2AA6CSOMRPL20IO Nuc Assembly

www.aethon.com © Copyright Aethon, Inc. 2022. All Rights Reserved Product Description The IO NUC Assembly is the next iteration of our SOM platform. This assembly has been specially designed to function across our family of robots. Specifications Label Requirement For OEM integration only – device cannot be sold to general public. The FCC / ISED certification label of a module shall be clearly visible at all times when installed in the host product; otherwise, the host product must be labeled to display the FCC / ISED certification number for the module, preceded by the word "contains" or similar wording expressing the same meaning, as follows: Contains FCC ID: 2AA6CSOMRPL20 Contains IC: 11082A-SOMRPL20 Contains FCC ID: PD98265NGU Contains IC: 1000M-8265NG Approvals and Standards Compliance • FCC, Part 15, IC, CE • EN 12100:2010, EN 60204-1:2006+A1:2009, IEC 60034-1:2004-04 • EN 61000-6-4:2007; EN 61000-6-2:2005; EN 60601-1- 2:2007, EN 55022 • EN 301 489-1, EN 301 489-17 • FCC CFR 47, Part 15; ICES-001; Australian RCM Compliance • ETSI EN 300 220+1 V2.4.1 & ETSI EN 300 220-2 V2.4.1 • EN 300 328 1.7.1, EN 301 893 1.6.1 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specification 293504 Dimensions 18.895”L x 14.237”W x 2.493”H (47.99 cm L x 36.162 cm W x 6.332 cm H) Operating Weight 10.0 lbs (5.536 kg) Communications Wi-Fi Environmental Interior use IO NUC Assembly www.aethon.com © Copyright Aethon, Inc. 2022. All Rights Reserved FCC Part 15 Warning: Changes or modifications to the robot, charging dock, or any related equipment not expressly approved by Aethon could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RSS GEN This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. This radio transmitter IC: 11082A-SOMRPL20 has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. • 418/433Mhz  Linx: ANT-418-CW-RH-SMA: Maximum gain -6.7dBi  Tagoglas: TI.10.0111: Maximum gain 0dbi • 2.4/5GHz  World Products: WPANT30220-S1A: (2.4GHz +2.8 dBi) (5GHz +0.2 dBi) RSS GEN (French) L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; www.aethon.com © Copyright Aethon, Inc. 2022. All Rights Reserved 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Dans le cas de l’équipement exempté de licence avec antennes amovibles, le manuel d’utilisation doit également contenir l’avis suivant à un endroit bien en vue : Cet émetteur radio IC: 11082A-SOMRPL20 a été approuvé par Innovation, Science et Développement économique Canada pour fonctionner avec les types d’antennes énumérés ci-dessous, avec le gain maximal admissible indiqué. Les types d’antennes non inclus dans cette liste qui ont un gain supérieur au gain maximal indiqué pour tout type répertorié sont strictement interdits d’utilisation avec cet appareil. • 418/433Mhz  Linx: ANT-418-CW-RH-SMA: Gain Maximum -6.7dBi  Tagoglas: TI.10.0111: Gain Maximum 0dbi • 2.4/5GHz  World Products: WPANT30220-S1A: (2.4GHz +2.8 dBi) (5GHz +0.2 dBi)

SGS North America Inc. Consumer and Retail 620 Old Peachtree Road NW, Suite 100, Suwanee, GA 30024 t (770) 570-1800 www.sgs.com Member of the SGS Group (SGS SA) February 11, 2022 Dear Sir/Madam, Re: Request for FCC module certification for FCC ID: 2AA6CSOMRPL20 We hereby request a Limited Modular certification for the FCC ID referenced above. Requirement (47CFR15.212 / KDB996369) Comply (Y/N) – Explanation 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Y 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Y 3. The module must contain power supply regulation on the module Y 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) N – The module does not use a unique antenna connector; it uses a standard SMA connector. 5. The module must demonstrate compliance in a stand-alone configuration Y 6. The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (see KDB Publication 784748) Y 7. The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee Y 8. The module must comply with RF exposure requirements Y This module is to be installed only in robot host products which are also manufactured by the applicant. When installed in the robots, the module (including the antenna) will be entirely enclosed within the host, such that the user cannot access the antenna. Sincerely, Martin Taylor, Agent for ST Engineering Aethon Inc. RF/EMC Engineer

SGS North America Inc. Consumer and Retail 620 Old Peachtree Road Suite 100 Suwanee GA 30024 t (770) 570-1800 f (770) 277-1240 www.sgs.com Member of the SGS Group (SGS SA) Attn: Director of Certification Confidentiality Request regarding application for FCC ID: 2AA6CSOMRPL20 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby requests confidential treatment of the documents listed below, associated with the certification application referenced above. Schematics Block Diagram Theory of Operation The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 180 days from the grant date, whichever is less. If the device is marketed within 180 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. Internal Photos External Photos Test Setup Photos User Manual Sincerely, Martin Taylor Agent for ST Engineering Aethon Inc. SGS North America Title: RF/EMC Engineer Date: 11 October 2021

EXTERNALPHOTOS FCC ID: 2AA6CSOMRPL20 IC: 11082A-SOMRPL20 2 © SGS SA 2016 ALL RIGHTS RESERVED 3 © SGS SA 2016 ALL RIGHTS RESERVED 4 © SGS SA 2016 ALL RIGHTS RESERVED 5 © SGS SA 2016 ALL RIGHTS RESERVED 6 © SGS SA 2016 ALL RIGHTS RESERVED 7 © SGS SA 2016 ALL RIGHTS RESERVED 8 © SGS SA 2016 ALL RIGHTS RESERVED WWW.SGS.COM

LABEL LOCATION FCC ID: 2AA6CSOMRPL20 IC: 11082A-SOMRPL20 2 © SGS SA 2016 ALL RIGHTS RESERVED Label Location WWW.SGS.COM
