2AAGF-WILLENPortable Loudspeaker

QUICK START GUIDEMARSHALLHEADPHONES.COM WILLEN – PORTABLE LOUDSPEAKER GETTING STARTED 001. PUSH AND HOLD THE CONTROL KNOB UNTIL THE SPEAKER TURNS ON. 002. PUSH AND HOLD THE BLUETOOTH ® BUTTON UNTIL THE LED TURNS TO A SLOW RED PULSE. 003. SELECT WILLEN FROM YOUR AUDIO DEVICE’S BLUETOOTH LIST. h_Iggy_QSG-COVER_2022-02-08_R1_0.indd 1-3h_Iggy_QSG-COVER_2022-02-08_R1_0.indd 1-32022-02-08 14:482022-02-08 14:48 DOWNLOAD THE MARSHALL BLUETOOTH APP TO GET THE MOST OUT OF YOUR SPEAKER. 3 4 2 5 6 1 Design of device and packaging are intellectual properties of Zound Industries International AB and Marshall Amplification Plc. © All Rights Reserved. MARSHALL, Marshall Amps, their respective logos, “Marshall” and “Marshall” trade dress are trademarks and intellectual property of Marshall Amplification Plc and may not be used without permission. Permission granted to Zound Industries Int ernational AB. The Bluetooth ® wordmark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Zound Industries International AB is under license. Go ogle Play is a trademark of Google LLC. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. R1.0 7 + 6 h_Iggy_QSG-COVER_2022-02-08_R1_0.indd 4-6h_Iggy_QSG-COVER_2022-02-08_R1_0.indd 4-62022-02-08 14:492022-02-08 14:49 ENGLISH GETTING STARTED 001. Push and hold the control knob until the speaker turns on. 002. Push and hold the Bluetooth button until the LED turns to a slow red pulse. 003. Select WILLEN from your audio device’s Bluetooth ® list. 1 USB-C POWER INPUT Charge the speaker by plugging it into a USB power source. 2 FASTENING STRAP Unhook the lower-right side of the strap by stretching it gently. 3 BLUETOOTH BUTTON Push and hold the Bluetooth button until the LED turns to a slow red pulse to start pairing mode. 4 MICROPHONE The microphone lets you to use Willen as a speaker phone. Push the Bluetooth button to toggle the call between Willen and your phone. 5 BATTERY INDICATOR The 5 segment battery indicator shows the battery charge. 6 CONTROL KNOB I. Push and hold to turn on/off II. Push once to play/pause III. Push right/left to skip forward/back IV. Hold right/left to fast forward/rewind V. Hold upwards/downwards to adjust the volume VI. Push once to answer or end a call VII. Push twice to reject a call 7 STACK MODE Connect two or more Willen speakers in a Stack session for a bigger sound. MAIN SPEAKER Triple press the Bluetooth button to start or end a Stack session. ADDITIONAL SPEAKER Double press the Bluetooth button on any speaker you want to add to or remove from the session. Download the Marshall Bluetooth app to get the most out of your speaker. The full user manual is available in the app or at marshallheadphones.com 001 BULGARIAN – БЪЛГАРСКИ ЕЗИК ARABIC – العربية НАЧАЛО 001. Натиснете и задръжте бутона за управление, докато високоговорителят се включи. 002. Натиснете и задръжте бутона за Bluetooth, докато светодиодът започне да примигва бавно с червена светлина. 003. Изберете WILLEN от списъка с Bluetooth ® на Вашето звуково устройство. البدء 001 . .اضغط مع الاستمرار على مقبض التحكم حتى يتم تشغيل مكبر الصوت 002 . .إلى وميض أحمر بطيء LED ل مؤشر ّ حتى يتحو Bluetooth اضغط مع الاستمرار على زر 003 ..بأجهزتك الصوتية Bluetooth ® من قائمة WILLEN د ّ حد 1 USB-C ВХОД ЗА ЗАХРАНВАНЕ Заредете високоговорителя, като го вк лючите в USB източник на захранване. 2 ЗАТЯГАЩ РЕМЪК Откачете долната дясна страна на ремъка, като го разтегнете внимателно. 3 БУТОН BLUETOOTH Натиснете и задръжте бутона за Bluetooth, докато светодиодът започне да примигва бавно с червена светлина, за да стартирате режим на сдвояване. 4 МИКРОФОН Микрофонът Ви позволява да използвате Willen като високоговорител. Натиснете бутона Bluetooth, за да превк лючите повикването меж ду Willen и Вашия телефон. 5 ИНДИК АТОР ЗА БАТЕРИЯ Индикаторът за нивото на батерията с 5 сегмента показва зареждането на батерията. 6 КОПЧЕ ЗА УПРАВЛЕНИЕ I. Натиснете и задръжте за вк лючване или изключване II. Натиснете веднъж за възпроизвеждане/пауза III. Натиснете надясно/наляво за прескачане напред/назад IV. Задръжте надясно/наляво за бързо превъртане напред/назад V. Задръжте нагоре/надолу за регулиране на силата на звукаe VI. Натиснете веднъж, за да отговорите или приключите обаждане VII. Натиснете два пъти, за да отхвърлите обаждане 7 РЕЖИМ STACK Свързва два или повече високоговорители Willen в Stack сесия за по-мощен звук. ОСНОВЕН ВИСОКОГОВОРИТЕЛ Натиснете три пъти бутона Bluetooth, за да започнете или приключите Stack сесия. ДОПЪЛНИТЕЛЕН ВИСОКОГОВОРИТЕЛ Натиснете двукратно бутона Bluetooth на всеки един от високоговорителите, който искате да добавите или премахнете от сесията. 6 مقبض التحكم I .اضغط مع الاستمرار للتشغيل أو إيقاف التشغيل II .اضغط مرة واحدة الإيقاف المؤقت/ للتشغيل III .للخلف/ي للأمام ّ ا للتخط ً يسار/ا ً اضغط يمين IV .الترجيع السريع/ا للتقديم ً يسار/ا ً اضغط يمين V .لأسفل لضبط /اضغط لأعلى مستوى الصوت VI .اضغط مرة واحدة للرد على مكالم إنهائهاx ة أو VII .اضغط مرتين لرفض مكالمة 7 STACK وضع قم بتوصيل اثنين أو أكثر من مكبرات صوت للحصول على Stackفي جلسة Willen . أكبر ٍ صوت مكبر الصوت الرئيسي لبدء أو Bluetooth اضغط ثلاث مرات على زر .Stack إنهاء جلسة مكبر الصوت الإضافي في أي مكبر Bluetooth اضغط مرتين على زر .صوت تريد إضافته أو إزالته من الجلسة 1 للطاقة USB-C مقبض التحكممدخل اشحن مكبر الصوت عن طريق توصيلها .USB بمصدر طاقة 2 حزام التثبيت ك الجانب الأيمن السفلي من الحزام عن ِ ف ه برفق. ّ طريق شد 3 BLUETOOTH زر حتى Bluetooth اضغط مع الاستمرار على زر بطيء إلى وميض أحمرLED يتحول مؤشر .لبدء وضع الاقتران 4 الميكرفون Willenتيح لك الميكروفون استخدام ُ ي Bluetooth زر اعة هاتف. اضغط على ّ كسم . وهاتفكWillen لتبديل المكالمة بين 5 مؤشر البطارية شرطات 5 م إلى َّ قس ُ ظهر مؤشر البطارية الم ُ ي .نسبة شحن البطارية Изтеглете приложението Marshall Bluetooth, за да извлечете максимума от Вашия високоговорител. Пълното ръководство за потребителя е достъпно в приложението или на marshallheadphones.com لتحقيق Marshall Bluetooth ل تطبيق ّ نز ر الصوت لديك. ّ كب ُ أق…

Text truncated - open the document above for the full version.

Rev 11/20/07 (Zound Industries International AB) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AAGF-WILLEN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (Block Diagram, Schematics, Operational Description, BOM, PCB Layout) (Block Diagram, Schematics, Operational Description, BOM, PCB Layout) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Short-term confidentiality period: 180 days Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (External Photos, Test Setup Photos, Manual, Internal Photos) (External Photos, Test Setup Photos, Manual, Internal Photos,) Sincerely, (signature) (printed name) Edison Xu

Zound Industries International AB Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2022-02-16 SUBJECT: 2AAGF-WILLEN To Whom It May Concern: I, the undersigned, hereby states this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules, and will apply the Supplier's Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. I understand the following FCC requirements: 1. Devices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.) 2. Pt 2.1077 contains the list of information that must be included in the Supplier's Declaration of Conformity, which must be supplied with each product sold. The SDoC compliance info shall be included in the User’s Manual or as a separate sheet. The info must contain the name, address, and phone number of the responsible party, which must be located within the United States. According to 2.909(b), the responsible party is either the Manufacturer or if the product is imported the Importer. Regards, Zound Industries International AB Signed ------------------------------- （Edison Xu）

Z:\8. 华信认证案件（Certificated project）\2021\A-G\D\东威\HQ211126EL31-STOCKWELL II BLUETOOTH报备模组\02 EMC 电磁兼容\05 Confirmed Document 确认文件\FCC ID签字文件\POA_Letter.docx (Zound Industries International AB) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2022-01-18 SUBJECT: FCC Application for (FCC ID: 2AAGF-STOCKIIBT) To Whom It May Concern: We, the undersigned, hereby authorize _Harry Li at Hwa-Hsing (Dongguan) Testing Co., Ltd._ on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by _ Harry Li at Hwa-Hsing (Dongguan) Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Edison Xu Signed (Must be signed by the person that is listed on the FCC Website)

Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 1 of 5 Project No.: 210427EL31-2 External EUT Photo Test models: WILLEN Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 2 of 5 Project No.: 210427EL31-2 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 3 of 5 Project No.: 210427EL31-2 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 4 of 5 Project No.: 210427EL31-2 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 5 of 5 Project No.: 210427EL31-2

Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 1 of 6 Project No.: 210427EL31-1 EUT Photos Test Model: WILLEN Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 2 of 6 Project No.: 210427EL31-1 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 3 of 6 Project No.: 210427EL31-1 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 4 of 6 Project No.: 210427EL31-1 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 5 of 6 Project No.: 210427EL31-1 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.3 Page 6 of 6 Project No.: 210427EL31-1 BT ANT

Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.4 Page 1 of 7 Test Report No.: 210427EL31-SE-US-01 RF Exposure Report FCC ID: 2AAGF-WILLEN Applicant: Zound Industries International AB Address: Centralplan 15 SE-111 20 Stockholm Sweden Manufacturer: Zound Industries International AB Address: Centralplan 15 SE-111 20 Stockholm Sweden Product: Portable Loudspeaker Brand: Marshall Test Model(s): WILLEN Series Model(s): N/A Test Date: Jan. 12, 2022 ~ Feb. 11, 2022 Issued Date: Feb. 11, 2022 Issued By: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Test Firm Registration No.: 915896 Standards: FCC Part 2 (Section 2.1091); KDB 447498 D01; IEEE C95.1 The above equipment has been tested by Hwa-Hsing (Dongguan) Testing Co., Ltd., and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : Reviewed by : Candy Zhang/ Report Engineer Tank tan/ Project Engineer Approved by : Harry Li/ Technical Director This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification.The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the federal government.The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.4 Page 2 of 7 Test Report No.: 210427EL31-SE-US-01 Table of contents Release control record................................................................................................ 3 1 General Information ......................................................................................... 4 1.1 General Description of EUT ............................................................................. 4 2 Evaluation of SAR Testing Exclusion ............................................................... 5 3 Evaluation Result ............................................................................................. 6 Appendix – Information on the Testing Laboratories .................................................... 7 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.4 Page 3 of 7 Test Report No.: 210427EL31-SE-US-01 Release control record Issue No. Reason for change Date issued 210427EL31-SE-US-01 Original Release Feb. 13, 2022 Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.4 Page 4 of 7 Test Report No.: 210427EL31-SE-US-01 1 General Information 1.1 General Description of EUT Product Portable Loudspeaker Brand Marshall Test Model(s) WILLEN Series Model(s) N/A Status of EUT Engineering Prototype Power Supply Rating DC 3.7V from Li-ion Battery or DC 5V from USB port Modulation Type GFSK, π/4DQPSK,8DPSK Transfer Rate 1/2/3Mbps Operating Frequency 2402 ~ 2480MHz Number of Channel BLE: 40 EDR: 79 Output Power（AVG） 6.57dBm Antenna Type FPCB Antenna Antenna Gain 3.69dBi Maximum peak Gain Antenna Connector N/A Accessory Device N/A Cable Supplied USB Cable: Unshielded, 50cm Note: 1. Please refer to the EUT photo document (Reference No.: 210427EL31-1&-2) for detailed product photo. 2. The above EUT information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. Lab: Hwa-Hsing (Dongguan) Testing Co., Ltd. Address: No.101, Bld N1, Yuyuan 2Rd, Yuyuan Industrial Park, HuangJiang Town, Dongguan, China Tel: 0769-83078199 Web.: www.hwa-hsing.com E-Mail: [email protected] Release Ver. 1.4 Page 5 of 7 Test Report No.: 210427EL31-SE-US-01 2 Evaluation of SAR Testing Exclusion Following FCC KDB 447498 D01 “General SAR test exclusion guidance” The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 …
