2AAIN-MNTORCHMONSTER TORCH

VCC for Amplifier 3.3V for System Power Supply 15V/ 1.5A 3.3V for BT On/Off Switch Circuit Signal Control Power 4 OHM Class D AMP 1x 15W @THD=1% I2S LED/Light Button I2C Audio Processor + MCU AP5064 BT clasiic AC6905C Aux-in Port DWHP83 UART GPIO DC-DC 5V for MCU LDO LDO 2402-2480MHz L/R Switch I2S I2S 5736MHz 2402-2480MHz 22M BLE MT2000 Battery (Out er) 2200ma/3.7V x 3 AC In 100V- 240V 16M 32.768 KHz

ACOUSTMAX INTERNATIONAL CO., LTD Agent Authorization Letter 2020-11-26 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen Huaxia Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Zhi yun Wu Position: Manager Company Name: ACOUSTMAX INTERNATIONAL CO., LTD Address: Unit D16/F Cheuk Nang Plaza 250 Hennessy Road Wanchai HongKong Tel / Fax 13510365603 / 852-25301919 E-Mail: [email protected]

Declaration statement Letter 2020-11-26 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Declaration statement Letter To Whom It May Concern: We hereby declare that (FCC ID: 2AAIN-MNTORCH) fulfill the requirements of 47 CFR Part 15C Section 15.247(g) & 15.247(h). Compliance for section 15.247(g) According to Bluetooth Core Specification, the Bluetooth system transmits the packet with the pseudorandom hopping frequency with a continuous data and the short burst transmission from the Bluetooth system is also transmitted under the frequency hopping system with the pseudorandom hopping frequency system. Compliance for section 15.247(h) According to Bluetooth Core specification, the Bluetooth system incorporates with an adaptive system to detect other user within the spectrum band so that it individually and independently to avoid hopping on the occupied channels. According to the Bluetooth Core specification, the Bluetooth system is designed not have the ability to coordinated with other FHSS System in an effort to avoid the simultaneous occupancy of individual hopping frequencies by multiple transmitter. Please contact me if there is any information you may need. Sincerely, Name: Zhi yun Wu Position: Manager Company Name: ACOUSTMAX INTERNATIONAL CO., LTD Address: Unit D16/F Cheuk Nang Plaza 250 Hennessy Road Wanchai HongKong Tel / Fax 13510365603 / 852-25301919 E-Mail: [email protected]

ACOUSTMAX INTERNATIONAL CO., LTD Long Term Confidentiality Request Letter 2020-11-26 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (FCC ID: 2AAIN-MNTORCH) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - e.g. Block diagram - e.g. SCH - e.g. Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Name: Zhi yun Wu Position: Manager Company Name: ACOUSTMAX INTERNATIONAL CO., LTD Address: Unit D16/F Cheuk Nang Plaza 250 Hennessy Road Wanchai HongKong Tel / Fax 13510365603 / 852-25301919 E-Mail: [email protected]

Model difference letter 2020,11,26 Dear MET Reviewer, This is a new Application from ACOUSTMAX INTERNATIONAL CO., LTD Model No.: MNTORCH, MNTORCH-2, MNTORCH-C, MNTORCH-X Only the model MNTORCH was tested, since the electrical circuit design, layout, components used and internal wiring were identical for the above models, with difference being color of appearance and model name. Thank you for your cooperation! Yours sincerely, Signatory: Name: Zhi yun Wu Position: Manager Company Name: ACOUSTMAX INTERNATIONAL CO., LTD Address: Unit D16/F Cheuk Nang Plaza 250 Hennessy Road Wanchai HongKong Tel / Fax 13510365603 / 852-25301919 E-Mail: [email protected]

FCC ID: 2AAIN-MNTORCH Test Model No.:MNTORCH FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH

FCC ID: 2AAIN-MNTORCH Test Model No.:MNTORCH

MONSTER TORCH Model No.: MNTORCH FCC ID: 2AAIN-MNTORCH Manufacturer:ACOUSTMAX INTERNATIONAL CO., LTD This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Marine Audio Model No.: KMC3 FCC ID: RGR-46KMC2 ISED: 11078A-KMC2 Power Supply: DC12V Manufacturer: Eastern Partner Limited This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH FCC ID: 2AAIN-MNTORCH

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 TEST REPORT The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No.: CQASZ20201001302E-01 Applicant: ACOUSTMAX INTERNATIONAL CO., LTD Address of Applicant: Unit D16/F Cheuk Nang Plaza 250 Hennessy Road WanchaiHongKong. Equipment Under Test (EUT): EUT Name: MONSTER TORCH Model No.: MNTORCH, MNTORCH-2, MNTORCH-C, MNTORCH-X Test Model No.: MNTORCH Brand Name: Monster FCC ID: 2AAIN-MNTORCH Standards: 47 CFR Part 15, Subpart C Date of Receipt: 2020-10-30 Date of Test: 2020-10-30 to 2020-11-16 Date of Issue: 2020-11-16 Test Result: PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By： ( Martin Lee ) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201001302E-01 Page:2 of 84 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20201001302E-01 Rev.01 Initial report 2020-11-16 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201001302E-01 Page:3 of 84 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2013) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2013) PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2013) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2013) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2013) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2013) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2013) PASS Restricted bands around fundamental frequency (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2013) PASS Note: Model No.: MNTORCH, MNTORCH-2, MNTORCH-C, MNTORCH-X Only the model MNTORCH was tested, since the electrical circuit design, layout, components used and internal wiring were identical for the above models, with difference being color of appearance and model name. Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201001302E-01 Page:4 of 84 3 Contents Page 1 VERSION .................................................................................................................................................................. 2 2 TEST SUMMARY .................................................................................................................................................... 3 3 CONTENTS .............................................................................................................................................................. 4 4 GENERAL INFORMATION ................................................................................................................................... 5 4.1 CLIENT INFORMATION .......................................................................................................................................... 5 4.2 GENERAL DESCRIPTION OF EUT .......................................................................................................................... 5 4.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD .................................................................................. 5 4.4 ADDITIONAL INSTRUCTIONS................................................................................................................................. 7 4.5 TEST ENVIRONMENT ............................................................................................................................................ 8 4.6 DESCRIPTION OF SUPPORT UNITS ......................................................................................................................... 8 4.7 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................. 9 4.8 TEST LOCATION ................................................................................................................................................. 10 4.9 TEST FACILITY ................................................................................................................................................... 10 4.10 ABNORMALITIES FROM STANDARD CONDITIONS ............................................................................................... 10 4.11 OTHER INFORMATION REQUESTED BY THE CUSTOMER ...................................................................................... 10 4.12 EQUIPMENT LIST ................................................................................................................................................ 11 5 TEST RESULTS AND MEASUREMENT DATA .............................................................................................. 12 5.1 ANTENNA REQUIREMENT ......................................................................................................................…
