2AABR-ID6382 in 1 Waterproof Bluetooth Speaker + Handset

This product in waterproof construction design with quality speaker sound can enrich and upgrade your lifestyle, enjoy your favor music at anywhere at anytime. Its Bluetooth wireless system can be able to pair with your devices (such as tablets, notebooks, smartphone) easily. Also, built-in microphone can let you talk over the phone while you are in bath. Switch speaker handset Product Description: Hanger Speaker Function key Volume down Volume up Restart the track Play next track Pause/ play DC cable in Before using this unit: Please ensure that the watertight cap of the DC plug is completed closed before using this unit. Trouble attribute to water seeping into the unit from to loosely closed watertight cap are not covered by the warranty. Water droplets that enter the speaker or microphone holes do not cause troubles. However, the product performance may temporarily decrease until the water droplets are dried. Problems may include unclear sound and difficulties in getting your voice clearly. If such circumstances exist, please remove water droplets and dry the product. Product Specifications: Bluetooth version Operating range (maximum) SNR speaker SNR handset Speaker impedance / Output: Handset impedance/ Output Power supply Battery Capacity Current consumption: Continuous standby time: Continuous transmission time: Bluetooth V2.1 +EDR A2DP and AVRCP 10 m (The transmission distance changed depending on the environment where the product is used. 4Ω 36mm 8Ω 30mm 4ohm / 2W 8ohm / 0.25W Built in Li-Polymer 3.7V / 800mAh 200 mA (Max) 180 Hours 8 hours #The actual continuous standby/transmission times may become shorter than those in the specifications depending on the environment or conditions for keeping/using the unit, etc. #Batteries are consumables. The battery service time gradually decreases after the charging and discharging cycles, even if the batteries are used properly. #The battery performance deteriorates quickly if the unit is kept under high temperature conditions. Please keep the unit in a cool, well-ventilated location, away from direct sunlight. Operating Temperature: Operating humidity range: Product size: Weight: Waterproof performance: Number of devices that can be registered 0 °C to – 40 °C 20-80% (no condensation) 65(W) x 151(H) x 40(D)mm 138g IP47 8 Charging the battery: ● Charging the battery from your PC via the USB charging cable included in the package. ● The LED lamp is lit red while the battery is charged. ● The LED lamp is lit green when the battery is fully charged. ● It takes around 1.5 hour to fully charge the battery 1. Connect the USB charging cable to the unit 2. Connet the USB charging cable to your PC * when he battery power is used up, a beeping alarm will sound, with the LED lamp blinking red. After a while, product will turn off Play music: Press to increase the volume. (when up to maximum, it will have ‘Beep~’ sound) Press to decrease the volume. (when up to minimum, it will have ‘Beep ~’ sound) Press to restart the current track. Press twice to play previous track. Press to play next track. Press to pause/ play the track. Press 1. when it is lit green LED, sound source play via handset 2. when it is lit off, sound source play via speaker Hold for 7 seconds to turn off connection of Bluetooth Part 1: pick up call 1. For incoming call, press to pick up the call, you will hear sound via speaker 2. Press (with green LED on), you can hear the sound via handset. Press (with green LED light off) to switch the sound source to speaker 3. Whenever you are hearing sound source via speaker or handset, you can press or to adjust the sound source volume. 4. Press once to have mute function, press once again back to normal. 5. After finish the conversation, please to hang up. **Note: To avoid / reduce echo, please do not turn the speaker to maximum voume. ** The blue light will be blinking for all incoming call. ** The blue light will be blinking when talking via speaker ** The green light button will lit up when talking via handset Part 2: Make a call 1. Hold for 2 seconds to redial the latest call you make. 2. Some smartphones have voice command, press once to enter voice command function with your smartphone. For detail, please refer your smartphone instruction. This performance is different depending on your smartphone setting. 3. After finish the conversation, press to hang up. Part 3: Pick up another incoming call Part 4 reject incoming call: Speaker & handset sound source switching: 1. While you are talking over the phone with another incoming call, press twice to pick up incoming call. 2. Press twice to switch to another party. 3. Press once to hang up the phone. 1. While it is ringing with incoming call, hold to reject the call. 2. If you are playing the song, press once again to continuously playing the song. Press (with green LED on), you can hear the sound via handset. Press (with green LED light off) to hear the sound via speaker. Initializing the registration history / resetting the hardware of product: Under the Off mode, hold & together until it sound a signal with red light. This product is a precision electronic device. Avoid using/keeping this product in a location that is subject to high temperature, high humidity or direct sunlight for many hours. When subject to significant temperature changes in the environment, this product may malfunction due to condensation inside the product. ● Do not leave this product under high temperature conditions. Leaving this product in a hot car cabin for many hours will result in rupture of the built-in battery, sparking, and other troubles, posing significant danger. ● Never leave this product in a car. Static electricity or fouling may cause a malfunction or electric shock. ● Do not touch the metal parts of this product such as the power supply connectors and the charging cable’s connector terminals. Do not repair, modify or disassemble this product on your own, unless operational instructions to the contrar…

Text truncated - open the document above for the full version.

ID Label

Internal photos

Test setup – Radiated Emission Test setup – Conducted Emission
