2AAD8-WU331300M Mini Wireless USB Adapter

1 / 36 Wireless 802.11b/g/n USB Adapter User Manual 2 / 36 C h a p t e r 1 : I n t r o d u c t i o n ... ... ... ... ... ... ... ... ... ... ... ... ... ....... ... ... ....3 1.1 Pr odu ct F eat u r es........................ ......... ..................................... .............3 1.2 Pac kage C on t e n t s.............................. .................................... ................3 1.3 Indicat or Descr ipt ion............................................................................3 CHAPTER 2 : Quic k Insta llation Guide.....................................4 2.1 Dr iver Inst allat ion..................................................................................4 2.2 Connect to Wireless Access Point.......................................................7 2.2.1 Using Client Utility..............................................................................7 2.2.2 Using Windows Zero Configuration.................................................12 CHAPTER 3: Client Utility........................................................16 3.1 Connection Profile Management..........................................................16 3.1.1 Add a new profile................................................................................17 3.1.2 Remove an existing profile................................................................19 3.1.3 Edit an existing profile........................................................................20 3.1.4 Make a copy of existing profile........................................................21 3.1.5 Set as default profile..........................................................................21 3.2 View Network Statistics, General Information, and Status..........22 3.2.1 General Information............................................................................22 3.2.2 Status.....................................................................................................23 3.2.3 View Network Statistics......................................................................23 3.3 Miscellaneous Settings............................................................................24 3.4 Establish secure connection with AP by WPS.....................................25 3.4.1 PIN Code.................................................................................................27 3.4.2 Push Button............................................................................................28 CHAPTER 4 Soft AP Function....................................................29 4.1 Switch to AP Mode and Station Mode..................................................29 4.1.1 Configure SSID and Channel.............................................................31 4.1.2 Setup Soft-AP Security.......................................................................32 4.2 Advanced Settings...................................................................................33 4.3 Wireless Statistics.....................................................................................34 4.4 Internet Connection Sharing (ICS).......................................................35 CHAPTER 5: Troubleshooting..................................................35 3 / 36 Chapter 1. Introduction Thank you for purchasing the wireless 802.11b/g/n USB adapter! This adapter is mini size design and you are able to plug it into the USB port. Excepting common wireless standards 802.11b/g, this wireless adapter is also 802.11n compatible - data transfer rate is 150/300Mbps, and that’s three times faster than 802.11g wireless network! 1.1 Product Features ◆ Complies with IEEE 802.11n, IEEE 802.11g and IEEE 802.11b standards ◆ Provides USB2.0 port ◆ Provides 150/300Mbps receiving rate and 150/300Mbps sending rate ◆ Supports 20MHz/40MHz frequency width ◆ Auto-detects and changes the network transmission rate ◆ Provides two work modes: Infrastructure and Ad-Hoc ◆ Supports Soft AP to establish your wireless LAN networking ◆ Supports 64/128-bit WEP, WPA, WPA2 encryption methods and 802.1x security authentication standard ◆ Supports WPS (Wi-Fi Protected Setup) encryption method to free you from remembering long passwords ◆ Easy-to-install, plug and play ◆ Supports Windows XP/VISTA/Win7/Win8/Linux/Macintosh 1.2 Package contents The following contents should be found in your box: ◆ One Wireless 802.11b/g/n USB adapter ◆ One CD (include driver/utility/user manual) Note: If any of the listed contents are damaged or missing, please contact the retailer from whom you purchased the product for assistance. 1.3 Indicator Description There is a LED indicator blinking when data communication is going on. 4 / 36 CHAPTER 2: Quick Installation Guide This chapter is to assist you how to use the included CD-ROM which comprises the Driver and the Client Utility Interface. 2.1 Driver Installation Please follow the following instructions to install your new wireless USB Adapter: 2.1.1 Insert the USB wireless network card into an empty USB 2.0 port of your computer when computer is switched on. Never use force to insert the card, if you feel it’s stuck, flip the card over and try again. 2.1.2 The following message will appear on your computer, click ‘Cancel / Close’. Under Windows XP Under Windows Vista and Windows 7 5 / 36 2.1.3 Insert the driver CD into your CD-ROM. You can see autorun screen below. if not, you can double click ‘autorun.exe’ on CD. Click ‘Install Driver’ to start the installation procedure 2.1.4 Installation descriptions shown. Click ‘Next’ to continue 6 / 36 2.1.5 Once the installation is finished the computer will be asked to reboot. you can click ‘Finish’ and reboot the computer to finish the installation of driver files. 2.1.6 A new icon will appear near the clock of system tray: Left-click the icon will launch wireless network configuration utility, and you can right-click the icon to show the quick menu of configuration utility. This icon also uses different color to show th…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD 2014-06-18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product name: 300M Mini Wireless USB Adapter Model No.: WU331EU, WU330EU, WU3XXEU, WU1XXETV FCC ID: 2AAD8-WU331 Sincerely, Client’s signature Client’s name / title: Joliam zhong / R&D Manager Contact information / address: 3/F Building A1, Junfeng Industrial Park, Yonghe Road, Fuyong, Baoan District, Shenzhen, Guangdong, China SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD 2014-06-18 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): Product name: 300M Mini Wireless USB Adapter Model No.: WU331EU, WU330EU, WU3XXEU, WU1XXETV FCC ID: 2AAD8-WU331 We affirm that between SIEMIC, Inc. and HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title: Joliam zhong / R&D Manager Contact information / address: 3/F Building A1, Junfeng Industrial Park, Yonghe Road, Fuyong, Baoan District, Shenzhen, Guangdong, China

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD 2014-06-18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAD8-WU331 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title: Joliam zhong / R&D Manager Contact information / address: 3/F Building A1, Junfeng Industrial Park, Yonghe Road, Fuyong, Baoan District, Shenzhen, Guangdong, China SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 HAOLIYUAN(SHENZHEN) ELECTRONIC CO.,LTD 2014-06-18 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2AAD8-WU331 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days. - User Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature Client’s name / title: Joliam zhong / R&D Manager Contact information / address: 3/F Building A1, Junfeng Industrial Park, Yonghe Road, Fuyong, Baoan District, Shenzhen, Guangdong, China

External Photos

label and label location FCC ID: 2AAD8-WU331

Internal Photos Antenna

FCC ID : 2AAD8-WU331 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 D01 General RF Exposure Guidance v05, section 4.3.1 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 802.11b 802.11g Frequency (MHz) Peak Output Power of Chain 1 (dBm) Peak Output Power of Chain 2 (dBm) Peak Output Power of Chain 1 (mW) Peak Output Power of Chain 2 (mW) Calculation Value of Chain 1 Calculation Value of Chain 2 Threshold Value 2412 1.64 1.55 1.459 1.429 0.453 0.444 3.0 2437 1.73 1.73 1.489 1.489 0.465 0.465 3.0 2462 1.76 1.75 1.500 1.496 0.471 0.469 3.0 Frequency (MHz) Peak Output Power of Chain 1 (dBm) Peak Output Power of Chain 2 (dBm) Peak Output Power of Chain 1 (mW) Peak Output Power of Chain 2 (mW) Calculation Value of Chain 1 Calculation Value of Chain 2 Threshold Value 2412 2.65 2.66 1.841 1.845 0.572 0.579 3.0 2437 2.66 2.27 1.845 1.687 0.576 0.527 3.0 2462 2.38 2.52 1.730 1.786 0.543 0.560 3.0 802.11n20 802.11n40 802.11n20 Total Peak Power Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Calculation Value Threshold Value 2412 4.72 2.97 0.923 3.0 2437 4.58 2.87 0.896 3.0 2462 4.31 2.70 0.847 3.0 802.11n40 Total Peak Power Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Calculation Value Threshold Value 2422 3.48 2.23 0.694 3.0 2437 3.58 2.28 0.712 3.0 2452 3.77 2.38 0.745 3.0 Threshold at which no SAR required is ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A Frequency (MHz) Peak Output Power of Chain 1 (dBm) Peak Output Power of Chain 2 (dBm) Peak Output Power of Chain 1 (mW) Peak Output Power of Chain 2 (mW) Calculation Value of Chain 1 Calculation Value of Chain 2 Threshold Value 2412 1.86 1.56 1.535 1.432 0.477 0.445 3.0 2437 1.41 1.72 1.384 1.486 0.432 0.464 3.0 2462 1.23 1.38 1.327 1.374 0.416 0.431 3.0 Frequency (MHz) Peak Output Power of Chain 1 (dBm) Peak Output Power of Chain 2 (dBm) Peak Output Power of Chain 1 (mW) Peak Output Power of Chain 2 (mW) Calculation Value of Chain 1 Calculation Value of Chain 2 Threshold Value 2422 0.62 0.32 1.153 1.076 0.359 0.335 3.0 2437 0.48 0.65 1.117 1.161 0.349 0.362 3.0 2452 0.82 0.68 1.208 1.169 0.379 0.367 3.0
