PASS 2DH5 Ant1 Hop 0.962 ≥0.878 PASS 3DH5 Ant1 Hop 0.986 ≥0.878 PASS Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Appendix E: Time of occupancy Test Result TestMode Antenna Frequency[MHz] BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.880 106.67 0.307 ≤0.4 PASS 2DH5 Ant1 Hop 2.887 106.67 0.308 ≤0.4 PASS 3DH5 Ant1 Hop 2.891 106.67 0.308 ≤0.4 PASS Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Appendix F: Number of hopping channels Test Result TestMode Antenna Frequency[MHz] Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Appendix G: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 0.41 -46.44 ≤-19.59 PASS High 2480 1.10 -46.99 ≤-18.9 PASS Low Hop_2402 0.16 -46.53 ≤-19.84 PASS High Hop_2480 0.40 -46.69 ≤-19.6 PASS 2DH5 Ant1 Low 2402 0.24 -47.02 ≤-19.76 PASS High 2480 0.88 -47.21 ≤-19.12 PASS Low Hop_2402 0.71 -45.74 ≤-19.29 PASS High Hop_2480 -1.15 -46.5 ≤-21.15 PASS 3DH5 Ant1 Low 2402 0.11 -46.73 ≤-19.89 PASS High 2480 0.64 -46.39 ≤-19.36 PASS Low Hop_2402 -2.11 -46.84 ≤-22.11 PASS High Hop_2480 0.56 -45.81 ≤-19.45 PASS Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 2DH5_Ant1_High_2480 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 3DH5_Ant1_Low_2402 3DH5_Ant1_High_2480 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference 0.70 0.70 --- PASS 30~1000 0.70 -41.54 ≤-19.3 PASS 1000~26500 0.70 -50.24 ≤-19.3 PASS 2441 Reference 1.41 1.41 --- PASS 30~1000 1.41 -44.7 ≤-18.59 PASS 1000~26500 1.41 -50.06 ≤-18.59 PASS 2480 Reference 0.97 0.97 --- PASS 30~1000 0.97 -46.41 ≤-19.03 PASS 1000~26500 0.97 -50.21 ≤-19.03 PASS 2DH5 Ant1 2402 Reference 0.77 0.77 --- PASS 30~1000 0.77 -46.84 ≤-19.23 PASS 1000~26500 0.77 -49.8 ≤-19.23 PASS 2441 Reference 1.63 1.63 --- PASS 30~1000 1.63 -47.39 ≤-18.37 PASS 1000~26500 1.63 -50.51 ≤-18.37 PASS 2480 Reference 0.81 0.81 --- PASS 30~1000 0.81 -47.24 ≤-19.19 PASS 1000~26500 0.81 -50.27 ≤-19.19 PASS 3DH5 Ant1 2402 Reference 0.57 0.57 --- PASS 30~1000 0.57 -47.66 ≤-19.43 PASS 1000~26500 0.57 -50.28 ≤-19.43 PASS 2441 Reference 1.59 1.59 --- PASS 30~1000 1.59 -47.63 ≤-18.41 PASS 1000~26500 1.59 -50.55 ≤-18.41 PASS 2480 Reference 0.94 0.94 --- PASS 30~1000 0.94 -44.64 ≤-19.06 PASS 1000~26500 0.94 -50.4 ≤-19.06 PASS Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 3DH5_Ant1_2402_0~Reference 3DH5_Ant1_2402_30~1000 3DH5_Ant1_2402_1000~26500 3DH5_Ant1_2441_0~Reference 3DH5_Ant1_2441_30~1000 3DH5_Ant1_2441_1000~26500 3DH5_Ant1_2480_0~Reference 3DH5_Ant1_2480_30~1000 3DH5_Ant1_2480_1000~26500 Appendix I: Duty Cycle Test Result TestMode Antenna Frequency[ MHz] ON Time [ms] Period [ms] Duty Cycle [%] DH5 Ant1 2402 2.88 3.75 76.80 2441 2.88 3.75 76.80 2480 2.89 3.75 77.07 2DH5 Ant1 2402 0.14 0.15 93.33 2441 2.89 3.75 77.07 2480 2.90 3.76 77.13 3DH5 Ant1 2402 2.89 3.75 77.07 2441 2.89 3.75 77.07 2480 2.89 3.74 77.27 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix J: Emissions in Restricted Bands Test Result Mode: DH5-2402 PK Final Data List NO. Freq. [MHz] PK Reading [dBμV/m] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Polarity Verdict 1 2310 39.57 47.03 7.46 74.00 26.97 Horizonta l PASS 2 2334.26 43 41.80 49.25 7.45 74.00 24.75 Horizonta l PASS 3 2344.51 45 40.91 48.36 7.45 74.00 25.64 Horizonta l PASS 4 2355.56 56 40.80 48.26 7.46 74…

Text truncated - open the document above for the full version.

EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: Motion Space Home Gym Model name: JLP60S-A1、JLP60S-A2、JLP60S-A3、JLP60S-A4、JLP60S-A5 FCC ID: 2A9QN-JLP60S Test Report Number: EFGX22120080-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Phone: +86-0755-829118671 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, Fax: +86-0755-82910749 No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China Page 1 of 25 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 7 2.5 Test equipment utilized 8 2.6 Auxiliary equipment used during test 9 2.7 Test software information: 9 2.8 Test setup- 10 2.9 Test results 12 3 Technical Requirement 13 3.1 Conducted emission AC power port 13 3.2 Duty cycle 14 3.3 20dB Occupied bandwidth 15 3.4 99% Occupied Bandwidth 16 3.5 Carrier frequency separation 17 3.6 Number of hopping frequencies 18 3.7 Time of occupancy (dwell time) 19 3.8 Peak Output Power 20 3.9 Conducted Band-edge & Spurious Emissions 21 3.10 Radiated emissions for transmitter 22 3.11 Hopping sequence requirement 24 4 Test Setup Photos 25 5 External Photo 25 6 Internal Photos 25 7 Appendix 25 Test Report No.: EFGX22120080-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 25 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2023-01-03 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2023-01-03 Albert Xu / Lab Manager Date Eurofins Name / Title Signature Test Report No.: EFGX22120080-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 25 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : Hong Kong M Spacer Limited Address : UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : Hong Kong M Spacer Limited Address : UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK Telephone : ./. Fax : ./. Test Report No.: EFGX22120080-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 25 1.5 Application details Date of receipt of application : 2022-12-02 Date of receipt of test item : 2022-12-02 Date of test : 2022-12-02 to 2022-12-20 Date of issue : 2023-01-03 1.6 Test item Product type : Motion Space Home Gym Model name : JLP60S-A1、JLP60S-A2、JLP60S-A3、JLP60S-A4、 JLP60S-A5 Brand : Motion Space Serial number : ./. Ratings : AC 100-240V~ 50/60Hz Test voltage : 120V Hardware Version : YD.ESP32.1D Software Version : PC260_OS_22d023_20220818 FCC ID : 2A9QN-JLP60S PMN : Motion Space Home Gym Additional information : ./. RadioTechnical data Frequency range : 2402MHz – 2480MHz Radio Tech. : Bluetooth Basic Rate+Enhanced Data Rate Frequency channel : CH0 – CH78, Total 79 channels Modulation : GFSK, π/4 DQPSK, 8DPSK Antenna type : FPC Antenna Antenna gain : 3.21 dBi The above sample(s) and sample information was/were submitted and identified on behalf of the applicant. Eurofins assures objectivity and impartiality of the test, and fulfills the obligation of confidentiality for applicant’s commercial infor- mation and technical documents. 1.7 Test standards Test Standards FCC Part 15 Sub- part C PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. 3: KDB558074 D01 15.247 Meas Guidance v05r02 Test Report No.: EFGX22120080-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. …

Text truncated - open the document above for the full version.
