2AAMHGC01Motor Cam

CRAYS Technology Limited
Motor Cam - FCC ID 2AAMHGC01 - CRAYS Technology Limited
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Oct 13, 2014
Application Purpose
Original Equipment
Date of Application
Oct 13, 2014
Equipment Note
Motor Cam
Frequency Range
2412.00000000 - 2462.00000000
Company
CRAYS Technology Limited
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Control Panel 2 Record Button Wi-Fi Button Operating Instructions Establishing Wi-Fi Connection 1. Mobile APP Installation i iPhone: Search for “Foxeye Wi-Fi” on the Apple’s App store. ii Android: Search for “Foxeye Wi-Fi” on Google play. 2. Wait for the device to boot up and enter recording mode. 3. Press the Wi-Fi button on the control panel, the recording will be interrupted shortly, and when the Wi-Fi indicator light is lit, the recording will resume. 4. Find "GC1" in the Wi-Fi listings on your mobile device, enter the default password "00000000", and select to connect. 5. Boot up the Foxeye Wi-Fi App, and proceed to use the app. Restore to Factory Settings 1. Make sure the device is not recording and the Wi-Fi is off. 2. Hold down the WI-FI button on the control panel for 10 seconds, the device will automatically reboot and is restored to factory settings. Light Indicators 1. Red light: Recording when lit, Stops recording when extinguished. 2. Blue light: Wi-Fi on when lit, Wi-Fi off when extinguished. 3. Green light: Device on when lit, off when extinguished. Formating Internal Memory 1. After the devices has booted, please turn off Wi-Fi and the recording function. 2. Press and hold both the Wi-Fi and recording button for about 10 seconds, the blue and red light will start to cross blinking to indicate the formatting process has started. 3. All lights will extinguish to indicate the formatting has been successful. 4. Formatting will wipe out all files in the memory including the locked files, please back up all the files you wish to keep before commencing to format. Adjustable LensPower / Micro USB Port Main Device 1 1. The time stamp function is disabled when Wi-Fi is on. 2. This device has loop recording and file lock down functions, locked files cannot be overwritten unless using connection via an external device such as a mobile phone. 3. This device has IPX6 waterproof ratings, but is not designed to submerge underwater. 4. Do not disassemble the device; all warranty will be invalid if the device has been disassembled. Precautions Modifying Wi-Fi Settings 1. Connect to the GC1 using a mobile device. 2. Select the WI-FI settings option; you can change the SSID and password there. 3M VHB Tape- Main Device Bike mount Rubber Strap Handlebar 3M VHB Tape- Cradle Record Light Wi-Fi Light Power Light Power Button 1. Button Descriptions i Power button: Press once to turn power on/off, Hold down 5 seconds for forced shutdown ii Wi-Fi button: Press once to turn Wi-Fi on/off, Hold down 10 seconds for restoring to factory settings iii Record button: Press once to lock the current video file (only works while recording), Hold down for 3 seconds to start/end recording. 2. When the ignition switch is turned to [ACC], the device is booted up, and will enter recording mode in about 5 seconds. 3. When the ignition switch is turned to [OFF], the current recording file is automatically saved and the device will proceed to shut down. 4. Wi-Fi is off by default, start-up time requires 15 seconds. 5. When Wi-Fi is enabled, the APP can be used to connect to the device to download, view, edit the files and give access to camera settings. 6. “The Foxeye Wi-Fi APP supports both the iOS and the Android systems. The microphone operation instrucion is as followed: 1. The microphone is defaulted as on every time the device is booted up. 2. During recording mode A. Stop recording, short press the power button once, the power light will blink twice, start recording, the sound will be muted. B. Stop recording, short press the power button once, the power light will blink once, start recording, the sound will be unmuted. 3. During Wi-Fi mode A. Short press the power button once, the power light will blink twice, the sound will be muted. B. Short press the power button once, the power light will blink once, the sound will be unmuted. User Manual GC01 / GC01X

Cover Letter(s)

Date: Sep. 30, 2014 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: 2AAMHGC01 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Crays technology limited. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, (signed by FCC listed Grantee contact) Name/Title: Devin.chen / P.M Company Name: Crays technology limited TEL: 002-86-2-82011700 Email: [email protected]

Cover Letter(s)

Date: SEP. 30, 2014 Subject: DoC declaration To whom it may concern, We, as the grantee of this project FCC ID: 2AAMHGC01, would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedure. Brand Name and Model Name of the specified radio equipment: Crays / GC01X FCC ID: 2AAMHGC01 Product Name: Motor Cam Regards, Signature Name/Title: Devin.Chen / P.M Company Name: Crays technology limited TEL: 002-86-2-82011700 Email: [email protected]

Cover Letter(s)

Product Declaration The GC01X series, Due to market segmentation, and only appearance so different colors, All designs are the same. Signature________________________________ Name/Title: devin.chen / P.M Crays technology limited TEL: +886-2-82011700 Email: [email protected]

External Photos

ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 1 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 1. 2. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 2 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 3. 4. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 3 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 5. 6. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 4 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 7. 8. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 5 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 9.

ID Label/Location Info

Label Information Trade Name: MotorCam Model Number: GC01X Label Size: 25 x 10mm Printing color: Black Label material: Label is Printed in the EUT Glue Material: Label is Printed in the EUT Label Size: 25 x 10mm Label location:

Internal Photos

ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 6 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 10. 11. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 7 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 12. Antenna 13. Battery ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 8 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 14. 15. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 9 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 16. 17. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 10 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 18. 19. ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 11 of 11 Sheets Rev. No 2.0 CONSTRUCTION PHOTOS OF EUT 20. 21.

RF Exposure Info

FCC ID: 2AAMHGC01 RF Exposure Evaluation of E.U.T. : MotorCam FCC ID. : 2AAMHGC01 MODEL : GC01X SERIAL MODEL : GC01 for APPLICANT : Crays technology limited ADDRESS : No.151,Qionglin S. Rd., Xinzhuang Dist., New Taipei City 24263, Taiwan(R.O.C.) Prepared by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU, LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 14-08-RBF-029-MPE FCC ID: 2AAMHGC01 TEST REPORT CERTIFICATION Applicant : Crays technology limited No.151,Qionglin S. Rd., Xinzhuang Dist., New Taipei City 24263, Taiwan(R.O.C.) Manufacturer : Crays technology limited No.151,Qionglin S. Rd., Xinzhuang Dist., New Taipei City 24263, Taiwan(R.O.C.) Description of EUT a) Type of EUT : MotorCam b) Trade Name : ---- c) Model No. : GC01X d) Serial Model No. : GC01 e) Power Supply : DC 5V from USB Battery: 3.7V 240mAh 0.89Wh Regulation Applied : OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5). Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC FCC ID: 2AAMHGC01 Date Test Item Received : Aug. 26, 2014 Date Test Campaign Completed : Sep. 17, 2014 Date of Issue : Sep. 25, 2014 Test Engineer : (Jiapeng Chen, Engineer ) Approve & Authorized Signer : S. S. Liou, Section Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN FCC ID: 2AAMHGC01 Product Information: Type of EUT: MotorCam FCC ID: 2AAMHGC01 Model: GC01X Serial Model: GC01 Description: MotorCam with IEEE 802.11b/g/n WiFi function. Model Difference: Only model name and color are different. The PCB and circuits design are the same. Maximum conducted output power (measured): 17.6 dBm or 57.544mW The following table lists the provided authorized antennas: Antenna Gain Model Antenna Type (dBi) Numeric WF0EM01-L060-2 WiFi Embedded Antenna 2.0 1.58 Below is an example of the RF Exposure Statement: IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC ID: 2AAMHGC01 Relative Requirement for Compliance According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following: TABLE 1 – LIMITS FOR MAXIMUN PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 .................. 6141.63*(100) 6 3-30 ..................... 1842/f4.89/f *(900/f 2 ) 6 30-300 .................. 61.40.1631.0 6 300-1500 ............... ...................... ......................f/300 6 1500-100,000 ......... ...................... ......................5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 ............... 6141.63*(100) 30 1.34-30 ............... 824/f2.19/f*(180/f2) 30 30-300 .................. 27.50.0730.2 30 300-1500 ............... ...................... ......................f/1500 30 1500-100,000 ......... ...................... ......................1.0 30 f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC ID: 2AAMHGC01 RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0 mW/cm 2 uncontrolled exposure limit. The formula shown in OET Bulletin 65 is used in the calculation. Equation from page 19 of OET Bulletin 65, Edition 97-01 is: S= PG / 4πR 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) hence R= (PG / 4πS) 1/2 For our device P = 57.544mW G = 1.58 R = 20 cm S = (57.544 * 1.58) / (4*π*20 2 ) = 0.0181 mW/cm 2 < 1.0 mW/cm 2 For complying the FCC limits for general population/uncontrolled exposure, the power density limit is 1.0 mW/cm 2 . The calculation result of the power density at a distance of 20 cm of our device is less than the limit. This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5).

Test Report

Rev. No 2.0 FCC Part 15 EMI TEST REPORT of E.U.T. : MotorCam FCC ID. : 2AAMHGC01 Model No. : GC01X Serial Model : GC01 for APPLICANT : Crays technology limited ADDRESS : No.151,Qionglin S. Rd., Xinzhuang Dist., New Taipei City 24263, Taiwan(R.O.C.) Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU VIL., LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. Tel : (02)26023052 Fax : (02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 14-08-RBF-029-01 ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : Crays technology limited No.151,Qionglin S. Rd., Xinzhuang Dist., New Taipei City 24263, Taiwan(R.O.C.) Manufacturer : Crays technology limited No.151,Qionglin S. Rd., Xinzhuang Dist., New Taipei City 24263, Taiwan(R.O.C.) Description of EUT a) Type of EUT : MotorCam b) Trade Name : ---- c) Model No. : GC01X d) Serial Model No. : GC01 e) Power Supply : DC 5V from USB Battery: 3.7V 240mAh 0.89Wh Regulation Applied : FCC Rules and Regulations Part 15 Subpart C I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC Summary of Tests Test Results Radiated Emission Pass Conducted Emission Pass Emission Bandwidth Pass Output Power Pass 100 kHz Bandwidth of Band Edges Pass Power Density Pass Out-of-Band Conducted Emission Pass ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Rev. No 1.0 Date Test Item Received : Aug. 26, 2014 Date Test Campaign Completed : Sep. 17, 2014 Date of Issue : Sep. 25, 2014 Test Engineer : (Jiapeng Chen, En gineer ) Approve & Authorized Signer : S. S. Liou, Section Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Rev. No 1.0 Table of Contents Page 1 GENERAL INFORMATION ....................................................................................................... 1 1.1 Product Description...................................................................................................................... 1 1.2 Characteristics of Device ............................................................................................................. 1 1.3 Test Methodology ........................................................................................................................ 1 1.4 Test Facility.................................................................................................................................. 1 2 PROVISIONS APPLICABLE...................................................................................................... 2 2.1 Definition ..................................................................................................................................... 2 2.2 Requirement for Compliance ....................................................................................................... 3 2.3 Restricted Bands of Operation ..................................................................................................... 5 2.4 Labeling Requirement .................................................................................................................. 5 2.5 User Information .......................................................................................................................... 6 3. SYSTEM TEST CONFIGURATION .......................................................................................... 7 3.1 Justification .................................................................................................................................. 7 3.2 Devices for Tested System........................................................................................................... 7 4 RADIATED EMISSION MEASUREMENT .............................................................................. 8 4.1 Applicable Standard ..................................................................................................................... 8 4.2 Measurement Procedure............................................................................................................... 8 4.3 Measuring Instrument ................................................................................................................ 10 4.4 Radiated Emission Data ............................................................................................................. 11 4.5 Field Strength Calculation ......................................................................................................... 25 4.6 Photos of Radiation Measuring Setup........................................................................................ 26 5 CONDUCTED EMISSION MEASUREMENT ........................................................................ 27 5.1 Standard Applicable ................................................................................................................... 27 5.2 Measurement Procedure............................................................................................................. 27 5.3 Conducted Emission Data .......................................................................................................... 28 5.4 Result Data Calculation ............................................................................................................. 30 5.5 Conducted Measurement Equipment ......................................................................................... 30 5.6 Photos of Conduction Measuring Setup..................................................................................... 31 6 ANTENNA REQUIR…

Text truncated - open the document above for the full version.

Test Setup Photos

ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 26 of 75 Sheets Rev. No 2.0 4.6 Photos of Radiation Measuring Setup ETC Report No. : 14-08-RBF-029-01 FCC ID.: 2AAMHGC01 Sheet 31 of 75 Sheets Rev. No 2.0 5.6 Photos of Conduction Measuring Setup

Contact Information

Applicant

Dean Liu
[email protected]+886-2-82011700Fax: +886-2-82011700

Test Firm

Taiwan Testing and Certification CenterAnderson Ku
[email protected]886-2-26023052Fax: +886-2-26010910

Technical Specifications

#Rule PartsFrequency RangePower Output
315C2.41 GHz - 2.46 GHz56.20 mW
Confidentiality
Long Term
Grant Notes
Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter RF Exposure procedures. End users must be informed of the requirements for satisfying RF Exposure compliance.
