Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Intentionally left blank. Document history VERSIONDATEMODIFICATIONS A05/11/2013Creation User manual - Pictograms Note Equipment optimization tip Prohibited action notice Noteworthy point warning Danger or potential risk warning Reminder of the pre-requisites for implementation of the next instructions Labguard ™ is one of bioMérieux's registered trademarks. The information and graphs contained in this manual are not binding. bioMérieux therefore reserves the right to implement changes to the document without prior notice. bioMérieux will not approve any modifications whatsoever to the equipment implemented by the user. bioMérieux shall under no circumstance be held liable for any direct or consequential injury or damage whatsoever suffered by the user or by any third party, as a result of modifications to the equipment. •This equipment is for professional use only. •Users are required to read all the accompanying documents, including the statutory information, before using the equipment. Unpacking the device ........................................... 6 Learning about the equipment ...................................... 7 Labguard 3D ™ equipment ..................................... 7 Front ................................................. 7 Rear ................................................. 8 Installing the device ............................................ 9 Switching the equipment on / off .................................... 10 Turning the device on ....................................... 10 Turning the device off ....................................... 10 Understanding the indicator lights ................................... 11 Alarm indicators .......................................... 11 Status indicator .......................................... 12 Technical characteristics ......................................... 13 Maintenance ............................................... 14 Changing the batteries ...................................... 14 Disposal .............................................. 14 Cleaning the device ........................................ 14 Options and accessories ......................................... 15 Equipment conformity .......................................... 16 FCC compliance .......................................... 16 Industry conformity Canada (IC) ................................. 16 EC compliance ........................................... 17 Compliance statement .................................... 17 Contents Unpacking the device Check that the device has not been damaged during transport. Then check that all the accessories listed below are present. Transmitter •Unit •Unit support 1 Labguard 3 6 MOBI_HR_QSG_EN-A Learning about the equipment Labguard 3D ™ equipment With Labguard 3D ™ equipment, you can: •Simultaneously measure the different physical parameters of the laboratory (temperature, humidity, CO2). •Provide alerts with visual alarms in real time in case of anomalies. •Save and transfer data and alarms to the Labguard ® software. Front 1Multi-function button 2Status indicator 3Alarm indicator 2 Labguard 3 7 MOBI_HR_QSG_EN-A Rear 14 battery access screws. Labguard 3 8 MOBI_HR_QSG_EN-A Installing the device 1.Fix the Tomguard support to the wall or to the unit to be monitored using the two screws or adhesive strips at the rear of the support. 2.Slide the device into the support. 3.For greater security, you can add a padlock. 3 Labguard 3 9 MOBI_HR_QSG_EN-A Switching the equipment on / off Turning the device on To turn the device on, press and hold the multi-function button for 5 seconds. The status light turns green. Turning the device off To turn the device off, press and hold the multi-function button for 5 seconds. The status light turns red. 4 Labguard 3 10 MOBI_HR_QSG_EN-A Understanding the indicator lights Alarm indicators The transmitter signals technical problems or measurement problems via alarms. The alarm indicators specify the type of alarm: Indicator lightsColorAlarm originType of alarm RedSensorTime threshold exceeded. OrangeSensorThreshold exceeded. PurpleSensorSensor absent. BlueTransmitterCommunication absent. YellowTransmitterMains power supply absent. 5 Labguard 3 11 MOBI_HR_QSG_EN-A Status indicator Check the status of the battery and the power of the radio signal by pressing the multi-function button for one second: •The status indicator lights up and indicates the battery status. •The status indicator lights up again and indicates the power of the radio signal status. Indicator lightsStatus Good. Average. Poor. Labguard 3 12 MOBI_HR_QSG_EN-A Technical characteristics Environmental conditions Altitudeup to 2,000 m Temperaturefrom 0 to 40°C max. Relative humidity (Rh) from 10 to 80% Product power supply Battery: •2 Li AAA batteries 1.5 V; 1,200 mAh, compliant with CEI 60086-4 standard Pollution level2 Atmospheric pressure700 hPa to 1,100 hPa Installation categoryType II according to Directive CEI 664 Device dimensions (W x H x D)Device (mm): •61 x 94 x 23 Device in packaging (mm): •167 x 133 x 74 Device weightDevice (g): •110 Device in packaging (g): •170 WirelessEmission bandwidth: •865 to 868 Mhz, 60 channels •868 to 868.8 Mhz, 12 channels •902 to 912 Mhz, 20 channels •433.05 to 434.79 Mhz, 8 channels Range: •100 m inside •400 m outside 6 Labguard 3 13 MOBI_HR_QSG_EN-A Maintenance Changing the batteries Risk of explosion : •Do not place the battery the wrong way round. •Do not short circuit. •Do not use damaged or leaking batteries. •Do not incinerate, recharge, dismantle, crush or expose to water. 1.Unscrew the lower part located at the rear of the device. 2.Remove the batteries carefully and replace them making sure the positive (+) and negative (-) terminals are correctly positioned. 3.Re-position the lower part then screw it back on. Only use recommended models to replace the battery. Disposal Recycle the lithium batteries in accordance with enforceable regulations. Dispose of them by the appropriat…
Text truncated - open the document above for the full version.
Attn: TIMCO Engineering lnc. 849 N. W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Authority to Act as Agent On our behalf, I appoint M. Thomas LEDRESSEUR from Emitech Angers - site de Juigné, 21 rue de la Fuye PA de Lanserre, 49610 Juigné sur Loire FRANCE, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission's regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by TIMCO Engineering lnc., still resides with bioMérieux. This authorization is valid until further written notice from bioMérieux. 23 December 2013 By Johan DEVELON, R&D Instruments Manager
October 29, 2013 Attn: TIMCO Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Confidentiality Request regarding application for certification of FCC ID: 2AA8Y-416030 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Operational description 416030-OpDes.pdf Block diagram 416030-BlkDia.pdf Schematics 416030-Schem.pdf Parts List 416030-Partslst.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its compet itors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Johan DEVELON R&D Instruments Manager
December 10, 2013 Attn: TIMCO Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 FCC ID: 2AA8Y-416030 IC : 11497A-416030 To Whom It May Concern: BioMérieux S.A., declare that: • The differences between models 416027 and 416030 are for the presence of a humidity sensor. Radio is strictly the same. Model Humidity sensor 416027 No 416030 Yes • The electronic scheme and the electronic part list refer to a 433 Mhz antenna and a 433 Mhz radio chip. As it is explained in the electronic part list, these components are not mounted in these three models. Sincerely, Johan DEVELON R&D Instruments Manager
General view
FABFGXXXX FABFGXXXX Model : 416030 XXXXXXXX N° : XXXXXXXX ! 5V 0,5A T-guard Tº /%Hr 915Mhz T-guard Tº /%Hr 915Mhz BIOMERIEUX SA Chemin de l’Orme 69280 Marcy l’Etoile MADE IN FRANCE FCC ID : 2AA8Y-416030 IC : 11497A-416030
Internal view Printed board Radio module Radio module without shield
RR051-12-106520-2-A Ed. 0 Certification test report According to the standard(s): CFR 47, FCC Part 15 Equipment under test: Tomguard labguard 3 radio FCC ID: 2AA8Y-416030 Company: BIOMERIEUX DISTRIBUTION: Mr BOUQUET (Company: BIOMERIEUX) Number of pages: 26 with 5 appendixes Technical Verification and Ed. Date Modified Written by Quality Approval pages Name Visa Name Visa 0 12-SEP-2013 Creation T. LEDRESSEUR Duplication of this document is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. RR051-12-106520-2/A Ed. 0 Page 2 out of 26 DESIGNATION OF PRODUCT: Tomguard labguard 3 radio Serial number (S/N): 1343902023 Reference / model (P/N): TOMGUARD Software version: not communicated MANUFACTURER: BIOMERIEUX COMPANY SUBMITTING THE PRODUCT: Company: BIOMERIEUX Address: RUE MARYSE BASTIE KER LANN CS 17219 35172 BRUZ CEDEX Responsible: Mr BOUQUET Person present during the tests: Mr BOUQUET DATES OF TEST: 04-JUL-2013; 09-JUL-2013; 12-JUL-2013 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE EMITECH ANGERS open area test site in JUIGNE SUR LOIRE (49) FRANCE FCC 2.948 Listed Site Registration Number: 90469 TESTED BY: T. LEDRESSEUR RR051-12-106520-2/A Ed. 0 Page 3 out of 26 CONTENTS TITLE PAGE 1. INTRODUCTION ............................................................................................................................................. 4 2. PRODUCT DESCRIPTION ............................................................................................................................. 4 3. NORMATIVE REFERENCE ............................................................................................................................ 4 4. TEST METHODOLOGY .................................................................................................................................. 5 5. TEST EQUIPMENT CALIBRATION DATES .................................................................................................. 6 6. TESTS AND CONCLUSIONS ........................................................................................................................ 7 7. RADIATED EMISSION LIMITS ...................................................................................................................... 8 8. ADDITIONAL PROVISIONS TO THE GENERAL RADIATED EMISSION LIMITATIONS ........................... 10 9. FUNDAMENTAL AND HARMONICS FIELD STRENGTH ........................................................................... 12 10. OUT-OF-BAND EMISSIONS ...................................................................................................................... 14 APPENDIX 1: Photos of the equipment under test APPENDIX 2: Test set up APPENDIX 3: Test equipment list APPENDIX 4: 20 dB bandwidth APPENDIX 5: Band edge RR051-12-106520-2/A Ed. 0 Page 4 out of 26 1. INTRODUCTION This document presents the result of certification test carried out on the following equipment: Tomguard labguard 3 radio in accordance with normative reference. 2. PRODUCT DESCRIPTION ITU Emission code: 500K7FD Class: A (commercial, industrial or business environment) Utilization: Indoor use Antenna type and gain: Integral antenna, -1dBi Operating frequency range: 902-928MHz Number of channels: 18 Channel spacing: 500kHz Frequency generation: P.L.L Modulation: F.S.K Power source: 3 Vdc (2 x 1,5Vdc batteries) Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 FCC Part 15 (2013) Radio Frequency Devices ANSI C63.4 (2003) Methods of Measurement of Radio-Noise Emissions from Low-voltage Electrical and Electronics Equipment in the range of 9 kHz to 40 GHz. RR051-12-106520-2/A Ed. 0 Page 5 out of 26 4. TEST METHODOLOGY Radio performance tests procedures given in CFR 47 part 15: Subpart B –Unintentional Radiators Paragraph 109: Radiated emission limits Subpart C – Intentional Radiators Paragraph 203: Antenna requirement Paragraph 205: Restricted bands of operation Paragraph 209: Radiated emission limits; general requirements Paragraph 215: Additional provisions to the general radiated emission limitations Paragraph 249: Operation within the bands 902-928 MHZ, 2400-2483.5 MHz, 5725-5850 MHz and 24.0-24.25 GHz. RR051-12-106520-2/A Ed. 0 Page 6 out of 26 5. TEST EQUIPMENT CALIBRATION DATES Equipment Model Type Last verification Next verification Validity 1922 Microwave DB C020180F- 4B1 Low-noise amplifier 1 to 18 GHz 01/08/2012 01/08/2013 01/10/2013 1939 IMC WR42 Horn antenna 20/04/2012 20/04/2016 20/06/2016 3036 ALC Microwave ALN02- 0102 Low-noise amplifier 04/04/2013 04/04/2014 04/06/2014 7998 Dipole antenna VHAP Schwarzbeck 22/10/2012 22/10/2014 22/12/2014 7999 Dipole antenna UHAP Schwarzbeck 22/10/2012 22/10/2014 22/12/2014 8511 Préamplificateur 8447D Hewlett Packard 28/06/2012 28/06/2013 28/08/2013 8523 R&S FSEM30 Spectrum analyser 07/09/2012 07/09/2014 07/11/2014 8526 Schwarzbeck VHBB 9124 Biconical antenna 12/06/2012 12/06/2016 12/08/2016 8533 HFH2-Z2 Loop antenna 01/05/2013 01/05/2014 01/07/2014 8534 Emco 3115 Horn antenna 30/10/2012 30/10/2016 30/12/2016 8535 Emco 3115 Horn antenna 30/10/2012 30/10/2016 30/12/2016 8543 Schwarzbeck UHALP 9108A Log periodic antenna 12/06/2012 12/06/2016 12/08/2016 8593 SIDT Cage 2 Full anechoic room 06/09/2011 06/09/2013 06/11/2013 8675 AOIP MN5102B Multimeter 15/01/2013 15/01/2015 15/03/2015 8707 R&S ESI7 Test receiver 03/10/2012 03/10/2014 03/12/2014 873…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 903.25 MHz - 911.75 MHz | - |

MODEM RADIO ETHERNET LABGUARD 3 IS USED TO RECEIVE MEASURES OF PHYSICAL PARAMETERS IN LABORATORY SUCH AS TEMPERATURE, HUMIDITY, CO2, ETC.
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
EMITTER LABGUARD 3 RADIO IS USED TO MEASURE AND CONTROL PHYSICAL PARAMETERS IN LABORATORY
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
