2AA3SSPEAKER-ABluetooth Speaker

speaker-AUserManual Thanks for choosing our mini bluetooth speaker, for you to use our product, we attached the using instructions, you can know about the introduction, using method from it, pls carefully read the using instructions before using. 1. Notes For the user to use the speaker correctly, to make sure the speaker work well, pls carefully read and follow: A. Please do not throw, avoiding product damage for droping. B. Do not touch benzene, thinner or other chemicals C. Do not near to strong magnetic field, electric field D. Please avoid direct sunlight or heating appliances E. Do not disassemble, repair, alteration F. To avoid danger, do not use the player and headphones when Cycling, driving a car and motorcycle. G. Do not listen to a larger volume, so as to avoid adverse effects on hearing H. Packaging waste, batteries, used electronic products, please handle properly by sorting 2. Features Bluetooth Audio: Bluetooth 3.0+EDR, the biggest transmittion distance is 10m. Eye Lamp: Eye lamp with touch control Break-point Memory: Automatic memory last exit tracks, volume Built-in Battery: Built-in rechargeable lithium battery, environmental protection, energy saving, practical 3. How to play music The machine automatically detects identify external boot device, boot into Bluetooth mode 4. Desk lamp function:This product has eye lamp function, touch a power switch symbol, lamp will turn on, and then touch a power switch symbol table lamp will turn off. 5. Product keys, jack functional definition A. [ON / OFF]: power switch; ON to ON, OFF is off. B. [USB]: power charging jack, you can use this machine distribution dedicated USB power cable connected to the computer's USB or charger interface for charging. 6. Indicator Description A. Work light: boot two alternately flashing blue light indicates that the machine is working properly, and looking around the paired device. When the two LEDs flash simultaneously and both appear off, it means the machine has been successfully connected to the associated paired device. B. Charge indicator: Plug in the USB cable connecting the machine buttons will appear around a red indicator light, said it is charging, the charging period of time when the red light turns blue lights indicate charging has been completed. 7. Bluetooth connection method A, the boot will issue a "Gululu ..." bang, two blue LED flash alternately. B, open mobile devices (cell phones, computers, etc.) of the Bluetooth function, search for Bluetooth devices C, manual clicks, the device automatically paired, connection, the connection is successful will issue a "grunt" sound, while two alternately flashing blue lights by switching to synchronous flashing. D, have been successfully paired devices, open the opportunity to automatically connect to the next. Note: Enter Bluetooth mode within 10 seconds, the Bluetooth device will automatically find and pair connection 10 seconds after going through the manual connection. 8. Charge Method Plug the power cord into the unit's [USB] jack and the other end of the USB into the computer's USB port, or connect a standard 5V 500mA charging interface, the charge of "Red Light", full of "Blue Light". The machine built overcharge protection circuit can be connected to a computer or charger prolonged use, approximately three hours can be filled with battery; battery life every time the volume due to the use of time varies. 9. Low battery When the battery low occurs, the system will automatically shut down, then please charge; if the machine is not used for a long time, at least once a month charge, you can protect the battery to extend battery life. 10. Troubleshooting 1, Q: boot automatically shut down? A: battery, please charge, recommended charging two hours before use. 2, Q: Play flash blue lights have been shut down or restart automatically after? A: battery, please charge, recommended charging two hours before use. 3, Q: can not be charged? A: Please use the unit charge distribution line, and make sure the USB port is connected voltage is normal. 4, Q: charging red light does not light or red light is dark? A: Normal. If the battery is fully charged or voltage block is full, the charging red light will not light or very dark, in short, the more battery power is low, the brighter red when charging. 5, Q: No sound speakers? A: determine the playing status, and adjusted to the appropriate volume. 6, Q: Bluetooth will not automatically connect? A: 1, only paired devices will connect automatically. 2, if the speaker only after 10 seconds into the open Bluetooth Bluetooth devices, the speaker does not connect automatically. 7, Q: Bluetooth no sound? A: 1, make sure that Bluetooth is connected successfully. 2, the volume of the Bluetooth device is turned on. 8, Q: No function or function keys wrong? A: powercycle. 11. Technical Specifications Output power: 3W * 2 Operating voltage: 3.7V Frequency Response: 100Hz-18KHz Ratio:≥80dB Distortion: <0.5% Audio input: Bluetooth Speaker Unit: 40mm, double magnetism, 16 core, 4Ω Input Power: Built-in polymer rechargeable battery 1000mAh 3.7V or external DC 5V Adjusting: buttons adjust Weight: about 700g 12. Packing Accessories MusicBox1sets Data line 1 piece Manual 1 piece Warranty card 1 piece 13. FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates use…

Text truncated - open the document above for the full version.

Shenzhen Vogoge Technology CO.,Ltd. Unit 201,2th Floor,Building B,8th Chong Qing Road,Fu Yong,Bao’an District,Shenzhen,China. To: SIEMIC, INC. 775 Montague Expressway. Milpitas, CA 95035, USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Vogoge Technology CO.,Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: Bluetooth Speaker Model No.: speaker-A, speaker-B, speaker-C, speaker-D, speaker-E, speaker-F, speaker-G, speaker-H FCC ID: 2AA3SSPEAKER-A We affirm that between SIEMIC and Shenzhen Vogoge Technology CO.,Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, signature : name / title : Liu Hongsheng/(Engineer) TEL/FAX:0755-27756042 /0755-29981996 E-MAIL: [email protected] information / address: Shenzhen Vogoge Technology CO.,Ltd. (Unit 201,2th Floor,Building B,8th Chong Qing Road,Fu Yong,Bao’an District,Shenzhen,China.)

SCS-F19: Confidentiality Request Letter Page 1 of 1 Rev 3.0 Shenzhen Vogoge Technology CO.,Ltd. Unit 201,2th Floor,Building B,8th Chong Qing Road,Fu Yong,Bao’an District,Shenzhen,China. Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AA3S SPEAKER-A Product: Bluetooth Speaker Model No.: speaker-A, speaker-B, speaker-C, speaker-D, speaker-E, speaker-F, speaker-G, speaker-H We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title : Liu Hongsheng/(Engineer) TEL/FAX:0755-27756042 /0755-29981996 E-MAIL: [email protected] information / address: Shenzhen Vogoge Technology CO.,Ltd. (Unit 201,2th Floor,Building B,8th Chong Qing Road,Fu Yong,Bao’an District,Shenzhen,China.)

Updated on 2005/02/07 by Kally Chan DECLARATION OF IDENTITY FCC ID: 2AA3SSPEAKER-A Hereby we: Shenzhen Vogoge Technology CO.,Ltd. (Name of Manufacturer) Basic Model Number: speaker-A Basic Brand Name: / Basic Product Name: Bluetooth Speaker Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): speaker-B, speaker-C, speaker-D, speaker-E, speaker-F, speaker-G, speaker-H New / Additional Brand Name(s): / Except the following(s) : Model numbers，outlook color Signature with Company Chop : Printed Name : Liu Hongsheng DATE:2013-9-13

Label Size:30*20mm(L*W) Label Location Model No.: speaker-A FCC ID: 2AA3SSPEAKER-A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Antenna Location

FCC ID: 2AA3SSPEAKER-A Keyway Testing Technology Co., Ltd. Report No. 13KWE0885930F Page 1 of 27 FCC TEST REPORT for Shenzhen Vogoge Technology CO.,Ltd. Bluetooth Speaker Model Number: speaker-A, speaker-B, speaker-C, speaker-D, speaker-E, speaker-F, speaker-G, speaker-H FCC ID: 2AA3SSPEAKER-A Prepared for : Shenzhen Vogoge Technology CO.,Ltd. Address : Unit 201,2th Floor,Building B,8th Chong Qing Road, Fu Yong, Bao’an District, Shenzhen, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 13KWE0885930F Date of Test : Aug. 25~30, 2013 Date of Report : Sept. 4,2013 FCC ID: 2AA3SSPEAKER-A Keyway Testing Technology Co., Ltd. Report No. 13KWE0885930F Page 2 of 27 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 5 2.1. Product Function.................................................................................................................... 5 2.2. Description of Device (EUT) .................................................................................................. 5 2.3. Independent Operation Modes .............................................................................................. 5 2.4. Difference between Model Numbers...................................................................................... 5 2.5. Test Supporting System......................................................................................................... 5 2.6. Test Facilities ......................................................................................................................... 5 2.7. List of Test and Measurement Instruments............................................................................ 6 3. TEST SET-UP AND OPERATION MODES .................................................................................. 7 3.1. Principle of Configuration Selection .......................................................................................7 3.2. Block Diagram of Test Set-up ................................................................................................ 7 3.3. Test Operation Mode and Test Software ............................................................................... 7 3.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 4. EMISSION TEST RESULTS ......................................................................................................... 8 4.1. Radiated Emission Test ......................................................................................................... 8 5. 20DB OCCUPY BANDWIDTH..................................................................................................... 18 5.1. Limits.................................................................................................................................... 18 5.2. Test setup ............................................................................................................................ 18 6. BAND EDGE COMPLIANCE TEST............................................................................................. 21 6.1. Limits.................................................................................................................................... 21 6.2. Test setup ............................................................................................................................ 21 7. ANTENNA REQUIREMENT: ....................................................................................................... 26 8. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 27 9. PHOTOGRAPHS OF THE EUT .................................................................................................. 27 FCC ID: 2AA3SSPEAKER-A Keyway Testing Technology Co., Ltd. Report No. 13KWE0885930F Page 3 of 27 Keyway Testing Technology Co., Ltd. Applicant: Address: Shenzhen Vogoge Technology CO.,Ltd. Unit 201,2th Floor,Building B,8th Chong Qing Road, Fu Yong, Bao’an District, Shenzhen, China Manufacturer: Address: Shenzhen Vogoge Technology CO.,Ltd. Unit 201,2th Floor,Building B,8th Chong Qing Road, Fu Yong, Bao’an District, Shenzhen, China E.U.T: Bluetooth Speaker Model Number: speaker-A, speaker-B, speaker-C, speaker-D, speaker-E, s peaker-F, speaker-G, speaker-H Trade Name: ------ Serial No.: ------ Date of Receipt: Aug. 25, 2013 Date of Test: Aug. 25~30, 2013 Test Specification: FCC Part 15, Subpart C: Oct. 1, 2012 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Sept. 4, 2013 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2AA3SSPEAKER-A Keyway Testing Technology Co., Ltd. Report No. 13KWE0885930F Page 4 of 27 1. TEST SUMMARY Test Items Test Requirement Uncertainty Result Conducted Emissions 15.207 ANSI C63.4 ±2.6dB N/A Radiated Emissions 15.209 15.249 ANSI C63.4 ±3.6dB PASS 20dB Bandwidth 15.249 ANSI C63.4 ±1kHz PASS Band Edge Compliance Test 15.249 ANSI C63.4 ±3.6dB PASS Antenna Requirement 15.203 ANSI C63.4 / PASS Note：N/A mean…

Text truncated - open the document above for the full version.

Set-up for Conducted Emission at the Mains Terminals Test Set-up for Radiated Emission Test
