2AAKS-DV12Car Radio Player with AM FM RDS USB SD DVD CD MP3 WMA ESP AUX ISO BT REMOTE

4 IN 1 WALLMOUNT ENTERTAINMENT SYSTEM WITH DVD/CD/USB/BLUETOOTH/AM/FM/WEATHERBAND DV1200 Instruction Manual D V 1 2 0 0 30 1 ! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. CLASS 1 LASER PRODUCT Laser product symbol: located on the rear panel of the unit, indicate this player is a class laser product, only use weak laser and no hazardous radiation outside of the unit. 1.Read through this instruction manual before installation and use. 2.Do not touch the power plug with wet hand. 3.Switch off the main power when the unit is not in use. (Disconnect the power plug from the power outlet when you do not intend to use the unit for a prolonged period of time.) Before moving the unit, remove the disc from the unit/ tray first. 4.Do not open the cover or touch any of the components exposed out of the unit, only for qualified technicians. 5.Do not expose the unit under direct sunlight or nearby objects that radiate heat to avoid damage the unit. 6.Do not place the unit in moist and humid conditions, which effect the pick-up of the unit lead to out of work. 7.Place the unit on a flat surface and ventilative condition. Please ensure the ventilation holes are not covered to avoid overheating and malfunction. 8.Clear the panel and case with soft dry cloth only, do not apply any kind of thinner, alcohol or sprays. 9.The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus . WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. PRECAUTION 2 29 Contents 1. Before Operation...........................................................................................3 1.1 Feature................................................................................................. 3 1.2 Precautions............................................................................................3 1.3 Maintenance and Cleaning of Discs..........................................................4 1.4 Battery Information of the Remote Control.................................................4 1.5 The Remote Control Description...............................................................5 1.6 Locations and Names of the Controls.........................................................6 1.7 Wiring Diagram............................................... ........................................7 1.8 Mouting Installation..................................................................................7 2. Common Operation.......................................................................................8 3. Radio Operation..........................................................................................10 4. Basic Disc, USB Operation...........................................................................12 4.1 Begin Playback......................................................................................12 4.2 Pause Playback.....................................................................................13 4.3 Stop Playback .......................................................................................13 4.4 Select Chapter/Track with the the >>|/|<< Buttons.....................................13 4.5 Select Chapter/Track with the Number Buttons.........................................13 4.6 Select Chapter/Track with the Root/PBC Menu.........................................13 4.7 Terminate the Playback..........................................................................14 5. Advanced Disc, USB Operation....................................................................14 5.1 Playback with Speed..............................................................................14 5.2 Playback with Slow Speed......................................................................14 5.3 Playback with Still Frame ........................................................................15 5.4 Playback Repeatedly.............................................................................15 5.4.1 One/All Repeat...................................................................................15 5.4.2 A-B Repeat.........................................................................................15 5.5 Playback from a specified Chapter/Track or a Specified Time....................16 5.6 Playback in Random..............................................................................16 5.7 Playback in Different Angle.....................................................................16 5.8 Playback in Zoom Mode.........................................................................16 5.9 Change the Caption Language...............................................................17 5.10 Change the Audio Language.................................................................17 5.11 Look over the Playback Status..... ..........................................................17 5.12 Program Playback................... .............................................................18 5.13 Playback the Picture CD in JPEG Format................................................18 5.14 Mp4 OPERATION................................................................................19 5.15 ESP and ID3 Function.......................................................…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We Furrion Ltd hereby declares: The product model(s) DV12XX, DV11XX (X=0-9), DV1100 are identical in the same PCB layout, interior structure and electrical circuits with the model DV1200 which tested in Global United Technology Services Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Date: 2013-07-05

Furrion Ltd Date (dd/mm/yyyy) 07/05/2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Furrion Ltd (address: Suite 3-5, 16/F Pacific Plaza, 410 Des Voeux Road West, Sai Wan, Hong Kong), hereby authorize Hans.hu (Company name: Global United Technology Services Co., Ltd. Address: 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong ) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 07/05/2014 Yours sincerely, Company Officer: Manager / Pei Hua Deng Telephone Number: 0769-86528327 Email: [email protected]

Furrion Ltd Date (dd/mm/yyyy) 07/05/2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: 2AAKS-DV12 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Furrion Ltd hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Manager / Pei Hua Deng Telephone Number: 0769-86528327 Email: [email protected]

Label location

Size：120mm*130mm

FCC ID:2AAKS-DV12 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest (2402MHz) 0.254 0.00008 1.0 PASS Middle (2441MHz) 0.152 0.00005 1.0 PASS Highest (2480MHz) 0.100 0.00003 1.0 PASS Remark: antenna gain=2.0 dBi

Global United Technology Services Co., Ltd. Report No.: GTSE13060087301 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS International Electrical Approvals or testing done by GTS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by GTS International Electrical Approvals in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” FCC REPORT Applicant: Furrion Ltd Address of Applicant: Suite 3-5, 16/F Pacific Plaza, 410 Des Voeux Road West, Sai Wan, Hong Kong Equipment Under Test (EUT) Product Name: Car Radio Player with AM FM RDS USB SD DVD CD MP3 WMA ESP AUX ISO BT REMOTE Model No.: DV12XX, DV11XX (X=0-9), DV1200, DV1100 Trade Mark: Furrion FCC ID: 2AAKS-DV12 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2012 Date of sample receipt: June 17, 2013 Date of Test: June 17-July 02, 2013 Date of report issued: July 02, 2013 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE13060087301 Global United Technology Services Co., Ltd. Project No.: GTSE130600873RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 33 2 Version Version No. Date Description 00 July 02, 2013 Original Prepared By: Date: July 02, 2013 Project Engineer Check By: Date: July 02, 2013 Reviewer Report No.: GTSE13060087301 Global United Technology Services Co., Ltd. Project No.: GTSE130600873RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 33 3 Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT:.................................................................................................................... 9 7.2 RADIATED EMISSION METHOD........................................................................................................... 10 7.2.1 Field Strength of The Fundamental Signal ................................................................................ 12 7.2.2 Spurious emissions.................................................................................................................... 13 7.2.3 Bandedge emissions.................................................................................................................. 17 7.3 20DB OCCUPY BANDWIDTH.............................................................................................................. 18 8 TEST SETUP PHOTO ............................................................................................................................ 20 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................21 Report No.: GTSE13060087301 Global United Technology Services Co., Ltd. Project…

Text truncated - open the document above for the full version.

Radiated Emission
