2AACZ-MSW1A01Smartwatch with BT, WIFI and NFC

i.safe MOBILE GmbH

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 22, 2023
Application Purpose: Original Equipment
Date of Application: Apr 18, 2023
Equipment Note: Smartwatch with BT, WIFI and NFC
Frequency Range: 2412.00000000 - 2472.00000000
Company: i.safe MOBILE GmbH
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

OPERATING MANUAL I S - S W 1.1 MODEL MSW1A01 Document No. 1062MM10REV00 Version: 2022-08-10 (c) 2022 i.safe MOBILE GmbH i.safe MOBILE GmbH i_Park Tauberfranken 10 97922 Lauda-Koenigshofen Germany Tel. +49 9343 60148-0 [email protected] www.isafe-mobile.comTemplate: TEMPMM01REV10 CONTENTS English.............................................................................. 4 This Operating Manual complies with these standards: IEC 60079, IEC 82079, ANSI Z535.6 Diese Bedienungsanleitung erfüllt die Anforderungen der folgenden Normen: IEC 60079, IEC 82079, ANSI Z535.6 4 ENGLISH READ AND UNDERSTAND THE INSTRUCTIONS PROTECT YOUR LIFE AND READ THE OPERATING MANUAL This Operating Manual is part of the device IS-SW1.1 (model MSW1A01). This Operating Manual provides important information for safe use of the device. Before using the device, read this Operating Manual carefully and pay particular attention to the “Safety” section and the warnings highlighted with the warning symbol. Also read the Safety Instructions before using the device. You can find these at www.isafe-mobile.com/en/support/downloads Make sure you have access to this Operating Manual when you need it. You can find the current Operating Manual at www.isafe-mobile.com/en/support/downloads Follow all instructions given on the device and on the packaging. Follow local safety regulations. INTENDED USE The I S -SW1.1 is a Smartwatch for use in explosion hazardous areas of Zone 1/21 and 2/22, in accordance with Directives 2014/34/EU, SI 2016 No. 1107, 1999/92/EC and the IECEx system, among others. Only use the device as described in this Operating Manual. Any other use is considered impro- per and can lead to death, severe injuries and damage to the device. The manufacturer i.safe MOBILE GmbH does not assume any liability for damage caused by improper use. The warranty expires in the event of improper use. EN5 WARRANTY You can find the warranty conditions at www.isafe-mobile.com/en/support/service For any damage caused by computer viruses that you download while using the Internet functions responsibility is at your hand. There is no right of recourse against i.safe MOBILE GmbH. EX MARKINGS ATE X: II 2G Ex ib IIC T4 Gb II 2D Ex ib IIIC T135°C Db EU Type Examination Certificate: EPS 22 ATEX 1 196 X CE-designation: IECEx: Ex ib IIC T4 Gb Ex ib IIIC T135°C Db IECEx Certificate: IECEx EPS 22.0028X UKEX: II 2G Ex ib IIC T4 Gb II 2D Ex ib IIIC T135°C Db EPS 22 UKEX 1 196 X UKCA-designation: Temperature range: -20 °C ... +55 °C (EN/IEC 60079-0) -10 °C ... +55 °C (EN/IEC 62368-1) Manufactured by: i.safe MOBILE GmbH i_Park Tauberfranken 10 97922 Lauda-Koenigshofen Germany 6 DEVICE OVERVIEW/FUNCTIONS 2 3 6 1 5 9 10 8 4 7 EN7 1 TOUCHSCREEN 2 POWER KEY: A long press switches the device on/off. A short press switches the stand- by mode on/off. 3 SIDE KEY RIGHT/MENU KEY: Press to scroll through widgets, features and menus./ Optional function - function can be assigned via Companion App (system integrated in connection with a smartphone). 4 SIDE KEY LEFT/SOS KEY: A long press of the SOS key sends an emergency call to a pre-saved emergency number (only in connection with a smartphone and an installed Lone Worker Protection app). /Optional function - function can be assigned via Com- panion App (system integrated in connection with a smartphone). 5 SENSORS 6 CHARGING CONTACTS 7 WRISTBAND 8 IS-DCSW1.1 DESKTOP CHARGER 9 USB INTERFACE: Connection for the i.safe PROTECTOR 2.0 USB-C Cable or for connec- tion to other devices. Also see sections “Charging” and “Data transfer”. 10 CHARGING CONTACTS 8 SAFETY Read the “Safety” section of this Operating Manual carefully before using the device. If you do not follow these instructions or do not understand them, this could lead to death, severe injuries and damage to the device. USER Only trained users who are qualified in the use of Ex devices in explosion hazardous areas and who have read and understood this Operating Manual may use this device. USE IN EXPLOSION HAZARDOUS AREAS DANGER Improper use can result in death or severe injuries! Only use the device in explosion hazardous areas of zones 1/21 and 2/22 or outside of explosion hazardous areas. Before entering an explosion hazardous area with the device, • make sure that no gap can be seen between the two halves of the device, •make sure the device is not damaged, •make sure that all the labels on the device are readable. If you use the device in an explosion hazardous area, read and follow the instructions in the “Possible User Errors” section. Switch off the device immediately and leave the explosion hazardous area without delay if • malfunctions occur on the device, •you have damaged the housing of the device, •you have exposed the device to excessive loads, •the labels on the device are no longer readable. USE OUTSIDE OF EXPLOSION HAZARDOUS AREAS DANGER Improper use can result in death or severe injuries! Do not use the device in places where its use is prohibited. Make sure you prevent the user errors described in the section entitled “Possible User Errors”. Only charge the device as described in the “Charging” section. DANGER Swallowing of small cells and batteries may lead to burns, perforation of soft tissue and death. Severe burns can occur within 2 hr of ingestion. Keep small cells and batteries which are considered swallowable out of the reach of children. In case of ingestion of a cell or battery, seek medical assistance promptly. EN9 NOTICE Incorrect use can damage the device. Protect the device, the IS-DCSW1.1 Desktop Charger and the Power Adapter from strong electrical magnetic fields as for example those emitted by induction cookers or microwave ovens, for example. Do not touch the touchscreen with sharp objects. POSSIBLE USER ERRORS DANGER Improper use can result in death or severe injuries! Follow the instructions below: Do not open the device. Do not damage the device. Do not loosen the screws on the back of the device. Do not modify the…

Text truncated - open the document above for the full version.

Attestation Statements

i.safe MOBILE GmbH i_Park Tauberfranken 10 97922 Lauda-Koenigshofen Germany Date: 2023-04-12 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AACZ-MSW1A01 US Agent – Attestation Statement / Part 2.911(d)(7) i.safe MOBILE GmbH certifies, that as of 04/12/2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AACZ-MSW1A01. i.safe MOBILE GmbH, accepts to maintain an agent of service of process in theUnitedStatesfor no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment,whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalfofi.safeMOBILE GmbH for FCC ID: 2AACZ-MSW1A01. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: i.safe MOBILE GmbHDesignated Agent: FCC US Agent, LLC Company Representative: Martin haafDesignated Agent Representative: Tim Payne Signature:Signature:

Attestation Statements

i.safeMOBILEGmbH To:FederalCommunicationsCommissionDate:2023/04/12 7435OaklandMillsRoad Columbia,MD21046 USA Attestation Section2.911(d)(5)(i)andSection2.911(d)(5)(ii) (KDB986446D01CoveredEquipment) Section2.911(d)(5)(i) i.safeMOBILEGmbHcertifiesthattheequipmentforwhichauthorizationissoughtis not“covered”equipmentprohibitedfromreceivinganequipmentauthorization pursuanttosection2.903oftheFCCrules. Section2.911(d)(5)(ii) i.safeMOBILEGmbHcertifiesthat,asofthedateofthefilingoftheapplication,the applicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyof itssubsidiariesoraffiliates)asanentityproducing“covered”equipment. TypeofEquipmentsubjecttoFCCCertification:Smartwatch FCCID:2AACZ-MSW1A01 Ifyouhaveanyquestions,pleasefeelfreetocontactme ContactPerson:Martinhaaf PositionintheCompany:Manager DateofSignature:2023-04-12 ___________________________ Signatory (signatureoftheapplicant)

Cover Letter(s)

i.safeMOBILEGmbH Date:2023-04-12 To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 ToWhomItMayConcern: Thei.safeMOBILEGmbH,theundersigned,herebyauthorizesMiss.Wendy ZhanfromShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,toact onthebehalfofthei.safeMOBILEGmbHsolelyinmattersrelatingtothe applicationforanFCCequipmentauthorizationforFCCID:2AACZ-MSW1A01 includingthesigningofdocumentsinconnectionwiththisApplication.Necessary actscarriedoutShenzhenMorlabCommunicationsTechnologyCo.,Ltd.on ourbehalfofthei.safeMOBILEGmbHinconnectionwiththeApplicationshall havethesameeffectasactsofthei.safeMOBILEGmbH.i.safeMOBILEGmbH alsoherebycertifythatnopartytothisapplicationissubjecttoadenialofbenefits, includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof 1988,21U.S.C.862. Thankyouforyourattentiontothismatter. YoursSincerely, Signatory: Contactname:Martinhaaf Title:Manager Tel:+49934360148-11 Email:[email protected] Companyname:i.safeMOBILEGmbH:

Cover Letter(s)

i.safeMOBILEGmbH Date:2023-04-12 To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 Re:RequestofConfidentialityforFCCID:2AACZ-MSW1A01 ToWhomitmayconcern: Pursuanttosections0.457and0.459ofCommission’sRules(CFR47), andSection552(b)(4)oftheFreedomofInformationAct,i.safeMOBILEGmbH herebyrequestsconfidentialityandtreatmentofcertaininformation accompanyingthisapplication.Thematerialscontaintradesecretsand proprietaryinformationnotcustomarilyreleasedtothepublic.Thepublic disclosureofthesemattersmightbeharmfultotheApplicantandprovide unjustifiedbenefitstoitscompetitors. WearealsoherebyrequestShort-TermConfidentialityfor180daysafterthegrant asoutlinedinPublicNoticeDA04-1705.Thisprovisionwillgivei.safeMOBILE GmbHtemporaryconfidentialityofcommerciallysensitiveinformationpriorto productrelease. TherequestedPermanentandShort-TermConfidentialexhibitsarelistedas follows: PERMANENTANDSHORT-TERMCONFIDENTIALLIST ExhibitDescription PERMANENT 1BlockDiagram 2OperationalDescription 3Schematics 4BOM 5Tuneupprocedure SHORT-TERM 6ExternalPhotos 7InternalPhotos 8Test-SetupPhotos 9UserManual TheApplicantunderstandsthatpursuanttoRule0.457,disclosureofthis applicationandallaccompanyingdocumentations,whereapplicable,willnotbe madepublicbeforethedateoftheGrantforthisapplication. Signatory: Name:Martinhaaf Companyname:i.safeMOBILEGmbH Address:i_ParkTauberfranken1097922Lauda-KoenigshofenGermany Tel:+49934360148-11 Email:[email protected]

Cover Letter(s)

i.safe MOBILE GmbH Supplier’sDeclarationOfConformity fortheFCCSDoCProcedure ThefollowingEquipmentadaptFCCSDoCProcedureaccordingtoFCCpart2.906: ProductName:Smartwatch BrandName:i.safeMOBILE ModelNumber:MSW1A01 ReportNumber:SZ22060142E01 It’sherewithconfirmedtocomplywiththerequirementsofFCCPart15Rules. Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Itisunderstoodthateachunitmarketedisidenticaltothedeviceastested,andanychangestothe devicethatcouldadverselyaffecttheemissioncharacteristicswillrequireretest. Thefollowingimporter/responsiblepartyinUnitedStates: NotAvailableatCertificationStage CompanyName:N/A CompanyAddress:N/A Telephone:N/A Fax:N/A Personisresponsibleformarkingthisdeclaration: MartinhaafManager __________________________________________________________________________ Name(Fullname)Position/Title 2023‐04‐12 __________________________________________________________________________ LegalSignatureDate

External Photos

FCC ID: 2AACZ- MSW1A01 IC: 11122A-MSW1A01 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

ID Label/Location Info

Label： location： BackView

Internal Photos

FCC ID: 2AACZ- MSW1A01 IC: 11122A-MSW1A01 Internal Photos 1. EUT uncover view 2. Antenna view WIFI/GPS Antenna Bluetooth Antenna NFC Antenna

RF Exposure Info

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22060142S01 Annex D Plots of Maximum SAR Test Results Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.03.27 WLAN 2.4GHz_802.11b 1Mbps_Front Side_10mm_Ch7 Communication System: UID 0, WLAN 2.4GHz 802.11b (0); Frequency: 2442 MHz;Duty Cycle: 1:1.024 Medium: HSL_2450 Medium parameters used: f = 2442 MHz; σ = 1.808 S/m; ε r = 38.829; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7624; ConvF(7.71, 7.71, 7.71) @ 2442 MHz; Calibrated: 2022.03.31 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE3 Sn373; Calibrated: 2022.12.28 - Phantom: Twin-SAM; Type: QD 000 P41 Ax; Serial: 2020 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) Ch7/Area Scan (61x71x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.145 W/kg Ch7/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.176 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 0.174 W/kg SAR(1 g) = 0.101 W/kg; SAR(10 g) = 0.057 W/kg Maximum value of SAR (measured) = 0.137 W/kg 0 dB = 0.137 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22060142S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2023.03.27 WLAN 2.4GHz_802.11b 1Mbps_Back Side_0mm_Ch1 Communication System: UID 0, WLAN 2.4GHz 802.11b (0); Frequency: 2412 MHz;Duty Cycle: 1:1.024 Medium: HSL_2450 Medium parameters used: f = 2412 MHz; σ = 1.762 S/m; ε r = 38.862; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7624; ConvF(7.71, 7.71, 7.71) @ 2412 MHz; Calibrated: 2022.03.31 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE3 Sn373; Calibrated: 2022.12.28 - Phantom: Twin-SAM; Type: QD 000 P41 Ax; Serial: 2020 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) Ch1/Area Scan (61x71x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.164 W/kg Ch1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.146 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 0.221 W/kg SAR(1 g) = 0.111 W/kg; SAR(10 g) = 0.058 W/kg Maximum value of SAR (measured) = 0.158 W/kg 0 dB = 0.158 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22060142S01

RF Exposure Info

Annual validation for test lab. Appendix Annual validation for Test Lab. General calibration information Date 2022.12.15 Test Laboratory ShenZhen Morlab Communications Technology Co., Ltd. Antenna serial No. D2450V2-SN: 805 Antenna Parameters with Head TSL Impedance, transformed to feed point 50.661Ω-5.59jΩ Return Loss -23.203dB General Antenna Parameters and Design Electrical Delay (one direction) 1.276 ns After long term use with 100W radiated power，only a slight warming of the dipole near the feed point can be measured The dipole is made of standard semirigid coaxial cable. The center conductor of the feeding line is directly connected to the second arm of the dipole. The antenna is therefore short-circuited for DC-signals. On some of the dipoles, small end caps are added to the dipole arms in order to improve matching when loaded according to the position as explained in the "Measurement Conditions" paragraph. The SAR data are not affected by this change. The overall dipole length is still according to the Standard No excessive force must be applied to the dipole arm， because they might bend or the soldered connections near the feed point may be damaged . Annual validation for test lab. Annual validation for test lab. Appendix Impedance Measurement Plot for Head TSL

RF Exposure Info

REPORT No.：SZ22060142S01 NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 34 TEST REPORT MANUFACTURER :i.safe MOBILE GmbH PRODUCT NAME :Smartwatch MODEL NAME :MSW1A01 BRAND NAME :i.safe MOBILE MARKETING NAME : IS-SW1.x ("x" represents a variable, it may be 1, 2, 3, RG, M1 etc.) FCC ID :2AACZ- MSW1A01 STANDARD(S) : FCC 47 CFR Part 2(2.1093) IEEE 1528-2013 RECEIPT DATE :2023-02-14 TEST DATE :2023-03-27 ISSUE DATE :2023-04-12 Edited by: Xie Yiyun (Rapporteur) Approved by: Shen Junsheng(Supervisor) REPORT No.：SZ22060142S01 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 34 DIRECTORY 1. SAR Results Summary .............................................................................................. 4 2. Technical Information ................................................................................................ 5 2.1. Applicant and Manufacturer Information ............................................................... 5 2.2. Equipment under Test (EUT) Description .............................................................. 5 2.3. Environment of Test Site ......................................................................................... 6 3. Specific Absorption Rate (SAR) ............................................................................... 7 3.1. Introduction .............................................................................................................. 7 3.2. SAR Definition .......................................................................................................... 7 4. RF Exposure Limits ................................................................................................... 8 4.1. Uncontrolled Environment ...................................................................................... 8 4.2. Controlled Environment ........................................................................................... 8 4.3. RF Exposure Limits .................................................................................................. 8 5. Applied Reference Documents ................................................................................. 9 6. SAR Measurement System ...................................................................................... 10 6.1. E-Field Probe .......................................................................................................... 11 6.2. Data Acquisition Electronics (DAE) ...................................................................... 12 6.3. Robot ....................................................................................................................... 12 6.4. Measurement Server .............................................................................................. 12 6.5. Light Beam Unit ...................................................................................................... 13 6.6. Phantom .................................................................................................................. 13 6.7. Device Holder ......................................................................................................... 13 6.8. Data Storage and Evaluation ................................................................................. 14 6.9. Test Equipment List ............................................................................................... 17 7. Tissue Simulating Liquids ....................................................................................... 18 8. SAR System Verification ......................................................................................... 20 9. EUT Testing Position ............................................................................................... 22 9.1. SAR Evaluations near the Mouth/Jaw Regions of theSAM ................................. 22 9.2. Limb-worn Accessory Configurations .................................................................. 22 10. Measurement Procedures ..................................................................................... 23 10.1. Spatial Peak SAR Evaluation.............................................................................. 24 10.2. Power Reference Measurement ......................................................................... 24 10.3. Area & Zoom Scan Procedures .......................................................................... 24 REPORT No.：SZ22060142S01 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 34 10.4. Volume Scan Procedures ................................................................................... 25 10.5. SAR Averaged Methods ...................................................................................... 26 10.6. Power Drift Monitoring ........................................................................................ 26 11. Conducted RF Output Power .............................…

Text truncated - open the document above for the full version.

Test Report

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 72 REPORT No.：SZ22060142W01 TEST REPORT APPLICANT : i.safe MOBILE GmbH PRODUCT NAME : Smartwatch MODEL NAME : MSW1A01 MARKETING NAME : IS-SW1.x ("x" represents a variable, it may be 1, 2, 3, RG, M1 etc.) BRAND NAME :i.safe MOBILE FCC ID :2AACZ- MSW1A01 STANDARD(S) :47 CFR Part 15 Subpart C RECEIPT DATE : 2022-06-29 TEST DATE :2023-02-09 to 2023-03-23 ISSUE DATE :2023-04-10 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 72 REPORT No.：SZ22060142W01 DIRECTORY 1. Summary of Test Result ················································································ 4 1.1. Testing Applied Standards ·········································································· 5 1.2. Test Equipment List ··················································································· 6 1.3. Measurement Uncertainty ··········································································· 8 1.4. Testing Laboratory ····················································································· 8 2. General Description ····················································································· 9 2.1. Information of Applicant and Manufacturer ··················································· 9 2.2. Information of EUT ····················································································· 9 2.3. Channel List of EUT ·················································································· 10 2.4. Test Configuration of EUT ·········································································· 11 2.5. Test Conditions ························································································ 11 2.6. Test Setup Layout Diagram ········································································ 11 3. Test Results ······························································································· 14 3.1. Antenna Requirement ··············································································· 14 3.2. Duty Cycle of Test Signal ··········································································· 15 3.3. Maximum Peak Conducted Output Power ···················································· 16 3.4. Maximum Average Conducted Output Power ··············································· 17 3.5. 6 dB Bandwidth ························································································ 18 3.6. Conducted Spurious Emissions and Band Edge ··········································· 19 3.7. Power Spectral Density ············································································· 20 3.8. Conducted Emission ················································································· 21 3.9. Restricted Frequency Bands ······································································ 22 3.10. Radiated Emission ···················································································· 23 Annex A Test Data and Result ·········································································· 25 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 72 REPORT No.：SZ22060142W01 Change History Version Date Reason for change 1.0 2023-04-10 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 72 REPORT No.：SZ22060142W01 1. Summary of Test Result No. Section Description Test Date Test Engineer Result Method Determination /Remark 1 15.203 Antenna Requirement N/A N/A PASS No deviation 2 N/A Duty Cycle of Test Signal Feb. 28, 2023 He Yuyang PASS No deviation 3 15.247(b) Maximum Peak Conducted Output Power Feb. 28, 2023 He Yuyang PASS No deviation 4 15.247(b) Maximum Average Conducted Output Power Feb. 28, 2023 He Yuyang PASS No deviation 5 15.247(a) Bandwidth Feb. 28, 2023 He Yuyang PASS No deviat…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Martin haaf

[email protected]+49 9343 60148-11Fax: +49 9343 60148-99

Test Firm

Shenzhen Morlab Communications Technology Co. Ltd.Mr. Su Feng

[email protected]+86 755 36698566

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.47 GHz	126.20 mW

Confidentiality

Long Term

Grant Notes

Output power is maximum Peak conducted. This device supports IEEE 802.11 b/g/n 20 MHz channel bandwidths. This device has integrated DXX and DTS transmitters certified under the same FCC ID. SAR compliance for body-worn operating configurations is limited to the belt- clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 10 mm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for next to mouth and simultaneous transmission use conditions are 0.13 W/kg and 0.15 W/kg, respectively.
