2AAJWSRK527Keyfob

Document Name : KF-BLE-Users Guide Rev.: 01.03 Product Name: KF-BLE-73730 Page : Page 1 of 9 Mfg: Belwith Products, LLC. Date : 07/21/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 BELWITH PRODUCTS, LLC www.belwith.com TABLE OF CONTENTS Contents Page # 1 Scope of this document 2 2 Basic Operation of the KeyFob 2 3 Electric specification 3 4 Mechanical Layout 4 5 Ordering Information 5 6 FCC, 2-part statement, compliance and exposure statement 6 7 RoHS Declaration 7 8 Datasheet status 8 9 Revision History 9 Document Name : KF-BLE-Users Guide Rev.: 01.03 Product Name: KF-BLE-73730 Page : Page 2 of 9 Mfg: Belwith Products, LLC. Date : 07/21/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 BELWITH PRODUCTS, LLC www.belwith.com 1) Scope of this document : This User Guide describes Belwith’s Bluetooth Low Energy KeyFob, also known herewithin alternately as “device” Series model number SRK527. Caution! Any changes or modifications to this KeyFob/device not approved by Belwith Products LLC could void the authority to operate this KeyFob/device. Do not attempt to modify the KeyFob/device for any other use. Over / under voltage will void all warranties, whether expressed or implied. 2) Basic operation of the KeyFob: The KeyFob /device is a compact battery operated miniature handheld device that generates data packets to Bluetooth Low energy devices. The KeyFob/device remains in a complete sleep mode (no power) until one of four soft buttons are pressed ( off to on condition). The KeyFob/device design cycles to a power OFF condition by either releasing of the button or if the button remains pressed the circuit is designed to turn the power off after a given time interval. Releasing and pressing any button will initiate transmission and the timer function as mentioned previously. This KeyFob/device is designed to work / connect exclusively with other Secure Remote devices. The data packets that are transmitted over the 37 hopping channels is/are exclusive to other paired Secure Remote devices. See website www.Belwith.com for other listed devices and /or modules. Pairing details are detailed in the Secure Remote phone application. Document Name : KF-BLE-Users Guide Rev.: 01.03 Product Name: KF-BLE-73730 Page : Page 3 of 9 Mfg: Belwith Products, LLC. Date : 07/21/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 BELWITH PRODUCTS, LLC www.belwith.com 3) Electric specification: Power: Power to the KeyFob/device is provided by a commercial available single cell “coin” type of Lithium Ion battery. 3.0 Volts nominal. Care, use and disposal of this battery is\are provided by the manufacture. The battery is non rechargeable type. It is serviced by prying the front and back halves of the KeyFob/device case apart. Slide battery out and insert new. (observe polarity). CAUTION: contains ESD sensitive circuit board. Precautions should be used when handling the internal circuit board in order to prevent permanent damage. LED indicators are provided to indicate various connection and power conditions of the KeyFob. Yellow = low battery, Red = error, Blue = connection to Bluetooth Specification : Part: IEC Name ANSI Name CR2032 Battery 5004LC Typical Capacity 225 mAh Nominal voltage 3.0 volts Usable temp. range -20 ... 70 degrees C Antenna PCB Antenna (Inverted F type) It is a 2.4 GHz PCB antenna. The Antenna was designed to match KeyFob circuitry. Do not attempt any modifications. KeyFob Ground Plane The KeyFob/device features extended ground plane structure on the PCB which is designed to reduce EMI radio interference. Do not alter this surface. Document Name : KF-BLE-Users Guide Rev.: 01.03 Product Name: KF-BLE-73730 Page : Page 4 of 9 Mfg: Belwith Products, LLC. Date : 07/21/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 BELWITH PRODUCTS, LLC www.belwith.com 4) Mechanical Layout: Case material: UL94-HB flame rated ABS. Keypad silicone. Specification : FRONT VIEW OF KEYFOB REAR VIEW OF KEYFOB Do not remove the “FIRST WATCH” label shown on back of KeyFob/device. It contains important information regarding FCC No. Item Dimension Tolerance 1. Length 52.34 mm +/- 0.80 2. Width 33.02 mm +/- 0.80 3. Height 14.73 mm +/- 0.80 4. Weight .05 lbs. +/- .2 lbs Buttons Document Name : KF-BLE-Users Guide Rev.: 01.03 Product Name: KF-BLE-73730 Page : Page 5 of 9 Mfg: Belwith Products, LLC. Date : 07/21/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 BELWITH PRODUCTS, LLC www.belwith.com 5) Ordering Information: PART Number: KF-BLE-73730. Model number SRK527. Contact Belwith Products LLC. directly for further information. Web address: www.belwith.com Part is available for online ordering. User guide is available in electronic form or as printed document upon request. Document Name : KF-BLE-Users Guide Rev.: 01.03 Product Name: KF-BLE-73730 Page : Page 6 of 9 Mfg: Belwith Products, LLC. Date : 07/21/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 BELWITH PRODUCTS, LLC www.belwith.com 6) FCC KeyFob/device, Exposure, and Compliance Statements Important Note: To comply with FCC RF exposure compliance requirements, the following antenna installation and device operating configurations must be satisfied - This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. ++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++ This device has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, and uses a Radiate radio frequency energy and if not used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that Interference will not occur in a particular instance. If this device does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged …

Text truncated - open the document above for the full version.

Belwith' PRODUCTS 6/28/2013 CETCB 114 Olinda Drive Brea,CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Belwith Products IXC, 3100 Broadway Ave SW, Grandville, MI, 49418, USA, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Belwith Products LLC products product: Key Fob Transceiver. Modules under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Belwith Products LLC products nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non- voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Belwith Products LLC products will notify the Federal Communications Commission if, at any time, the situation changes causing Belwith Products LLC products to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 616- 247-4000 Sincerely, General Manager and CFO Belwith Products LLC products m. Belwith HICKORY HARDWARE' FIRST WATCH' SECU R1TY KEELER' 3100 Broadway Avenue SW, Grandville, MI 49418 • Tel: (616) 247-4000 • Fax (616) 247-4060 • www.belwith.com

Belwith" PRODUCTS 06/28/2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, Belwith Products LLC, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission's Rules, and Section 552 (bj (4) of the Freedom of Information Act, These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be Released to the public by that person. If you have any^fuestions, please do not hesitate to contact us at 616 247 4000. Sincerely Thomas Guido General Manager and CFO Belwith Products LLC m HICKORY HARDWARE* F-1RST WATCI-r SECU RiTY KEELER" 3100 Broadway Avenue SW, Grandville, MI 49418 • Tel: (616) 247-4000 • Fax (616) 247-4060 • www.belwith.com

Document Name : KF-BLE-label_information Rev.: 01.01 Product Name: KF-BLE-73730 Page : Page 1 of 5 Confidential Mfg: Belwith Products, LLC. Date : 08/04/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 This document contains Confidential Information regarding label construction for FCC ID KeyFob 2AAJWSRK527. This document is supplementing: 1) KF-BLE User Guide 2) KF BLE Schematic Layout (confidential) 3) KF BLE Instruction Guide (confidential) 4) KF BLE Block Flow diagram (confidential) The Information contained herewithin is considered confidential subject to terms and conditions of confidentiality statement. Contents Page # 1 Scope of this document 2 2 Label details 3 3 Datasheet status 4 4 Revision History 5 Document Name : KF-BLE-label_information Rev.: 01.01 Product Name: KF-BLE-73730 Page : Page 2 of 5 Confidential Mfg: Belwith Products, LLC. Date : 08/04/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 1) Scope: the purpose is to detail the label details for the KF-BLE-73730. Model SRK527, FCC ID 2AAJWSRK527 Document Name : KF-BLE-label_information Rev.: 01.01 Product Name: KF-BLE-73730 Page : Page 3 of 5 Confidential Mfg: Belwith Products, LLC. Date : 08/04/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 2) The following label to be applied permanently to the KeyFob as shown. Do not remove this label Specification : No. Item Dimension 1. Base material Polyester 2. Adhesive Acrylic 3. Color White 4. Thickness 8 mils Document Name : KF-BLE-label_information Rev.: 01.01 Product Name: KF-BLE-73730 Page : Page 4 of 5 Confidential Mfg: Belwith Products, LLC. Date : 08/04/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 3) Datasheet status:  This data sheet contains the final specification (RELEASE).  Belwith reserves the right to make changes at any time without notice in order to improve design and supply the best possible product. Subject to FCC guidelines.  Supplementary data is available upon request.  Information supplied here is the most recent at the time of publication.  Consult the most recently issued data sheet before initiating or completing a design.  Contact Belwith customer service to secure the latest version of this data sheet: www.belwith.com  All rights reserved. Design of these products shown here have U.S and foreign patents pending. Document Name : KF-BLE-label_information Rev.: 01.01 Product Name: KF-BLE-73730 Page : Page 5 of 5 Confidential Mfg: Belwith Products, LLC. Date : 08/04/2013 Model #: SRK527 FCC ID: 2AAJWSRK527 4) Revision History Revision Date Author Modification/Remarks 01.01 8/4/2013 GM Create new

SAR TEST EXCLUSION This device, FCC ID: 2AAJWSRK527, is excluded from SAR testing by the following justification. The maximum power that the transmitter IC is capable of is 1 mW. By using the following formula from section 4.3.1 of KDB 447498: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR and using the minimum test separation distance of 5 mm, the resulting calculated SAR value is: (1 mW)/5 mm) * (√2.4 GHz) = 0.3 This value is below the exclusion threshold for both the 1-g SAR and 10-g extremity SAR requirements.

Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for KEYFOB Model: SRK527 Prepared for BELWITH PRODUCTS, LLC 3100 BROADWAY AV SW GRANDVILLE, MICHIGAN 49418 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JULY 14, 2013 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 14 28 64 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos  Test Setup Diagram  Antenna and Amplifier Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of the Radiated Test Site Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Keyfob Model: SRK527 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: Belwith Products, LLC 3100 Broadway AV SW Grandville, Michigan 49418 Test Date(s): June 26, 2013; and July 12, 2013 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the emissions tests performed on the Keyfob, Model: SRK527 (EUT). The Emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B for …

Text truncated - open the document above for the full version.

Ref Lvl 92 dB  V Ref Lvl 92 dB  V RBW 1 MHz VBW 1 MHz RF Att 0 dB A IN1 Unit dB  V TRG SWT 100 ms Center 2.48 GHz10 ms/ P0 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] 0.33 dB 1.803607 ms 1 [T1] 33.15 dB  V 36.072144 ms 1 [T1] 0.33 dB 1.803607 ms D1 74 dB  V D2 54 dB  V Date: 26.JUN.2013 11:21:51 Time of One Pulse – Data Mode (Worst Case) – Keyfob Ref Lvl 92 dB  V Ref Lvl 92 dB  V RBW 1 MHz VBW 1 MHz RF Att 0 dB A IN1 Unit dB  V TRG P0 TDS SWT 200 ms Center 2.48 GHz20 ms/ 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] 0.76 dB 101.002004 ms 1 [T1] 33.86 dB  V 56.112224 ms 1 [T1] 0.76 dB 101.002004 ms D1 74 dB  V D2 54 dB  V Date: 26.JUN.2013 11:21:27 Worst Case 100 mS – Data Mode (Worst Case) – Keyfob Duty Cycle = 1.803607 ms * 2 = 3.607214 ms / 100 ms = 3.607214% The maximum 20 dB peak to average ratio can be utilized.

Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D12 FRONT VIEW BELWITH PRODUCTS, LLC KEYFOB MODEL: SRK527 FCC SUBPART B AND C – RADIATED EMISSIONS – ABOVE 30 MHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D13 REAR VIEW BELWITH PRODUCTS, LLC KEYFOB MODEL: SRK527 FCC SUBPART B AND C – RADIATED EMISSIONS – ABOVE 30 MHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D14 FRONT VIEW BELWITH PRODUCTS, LLC KEYFOB MODEL: SRK527 FCC SUBPART B AND C – RADIATED EMISSIONS – BELOW 30 MHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Report Number: B30712A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Keyfob Model: SRK527 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D15 REAR VIEW BELWITH PRODUCTS, LLC KEYFOB MODEL: SRK527 FCC SUBPART B AND C – RADIATED EMISSIONS – BELOW 30 MHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS
