2AAA9-RA200Wireless Router

Quick Start | 1 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 Quick Start Guide I NTRODUCTION This document will guide you through the process of setting up and registering a Relay2 Access Point (AP) and establishing a WLAN with version 1.3.1 of the Relay2 Cloud Wireless Manager. Detailed information on these and other advanced features can be found in Relay2’s WLAN System Test Manual, version 1.3.1. B EFORE YOU START The Relay2 Access Point cannot function as a standalone unit. Before connecting your AP to a network, make sure to check the following: Acquire a Relay2 account from your Service Provider if you have not already done so; provide your name, company e-­‐mail address, phone number, and a username in the form of an e-­‐mail address for account creation. The Relay2 Cloud Wireless Manager is accessed through a variety of web browsers, including Internet Explorer 9 and above, Google Chrome 26 and above, Mozilla Firefox 6 and above, Safari 5 and above, and Opera. The Relay2 AP must be connected to a network that can reach the Internet. If your network has a firewall that blocks outbound traffic to the Internet, make sure to configure your firewall to allow at least HTTP and HTTPS ports. The AP’s management network interface will automatically obtain an IP address from the DHCP server by default. If your network requires the use of static IP address, refer to section 6 for details on how to configure your Relay2 AP accordingly. _____________________________________________________________________________ Q UICK S ETUP O VERVIEW Quick Start | 2 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 1. Hook up and install your AP. Insert power and/or Ethernet cables (for PoE+) Position AP for maximum signal coverage. 2. Login to Cloud Wireless Manager. Log in at [www.relay2.net]. Check for AP registration on “Dashboard” page. 3. Add a WLAN. Navigate to “Configure —> WLAN”. Click “Add New” and fill in respective fields. Select “Enabled” and hit “Apply” to activate WLAN. 4. Test your WLAN connection. Connect to your WLAN SSID with a WiFi device. Check for connection events. Quick Start | 3 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 1. Hook up and install your AP 1.1. Check Your AP Packaging List Quick Start | 4 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 1.2. Installing Your Access Point a. When mounting the AP on a wall, follow the instructions in the diagrams below. Quick Start | 5 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 Quick Start | 6 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 Quick Start | 7 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 1.3. Setting Up Your Access Point a. The Relay2 AP can be placed on a desk or mounted on a wall. If mounted, the AP can be tilted to provide maximum signal coverage. Use this diagram to position the AP so that it provides the most signal coverage for your purposes. b. Avoid placing objects on top of the AP. c. Avoid installing the AP near magnetic and/or metal objects. d. For more information relating to the setup of the Relay2 AP, see section 2 of this document. Quick Start | 8 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 1.4. Your Access Point Hardware Features a. Power can be supplied either through: a 48VDC adaptor, or an IEEE 802.3at PoE+ (PoE plus) switch port that can supply up to 25W power over an Ethernet cable inserted into the RJ45 port (B7). b. If you do not have a PoE+ switch, you can use the power adaptor that comes with the AP. The AP’s power cable can be inserted into the DC port (B6). c. CAT5 or CAT6 class cable should be used for Ethernet. Insert the Ethernet cable into the RJ45 port (B7). d. The Relay2 AP also features a serial port (B8), a USB port (B9), and an optional SIM card port (B10). e. Once the AP has been provided power, it will initiate an LCD/LED startup sequence. f. In the LED startup sequence, all three LED lights—Status (A2), Radio (A3), and Ethernet (A4)—should blink green and then turn solid green. g. The AP’s power and Ethernet cables can be trunked into the guides beneath their respective ports, as shown below: Quick Start | 9 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 2. AP Boot The first time you power on your Relay2 AP, it will take 5 – 10 minutes depending on the software version number installed on your AP. Additional time may be needed if the AP detects that there is a new software image available for download to automatically update the AP. The first time boot process may result in several cycles through the start up states. The start up sequence will be shown on the LCD screen, and may include the following: 1. Welcome to R2OS (The Relay2 Operating System) – AP is booting up 2. AP Configuration is being pushed from the Relay2 cloud controller 3. Connect – Connecting to certificate server 4. Registered -­‐ Found and registered with the cloud controller 5. Download – Found new AP SW image to be downloaded; AP will reboot after image update 6. Radio 1&2 UP –AP has successfully connected to the cloud controller 7. Miscellaneous messages: Reboot, Bootstrap Additional information about the boot up process can be found in the Appendix of the separate User’s Guide. Quick Start | 10 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 3. Logging in a. Log in with your provided account at www.relay2.net NOTE: A new account is always provisioned with your email address as the login name, and your email as the initial password. We strongly encourage you to change the password at your earliest opportunity. b. Upon logging in, you will be directed to the “Monitor -­‐> Dashboard” page. Quick Start | 11 © 2014 Relay2, Inc. All rights reserved. Document Version 1.3.1 If your AP(s) do not show as being “Up”, please wait 2-­‐3 minutes for them to initialize and come online. 4. ADDING A WLAN a. If you are logged in as a service provider, select …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Relay2, Inc. 2015.8.15 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Relay2, Inc.. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: Wireless Router model name: RA200 FCC ID: 2AAA9-RA200 Sincerely, Client’s signature : Joseph Lin Client’s name / title: Product Manager Applicant company: Relay2, Inc. address: 1525 McCarthy Blvd. Suite 209 Milpitas,, CA 95035 United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Relay2, Inc. 2015.8.15 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAA9-RA200 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Software Configuration Control letter The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Joseph Lin Client’s name & title : Sr. Hardware PM Director Contact information / address: 1525 McCarthy Blvd. Suite 209 Milpitas,, CA 95035 United States

Relay2, Inc. WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for IC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for IC : 2AAA9-RA200 Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Company Name: Relay2, Inc. Address : 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Name / Title : Joseph Lin/Sr. Hardware PM Director Signature : Phone : (408) 380-0031 Email : [email protected] Date :06/08/2015

Project No: STS1506069 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1506069 Photo 3 Photo 4 Project No: STS1506069 Photo 5 Photo 6 Project No: STS1506069 Photo 7 Photo 8

Label Wireless Router Model name: RA200 FCC ID: 2AAA9-RA200 IC: 20348-RA200 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

Project No: STS1506069 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Antenna C Antenna A Antenna A Antenna C 2412-2462MHZ 2422-2452MHZ Antenna B Antenna B 5180-5240MHZ 5745-5825 MHZ Project No: STS1506069 Photo 3 Photo 4 RX Antenna Project No: STS1506069 Photo 5 Photo 6 Project No: STS1506069 Photo 7 Photo 8 Project No: STS1506069 Photo 9 Photo 10 Project No: STS1506069 Photo 11 Photo 12 Project No: STS1506069 Photo 13 Photo 14 Project No: STS1506069 Photo 15 Photo 16 Project No: STS1506069 Photo 17 Photo 18 Project No: STS1506069 Photo 19 Photo 20

RF Exposure Report RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) F= Frequency in MHz Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Test Results Gain (G) 2.4G: ANT-A=4.888 dBi ANT-B=4.638 dBi ANT-C=4.158 dBi Total gain=9.3378≈9.3 5G: ANT-A=5.924 dBi ANT-B=4.425 dBi ANT-C=6.431 dBi Total gain=10.4055≈10.4 tune up power 2.4G Mode WIFI IEEE 802.11b 18.0±1dBm IEEE 802.11g 17.0±1dBm IEEE 802.11n HT20 17.5±1dBm IEEE 802.11n HT40 14.0±1dBm 5G Protocol Channel Frequency (MHz) tune up power A B C 802.11a 5200 7±1dBm 7±1dBm 7±1dBm 802.11n 5200 5.5±1dBm 5.5±1dBm 5.5±1dBm 802.11a 5785 11±1dBm 11±1dBm 11±1dBm 802.11n 5785 6±1dBm 6±1dBm 6±1dBm Protocol Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm²) Limit (mW/cm²) A B C A B C total 802.11 b 2437 79.43 79.43 79.43 0.0487 0.0460 0.0412 0.2359 1.000 802.11 g 2437 63.10 63.10 63.10 0.0387 0.0365 0.0327 0.1079 1.000 802.11 n 2437 70.79 70.79 70.79 0.0434 0.0410 0.0367 0.1211 1.000 802.11a 5200 6.310 6.310 6.310 0.0049 0.0035 0.0055 0.0139 1.000 802.11n 5200 4.467 4.467 4.467 0.0035 0.0025 0.0039 0.0099 1.000 802.11a 5785 15.85 15.85 15.85 0.0123 0.0087 0.0139 0.0349 1.000 802.11n 5785 5.012 5.012 5.012 0.0039 0.0028 0.0044 0.0111 1.000

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No: STS1506069F02 Issued for Relay2, Inc. 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Product Name: Wireless Router Brand Name: Relay2 Model No.: RA200 Series Model: N/A FCC ID: 2AAA9-RA200 IC: 20348-RA200 Test Standard: FCC Part 15.247 RSS 247 Issue 1 MAY 2015 S T L A B S Page 2 of 60 Report No.: STS1506069F02 TEST RESULT CERTIFICATION Applicant’s name ................. : Relay2, Inc. Address ................................. : 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Manufacture's Name ........... : Relay2, Inc. Address ................................. : 1525 McCarthy Blvd., Suite 209, Milpitas, CA 95035, USA Product description Product name ........................... : Wireless Router Model and/or type reference : RA200 Serial Model .............................. : N/A Standards ............................. : FCC Part15.247 RSS-247 Issue 1 MAY 2015 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 24 July. 2015 ~31 July. 2015 Date of Issue ......................................... : 01 Aug. 2015 Test Result ............................................. : Pass Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 60 Report No.: STS1506069F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TEST 11 2.4 DESCRIPTION OF SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 TEST SETUP 18 3.2.4 EUT OPERATING CONDITIONS 18 3.2.5 TEST RESULT 19 4. CONDUCTED SPURIOUS EMISSIONS 25 4.1 APPLIED PROCEDURES / LIMIT 25 4.2 TEST PROCEDURE 25 4.3 DEVIATION FROM STANDARD 25 4.4 TEST SETUP 25 4.5 EUT OPERATION CONDITIONS 25 4.6 TEST RESULTS 26 5. POWER SPECTRAL DENSITY TEST 38 5.1 APPLIED PROCEDURES / LIMIT 38 5.2 TEST PROCEDURE 38 5.3 DEVIATION FROM STANDARD 38 5.4 TEST SETUP 38 5.5 EUT OPERATION CONDITIONS 38 5.6 TEST RESULTS 39 6. BANDWIDTH TEST 47 6.1 APPLIED PROCEDURES / LIMIT 47 6.2 TEST PROCEDURE 47 Page 4 of 60 Report No.: STS1506069F02 Table of Contents Page 6.3 DEVIATION FROM STANDARD 47 6.4 TEST SETUP 47 6.5 EUT OPERATION CONDITIONS 47 6.6 TEST RESULTS 48 7. PEAK OUTPUT POWER TEST 56 7.1 APPLIED PROCEDURES / LIMIT 56 7.2 TEST PROCEDURE 56 7.3 DEVIATION FROM STANDARD 56 7.4 TEST SETUP 56 7.5 EUT OPERATION CONDITIONS 56 7.6 TEST RESULTS 57 8. ANTENNA REQUIREMENT 58 8.1 STANDARD REQUIREMENT 58 8.2 EUT ANTENNA 58 APPENDIX - PHOTOS OF TEST SETUP 59 Page 5 of 60 Report No.: STS1506069F02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 01 Aug. 2015 STS1506069F02 ALL Initial Issue Page 6 of 60 Report No.: STS1506069F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) RSS 247, Subpart C Standard Section Test Item Judgment Remark 15.207 Issue 4 nov 2014 Issue 3: 7.2.4 Conducted Emission PASS 15.247 (a)(2) Issue 1 Issue 5 (5.2) 6dB&99% Bandwidth PASS 15.247 (b) (reference KDB 558074 d05 v02. /9.1.2) Issue 1 Issue 5 (5.2) Peak Output Power PASS 15.247 (c) Issue 1 Issue 5 (5.5) Radiated Spurious Emission PASS 15.247 (d) Issue 1 Issue 5 (5.5) Conducted Spurious Emission PASS 15.247 (e) Issue 1 Issue 5 (5.2) Power Spectral Density PASS 15.205 Issue 1 Issue 5 (5.5) Band Edge Emission PASS 15.203 Issue 4 nov 2014 Issue 3: 7.1.2 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 7 of 60 Report No.: STS1506069F02 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 8 of 60 Report No.: STS1506069F02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Router Trade Name Relay2 Model Name RA200 Serial Model N/A Model Difference N/A Product Description The EUT is a Wireless Router Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz 802.11n 40: 2422~2452MHz Modulation Type: CCK/O…

Text truncated - open the document above for the full version.

DTS Setup photo DTS conduction DTS radiation L DTS radiation H
