2AA2O-FSNARFugoo Bluetooth Speaker Remote Control

Remote Control User Manual model FSNAR page 1 1/16/2014 Fugoo Bluetooth Speaker Remote Control User Manual model FSNAR Contents In the box 2 Using the remote control 2 Remote control buttons 2 First-time setup: pairing the remote with your Fugoo Bluetooth Speaker 2 Using the remote control with your Fugoo Bluetooth Speaker 2 Using another Fugoo remote with your Fugoo Bluetooth Speaker 3 Replacing the battery 3 Customer support 4 Legal notices 4 Remote Control User Manual model FSNAR page 2 1/16/2014 In the box • Fugoo remote control (included with some models) • Remote wrist strap (included with some models) Using the remote control Remote control buttons # Description 1 Play/Pause 2 Next track 3 Previous track 4 Volume up 5 Volume down 6 Action First-time setup: pairing the remote with your Fugoo Bluetooth Speaker The remote for the Fugoo Bluetooth Speaker works over a Bluetooth wireless link. Follow these instructions to pair the remote with the speaker before use. You'll probably only need to pair the remote with the speaker the first time you use it. 1. Turn on your speaker. 2. Reconnect the speaker to your phone or to any other Bluetooth device it's been previously connected to. You can typically reconnect simply by having both the speaker and the other device on, and then by placing them within 30 feet of each other. 3. Hold or place the remote within two inches of the speaker. 4. Press any button on the remote. You may hear a voice prompt confirm that pairing has been successful. Using the remote with your Fugoo Bluetooth Speaker  Once the remote and the speaker have been paired, press the + (volume up) button once to re-establish the connection between the remote and the speaker. You may hear a voice prompt confirm that pairing has been successful.  The buttons on the remote work the same way as the corresponding buttons on the speaker itself, except that the remote also has Next Track and Previous Track buttons.  See the Fugoo Bluetooth Speaker User Manual for detailed descriptions of how to use the various buttons to control streaming music and speakerphone calls. Remote Control User Manual model FSNAR page 3 1/16/2014 Using another Fugoo remote with your Fugoo Bluetooth Speaker If your speaker has been previously paired with a Fugoo remote, follow these steps to clear the speaker's pairing list before can using another Fugoo remote with the speaker. 1. Turn on your speaker. 2. P ress and hold the Bluetooth button for 10 seconds to clear the pairing list. 3. Reconnect the speaker to your phone or to any other Bluetooth device it's been previously connected to. You can typically reconnect simply by having both the speaker and the other device on, and then by placing them within 30 feet of each other. 4. Hold or place the remote within two inches of the speaker. 5. Press any button on the remote. You may hear a voice prompt confirm that pairing has been successful. Replacing the battery The remote for the Fugoo Bluetooth Speaker operates from a readily-available 3 volt CR2032 lithium button cell battery. It may last as long as three years, so will rarely need replacing. 1. Use a small Phillips screwdriver to loosen the captive screw on the underside of the remote. Turn the screw until it releases and pops upward. Don't try to remove the screw, which is held in place by a spring. 2. Insert the edge of a small coin, or a CR2032 battery, into the slot in the battery cover (beneath the lanyard hole), and gently pry the cover open. 3. Turn the battery cover over, and pop the old battery out with a thumbnail or a small flat-blade screwdriver. 4. Orient the new battery so that its ' +' sign is facing the inside of the battery cover (also marked with a " +". sign). 5. Insert the battery under the two plastic tabs next to the edge of the battery cover. 6. Press the new battery firmly to seat it against the remaining plastic tab. 7. Insert the battery cover back into the metal frame of the remote control, and press it firmly until it seats securely, and its edge is flush with the body of the remote. 8. Re-tighten the screw in the battery cover, just enough to seat it. Remote Control User Manual model FSNAR page 4 1/16/2014 Legal notices FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC Statement This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not …

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Project No.: 1312C269 Page 2 of 7

Neutron Engineering Inc. Project No.: 1312C269 Page 3 of 7 Neutron Engineering Inc. Project No.: 1312C269 Page 4 of 7 Neutron Engineering Inc. Project No.: 1312C269 Page 5 of 7 Neutron Engineering Inc. Project No.: 1312C269 Page 6 of 7 Neutron Engineering Inc. Project No.: 1312C269 Page 7 of 7

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: 2AA2O-FSNAR Project No. : 1312C269 Equipment : Fugoo Bluetooth Speaker Remote Model : FSNAR Applicant : Fugoo Corporation Address : 8001 Irvine Center Drive, Suite 250, Irvine, CA, USA 92618 According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. GENERAL CONCULUSION: Table for Filed Antenna: Ant. Manufacturer Model Name Antenna TypeConnector Gain (dBi) 1 N/A N/A Integral N/A 2.23 Maximum measured transmitter power: Output Power (dBm) Out Power (mW)Limit (mW) 4.03 2.5 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output power of this EUT is 4.03dBm (2.5mW), less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 1 of 51 FCC&IC Radio Test Report FCC ID: 2AA2O-FSNAR IC: 11419A-FSNAR This report concerns (check one): Original Grant Class II Change Issued Date : Jan. 13, 2014 Project No. : 1312C269 Equipment : Fugoo Bluetooth Speaker Remote Control Model Name : FSNAR Applicant : Fugoo Corporation Address : 8001 Irvine Center Drive, Suite 250, Irvine, CA, USA 92618 Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 26, 2013 Date of Test: Dec. 26, 2013~ Jan. 09, 2014 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 2 of 51 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 3 of 51 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 TEST PROCEDURE 14 4.1.3 DEVIATION FROM TEST STANDARD 14 4.1.4 TEST SETUP 15 4.1.5 EUT OPERATING CONDITIONS 15 4.1.6 EUT TEST CONDITIONS 15 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 19 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 5 . BANDWIDTH TEST 34 5.1 APPLIED PROCEDURES / LIMIT 34 5.1.1 TEST PROCEDURE 34 5.1.2 DEVIATION FROM STANDARD 34 5.1.3 TEST SETUP 34 5.1.4 EUT OPERATION CONDITIONS 34 5.1.5 EUT TEST CONDITIONS 34 5.1.6 TEST RESULTS 35 6 . MAXIMUM OUTPUT POWER TEST 37 Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 4 of 51 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 37 6.1.1 TEST PROCEDURE 37 6.1.2 DEVIATION FROM STANDARD 37 6.1.3 TEST SETUP 37 6.1.4 EUT OPERATION CONDITIONS 37 6.1.5 EUT TEST CONDITIONS 37 6.1.6 TEST RESULTS 38 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 39 7.1 APPLIED PROCEDURES / LIMIT 39 7.1.1 TEST PROCEDURE 39 7.1.2 DEVIATION FROM STANDARD 39 7.1.3 TEST SETUP 39 7.1.4 EUT OPERATION CONDITIONS 39 7.1.5 EUT OPERATION CONDITIONS 39 7.1.6 TEST RESULTS 39 8 . POWER SPECTRAL DENSITY TEST 44 8.1 APPLIED PROCEDURES / LIMIT 44 8.1.1 TEST PROCEDURE 44 8.1.2 DEVIATION FROM STANDARD 44 8.1.3 TEST SETUP 44 8.1.4 EUT OPERATION CONDITIONS 44 8.1.5 EUT TEST CONDITIONS 44 8.1.6 TEST RESULTS 45 9 . MEASUREMENT INSTRUMENTS LIST 47 10 . EUT TEST PHOTO 49 Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 5 of 51 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FICP-2-1312C269 Original Issue. Jan. 13, 2014 Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 6 of 51 1. CERTIFICATION Equipment : Fugoo Bluetooth Speaker Remote Control Brand Name : FUGOO Model Name : FSNAR Applicant : Fugoo Corporation Manufacturer : Fugoo Corporation Address : 8001 Irvine Center Drive, Suite 250, Irvine, CA, USA 92618 Date of Test : Dec. 26, 2013~ Jan. 09, 2014 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 Canada RSS-210:2010 RSS-GEN Issue 3, Dec 2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FICP-2-1312C269) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FICP-2-1312C269 Page 7 of 51 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Canada RSS-210:2010; RSS-GEN Issue 3, Dec 2010 Standard(s) Section Test Item Judgment Remark 15.207 RSS-GEN 7.2.2 Conducted Emission PASS N/A 15.247(d) RSS-210 Annex 8 (A8.5) Antenna conducted Spurious Emission PASS 15.247(a)(2) RSS-210 Annex 8 (A8…
