2AAAQH660WG-PON ONT

H660W Power Adapter RJ45 UTP Cable (CAT5e) QIG (Quick Guide) 2.3 Rear View ④ Connect the Ethernet cable from LAN port to PC. ⑤ Connect a power adapter from power port to a live AC outlet. ⑥ Turn on the unit by pushing the power button. ⑦ Push WLAN button to enable WiFi. ① Remove the protective cap of GPON port. ② Connect an SC/UPC connector optic cable to the port. ③ And then arrange optic line on splice tray, not to give damage to GPON connection due to any possible pull. 3. Installation GPON Optical Network Terminal (ONT) with Wi-Fi H660W QIG (Quick Guide) Information furnished by Dasan Networks, Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Dasan Networks for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of DASAN Networks. DASAN Networks reserves the rights to change specifications at any time without notice. Copyright © 2014 by DASAN Networks, Inc. All rights reserved. DASAN Networks, Inc.www.dasannetworks.com/en It emDescription ① OPTIC LINEConnect the network. ② LAN1~4Connect PC or LAN. ③ Power PortConnect power adapter . ④ ON/OFFTurn on/off the unit. ⑤ RESETReboot the unit. ⑥ WPSEnable WPS process. ⑦ WLANEnable WiFi function. V1 2.2 Specification It emSpecification System Memory128MB DDR3 Flash Memory128MB Nand Flash 1 GPON port (1G, SC/UPC) Uplink Interface Service Interface4 10/100/1000Base-T ports (RJ45) Wireless Internal antenna IEEE 802.11b/g/n compliant Bandwidth: 2.4GHz Two Transmit and Two Receive path (2T2R) LEDPWR, PON, ALM, WLAN, WPS, LAN1~4 Power Adapter Operating Temp. Output: 12VDC/1A 0 to 40°C Operating Humidity5 to 95% (non-condensing) Dimensions (W x D x H) 160 x 125 x 43 mm ButtonON/OFF power, WLAN, WPS, RESET 2.4 Front View (LEDs) 4. Initial Web Access You can access the unit through a web browser by using the “initial LAN IP” at first. The detail procedure is as follows: ① Connect LAN1 port of the unit to your PC using Ethernet cable. ② Configure IP assignment of your PC to DHCP (dynamic assignment). How to configure dynamic IP on your PC is as follows: For Windows XP: Start > Setting > Network Connections > Local Area Connection double click > Internet Protocol (TCP/IP) double click > Obtain an IP address automatically and Obtain DNS server address automatically selection > OK For Windows 7: Start > Control Panel > View network status and tasks under Network and Internet (View by: Category) > Change adapter settings on the left menu > Local Area Connection right-click > Properties > Internet Protocol Version 4 (TCP/IPv4) double click > > Obtain an IP address automatically and Obtain DNS server address automatically selection > OK The PC will be allocated IP address automatically through the unit. ③ Open a web browser, and enter http://192.168.1.100:8080 in a URL field. ④ Type “user/user” in user name/password field, and log into the system. Initial page is displayed. The default SSID and its password are as follows: SSID: DASAN_GONTxxxxxx (xxxxxx is the last 6 digit/letters of MAC address of your unit.) Password: 1234567890a To change the SSID and/or password, move onto Basic Settings > Wireless LAN > SSID Setting on the web, and click Modify. And change them and click Apply. And then click Apply Config on top of page, and reboot the unit. DASAN Tower, 49, Daewangpangyo-ro 644 Beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 KOREA LabelLightSt atusDescription PWRGreen On OffThe system is turned off. The system is turned on. No optical signal, Firmware update fail or other faults. Error rate high. Required to check optic cable routing or vending. ONT normally operating. Loopback test being performed. PON ALM Red Green Orange Orange On No optic signal. On Optic signal normal. Normally registered. Blink On Blink Blink Blink Firmware being downloaded. Do not turn off the unit. Service held after registered normally. ONT not registered. Keep blinking before registration process finished. Red On WLANGreen On WiFi function enabled. Off WiFi function disabled. WPSGreen BlinkIn progress. OnSuccess (for 5 seconds) Off Disabled or process finished. Off Off Link is down. LAN 1~4 Green OnThe 1G port link is up. Blink on the service port. Orange OnThe 10/100M port link is up. Blink on the service port. The 1G transmit or receive activity is present The 10/100M transmit or receive activity is present 2.1 Package Contents 2. Introduction 1 2 3 GPON Port Splice Tray 3 2 1 4 5 6 7 4 5 6 7 1. Caution - This unit is indoor use and all the communication wirings are limited to inside of the building. - Never look directly at the fiber TX port and fiber cable ends when they are powered on. - DO NOT use near water. - DO NOT place near high temperature source. - DO NOT disassemble the unit. - DO NOT operate the unit in a location where the maximum ambient temperature exceeds 104°F. - Open optical connections must use a protective cap under all circumstances to protect against physical damage and dirt. - Avoid impact stresses when handling connectors. Physical damage to the faces of optical connections impairs transmission quality (higher attenuation). - Avoid a bend radius in excess of 1.18 in for fiber optic links. - Check the available voltage supply. - It may only be repaired by authorized service personnel. FCC Certification Requirements ● Caution Any changed or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate this equipment. ● FCC RF exposure requirements The antenna used with this module must be installed to provide a separation distance of at least 20cm from all persons, and must not transmit simultaneously with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. ● User Information This device complies with Part 15 of the FCC`s Rule. Operation is subject to th…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Sep. 04, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, DASAN Networks, Inc. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (G-PON ONT, H660W) Sincerely, Ryu, Yang Sik Manager DASAN Networks, Inc. DASAN Tower, 49, Daewangpangyo-ro644Beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 KOREA

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Sep. 04, 2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAAQH660W We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Ryu, YangSik / Manager Contact information / address: 82-70-7010-1514 / DASAN Tower, 49, Daewangpangyo- ro644Beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 KOREA SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 Sep. 04, 2014 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2AAAQH660W To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - e.g. User Manual - e.g. Ext Photo - e.g. Int Photo - e.g. Test Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title : Ryu, YangSik / Manager Contact information / address : 82-70-7010-1514 / DASAN Tower, 49, Daewangpangyo- ro644Beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 KOREA

DASAN Networks Inc. DASAN Tower, 49, Daewangpangyo-ro 644 Beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Date: Sep 02, 2014 SIEMIC 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: 2AAAQH660W including signing of all documents relating to these matters. Any and all acts carried out by DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from DASAN Networks Inc. . “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, YangSik Ryu Manager

FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 1 FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 2 FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 3

FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 1 FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 2 FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 3 FCC ID: 2AAAQH660W Copyright Ⓒ 2014, DT&C Co., Ltd. View 4 <Antenna>

-~ - - ± &dBm ) - - The MPE calculation for this exposure is shown below. ▪=+- =+ == - ▪S=- = = MHz MPE Calculations : (WLAN: 802.11b) Dasan Networks, Inc. FCCID: 2AAAQH660W Frequency range : 2412 MHz2462 dBm Min. Measured RF output power :dBm Target Power & Tolerance :dBm 15.184 15.00114 Maximum antenna peak gain :dBi Maximum output power for the calculation : 16.00 dBm dB ( Max. 3.30 16 The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the EIRPPGNote 16.00 dBm3.30 dBiP = Power input to the antenna(dBm) 19.30 dBm85.114 mWG = Power gain of the antenna(dBi) Power density at the specific separation EIRP / ( 4 R 2 π ) Note 85.114 / ( 4 X 20 2 X π )S = Maximum power dencity(mW/cm 2 ) The maximum permissible exposure(MPE) of the general population/Uncontrolled for this device is 1.0 mW/cm 2 . 0.016933 mW/cm 2 EIRP = Equivalent Isotropic Radiated Power(mW) R = Distance to the center of the radiation of the antenna(20cm) Conclusion : The exposure condition of this device is compliant with FCC rules. TRF-RF-206(01)140415 -~ - - ± &dBm ) - - The MPE calculation for this exposure is shown below. ▪=+- =+ == P = Power input to the antenna(dBm) 25.30 dBm338.845 mWG = Power gain of the antenna(dBi) The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the EIRPPGNote 22.00 dBm3.30 dBi 20 Maximum antenna peak gain : 3.30 dBi Maximum output power for the calculation : 22.00 dBm 1 dB ( Max. 22 dBm Min. Measured RF output power :21.143 dBm Target Power & Tolerance : 21.00 dBm FCCID: 2AAAQH660WDasan Networks, Inc. MPE Calculations : (WLAN: 802.11g) Frequency range : 2412 MHz2462 MHz - ▪S=- = = The maximum permissible exposure(MPE) of the general population/Uncontrolled for this device is 1.0 mW/cm 2 . 0.067412 mW/cm 2 EIRP = Equivalent Isotropic Radiated Power(mW) R = Distance to the center of the radiation of the antenna(20cm) Conclusion : The exposure condition of this device is compliant with FCC rules. Power density at the specific separation EIRP / ( 4 R 2 π ) Note 338.845 / ( 4 X 20 2 X π )S = Maximum power dencity(mW/cm 2 ) TRF-RF-206(01)140415 -~ - - ± &dBm ) - - The MPE calculation for this exposure is shown below. ▪=+- =+ == P = Power input to the antenna(dBm) 27.30 dBm537.032 mWG = Power gain of the antenna(dBi) The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the EIRPPGNote 24.00 dBm3.30 dBi 22 Maximum antenna peak gain : 3.30 dBi Maximum output power for the calculation : 24.00 dBm 1 dB ( Max. 24 dBm Min. Measured RF output power :22.744 dBm Target Power & Tolerance : 23.00 dBm FCCID: 2AAAQH660WDasan Networks, Inc. MPE Calculations : (WLAN: 802.11n HT20) Frequency range : 2412 MHz2462 MHz - ▪S=- = = The maximum permissible exposure(MPE) of the general population/Uncontrolled for this device is 1.0 mW/cm 2 . 0.106840 mW/cm 2 EIRP = Equivalent Isotropic Radiated Power(mW) R = Distance to the center of the radiation of the antenna(20cm) Conclusion : The exposure condition of this device is compliant with FCC rules. Power density at the specific separation EIRP / ( 4 R 2 π ) Note 537.032 / ( 4 X 20 2 X π )S = Maximum power dencity(mW/cm 2 ) TRF-RF-206(01)140415 -~ - - ± &dBm ) - - The MPE calculation for this exposure is shown below. ▪=+- =+ == P = Power input to the antenna(dBm) 25.30 dBm338.845 mWG = Power gain of the antenna(dBi) The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the EIRPPGNote 22.00 dBm3.30 dBi 20 Maximum antenna peak gain : 3.30 dBi Maximum output power for the calculation : 22.00 dBm 1 dB ( Max. 22 dBm Min. Measured RF output power :20.684 dBm Target Power & Tolerance : 21.00 dBm FCCID: 2AAAQH660WDasan Networks, Inc. MPE Calculations : (WLAN: 802.11n HT40) Frequency range : 2422 MHz2452 MHz - ▪S=- = = The maximum permissible exposure(MPE) of the general population/Uncontrolled for this device is 1.0 mW/cm 2 . 0.067412 mW/cm 2 EIRP = Equivalent Isotropic Radiated Power(mW) R = Distance to the center of the radiation of the antenna(20cm) Conclusion : The exposure condition of this device is compliant with FCC rules. Power density at the specific separation EIRP / ( 4 R 2 π ) Note 338.845 / ( 4 X 20 2 X π )S = Maximum power dencity(mW/cm 2 ) TRF-RF-206(01)140415

DEMC1407-02828 FCC ID: 2AAAQH660W Report No.: DRTFCC1409-1165 TRF-RF-221(00)140218 Page 2 / 102 Copyright ○ C 2014, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1409-1165 Sep. 12, 2014 Initial issue DEMC1407-02828 FCC ID: 2AAAQH660W Report No.: DRTFCC1409-1165 TRF-RF-221(00)140218 Page 3 / 102 Copyright ○ C 2014, DT&C Co., Ltd. Table of Contents 1. EUT DESCRIPTION .................................................................... 4 2. INFORMATION ABOUT TESTING .............................................. 5 2.1 Test mode .......................................................................................................................... 5 2.3 Auxiliary equipment ......................................................................................................... 5 2.4 Tested environment ......................................................................................................... 5 2.5 EMI suppression Device(s) / Modifications ................................................................... 5 3. SUMMARY OF TESTS ................................................................ 6 4. TEST METHODOLOGY .............................................................. 7 4.1 EUT configuration ............................................................................................................ 7 4.2 EUT exercise ..................................................................................................................... 7 4.3 General test procedures .................................................................................................. 7 4.4 Description of test modes ............................................................................................... 7 5. INSTRUMENT CALIBRATION .................................................... 8 6. FACILITIES AND ACCREDITATIONS ........................................ 8 6.1 Facilities ............................................................................................................................ 8 6.2 Equipment ......................................................................................................................... 8 7. ANTENNA REQUIREMENTS ..................................................... 8 8. TEST RESULT ............................................................................ 9 8.1 6dB bandwidth .................................................................................................................. 9 8.2 Maximum peak conducted output power ..................................................................... 23 8.3 Maximum power spectral density ................................................................................. 27 8.4 Out of band emissions at the band edge / conducted spurious emissions ............. 41 8.5 Radiated spurious emissions ....................................................................................... 90 8.6 Power-line conducted emissions ................................................................................. 96 8.7 Occupied bandwidth ...................................................................................................... 99 9. LIST OF TEST EQUIPMENT ................................................... 100 APPENDIX I................................................................................. 101 DEMC1407-02828 FCC ID: 2AAAQH660W Report No.: DRTFCC1409-1165 TRF-RF-221(00)140218 Page 4 / 102 Copyright ○ C 2014, DT&C Co., Ltd. 1. EUT DESCRIPTION FCC Equipment Class Digital Transmission System(DTS) Product G-PON ONT Model Name H660W Add Model Name N/A Power Supply DC 12 V Frequency Range 2.4 GHz Band ▪ 802.11b/g/n(HT20): 2412 MHz ~ 2462 MHz ▪ 802.11n(HT40): 2422 MHz ~ 2452 MHz Modulation Type CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM Transmissions category Completely uncorrelated signal Antenna Specification Antenna type: Internal Antenna Antenna gain ▪ 2.4 GHz Band: ANT 1 : 3.300 dBi & ANT 2 : 3.300 dBi Antenna configuration ▪ 802.11b/g: Single Transmitting (ANT 1) ▪ 802.11n(MCS0 ~ 7) : Single Transmitting (ANT 1 or ANT 2) ▪ 802.11n(MCS8 ~ 15): Multiple Transmitting (ANT 1 and ANT 2) DEMC1407-02828 FCC ID: 2AAAQH660W Report No.: DRTFCC1409-1165 TRF-RF-221(00)140218 Page 5 / 102 Copyright ○ C 2014, DT&C Co., Ltd. 2. INFORMATION ABOUT TESTING 2.1 Test mode Test mode Worst case data rate Tested Frequency(MHz) Lowest Middle Highest TM 1 802.11b 1 Mbps 2412 2437 2462 TM 2 802.11g 6 Mbps 2412 2437 2462 TM 3 802.11n(HT20) MCS 0 2412 2437 2462 TM 4 802.11n(HT40) MCS 0 2422 2437 2452 The worst case data rate for each modulation is determined as above test mode. And all tests conducted in this report were made at the worst case data rate of each modulation. 2.3 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note Laptop X51RL 85N0AS318314227 ASUS FCC DoC - - - - - 2.4 Tested environment Temperature : 23 ~ 24 °C Relative humidity content : 42 ~ 43 % R.H. Details of power supply : DC 12 V 2.5 EMI suppression Device(s) / Modifications EMI suppression device(s) added and/or modifications made during testing → None DEMC1407-02828 FCC ID: 2AAAQH660W Report No.: DRTFCC1409-1165 TRF-RF-221(00)140218 Page 6 / 102 Copyright ○ C 2014, DT&C Co., Ltd. 3. SUMMARY OF TESTS FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 I. Transmitter Mode (TX) 15.247(a) RSS-210 [A8.2] 6 dB Bandwidth > 500 kHz Conducted C 15.247(b) RSS-210 [A8.4] Transmitter Output Power < 1 Watt C 15.247(d) RSS-210 [A8.5] Out of Band Emissions / Band Edge 20 dBc in any 100 kHz BW C 15.247(e) RSS-210 [A8.2] Transmitter Power Spectral Density < 8 dBm / 3 kHz C - RSS Gen [4.6.1] Occupied Bandwidth (99%) RSS-Gen(4.6.1) C 15.205 15.209 RSS-210 [A8.5] General Field Strength Limits (Restricted Bands and Radiated Emission Limits) FCC 15.209 limits Radiated C Note 2 15.207 RSS-Gen [7.2.4] AC Conducted Emissions FCC 15.207 limits AC Line Conducted C 15.203 - Antenna …
