2AACFPS039Bluetooth Speaker

Bluetooth Nude Super MNot paired ON Quick Start Guide Guide d’Installation Rapide Guía De Inicio Rápido Schnellstartanleitung Contents Contenu Contenido Inhalt Bluetooth Nude Super MNot paired ON 0-30% 2 sec USB NudeAudio Two Year Warranty Disruptive Hong Kong Limited, trading as NudeAudio, warrants this product to be free from defects in workmanship and materials at the point of sale. Subject to this product being used in accordance with its instructions for use, the product shall continue to be free from defects, for a period of two (2) years from the date of original purchase. Any damage or defects caused by a failure to follow the instructions which relate to this product or as the result of an accident, abuse, misuse, misapplication, product modification, faulty ancillary equipment, improper voltage or current, lightning or other acts of God, commercial non-home use, normal wear and tear, shipping damage or loss, damage to digital media players or damage caused by the actions of anyone other than Disruptive Hong Kong Limited are expressly excluded from the warranty stated above. Disruptive Hong Kong Limited will, at its sole election, repair or replace any product that proves to be defective in either or both of workmanship or materials and as covered by this warranty. If the product is no longer manufactured or is out of stock at or after the time Disruptive Hong Kong Limited learns of the warranty claim, Disruptive Hong Kong Limited may, at its sole election, replace your product with a similar product. Disruptive Hong Kong Limited’s liability is limited to the repair or replacement, of any defective product under warranty and any incidental or consequential damages are expressly excluded to the fullest extent permitted by law. This warranty is not transferable and does not extend to users other than the person who originally purchased the product. Nothing in this manual shall limit or exclude liability of Disruptive Hong Kong Limited for death or personal injury resulting from Disruptive Hong Kong Limited’s negligence, for fraud or fraudulent misrepresentation or breach of the terms implied by Section 12 of the Sale of Goods Act 1979. This warranty gives you specific legal rights in addition to the ones afforded you by the laws of your country. This warranty is not intended to operate to limit such legal rights. Australian Consumer Law In Australia, the Trade Practices (Australian Consumer Law) Amendment Regulations 2010 (No. 1) apply. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. Return Policy / Warranty Service Warranty claims will only be valid when proof of purchase is supplied to Disruptive Hong Kong Limited to evidence that the product was purchased from an authorised Disruptive Hong Kong Limited dealer and that the claim is within two (2) years of purchase. To make a warranty claim you must first contact Disruptive Hong Kong Ltd, Rm 2002, 20/F King Palace Plaza, 52A Sha Tsui Road, Tsuen Wan, Hong Kong stating your name, full postal address, contact telephone number, the name of the product and its serial number, date and place of purchase and a detailed description of the problem you are experiencing. If the defect is covered by this warranty then you will be provided with an authorisation number and instructions for return shipment. Where possible, you must send to Disruptive Hong Kong Limited the damaged or defective product. The returned product MUST be accompanied by the original proof of purchase. We highly recommend that you retain a copy of this proof of purchase for your records. Disruptive Hong Kong Limited shall not be responsible for lost or damaged products during shipment. Any product returned without the original proof of purchase will be returned without being examined or tested and such return shall be at the customer’s expense. To avoid any additional charges, all returns and exchanges must include the original packing materials, product box, all included accessories which may include, but not necessarily be limited to, power adapters or power cords, connecting cables, remote controls, adapters, inserts, cards and instruction manuals. The absence of any of the aforementioned items may mean that you incur a charge for their replacement. Disruptive Hong Kong Limited shall not be liable for any indirect or direct consequential loss. UK WARNING To reduce the risk of fire or electric shock, do not expose this unit to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. CAUTION Use of controls or adjustments of performance or procedures other than those specified may result in hazardous radiation exposure. Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. UNPACKING AND INSTALLATION Unpack your unit carefully. We recommend that you save the packaging in case you ever need to store your unit. To avoid damage, never place the unit or its batteries near radiators, in front of heating vents, under direct sunlight or near water. FOR YOUR SAFETY ‒When disconnecting the power supply, pull the plug first. Do not pull the cord by itself. ‒Never handle the power plug with wet hands, as this could cause fire or electric shock. ‒Refer servicing to qualified personnel only. ‒Do not open the housing. ‒Do not twist or pinch the power supply cord. If the plug or power supply cord needs to be replaced, ensure that it complies with the manufacturer’s recommendation. ‒Unplug the unit during lightning storms and when unused for extended periods of time. ‒Where the…

Text truncated - open the document above for the full version.

Model difference The models are Nude SuperM, PS039STD, PS039BKG, PS039CLG, PS039MTG, PS039PTG, PS039PNG, PS039PLG, PS039YLE, PS039MTJ, PS039KCG, PS039KSG, PS039CPG, PS039DSG and PS039NLG, and all models are same product just different surface color and model names. Signature: Name / title: Patrick Tse / Quality Manager Contact information / address:Room 2002, 20/F King Palace Plaza, 52A Sha Tsui Road Tsuen Wan N.T. Hong Kong electrically identicalonly difference is about surface color and model names.

DATE : Sep. 16, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AACFPS039 Product Name: Bluetooth Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Agency agreement expiration date: Sep. 16, 2014 to Sep. 15, 2015 By: Patrick Tse Signature Printed Title: Quality Manager On behalf of : Disruptive Hong Kong Limited Telephone: 852-35683480

LABEL: Model Name:PS039 FCC ID: 2AACFPS039 IC: 11155A‐PS039

The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where z f(GHz) is the RF channel transmit frequency in GHz z Power and distance are rounded to the nearest mW and mm before calculation z The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 3. EUT RF Exposure The Max Conducted Peak Output Power is 3.24dBm (2.11mW) in lowest channel and the Max Conducted Average Output Power is less than 2.11mW. The best case gain of the antenna is 0dBi. 2.11/5*√2.402=0.65 ≤3.0 Conclusion: No SAR test is required.

Report No. : EESZG07160009-2 Page 1 of 38 TEST REPORT Product : Bluetooth Speaker Trade mark : NUDE AUDIO Model/Type reference : Nude SuperM, PS039STD, PS039BKG, PS039CLG, PS039MTG, PS039PTG, PS039PNG, PS039PLG, PS039YLE, PS039MTJ, PS039KCG, PS039KSG, PS039CPG, PS039DSG, PS039NLG Serial number : N/A Ratings : Charging input: 5V, 1A lithium ion battery: 3,7V, IPX5, Class III FCC ID : 2AACFPS039 Report number : EESZG07160009-2 Date : July 29, 2014 Regulations : See below Test Standards Results 47 CFR FCC Part 15 Subpart C 15.247: 2013 PASS Prepared for: Disruptive Hong Kong Limited Room 2002,20/F, King Palace Plaza, 52A Sha Tsui Road, Tsuen Wan, N.T. Hong Kong Prepared by: Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date: July 29, 2014 Jimmy Li Lab manager Check No.: 1702005401 Report No. : EESZG07160009-2 Page 2 of 38 TABLE OF CONTENTS 1. CERTIFICATION INFORMATION ............................................................................................................... 4 2. TEST SUMMARY ........................................................................................................................................ 4 3. MEASUREMENT UNCERTAINTY .............................................................................................................. 5 4. PRODUCT INFORMATION ......................................................................................................................... 5 5. TEST EQUIPMENT LIST ............................................................................................................................. 5 6. SUPPORT EQUIPMENT LIST .................................................................................................................... 5 7. 99% BANDWIDTH MEASUREMENT ......................................................................................................... 6 7.1. LIMITS ................................................................................................................................................. 6 7.2. BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 6 7.3. TEST PROCEDURE ........................................................................................................................... 6 7.4. TEST RESULT .................................................................................................................................... 6 8. 6DB BANDWIDTH MEASUREMENT ......................................................................................................... 9 8.1. LIMITS ................................................................................................................................................. 9 8.2. BLOCK DIAGRAM OF TEST SETUP .................................................................................................. 9 8.3. TEST PROCEDURE ........................................................................................................................... 9 8.4. TEST RESULT .................................................................................................................................... 9 9. POWER SPECTRAL DENSITY ................................................................................................................ 12 9.1. LIMITS ............................................................................................................................................... 12 9.2. BLOCK DIAGRAM OF TEST SETUP ................................................................................................ 12 9.3. TEST PROCEDURE ......................................................................................................................... 12 9.4. TEST RESULT .................................................................................................................................. 12 10. MAXIMUM PEAK CONDUCTED OUTPUT POWER MEASUREMENT .............................................. 15 10.1. LIMITS ............................................................................................................................................... 15 10.2. BLOCK DIAGRAM OF TEST SETUP ................................................................................................ 15 10.3. TEST PROCEDURE ......................................................................................................................... 15 10.4. TEST RESULT .................................................................................................................................. 15 11. CONDUCTED BANDEDGE EMISSION MEASUREMENT ...................................................................... 18 Report No. : EESZG07160009-2 Page 3 of 38 11.1. LIMITS ............................................................................................................................................... 18 11.2. BLOCK DIAGRAM OF TEST SETUP ................................................................................................ 18 11.3. TEST PROCEDURE ......................................................................................................................... 18 11.4. TEST RESULT .................................................................................................................................. 18 12. CONDUCTED SPURIOUS EMISSION MEASUREMENT .................................................................... 20 12.1. LIMITS ............................................................................................................................................... 20 12.2. BLOCK DIAGRAM OF TEST SETUP ................................................................................................ 20 12.3. TEST PROCEDURE ......................................…

Text truncated - open the document above for the full version.
