2A9QN-JLW01JMotion Space Button

Product Manual JLP60S Home Gym 12 Product Introduction Home Gym Device Waist Band Connecting Buckle AnkleBand Folding Handle Folding Switch Wireless SwitchConnecting Buckle Power Switch Packing List Display Screen Universal Wheel AC Power Cord Product Manual Power Socket Control Panel Pole Bracket Speaker Handle 34 Safety Precautions Thank you for choosing the Home Gym. The correct use of the product is the guarantee of safe exercise. To protect the personal safety of you and yourfamily during exercise, please read this manual carefully before using the Home Gym,and strictly follow the precautions in the instructions when using. User-related 1 . Please wear appropriate sports shoes and clothes to use this equipment, and perform appropriate warm- up exercises first. 2 . If you feel any discomfort or any abnormalities in your body during using, please stop exercising immediately and consult a doctor. 3 . Elderly people over 6 5 years of age, pregnant women, pregnant women, breastfeeding mothers, who have undergone surgery within 6 months, sufferfrom heart disease, high blood pressure, asthma and o ther diseases that cannot engage in strenuous exercise, and other medical advice is not recommended. In the case of strenuous exercise, we do not recommend that you use the Home Gym, if you are using it, please stop using it immedi- ately. 4 . Before and after using, it is strictly prohibited to drinkalcoholic beverages and any excitement products prohibited by national laws and regulations. 5 . Fatigue, failure to use the operation method and excessive exercise may cause yo u to be injured. You should make accurate judgments about your physical condition and endurance before exercising, and ensure that the exercise, intensityand duration are appropriate. 6 . When using the Home Gym, please keep children and pets awayfrom the Home Gym to avoid danger. 7 . Minors must use this equipment under the supervision and guidance of their guardians, not alone. 8 . When the operator with long hair uses this machine, it is recommended to coil or tie up the hai r to prevent the hair from entering the gap of the equipment bymistake. 9 . Keep indoors with a certain humidity in winter to avoid static electricity. Static electricity may interfere with the operation of the equipment and even cause damage to the equipment. Chemical fiber fabrics are prone to static electricity. Avoid wearing chemical fiber clothing to use this equipment . Equipment and using environment 1 . The Home Gym is an indoor sports equipment, please do not place it outdoors. 2 . When using the Home Gym, make sure that the Home Gym is in a safe and open space in at least 2 square- meters. 3 . The location of the Home Gym should be far away from water, heat and flammable and explosive materials. 4 . The Home Gym is a special equipment for sports, please do not disassemble it at will, and do not modify it for other purposes at will to avoid potential safety hazards. 5 . Do not splash liquids on the Home Gym, and do not place any foreign objects on the Home Gym. 6 . Do not insert your fingers or any foreign objects into the gap of the Home Gym to avoid danger. 7 . Do not touch the power cord, power socket and power switch with wet hands. 8 . Please do not use the power cord or plug that is damaged or stuck with water. If the power cord of the Home Gym is damaged, please consult the after- sales service person- nel or personnel with relevant profe ssional qualifications to replace it, so as to avoid injury. 9 . After using, please turn off the Home Gym and unplug the Home Gym in time. 1 0 . When cleaning the machine, you must unplug the power cordand wipe it with a clean and soft towel that does not drip. 1 1 . The Home Gym should be placed on a clean, flat, and hard ground. Do not place soft cushions such as blankets or yoga mats under the equipment. 1 2 . The rollers of the Home Gym are only suitable for indoor wooden and tiled floors. Please do not use them on bumpy roads such as asphalt roads in outdoor scenes. 1 3 . The current product is only suitable for home use, commercial scenarios ( such as gyms, etc. ) are not applicable. 1 4 . Please cooperate with the Home Gym' s own power cord for use, do not use other power cords for power supply. 5 6 16. The power plug must be grounded reliably, and try to avoidusing other electrical appliances on the same power supply line. Please do not use the power cord or plug that is damaged or stuck with water. The power cord of the Home Gym is dedicated. If it is damaged, it must be replaced by the manufacturer, service center or personnel with relevant professional qualifications to avoid injury. 17. Do not plug the machine into a socket that is short-circuited to ground or leakag e, to avoid electric shock. Warning According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time infuture you need to dispose of this product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Operating Instructions Preparation before use A. When opening the folded Home Gym, please make sure to emptythe items in theHome Gym placement area and place the Home Gym slowly on the ground. Do not let go directly in the middle of unfolding to avoid pressing your feet. B. The Home Gym needs to be energized for use. Please do not pull out the rope before it is powered on, otherwise the rope will not be retracted, if you accidentally pull the rope out without power…

Text truncated - open the document above for the full version.

Declaration on model difference We, _ Hong Kong M Spacer Limited _ the undersigned hereby declare that the device's schematics ，PCB layout and all other electrical aspects of the device are identical. The only differences are model no. and colors for trading purpose. Product Name: Motion Space Button Models ：JLW01J-A1、JLW01J-A2、JLW01J-A3、JLW01J-A4、LW01J-A5 Name : Wenjie Liu Company: Hong Kong M Spacer Limited

Date: 2023/01/03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Motion Space Button / JLW01J-A1 、JLW01J-A2、JLW01J-A3、JLW01J-A4、LW01J-A5 / 2A9QN-JLW01J) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Signature: Name: wenjie liu Applicant: Hong Kong M Spacer Limited Address: UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK TEL: 18566070767

date: 2023/01/03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Eurofins Electrical Testing Service (Shenzhen) Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: wenjie liu Applicant: Hong Kong M Spacer Limited Address: UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK TEL: 18566070767

REVISIONS RECORD DESCRIPTIONREVISIONDATEREVISED BY GUANGZHOU SHIYUAN ELECTRONIC CO.,LTD. TOLERANCE UNLESS OTHERWISE SPECIFIED N/APART NAMESCALE SIZE SHEET 1:1NOTES: N/A 1/1 CHK'DAPP'D UNITmm MATERIALSEEDRAWING TECHNOLOGY SEEDRAWING DRAWN =CRITICAL DIMDRAWING No. MAT'L SEE NOTES: N/A NewV1.0 luo yanxia 2022/06/07 更新FCC IDV1.1 luo yanxia 2022/07/14 罗艳霞 刘雅静 铭牌贴纸 APButton-G03-R24213-V1.1 无线开关铭牌贴纸-Squatz 60mm 40mm 工艺参数： 1. 材质： 75#哑银龙，背压花底胶，可打印雾膜 2. 尺寸：60*40mm 3. 印刷颜色：来料空白，所有内容都为工厂打印，卷装来料 4. 所有材质及油墨需符合RoHS 5. 高温高湿环境下（60°C，相对湿度60%）无翘角、 起泡、脱落现象，粘贴测试24小时后无以上不良 现象出现。 FCC ID: 2A9QN-JLW01J Made in China Model No.: JLW01J-A1 Voltage: 3V Motion Space Button

Manufacturer: CVTE Company address:192 Kezhu Road, Science Park, Guangzhou, P.R.China

Test Report No.: EFGX22120080-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 20 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: Motion Space Button Model name: JLW01J-A1、JLW01J-A2、JLW01J-A3、JLW01J-A4、LW01J-A5 FCC ID: 2A9QN-JLW01J Test Report Number: EFGX22120080-IE-01-E04 Test Report No.: EFGX22120080-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 20 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 7 2.5 Test equipment utilized 7 2.6 Auxiliary Equipment Used during Test: 7 2.7 Test software information: 7 2.8 Test setup 8 2.9 Test results 10 3 Technical requirement and result 11 3.1 20 dB bandwidth 11 3.2 Radiated emission 13 Test Report No.: EFGX22120080-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 20 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2022-01-03 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2022-01-03 Albert Xu / Lab Manager Date Eurofins Name / Title Signature Test Report No.: EFGX22120080-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 20 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : Hong Kong M Spacer Limited Address : UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : Hong Kong M Spacer Limited Address : UNIT 808,8/F WITTY COMM BLDG 1A-1L TUNG CHOI ST HK Telephone : ./. Fax : ./. Test Report No.: EFGX22120080-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 20 1.5 Application details Date of receipt of application : 2022-12-02 Date of receipt of test item : 2022-12-02 Date of test : 2022-12-02 to 2022-12-20 Date of issue : 2022-01-03 1.6 Test item Product type : Motion Space Button Model name : JLW01J-A1、JLW01J-A2、JLW01J-A3、JLW01J-A4、 LW01J-A5 Brand : Motion Space Serial number : ./. Ratings : 3.0Vdc supplied by a type “CR2032” Battery Test voltage : 3Vdc FCC ID : 2A9QN-JLW01J Hardware Version : YD.R11.1 Software / Firmware Version : tina_banjo-R11_HPS20_fd3ccc6_20220214.img PMN : Motion Space Button Additional information : ./. RadioTechnical data Frequency range : 2405MHz Radio Tech. : 2.4G SRD Frequency channel : 1 Modulation : GFSK Antenna type : PCB antenna Antenna gain : 0 dBi 1.7 Test standards Test Standards FCC Part 15 Subpart C December 16, 2020 PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators RSS-210 Issue 10 December 2019 RSS-210 — Licence-Exempt Radio Apparatus: Category I Equipment Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. Test Report No.: EFGX22120080-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 20 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. or The deviations as specified were ascertained in the cours…

Text truncated - open the document above for the full version.
