2A9QP-BTRCSReeses WIRELESSSPEAKER

WirelessSpeaker Itemno.:FBHSY-BT-RCS UserManual Power: PleasechargeyourBluetoothspeakerfullybeforeitsfirstuse. Tochargethebattery:  UsingaMicroUSBChargingCable(included),inserttheUSBpowercableintothemicroUSB portlocatedonthebackofthespeaker.ConnecttheotherendoftheUSBcordintoapowered USBsourcesuchasacomputer,laptoporUSBACadapter. WhenyourBluetoothspeakerischarging,theindicatorlightwillturnred. OnceyourBluetoothspeakerisfullycharged,theredlightwillturnoff. Bluetooth：  Longpressthe“Power”buttontoturnyourBluetoothspeakeron. MakesuretheBluetoothfunctiononyourdeviceisturnedon. Searchthespeakernamed“ORB-BTS-10R”. Onceyouhaveselectedthepairname,yourdevicewillpairwiththedevice. Onceyourspeakerispaired,atonewillbeheard.  Startplayingmusiconyourdevice.Makesurethatyoukeepyourdevicewithina33feetrange ofyourBluetoothspeaker.  Adjustthevolumeofyourdevicetoacomfortablelevelviashortpressthe“”&“”buttons.  Switchthesongsvialongpressthe“”&“”buttons. Shortpressthe“Power”buttontoplay/pausesong.  Longpressthe“Power”buttontoturnofftheunitwhennotinuse. AUX-IN: ForothercompatiblemusicdevicesoryourMP3/MP4players,usethesuppliedaudioline cabletoconnectfromthedevice’s“LineOut”tothe“AuxIn”ofthisdevices.Speakerwill turnto“AUX“stateautomaticallywheninserttheaudiocable. Whenusinganexternaldevice,allfunctionswillbecontrolledbytheexternaldevice exceptthe“Power/Play/Pause”function. Specification:  Speakeroutput:3W*1  Wirelessdistance:32.8ft BatteryCapacity:500mAh FrequencyResponse:160Hz-18KHz Caution: Thisisnotatoy.Pleasekeepawayfromchildren. Pleasekeepawayfromwater/heat.  LowpowermaycausepoorconnectionevennoworkingofBluetooth. Donotoverchargethebattery.  Batterypackshallnotbeexposedtoexcessiveheatsuchassunshine,fireorthelike. FCCID:2A9QP-BTRCS FCCStatement 1.ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo conditions: (1)Thisdevicemaynotcauseharmfulinterference,and(2)Thisdevicemustacceptany interferencereceived,includinginterferencethatmaycauseundesiredoperation. 2.Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould voidtheuser’sauthoritytooperatetheequipment. ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice, pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing measures: —Reorientorrelocatethereceivingantenna. —Increasetheseparationbetweentheequipmentandreceiver. —Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris connected. —Consultthedealeroranexperiencedradio/TVtechnicianforhelp. FCCRadiationExposureStatement: ThisequipmentcomplieswithFCCradiationexposurerequirement. ThedevicecanbeusedinportableexposureconditionwithoutRFstriction.

ORBIT INNOVATIONS LLC 148 West 37th Street, 14th Floor, New York, 10018, United States Tel: 18825861614 Email: [email protected] Date: 03/07/2023 To: FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, ORBIT INNOVATIONS LLC hereby declare that˖ Product Name: ġ Reese’s WIRELESS SPEAKER Model No.: FBHSY-BT-RCS FCC ID: 2A9QP-BTRCS For BT Mode: BLE 1M/2M are disable by software For Below are activated: Bluetooth EDR;ʋ/4-DQPSK),BDR(GFSK) ,EDR(8DPSK) Except for the manufacturer, the end user does not have any capability to modify/change the RF parameters. We acknowledge that it is the manufacturer’s responsibility to provide the radio configurations to ensure compliance with Commission’s rules. Sincerely Yours, Signature: Printed Name: Echo Choi Tiltle: Sales meEchoChoi Reeses WIRELESS SPEAKER

ORBIT INNOVATIONS LLC 148 West 37th Street, 14th Floor, New York, 10018, United States Tel: 18825861614 Email: [email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 03/07/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: 2A9QP-BTRCS ORBIT INNOVATIONS LLC certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Contact Person: Echo Choi Title: Sales Company Name: ORBIT INNOVATIONS LLC Address: 148 West 37th Street, 14th Floor, New York, 10018, United States

ORBIT INNOVATIONS LLC 148 West 37th Street, 14th Floor, New York, 10018, United States Tel: 18825861614 Email: [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 03/07/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2A9QP-BTRCS ORBIT INNOVATIONS LLC certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Contact Person: Echo Choi Title: Sales Company Name: ORBIT INNOVATIONS LLC Address: 148 West 37th Street, 14th Floor, New York, 10018, United States

U.S. AGENT LETTER OF ATTESTATION Date: 2023-03-07 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2A9QP-BTRCS ORBIT INNOVATIONS LLC certifies that, as of the date of the filing of the application, ORBIT INNOVATIONS LLC is our designated U.S. agent for service of process for the above referenced FCC ID. ORBIT INNOVATIONS LLC accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. ORBIT INNOVATIONS LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent and Applicant Information: Name: ORBIT INNOVATIONS LLC Address: 148 West 37th Street, 14th Floor, New York, 10018, United States FRN: 0033184391 Tel.: 18825861614 Email: [email protected] Signed by (printed name): Echo Choi Signature:

Block Diagram Power channel Audio signal Control signal Bluetooth Charging Unit Lithium Battery Power key Status LED blue/red Amplifier Oscillator 26MHZ Antenna Speaker AB5607E 2402-2480MHz DC 3.7V

ORBIT INNOVATIONS LLC 148 West 37th Street, 14th Floor, New York, 10018, United States Tel: 18825861614 Email: [email protected] FCC Authorization Date: 03/07/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, ORBIT INNOVATIONS LLC the undersigned, hereby authorize China Certification ICT Co., Ltd (Dongguan) Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Printed Name: Echo Choi Title: Sales QA-FR-170-B

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Antenna

Circuit Description Battery (DC 3.7V) provides energy for the Bluetooth chip (AB5607E); Crystal oscillator (26MHz) provides the clock signal for the Bluetooth chip. Bluetooth signals get through a matching circuit, and then transmitted to the space through the antenna (2402-2480MHz). When the product is connected, the product can in two-way communication with other Bluetooth Devices, and then the device’s Bluetooth module sends Bluetooth signals into space, the product receives the Bluetooth signal through an antenna, transmission to the Bluetooth chip via matching circuit. Modulation Technique: GFSK, π/4-DQPSK, 8DPSK

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230206394-00 Page 60 of 60 5. RF EXPOSURE EVALUATION 5.1 Applicable Standard According to§15.247(i) and §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB447498 D01 General RF Exposure Guidance v06: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ꞏ [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 5.2 Measurement Result The max conducted power including tune-up tolerance is 5.0 dBm (3.16 mW), which was declared by the manufacturer. [(max. power of channel, mW)/(min. test separation distance, mm)][√f(GHz)] =3.16/5*(√2.480) = 1< 3.0 Result: Compliant. The stand-alone SAR test is not necessary. ===== END OF REPORT =====

A B C D 1 2 3 4 5 6 D C B A C1 105P C2 105P Y1 26M S1 S2 S3 LED2 1 SD 2 BYPASS 3 IN+ 4 IN- 8 OUT2 7 GND 6 VDD 5 OUT1 U4 IC-HAA8002D-SOP8 R3 47K C6 225P C7 104P R5 10K R6 33K C8 106P R2 5.1K R7 1K C4 105P LED1 R 1 CHRG 2 GND 5 PROG 4 VCC 3 BAT U3 IC-4054 VCC D- D+ ID GND USB1 J2 J1 BT_ANT OSCI OSCO PB4/USBDM/SDDAT PB3/USBDP PA6/SDCLK PA5/SDCMD PF2/MICL/PA7/SDDAT PF3/DACR DACL GND PE7/AUXR2/FMANT VUSB VDDIO VBAT PWRKEY U1 IC-AB5607E_SOP16 ANT B E C Q1 8050 R4 10K 1 2 3 4 J3 C3 105P VBAT DACL VBAT 5V 5V VBAT OSCI OSCO K1 DP LED MUTE DET DACL AUX PWRKEY VBAT VDDIO K1 DP PWRKEY OSCI OSCO DP VBAT 5V MUTE GND DET AUX LED VDDIO SP- SP-

Inverted F Antenna Specification S ummary ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical Center 2400MHz 2450MHz 2500MHz 2400MHz 2450MHz 2500MHz Frequency -1.73dBi -0.84dBi -0.68dBi -6.15dBi -3.70dBi -2.32dBi MAX. Gain-0.68dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 12.3mm Manufacture Shenzhe R-watson Technology Co.,LTD A ntenna Photo & Length Add:3F,Building C,ZhongWong Industral,Jiuwei,Xixiang Town,Baoan,Shen z hen,Guangdong Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dBi) Frequency (MHz) MaxMinAvg 2400-1.73178-30.0815-8.48713 2450-0.845801-38.5605-7.88012 2500-0.685586-24.0318-6.79139 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dBi) Frequency (MHz) MaxMinAvg 2400-6.1530-24.1420-13.0295 2450-3.7054-26.5836-10.6700 2500-2.32122-30.4301-9.70536 ANT Test Labs：Attestation of Global Compliance Co., Ltd.

TEST REPORT Applicant: ORBIT INNOVATIONS LLC Address: 148 West 37th Street, 14th Floor, New York NY 10018 FCC ID: 2A9QP-BTRCS Product Name: Reeses WIRELESS SPEAKER Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230206394-00 Date Of Issue: 2023/3/8 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230206394-00 Page 2 of 60 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230206394-00 Page 3 of 60 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.1 EUT Operation Condition: ............................................................................................................................. 7 1.2.2 Support Equipment List and Details .............................................................................................................. 7 1.2.3 Support Cable List and Details ...................................................................................................................... 7 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 7 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 9 2. SUMMARY OF TEST RESULTS .......................................................................................... 10 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 11 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 11 3.1.1 Applicable Standard ..................................................................................................................................... 11 3.1.2 EUT Setup.................................................................................................................................................... 12 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 13 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 14 3.2.1 Applicable Standard ..................................................................................................................................... 14 3.2.2 EUT Setup.................................................................................................................................................... 14 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 15 3.2.4 Test Procedure ............................................................................................................................................. 15 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.3 20 DB EMISSION BANDWIDTH ........................................................................................................... 16 3.3.1 Applicable Standard .............…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View Radiated Emission Below 1GHz View Radiated Emission Above 1GHz View
