2A9XL-MWFD05ASmart Finder with Bluetooth

European Union-Disposal Information The symbol above means that according to local laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities. The separate collection and recycling of your product and/or its battery at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. Regulatory Safety Information Instructions for device button 1. Power on After installing the battery, long press the button for five seconds, the device will beep, the light will flash three times, and the device will be turned on. 2. Device status confirmation Double-click the device button, the device will beep, and the light will flash three times, indicating that the device is working. If the device does not ring, the device is off. Long press the button for five seconds to turn it on. 3. The device enters the pairing state again After removing the device in the app, the device will beep and the light will flash six times, it will not shut down and will be in the pairing mode. If there is no re-pairing within 10 minutes, the device will leave the pairing state. If you want to pair a device at this time, you need to click the device button once, the device will beep, and the light will flash once. At this time, the device enters the pairing state and can be paired with the app again. Product overview Power button LED Hanging hole Key chain Apple system Android system 1. Turn on the device Press and hold the button for 5 seconds, the device will beep and turn on. 2. Pair the device · Open the Find My app. · Hold the device close to your iPhone, tap the Items tab, tap + and then Add Other Item. · Tap Connect. · Type a name for your device, select an emoji. · Tap Agree to acknowledge that this item will be linked to your Apple ID. · Tap Finish. 3. Enable Lost Mode · Open the Find My app, tap the Items tab, then tap your item. · Under Lost Mode, tap Enable. · Read the instructions, tap Continue and enter a phone number or email address. · Confirm the information, customize the lost message, and tap Activate to complete the setup. 4. Remove the device · Open the Find My app, tap the Items tab, then tap your item. · Tap Remove Item and then tap Remove to complete the operation. Note: After removing the device in the app, the device will beep and the light will flash six times, it will not shut down and will be in the pairing mode. If there is no re-pairing within 10 minutes, the device will leave the pairing state, and the device and app cannot be paired at this time. If you need to pair the device, you need to click the device button once, the device will ring and the light will flash once. At this point, the device enters the pairing state and can be re-paired with the app. WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the oesophagus. If you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poison Information Centre for fast expert advice. KEEP BATTERIES OUT OF REACH OF CHILDREN • • • • • • Keep in original package until ready to use Call a local poison control center for treatment information. Australia: 13 11 26 Canada: 1-800-268-9017(Ontario), 1-800-567-8911(BC), 1-800-463-5060 (Quebec) US: 800-498-8666.Verify suitable. emergency call numbers for your country. Do not use if the compartment is not secure. Dispose of used button batteries promptly and safely. Flat batteries can still be dangerous. Risk of fire and burns. Do not recharge, disassemble, heat (-20°C +70°C)or incinerate. Rated voltage 3V /定格电压 3V Rated current ~175 mAh / 定格电流 ~175 mAh Safety Statement 注意！ 依据 低功率电波辐射性电机管理办法 80 第十二条 经型式认证合格之低功率射频电机，非经许可，公司，商号 或使用者均不得擅自变 更频率、加大功率或变更原设计之特性及功能 第十四条 任功率射频电机之使用不得影管飞航安全及干扰合法通信;经发现 有干扰现象时，应立即停 用，并改善至无干摄时方得继续使用。 前项合法通信，指依电信法规定作业之无线电通信 低功率射频电机须忍受合法通信或工业、科学及医疗用电波辐射性 电机设备之干扰。 Article 12 Without permission, any company, firm or user shall not alter the frequency, increase the power, or change the characteristics and functions of the original design of the certified lower power frequency electric machinery. Article 14 The application of low power frequency electric machineries shall not affect the navigation safety nor interfere a legal communication, if an interference is found, the service will be suspended until improvement is made and the interference no longer exists. The foregoing legal communication refers to the wireless telecommunication operated according to the telecommunications laws and regulations. The low power frequency electric machinery should be able to tolerate the interference of the electric wave radiation electric machineries and equipment for legal communications or industrial and scientific applications. 2 Sign up Open Findthing App, and sign up. Note: Please do not pair the device in the phone's Bluetooth list, otherwise, the device will not be connected to the App. 3 Turn on Bluetooth and Location service 4 Pair the device Tap the "+" button in Findthing App, and pair the device. 5 Ring the device * More introductions and FAQ please refer to the 'help' section in Findthing App. 6 Attach the device to the things you care about 1 Download Findthing App Search for "Findthing" on the Google play, or scan the below QR code to download the Findthing App. FAQ: 1. When can the device be located? When an item is separated from its owner for a period of time, it can be found by other Apple devices that are part of the Find My network, and the owner can start to get the location of the device. 3.How is my privacy protected? Only you can see where your item is. Your location data and history are never stored on the item itself. Devices that relay the location of your item also stay anonymous, and tha…

Text truncated - open the document above for the full version.

1/1 AOGES CO., LIMITED US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: AOGES CO., LIMITED FRN: 0033947847 Contact Name: XIAOYAN LAl Address: 1624 Market St, Ste 226, #30327 Denver CO, 80202 USA Telephone No: +1 303 623 1940 Email: [email protected] Applicant: Company name: Microwoo Electronic Technology Co., Ltd. Product Description: Smart Finder with Bluetooth Grantee code: 2A9XL FCC ID: 2A9XL-MWFD05A Contact Name: Linda Kang Address: Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Telephone No: +86-0755-29100219 Email: [email protected] [Microwoo Electronic Technology Co., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [AOGES CO., LIMITED] is our designated US agent for service of process for the above referenced FCC ID. [Microwoo Electronic Technology Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [AOGES CO., LIMITED] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/09/15 Applicant’s Name: Microwoo Electronic Technology Co., Ltd. US Agent’s Name: AOGES CO., LIMITED Title: Sales Title: CEO Signature Signature FRN: 0033248683

C5266091_X24_Ed.2 1/1 Microwoo Electronic Technology Co., Ltd. “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Microwoo Electronic Technology Co., Ltd. Grantee code: 2A9XL FCC ID: 2A9XL-MWFD05A Contact Name: Linda Kang Address: Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Telephone No: +86-0755-29100219 Fax No: +86-0755-29100219 Email: [email protected] i. [Microwoo Electronic Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Microwoo Electronic Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Microwoo Electronic Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2023/09/15 Applicant’s Name: Microwoo Electronic Technology Co., Ltd. Title: Sales Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Microwoo Electronic Technology Co., Ltd. Product Similarity Declaration Product name: Smart Finder Model name: MWFD05A, MWFD06A, MWFD07A FCC ID: 2A9XL-MWFD05A We (Microwoo Electronic Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including materials, etc.,), the only difference is the model name, shell pattern and shape. Demonstrate the detail (descriptions and pictures) as to the difference list above. Model Name Front Back MWFD05A MWFD06A Microwoo Electronic Technology Co., Ltd. MWFD07A Signature: Name: Linda Kang Title: Sales Place, date: HK, 2023.09.22

C5266091_X8_Ed.1 1/1 Microwoo Electronic Technology Co., Ltd. Letter of Authorization Company: Microwoo Electronic Technology Co., Ltd. Address: Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Product Name: Smart Finder Model Number: MWFD05A, MWFD06A, MWFD07A FCC Identifier: 2A9XL-MWFD05A We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Linda Kang Date: 2023/09/15 Title: Sales Signature of applicant:

C5266091_X10_Ed.2 1/1 Microwoo Electronic Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023/09/15 Subject: Request for Confidentiality FCC ID: 2A9XL-MWFD05A To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: Linda Kang Title: Sales

Page 1 of 6 Report No.: STS2307332 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: MWFD05A Photo 1 Photo 2 Page 2 of 6 Report No.: STS2307332 Photo 3 Photo 4 Page 3 of 6 Report No.: STS2307332 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2307332 Model: MWFD06A Photo 7 Photo 8 Page 5 of 6 Report No.: STS2307332 Model: MWFD07A Photo 9 Photo 10 Page 6 of 6 Report No.: STS2307332 Photo 11 Photo 12

Label Size:5*15mm The label is printed on the shell FCC ID: 2A9XL-MWFD05A .

Page 1 of 4 Report No.: STS2307332 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1( Model: MWFD05A) Photo 2 ( Model: MWFD06A) BT Antenna BT Antenna Page 2 of 4 Report No.: STS2307332 Photo 3 ( Model: MWFD07A) Photo 4 BT Antenna Page 3 of 4 Report No.: STS2307332 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2307332 Photo 7 Photo 8

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Radio Test Report Report No.:STS2307332H02 Issued for Microwoo Electronic Technology Co., Ltd. Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Product Name: Smart Finder Brand Name: N/A Model Name: MWFD05A Series Model(s): MWFD06A, MWFD07A FCC ID: 2A9XL-MWFD05A Test Standards: FCC 47CFR §2.1093 Page 2 of 9 Report No.: STS2307332H01 TEST REPORT Applicant’s Name ................. : Microwoo Electronic Technology Co., Ltd. Address ................................. : Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Manufacturer's Name .......... : Microwoo Electronic Technology Co., Ltd. Address ................................. : NO.13, Hengrui 2nd Road, Tangxiayong Community, Yan Luo Street, Baoan District, Shenzhen, China. Product Description Product Name ........................ : Smart Finder Brand Name........................... : N/A Model Name .......................... : MWFD05A Series Model(s) ...................... : MWFD06A, MWFD07A Test Standards ..................... : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 26 July 2023 Date (s) of performance of tests ............. : 26 July 2023 ~ 11 Sept. 2023 Date of Issue ........................................... : 11 Sept. 2023 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Sean she) Authorized Signatory : (Chris Chen) Page 3 of 9 Report No.: STS2307332H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2307332H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 11 Sept. 2023 STS2307332H02 ALL Initial Issue Page 5 of 9 Report No.: STS2307332H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Finder Brand Name N/A Model Name MWFD05A Series Model(s) MWFD06A, MWFD07A Model Difference Only the appearance and model name are different Product Description The EUT is Smart Finder Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Antenna gain: 2.2dBi Antenna Designation: Inverted F Rating Input: By battery (DC 3V, 50mAh) Hardware Version 1.0.0 Software Version 1.3.9 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2307332H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2307332H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2307332H01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conju…

Text truncated - open the document above for the full version.

Antenna specification Model: DN0007 Brand: TEXAS Manufacturer: TEXAS INSTRUMENTS 1. Antenna describe: Antenna Model: DN0007 Antenna plate: 2.4 GHz Inverted F Antenna Frequency range: 2400-2500MHz Antenna gain: 2.2dBi Connector type: PCB 2. Radiation pattern Total Peak Gain: 2.2dBi Frequency Efficiency(%) Peak GAIN （dBi） 2.400 40.26 1.9 dBi 2450 41.46 2.2dBi 2500 39.74 1.7dBi 2575 38.36 1.4dBi 3.Antenna structure drawing

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Radio Test Report Report No.:STS2307332W02 Issued for Microwoo Electronic Technology Co., Ltd. Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Product Name: Smart Finder Brand Name: N/A Model Name: MWFD05A Series Model(s): MWFD06A, MWFD07A FCC ID: 2A9XL-MWFD05A Test Standards: FCC Part15.247 Page 2 of 72 Report No.: STS2307332W02 TEST REPORT Applicant’s Name ..................: Microwoo Electronic Technology Co., Ltd. Address ..................................: Workshop 60, 3/F, Block A, East Sun Industrial Centre No.16 Shing Yip Street, KL, HK, China. Manufacturer's Name ...........: Microwoo Electronic Technology Co., Ltd. Address ..................................: NO.13, Hengrui 2nd Road, Tangxiayong Community, Yan Luo Street, Baoan District, Shenzhen, China. Product Description Product Name .........................: Smart Finder Brand Name ...........................: N/A Model Name ...........................:... : MWFD05A Series Model(s) .....................: MWFD06A, MWFD07A Test Standards ......................: FCC Part15.247 Test Procedure .......................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 26 July 2023 Date (s) of performance of tests ............. : 26 July 2023 ~ 11 Sept. 2023 Date of Issue ........................................... : 11 Sept. 2023 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Sean she) Authorized Signatory : (Chris Chen) Page 3 of 72 Report No.: STS2307332W02 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS 21 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 34 5.1 LIMIT 34 5.2 TEST PROCEDURE 34 5.3 TEST SETUP 34 5.4 EUT OPERATION CONDITIONS 34 5.5 TEST RESULTS 34 6. POWER SPECTRAL DENSITY TEST 35 6.1 LIMIT 35 6.2 TEST PROCEDURE 35 6.3 TEST SETUP 35 Page 4 of 72 Report No.: STS2307332W02 Table of Contents 6.4 EUT OPERATION CONDITIONS 35 6.5 TEST RESULTS 35 7. BANDWIDTH TEST 36 7.1 LIMIT 36 7.2 TEST PROCEDURE 36 7.3 TEST SETUP 36 7.4 EUT OPERATION CONDITIONS 36 7.5 TEST RESULTS 36 8. PEAK OUTPUT POWER TEST 37 8.1 LIMIT 37 8.2 TEST PROCEDURE 37 8.3 TEST SETUP 38 8.4 EUT OPERATION CONDITIONS 38 8.5 TEST RESULTS 38 9. ANTENNA REQUIREMENT 39 9.1 STANDARD REQUIREMENT 39 9.2 EUT ANTENNA 39 APPENDIX 1-TEST DATA 40 1. DUTY CYCLE 40 2. MAXIMUM AVERAGE CONDUCTED OUTPUT POWER 44 3. MAXIMUM PEAK CONDUCTED OUTPUT POWER 48 4. -6DB BANDWIDTH 52 5. MAXIMUM POWER SPECTRAL DENSITY LEVEL 56 6. BAND EDGE 60 7. CONDUCTED RF SPURIOUS EMISSION 65 APPENDIX 2- EUT TEST PHOTO 72 Page 5 of 72 Report No.: STS2307332W02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 11 Sept. 2023 STS2307332W02 ALL Initial Issue Page 6 of 72 Report No.: STS2307332W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 72 Report No.: STS2307332W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated>6G ±5.22dB 7 Conducted Emission (9KHz-150KHz) ±2.14dB 8 Conducted Emission (150KHz-30MHz) ±2.54dB 9 Power Spectral Density, Conducted ±1.25dB 10 Occupied Channel Bandwidth ±3.5% Page 8 of 72 Report No.: STS2307332W02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Find…

Text truncated - open the document above for the full version.

Page 1 of 2FCC ID: 2A9XL-MWFD05A DTS Setup photo Model name: MWFD05A DTS radiation L DTS radiation H
