INTRODUCTION Congratulations on your purchase of the RC Train with Lights and Sounds. Please read all instructions and warnings on this sheet prior to using the RC Train with Lights and Sounds with sound. Keep this instruction sheet as it contains important information for future reference. RC TRAIN WITH LIGHTS AND SOUNDS • Push the left/right button, let the train turn left/right • Turn on the Train CONTENTS FAO Bear ConductorRemote Controller Cargo Car Caboose Motorized Train Car Motorized Train CarRemote Controller ASSEMBLY • Use a Phillips head screwdriver to remove the bottom battery cover • Remove demo batteries and install new batteries • Insert 2 “AAA”1.5V batteries in the polarity shown • Replace the battery cover and tighten • Link them as shown above FUNCTIONS • Demo sound button Push the top of the bell for demo sounds (only available when the train is turned off) 3+ AGES RightLeft • Push the Mute button to turn off the sounds + + • Use a Phillips head screwdriver to remove the bottom battery cover • Insert 2 “AA”1.5V batteries in the polarity shown • Replace the battery cover and tighten + + On/OffMuteOn/OffMute Tips: The train and remote controller will go to sleep model if there is no operation for 10 minutes (the train light will flicker and no sound). Need to push the left/right button on the remote controller to trigger again. 11” 8.5” This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. WARNINGS - PLEASE READ CAREFULLY BEFORE USE The artwork and design of this manual are protected by US copyright law and may not be reproduced, distributed, displayed, published or used for any purpose without prior written permission. It is not permitted to alter, remove or reproduce any trademarks or copyright notice from this manual. Printed in China FAO ® and FAO Schwarz ® names and logos are trademarks or registered trademarks. All rights reserved. Distributed by © 2020 MerchSource, LLC. Irvine, CA 92618. For customer support please call 1-888-987-6533. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. BATTERY WARNING: • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries. • Alkaline batteries are recommended. Use only the specified voltage. • Insert batteries using the correct polarity. Always use, replace, and recharge (if applicable) batteries under adult supervision. • Do not charge with non-rechargeable batteries. • Do not short-circuit the battery supply terminals. • Do not dispose of batteries in fire, batteries may explode or leak. • Remove batteries before storing. • Recycle or dispose of batteries according to federal, state, and local laws. • Keep these instructions for future reference. Model Number: 1012121 Colors & styles may vary. · NEVER LEAVE THIS PRODUCT UNATTENDED DURING USE. · INSPECT THE TRAIN BEFORE EVERY USE, IF THERE ARE ANY CRACKS OR BROKEN PARTS , DISCONTINUE USE AND DISCARD IMMEDIATELY. · NOT INTENDED FOR CHILDREN UNDER 3. SMALL PARTS MAY POSE A CHOKING HAZARD. · ADULT ASSEMBLY AND SUPERVISION REQUIRED AT ALL TIMES. · BEWARE OF SHARP EDGES AND OTHER FUNCTIONAL SHARP POINTS. · STORAGE OF OBJECTS INSIDE THE BOX CAR DURING OPERATION MAY IMPACT TRAIN PERFORMANCE AND HINDER MOTION. WARNING: CHOKING HAZARD – Small Parts. Not for Children under 3 years.

Page 1 of 2 External Photos Page 2 of 2

Label Artwork and Location

Page 1 of 2 Internal Photos Page 2 of 2

1 INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a Toy RC Toyland Train operating at 2.4G Band. The EUT can be powered by DC 3.0V (2 x 1.5V AA batteries). For more detail information pls. refer to the user manual. Antenna Type: Integral antenna. Antenna Gain: 0dBi. The normal radiated output power (e.i.r.p) is: 4.0dBm (tolerance: +/- 3dB). The normal conducted output power is 4.0dBm (tolerance: +/- 3dB). Modulation Type: GFSK. According to the KDB 447498: The Maximum peak radiated emission for the EUT is 102.0 dBμV/m at 3m in the frequency 2453MHz The EIRP = [(FS*D) ^2 / 30] mW = 6.77dBm which is within the production variation. The Minimum peak radiated emission for the EUT is 100.9 dBμV/m at 3m in the frequency 2441MHz The EIRP = [(FS*D) ^2 / 30] mW = 5.67dBm which is within the production variation. The maximum conducted output power specified is 7dBm= 5.012mW The source- based time-averaging conducted output power =5.012* Duty cycle mW <5.012 mW(Duty cycle <100%) The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.453) mW = 9.58 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. The duty cycle is simply the on-time divided by the period: The duration of one cycle = 3.9855ms Effective period of the cycle = 391.3μs = 0.3913ms DC =0.3913ms / 3.9855ms =0.0982 or 9.82% FCC ID: 2AALAHD20A24GT

Shantou City Hengdi Industry Co., Ltd TEST REPORT SCOPE OF WORK FCC TESTING– MODEL: 1012928 REPORT NUMBER GZHH00359990-001 ISSUE DATE JULY 6, 2020 PAGES 24 DOCUMENT CONTROL NUMBER FCC ID 249_C © 2017 INTERTEK Intertek Report No.: GZHH00359990-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Service Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community GuanHu Subdistrict, LongHua District, Shenzhen, People’s Republic of China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 24 FCC ID 249_C Test Report Shantou City Hengdi Industry Co., Ltd Application for Certification FCC ID: 2AALAHD20A24GT Toy RC Toyland Train Brand Name: FAO Schwarz Model: 1012928 Additional Model: 1012121 2.4GHz Transmitter Report No.: GZHH00359990-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-19] Prepared and Checked by: Approved by: Sign on file Terry Tang Assistant Supervisor Kidd Yang Technical Supervisor Date: July 6, 2020 Intertek Report No.: GZHH00359990-001 Version: 01-November-2017 Page: 2 of 24 FCC ID 249_C Test Report MEASUREMENT/TECHNICAL REPORT This report concerns (check one:) Original Grant X Class II Change Equipment Type: DXX - Part 15 Low Power Communication Device Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator − the new 47 CFR [10-1-19 Edition] provision. Report prepared by: Terry Tang Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community GuanHu Subdistrict, LongHua District, Shenzhen, People’s Republic of China Tel / Fax: 86-755-8601 6288/86-755-8601 6751 Intertek Report No.: GZHH00359990-001 Version: 01-November-2017 Page: 3 of 24 FCC ID 249_C Test Report Table of Contents 1.0 Summary of Test Result .......................................................................................... 4 2.0 General Description ................................................................................................. 5 2.1 Product Description ................................................................................................. 5 2.2 Related Submittal(s) Grants .................................................................................... 5 2.3 Test Methodology .................................................................................................... 5 2.4 Test Facility ............................................................................................................ 5 3.0 System Test Configuration ...................................................................................... 6 3.1 Justification ............................................................................................................. 6 3.2 EUT Exercising Software ......................................................................................... 6 3.3 Special Accessories ................................................................................................ 6 3.4 Equipment Modification ........................................................................................... 6 3.5 Measurement Uncertainty ....................................................................................... 6 3.6 Support Equipment List and Description .................................................................. 6 4.0 Emission Results ..................................................................................................... 7 4.1 Radiated Test Results ............................................................................................. 7 4.1.1 Field Strength Calculation ..................................................................................... 7 4.1.2 Radiated Emission Configuration Photograph ....................................................... 8 4.1.3 Radiated Emissions .............................................................................................. 8 4.1.4 Transmitter Spurious Emissions ......................................................................... 11 5.0 Equipment Photographs ........................................................................................ 15 6.0 Product Labelling ................................................................................................... 15 7.0 Technical Specifications ........................................................................................ 15 8.0 Instruction Manual ................................................................................................. 15 9.0 Miscellaneous Information .................................................................................... 16 9.1 Bandedge Plot ............................…
