2AAA9-R2CAPND900NWireless Router

Quick Start | 1 © 2013 Relay2, Inc. All rights reserved. Quick Start Guide Customers INTRODUCTION This document will guide you through the process of setting up and registering an Access Point (AP) and establishing a WLAN in version 1.2.0 of the Relay2Cloud Wireless Manager. Detailed information on these and other advanced features can be found in Relay2’s WLAN System Test Manual, version 1.2.0- 20130915. BEFORE YOU START The Relay2 Access Point cannot function as a standalone unit. Before connecting your AP to a network, make sure to check the following: Acquire a Relay2 account from your Service Provider if you have not do so; provide your name, company e-mail address, phone number, and a username in the form of an e-mail address for account creation. The Relay2 Cloud Wireless Manager is accessed through a variety of web browsers, including Internet Explorer 9 and 10, Google Chrome 26 and above, Mozilla Firefox 6 and above, Safari 5 and above and Opera. The Relay2 AP must be connected to a network that can reach the Internet. If your network has a firewall that blocks outbound traffic to the Internet, make sure to configure your firewall to allow at least HTTP and HTTPS ports. The AP’s management network interface will automatically obtain an IP address from the DHCP server by default.If your network requires the use of static IP address, refer to section 5 for details on how to configure your Relay2 AP accordingly. _____________________________________________________________________________ Quick Start | 2 © 2013 Relay2, Inc. All rights reserved. QUICK SETUP OVERVIEW 1. Hook up and install your AP. Insert power and Ethernet cables. Position AP for maximum signal coverage. 2. Loginto Cloud Wireless Manager. Log in at [www.relay2.net.cn]. Check for AP registration on “Dashboard” page. 3. Add a WLAN. Navigate to “Configure —> WLAN”. Click “Add New” and fill in respective fields. 4. Test your WLAN connection. Connect to your WLAN SSID with a WiFi device. Check for connection events. Quick Start | 3 © 2013 Relay2, Inc. All rights reserved. 1. Hook up and install your AP 1.1. Check Your AP Packaging List Quick Start | 4 © 2013 Relay2, Inc. All rights reserved. 1.2. Installing Your Access Point a. When installing on a flat surface, attach the rubber pads to the back of the AP as shown below. b. If mounting the AP on a wall, follow the instructions in the diagrams below. Quick Start | 5 © 2013 Relay2, Inc. All rights reserved. Quick Start | 6 © 2013 Relay2, Inc. All rights reserved. Quick Start | 7 © 2013 Relay2, Inc. All rights reserved. 1.3. Setting Up Your Access Point a. The Relay2 AP can be placed on a desk or mounted on a wall. If mounted, the AP can be tilted to provide maximum signal coverage. Use this diagram to position the AP so that it provides the most signal coverage for your purposes. b. Avoid placing objects on top of the AP. c. Avoid installing the AP near magnetic and/or metal objects. d. If you are installing the Relay2 AP outdoors, make sure to place a water-resistant shield over it. e. For more information relating to the setup of the Relay2 AP, see section 2 of this document. Quick Start | 8 © 2013 Relay2, Inc. All rights reserved. 1.4. Your Access Point Hardware Features a. Power can be supplied either through a 48VDC adaptor, or an IEEE 802.3at PoE+ (PoE plus) Switch port that can supply up to 25W power over Ethernet cable inserted into the RJ45 port (B7). We recommend using the PoE+ for better management. b. If you do not have a PoE+ Switch, you can use the power adaptor that comes with the AP. The AP’s power cable can be inserted into the DC port (B6). c. The Ethernet cable is better to use CAT5 or CAT6 class cable, which can be inserted into the RJ45 port (B7). d. The Relay2 AP also features a serial port (B8), a USB port (B9), and an optional SIM card port (B10). e. Once the AP is receiving power, it will initiate an LCD/LED startup sequence. f. In the LED startup sequence, all three LED lights—Status (A2), Radio (A3), and Ethernet (A4)—should blink green and then turn solid green. g. The AP’s power and Ethernet cables can be trunked into the grooves beneath their respective ports, as shown below: Quick Start | 9 © 2013 Relay2, Inc. All rights reserved. Quick Start | 10 © 2013 Relay2, Inc. All rights reserved. 2. AP Boot UP Relay2 AP first time boot up will take about 5 – 10 minutes depending on the software version number installed on the AP that you receive. Longer time will be needed if AP detects there is new software version and download the new software image to update the AP. You can view the LCD screen provided in the AP to tell the current AP status: 1. Welcome to R2OS 2. Bootup 3. Registered (found Cloud Controller and registered with Cloud Controller) 4. Connect – Connecting to Cloud Controller 5. Download – Found new AP SW image and is downloading and will reboot after image update 6. Radio 1&2 UP – The state that AP has successfully connected to Cloud Controller 3. Logging in a. Log in with your provided Super-User account at [www.relay2.net.cn]. b. Upon logging in, you will be directed to the “Monitor -> Dashboard” page. Quick Start | 11 © 2013 Relay2, Inc. All rights reserved. If all three rings are not already green, wait 1-2 minutes for their appearance. 4. ADDING A WLAN a. Navigate to “Configure —> WLAN,” then click on “Add New”. Quick Start | 12 © 2013 Relay2, Inc. All rights reserved. b. Add a WLAN profile name, SSID, and modify settings as desired; then click “Apply”. c. Your WLAN has been created. Quick Start | 13 © 2013 Relay2, Inc. All rights reserved. 5. TESTING YOUR WLAN CONNECTION a. Test your WLAN configuration by connecting an electronic device with WiFi capabilities to your WLAN SSID. You may also wish to launch a web browser and see if you can connect to the Internet. b. Navigate to “Monitor —> Client Station” to check for these connection events in descending order: Association, Authentication,and Connection. If all three appear, yo…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Relay2, Inc. 2013-11-15 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAA9-R2CAPND900 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Contact information / address: 1525 McCarthy Blvd. Suite 209

Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 23 of 43 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B.i. Photograph 1: EUT External Photo Whole Package - Top View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 24 of 43 www.siemic.com.cn EUT - Front View EUT - Rear View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 25 of 43 www.siemic.com.cn EUT - Top View EUT - Bottom View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 26 of 43 www.siemic.com.cn EUT - Left View EUT - Right View

Labeel Locaation

Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 27 of 43 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo Cover Off - Top View Adapter-front view Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 28 of 43 www.siemic.com.cn Mainborad - Top View Mainborad Uncover - Top View-1 Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 29 of 43 www.siemic.com.cn Mainborad Uncover - Top View-2 Mainborad - Bottom View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 30 of 43 www.siemic.com.cn Mainborad Uncover - Bottom View LED board - Top View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 31 of 43 www.siemic.com.cn LED board - Bottom View Control board - Top View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 32 of 43 www.siemic.com.cn Control board – Botton View 2.4GHz RF board - Top View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 33 of 43 www.siemic.com.cn 2.4GHz RF board Uncover - Top View 2.4GHz RF board – Botton View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 34 of 43 www.siemic.com.cn 5GHz RF board - Top View 5GHz RF board Uncover - Top View Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15 Subpart B Class B: 2013 , ANSI C63.4:2009 Report No.: 13070456-FCC-E Issue Date: November 13, 2013 Page: 35 of 43 www.siemic.com.cn 5GHz RF board – Botton View WIFI Antenna View

Relay2, Inc. Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A November 13, 2013 Report No.: 13070456-FCC-H2 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Herith Shi Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC 2.1091 Report No.: 13070456-FCC-H2 Issue Date: November 13, 2013 Page: 2 of 8 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . SIEMIC (Shenzhen-China) Laboratories Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC 2.1091 Report No.: 13070456-FCC-H2 Issue Date: November 13, 2013 Page: 3 of 8 www.siemic.com.cn This page has been left blank intentionally. Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC 2.1091 Report No.: 13070456-FCC-H2 Issue Date: November 13, 2013 Page: 4 of 8 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS.......................................................................................................................................... 6 3 FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ...................................................................... 7 Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC 2.1091 Report No.: 13070456-FCC-H2 Issue Date: November 13, 2013 Page: 5 of 8 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programmer was to demonstrate compliance of the Relay2, Inc., Wireless Router and Model: R2-CAP-ND-900N against the current Stipulated Standards. The Wireless Router has demonstrated compliance with the FCC 2.1091. EUT Information EUT Description : Wireless Router Main Model : R2-CAP-ND-900N Serial Model N/A Antenna Gain : WIFI 2.4GHz: 3dBi WIFI 5GHz: 5dBi Input Power : Adapter: Model:FSP025-1AD207A Input: AC 100-240V 50/60Hz 0.7A Output: DC 48V 0.52A Classification Per Stipulated Test Standard : Class B Emission Product Per FCC 2.1091 Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC 2.1091 Report No.: 13070456-FCC-H2 Issue Date: November 13, 2013 Page: 6 of 8 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Wireless Router with stipulated standards Applicant / Client Relay2, Inc. 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Manufacturer N/A Laboratory performing the tests SIEMIC (Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen, Guangdong, China Tel: +86-0755-2601 4629 / 2601 4953 Fax: +86-0755-2601 4953-810 Email: [email protected] Test report reference number 13070456-FCC-H2 Date EUT received October 10, 2013 Standard applied FCC 2.1091 Dates of test (from – to) October 10 to November 12, 2013 No of Units #1 Equipment Category JBP Trade Name N/A RF Operating Frequency (ies) WIFI(802.11a/b/g/n20): 2412-2462 MHz; 5180-5240 MHz; 5745-5825MHz WIFI (802.11n40): 2422-2452 MHz; 5190-5230 MHz; 5755-5795 MHz Number of Channels WIFI 2.4G(802.11a/b/g/n-20): 11CH WIFI 5.18-5.24G(802.11a/ n-20): 8CH WIFI 5.745-5.825G(802.11a/ n-20): 5CH WIFI 2.4G(n-40): 7CH WIFI 5.19-5.23G(n-40):2CH WIFI 5.755-5.795G(n-40): 2CH Modulation WIFI(802.11a/b/g/n): DSSS/OFDM FCC ID 2AAA9-R2CAPND900N Title: EMC Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC 2.1091 Report No.: 13070456-FCC-H2 Issue Date: November 13, 2013 Page: 7 of 8 www.siemic.com.cn 3 FCC §2.1091 - MaximuM Permissible exposure (MPE) 3.1 Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density 3.2 Test Data Predication of MPE limit at a given distance Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of rad…

Text truncated - open the document above for the full version.

Relay2, Inc. Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A November 13, 2013 Report No.: 13070456-FCC-R1 (This report supersedes none) Modifications made to the product : None This Test Report is Issued Under the Authority of: Herith Shi Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 2 of 224 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . SIEMIC (Shenzhen-China) Laboratories Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 3 of 224 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 4 of 224 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS ......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ................................................................ 12 ANNEX A. TEST INSTRUMENT & METHOD ...................................................................................................... 199 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ......................................................................................... 204 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT .............................................................................. 219 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST .......................................... 223 ANNEX E. DECLARATION OF SIMILARITY ...................................................................................................... 224 Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 5 of 224 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Relay2, Inc., Wireless Router and model: R2-CAP-ND-900N against the current Stipulated Standards. The Wireless Router has demonstrated compliance with the FCC Part 15.247: 2013, ANSI C63.4: 2009. EUT Information EUT Description : Wireless Router Main Model : R2-CAP-ND-900N Serial Model : N/A Antenna Gain : WIFI 2.4GHz: 3 dBi WIFI 5GHz: 5 dBi Input Power : Adapter: Model:FSP025-1AD207A Input: AC 100-240V 50/60Hz 0.7A Output: DC 48V 0.52A Classification Per Stipulated Test Standard : FCC Part 15.247: 2013, ANSI C63.4: 2009 Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 6 of 224 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Wireless Router with stipulated standard Applicant / Client Relay2, Inc. 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Manufacturer Relay2, Inc. 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Laboratory performing the tests SIEMIC( Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen, Guangdong, China Tel: +86-0755-2601 4629 / 2601 4953 Fax: +86-0755-2601 4953-810 Email: [email protected] Test report reference number 13070456-FCC-R1 Date EUT received October 10, 2013 Standard applied FCC Part 15.247: 2013, ANSI C63.4: 2009 Dates of test (from – to) October 10 to November 12, 2013 No of Units : #1 Equipment Category : Spread Spectrum System/Device Trade Name : N/A RF Operating Frequency (ies) WIFI(802.11a/b/g/n20): 2412-2462 MHz; 5180-5240 MHz; 5745-5825MHz WIFI (802.11n40): 2422-2452 MHz; 5190-5230 MHz; 5755-5795 MHz Number of Channels WIFI 2.4G(802.11a/b/g/n-20): 11CH WIFI 5.18-5.24G(802.11a/ n-20): 8CH WIFI 5.745-5.825G(802.11a/ n-20): 5CH WIFI 2.4G(n-40): 7CH WIFI 5.19-5.23G(n-40):2CH WIFI 5.755-5.795G(n-40): 2CH Modulation WIFI(802.11a/b/g/n): DSSS/OFDM FCC ID 2AAA9-R2CAPND900N Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Ser…

Text truncated - open the document above for the full version.

Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 204 of 224 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B.i. Photograph 1: EUT External Photo Whole Package - Top View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 205 of 224 www.siemic.com.cn EUT - Front View EUT - Rear View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 206 of 224 www.siemic.com.cn EUT - Top View EUT - Bottom View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 207 of 224 www.siemic.com.cn EUT - Left View EUT - Right View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 208 of 224 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo Cover Off - Top View Adapter-front view Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 209 of 224 www.siemic.com.cn Mainborad - Top View Mainborad Uncover - Top View-1 Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 210 of 224 www.siemic.com.cn Mainborad Uncover - Top View-2 Mainborad - Bottom View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 211 of 224 www.siemic.com.cn Mainborad Uncover - Bottom View LED board - Top View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 212 of 224 www.siemic.com.cn LED board - Bottom View Control board - Top View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 213 of 224 www.siemic.com.cn Control board – Botton View 2.4GHz RF board - Top View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 214 of 224 www.siemic.com.cn 2.4GHz RF board Uncover - Top View 2.4GHz RF board – Botton View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 215 of 224 www.siemic.com.cn 5GHz RF board - Top View 5GHz RF board Uncover - Top View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 216 of 224 www.siemic.com.cn 5GHz RF board – Botton View WIFI Antenna View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 217 of 224 www.siemic.com.cn Annex B.iii. Photograph 3: Test Setup Photo Conducted Emissions Test Setup Front View Conducted Emissions Test Setup Side View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 218 of 224 www.siemic.com.cn Radiated Spurious Emissions Test Setup Below 1GHz - Front View Radiated Spurious Emissions Test Setup Above 1GHz –Front View Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 219 of 224 www.siemic.com.cn Annex C. TEST SETUP AND SUPPORTING EQUIPMENT EUT TEST CONDITIONS Annex C. i. SUPPORTING EQUIPMENT DESCRIPTION The following is a description of supporting equipment and details of cables used with the EUT. Manufacturer Equipment Description (Including Brand Name) Model Calibration Date Calibration Due Date Lenovo Laptop E40& 0579A52 N/A Lenovo Laptop E40& 0579A52 Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 220 of 224 www.siemic.com.cn LISN 120V60Hz Wooden table, 80cm above ground plane Adapter EUT PC Block Configuration Diagram for AC Line Conducted Emissions Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 221 of 224 www.siemic.com.cn Wooden/non-conductive table, 80cm above ground plane EUT PC Adapter Block Configuration Diagram for Radiated Emissions Receiving Antenna 3 meter Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R1 Issue Date: November 13, 2013 Page: 222 of 224 www.siemic.com.cn Annex C.ii. EUT OPERATING CONDITIONS The following is the description of how the EUT is exercised during testing. Test Descripti…

Text truncated - open the document above for the full version.

Title: RF Test Report for Wireless Router Main Model: R2-CAP-ND-900N Serial Model: N/A To: FCC Part 15.407: 2013, ANSI C63.4: 2009 Report No.: 13070456-FCC-R2 Issue Date: November 13, 2013 Page: 82 of 89 www.siemic.com.cn Annex B.iii. Photograph 3: Test Setup Photo Conducted Emissions Test Setup…
