2AANF-I7HDMID

 i7HD   QuickStartGuide ThankyouforyourchoosingandbuyingRamostablet, sincerelyhopethatyouwillenjoyit.Pleasecarefully readthisoperationmanualbeforeusingthetablet.  Precautions 1. Donotusealcohol,diluentsoranyother chemicaltocleanthesurface,otherwise,itwillbe corrodedandevendamaged. 2. Ifyouhaveanyquestionsaboutthetablet, pleasecontactwiththedealers.Attemptto disassembletheproductmaydamageitandvoid yourwarranty.Userswillberesponsibleforall theconsequencescausedbydisassembling. 3. Performanceandfunctionalityoftheproduct maybedifferentiftheversionofsoftwareand hardwareisdifferent.Anychangewillbewithout notice.Ourcompanyreservestherightto improvetheproducts. Main Functions  7′′ 800*1280capacitivemulti-touchscreen.  BasedonAndroid4.4.4operatingsystem/  SupportsWi-FiandBluetoothfunction.  SupportsMP3/AAC/OGG/WAVforaudio.  Supportsautomaticbrowseforpicturein JPG/BMP/GIF/PNG.   SupportsAVI/3GP/MP4/MKV/MOV/TS/FLV     andupto1080Pforvideo.  SupportsOTGfunction,externalmouseand keyboardandUSBFlashDrive.  SupportsTXT,PDFformatandbookmark function(needtoinstallthecorresponding application).  Supportsgravitysensor,automaticallyswitch  landscapeandportrait.  Supportsfrontandrearcameras. Packing List  i7HDMachineX1   ChargerX1   USBCableX1   QuickStartGuide+WarrantyCardX1   CertificationX1 ID design and Buttons functions  1.Keyfunctiondescription 1Earphonejack2USB/OTG/ChargingPort 3Frontcamera4Powerbutton 5Volumebutton6TFCardslot 73Gcardslot8Rearcamera 2. Pressthepowerbuttonfor3secondstoturnon/  turnoff.Pressitinaveryshorttimeforscreen  savers,repeatagaintowakeitup.    3.Pressboththepowerandvolumebuttonsatthe  sametimetocapturescreen.  Basic Operations  On/Off In the shutdown state, press the power button for 3sandthe tablet will enter themain screen afterthebootscreendisplay.Inthebootstate, press the power button for 3s and an options menupopsup,select “Poweroff”.  Connecttocomputerandfiletransfer When the tablet turns on, connect to the computer with the USB cable and use MTP mode, which functions as removable disk, then userscanuploadanddownloaddata.  Charging ConnectthechargerwithstandardUSBcable. Plugthechargerintothepowersocket. Connect tablet with USB cable, then charging begins. Whentablethintslowpower,pleasechargeitin timeusingthequalifiedchargerofi7HD. Chargingcanalsobeworkableinshutdown stateanditwilltakeabout5hourstofinish.  Resetthetablet Ifplayerhappenscrashorotherabnormal problems,pleasepressthepowerbuttonfor10 secondstoresetthetablet.  Home Screen  Longpressthepowerbuttonfor3seconds,the tablet enters the lock screen interface after the bootscreenshows.   Screenlock:Dragthelockicontounlock direction,thetabletwillbeunlockandenterthe mainscreenasbelowpicture.      Underanyinterface,clicktheicon toreturn totheupperdirectory,clicktheicon to returntothehomescreen,andclicktheicon  toshowthelistoftheapplicationswhich recentlyused.   Statusbar：Youcancheckthe time,batteryconsumption,networkstatusetc.  Touchthesettingicon   andenterthe Applicationinterface.   Allappsareshownintheapplicationprogram interface.Touchanyapplicationiconwillentertothe relevantapplicationprograminterface.         Settings Inallappsscreen,touchthesettingicon and enterthesettinginterfaceshownasbelow:  Inthisinterface,youcansearchBluetooth,view BandwidthUsage,Sound,Display,Storage,Battery, Apps,Security,Backup&Options,Date&Time, Language&Input,Accessibility,abouttabletandso on.Usercansetitaccordingtodemands.Showas belowpicture.    Wi-FiSettings Step1:SetWLANbeon,tabletwillautomaticallyscan theavailablenetworks. Step2:Selecttargetnetworkandinputthecorrect networkpassword.Select “Connect”.  Applications  Aftersettingupuser’sownemail account,usercansendandreceive mails.Itwillkeepautomatically updatingthenewemails.    Galleryprogramsupportsviewing picturebyfolderpath.Userscan zoomoutasingleimagebydouble clickingitortwofingerstouch.Users cansliderightorlefttoviewimages. Clickingtheimagecancontrolthe menutohideorshow.    Thewebbrowsersupports double-clickortouchingby two-fingerstozoomthewebpage. Commonwebsitecanbequickly openedbysitenavigation.Support multiplelabels,clickingtheTABto switchpages.Intelligentfull-screen andtheviewingareafitthebest.  Quicklybrowseviaclassified documents,supportfiles managementbypath.  Supportsseveralsetsofalarms, supportalarmevenifinoffstate. Supportworldclock,stopwatch,and timer,tomeetusers’possibleneed.  Therecorderhelpsquicklysaving voicemessageandsupportfileswith 3GPPformat.  Alltheappswillbemanaged centrallywhicharedownloadedfrom thesystemapplication. Firmware Upgrade 1.PleaseloginRamoswebsite (http://www.ramos.com.cn)todownloadthelatest firmwareupgradepackagetoyourcomputer. 2.Afterdecompressionfirmwareupgradepackageon thecomputer,pleasereadtheImportantcarefullyand thenfollowtheinstructionstoupgradethefirmware. 3.Thepurposeoffirmwareupgradeisupdatingthe machinefunction.  Specification Screen：7”，800x1280 CPU：Intel ® Atom  Z3735F  DDR：DDR3L1GB OS：Android4.4.4 WLAN：802.11n/g/b SupportG-Sensor Bluetooth：Bluetooth3.0+EDR Language：English,Chinese,andothe…

Text truncated - open the document above for the full version.

Shenzhen Ramos Digital Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2015-09-08 SUBJECT: FCC Application for ( FCCID: 2AANF-I7HD) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date:2015/1/20 Name: Lai liqun Title: Manager Tel: 61566931

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 ShenZhen Ramos Digital Technology Co., Ltd 2015/09/08 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ___ ShenZhen Ramos Digital Technology Co., Ltd _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： MID Trade Name： ramos Model Name： i7HD Serial Model： N/A FCC ID： 2AANF-I7HD Sincerely, Signature Name: Lai liqun Title: Manager Address: Room 1801-1805 & 1820, Block A XiNian Center, West of No. 9 Tairan Road, ShenNan Road, Shenzhen China 518057

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 ShenZhen Ramos Digital Technology Co., Ltd 2015-09-08 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID:2AANF-I7HD We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Name: Lai liqun Title: Manager Address: Room 1801-1805 & 1820, Block A XiNian Center, West of No. 9 Tairan Road, ShenNan Road, Shenzhen China 518057

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label MID Model NO.: i7HD FCC ID: 2AANF-I7HD ShenZhen Ramos Digital Technology Co., Ltd Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

FCC ID : 2AANF-I7HD RF EXPOSURE EVALUATION METHOD FCC ID:2AANF-I7HD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. WIFI: TX 802.11b Mode Te s t Channe Frequency Maximum Peak Conducted Output Power（PK） Maximum Peak Conducted Output Power（AV） Maximum Peak Conducted Output Power （AV） (MHz) (dBm) (dBm) mW CH01 2412 13.68 9.36 8.630 CH06 2437 13.97 9.45 8.810 CH11 2462 13.88 9.36 8.630 TX 802.11g Mode CH01 2412 12.56 7.43 5.534 CH06 2437 12.67 7.54 5.675 CH11 2462 12.85 7.72 5.916 TX 802.11n(20) Mode CH01 2412 10.21 7.98 6.281 CH06 2437 10.42 8.19 6.592 CH11 2462 10.28 8.05 6.383 TX 802.11n(40) Mode CH03 2422 9.83 7.41 5.508 CH06 2437 9.54 7.12 5.152 CH09 2452 9.33 6.91 4.909 FCC ID : 2AANF-I7HD BT 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) CH00 2402 3.21 2.094 CH39 2441 3.97 2.495 CH78 2480 3.01 2.000 2Mbps CH00 2402 2.24 1.675 CH39 2441 3.09 2.037 CH78 2480 2.17 1.648 3Mbps CH00 2402 2.52 1.786 CH39 2441 3.33 2.153 CH78 2480 2.39 1.734 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] WIFI: Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit TX 802.11b Mode CH01 7.6~9.6 9.6 9.120 5 2.412 2.83 3 CH06 7.6~9.6 9.6 9.120 5 2.437 2.85 3 CH11 7.6~9.6 9.6 9.120 5 2.462 2.86 3 TX 802.11g Mode CH01 7.0~9.0 9.0 7.943 5 2.412 2.47 3 CH06 7.0~9.0 9.0 7.943 5 2.437 2.48 3 CH11 7.0~9.0 9.0 7.943 5 2.462 2.49 3 TX 802.11n-HT20 Mode CH01 7.0~9.0 9.0 7.943 5 2.412 2.47 3 CH06 7.0~9.0 9.0 7.943 5 2.437 2.48 3 CH11 7.0~9.0 9.0 7.943 5 2.462 2.49 3 TX 802.11n-HT40 Mode FCC ID : 2AANF-I7HD CH03 6.0~8.0 8.0 6.310 5 2.422 1.96 3 CH06 6.0~8.0 8.0 6.310 5 2.437 1.97 3 CH09 6.0~8.0 8.0 6.310 5 2.452 1.98 3 BT Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit 1Mbps CH00 2~4 4 2.512 5 2.402 0.779 3 CH39 2~4 4 2.512 5 2.441 0.785 3 CH78 2~4 4 2.512 5 2.480 0.791 3 2Mbps CH00 2~4 4 2.512 5 2.402 0.779 3 CH39 2~4 4 2.512 5 2.441 0.785 3 CH78 2~4 4 2.512 5 2.480 0.791 3 3Mbps CH00 2~4 4 2.512 5 2.402 0.779 3 CH39 2~4 4 2.512 5 2.441 0.785 3 CH78 2~4 4 2.512 5 2.480 0.791 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT-BT FCC ID:2AANF-I7HD Product： MID Trade Name： ramos Model Name： i7HD Serial Model： N/A Report No.： NTEK-2015NT0709293F2 Prepared for ShenZhen Ramos Digital Technology Co., Ltd Room 1801-1805 & 1820, Block A XiNian Center, West of No. 9 Tairan Road, ShenNan Road, Shenzhen China 518057 Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 73 Report No.:NTEK-2015NT0709293F2 TEST RESULT CERTIFICATION Applicant’s name ................. : ShenZhen Ramos Digital Technology Co., Ltd Address ................................. : Room 1801-1805 & 1820, Block A XiNian Center, West of No 9 Tairan Road, ShenNan Road, Shenzhen China 518057 Manufacture's Name ............ : ShenZhen Ramos Digital Technology Co., Ltd Address ................................. : Room 1801-1805 & 1820, Block A XiNian Center, West of No 9 Tairan Road, ShenNan Road, Shenzhen China 518057 Product description Product name ........................... : MID Model and/or type reference : i7HD Serial Model： N/A Standards ............................. : FCC Part15.247: 01 Oct. 2014 Test procedure ..............................ANSI C63.10-2013 and Public Notice-DA 00-705 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 09 Jul. 2015 ~06 Aug. 2015 Date of Issue ........................................... : 06 Aug. 2015 Test Result ............................................... : Pass Testing Engineer : (Eileen Liu) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 73 Report No.:NTEK-2015NT0709293F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 23 3.2.1 RADIATED EMISSION LIMITS 23 3.2.2 TEST PROCEDURE 24 3.2.3 DEVIATION FROM TEST STANDARD 24 3.2.4 TEST SETUP 25 3.2.5 EUT OPERATING CONDITIONS 26 3.2.6 TEST RESULTS (BELOW 30 MHZ) 27 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 28 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 30 4 . NUMBER OF HOPPING CHANNEL 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . AVERAGE TIME OF OCCUPANCY 33 5.1 APPLIED PROCEDURES / LIMIT 33 Page 4 of 73 Report No.:NTEK-2015NT0709293F2 Table of Contents Page 5.1.1 TEST PROCEDURE 33 5.1.2 DEVIATION FROM STANDARD 33 5.1.3 TEST SETUP 34 5.1.4 EUT OPERATION CONDITIONS 34 5.1.5 TEST RESULTS 35 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . BANDWIDTH TEST 48 7.1 APPLIED PROCEDURES / LIMIT 48 7.1.1 TEST PROCEDURE 48 7.1.2 DEVIATION FROM STANDARD 48 7.1.3 TEST SETUP 48 7.1.4 EUT OPERATION CONDITIONS 48 7.1.5 TEST RESULTS 49 8 . PEAK OUTPUT POWER TEST 55 8.1 APPLIED PROCEDURES / LIMIT 55 8.1.1 TEST PROCEDURE 55 8.1.2 DEVIATION FROM STANDARD 55 8.1.3 TEST SETUP 55 8.1.4 EUT OPERATION CONDITIONS 55 8.1.5 TEST RESULTS 56 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 62 9.1 DEVIATION FROM STANDARD 62 9.2 TEST SETUP 62 9.3 EUT OPERATION CONDITIONS 62 9.4 TEST RESULTS 63 10 . ANTENNA REQUIREMENT 71 10.1 STANDARD REQUIREMENT 71 10.2 EUT ANTENNA 71 11 . EUT TEST PHOTO 72 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 73 Report No.:NTEK-2015NT0709293F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 73 Report No.:NTEK-2015NT0709293F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 73 Report No.:NTEK-2015NT0709293F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment…

Text truncated - open the document above for the full version.
