2AANZEBSK-S2-IN-1 Wireless Speaker & Earbuds

DGL Group LTD. 195 Raritan Center Parkway, Edison, NJ 08837, United States Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Mar.16, 2022 Subject; Request for Confidentiality FCC ID: 2AANZEBSK-S To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Parts List It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Amy Chao Title: General Manager

DGL Group LTD. 195 Raritan Center Parkway, Edison, NJ 08837, United States Agent Authorization Company: DGL Group LTD. Address: 195 Raritan Center Parkway, Edison, NJ 08837, United States Product Name: 2-IN-1 Wireless Speaker & Earbuds Model Number(s): NOR-EBSK-GRN, NOR-EBSK, NOR-EBSK-XXX, EW-EBSK-GRN, EW-EBSK, EW-EBSK-XXX Product Description: 2-IN-1 Wireless Speaker & Earbuds We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Mar.16, 2022 Name: Amy Chao Title: General Manager Company: DGL Group LTD.

DGL Group LTD. 195 Raritan Center Parkway, Edison, NJ 08837, United States Mar.16, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AANZEBSK-S Models: NOR-EBSK-GRN, NOR-EBSK, NOR-EBSK-XXX, EW- EBSK-GRN, EW-EBSK, EW-EBSK-XXX To Whom It May Concern: We, The DGL Group LTD. hereby declare that the model : NOR-EBSK-GRN is identical with the model : NOR-EBSK, NOR-EBSK-XXX, EW-EBSK-GRN, EW- EBSK, EW-EBSK-XXX, Only the appearance of the color is different, everything else is completely the same. X is just a letter. Except for the different above, no other modification is performed. Sincerely, DGL Group LTD. Signature: [Amy Chao, General Manager]

Report No.: AGC01559220303AP02 Page 1 of 4 EXTERNAL PHOTOS All VIEW OF EUT-1 All VIEW OF EUT-2 Report No.: AGC01559220303AP02 Page 2 of 4 TOP VIEW OF EUT BOTTOM VIEW OF EUT Report No.: AGC01559220303AP02 Page 3 of 4 FRONT VIEW OF EUT BACK VIEW OF EUT Report No.: AGC01559220303AP02 Page 4 of 4 LEFT VIEW OF EUT RIGHT VIEW OF EUT ****************************************End of Report****************************************

FCC ID Label Location 10mm*20mm FCC ID: 2AANZEBSK-S This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Report No.: AGC01559220303AP02 Page 1 of 3 INTERNAL PHOTOS OPEN VIEW OF EUT (FIGURE 1) ANTENNA CLOSE-UP PHOTO-1 Antenna Report No.: AGC01559220303AP02 Page 2 of 3 VIEW OF BATTERY INTERNAL VIEW OF EUT (FIGURE 1) Report No.: AGC01559220303AP02 Page 3 of 3 INTERNAL VIEW OF EUT (FIGURE 2) ****************************************End of Report****************************************

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description 2-IN-1 Wireless Speaker & Earbuds Test Model NOR-EBSK-GRN Series Model NOR-EBSK, NOR-EBSK-XXX, EW-EBSK-GRN, EW-EBSK, EW-EBSK-XXX FCC ID 2AANZEBSK-S 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION BR/EDR Pt=3.585dBm=2.28mW The value of the Maximum output power Pt is referred to the test report of the CFR47 §15.247. The result for RF exposure evaluation SAR=(2.28mW /5mm) .[√2.480(GHz)]= 0.716<3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. BLE Pt=2.989dBm=1.99mW The value of the Maximum output power Pt is referred to the test report of the CFR47 §15.247. The result for RF exposure evaluation SAR=(1.99mW /5mm) .[√2.480(GHz)]= 0.625<3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. 4. CONCLUSION The SAR evaluation is not required.

Page 1 of 44 FCC Test Report Report No.: AGC01559220303FE02 FCC ID : 2AANZEBSK-S APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : 2-IN-1 Wireless Speaker & Earbuds BRAND NAME : EDGEWOOD MODEL NAME : NOR-EBSK-GRN, NOR-EBSK, NOR-EBSK-XXX, EW-EBSK-GRN, EW-EBSK, EW-EBSK-XXX APPLICANT : DGL Group LTD. DATE OF ISSUE : Mar. 14, 2022 STANDARD(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC01559220303FE02 Page 2 of 44 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Mar. 14, 2022 Valid Initial Release Report No.: AGC01559220303FE02 Page 3 of 44 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ....................................................................................................... 6 2.3. RELATED SUBMITTAL(S)/GRANT(S) ....................................................................................................... 7 2.4. TEST METHODOLOGY ............................................................................................................................. 7 2.5. SPECIAL ACCESSORIES .......................................................................................................................... 7 2.6. EQUIPMENT MODIFICATIONS ................................................................................................................. 7 2.7. ANTENNA REQUIREMENT ....................................................................................................................... 7 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4. DESCRIPTION OF TEST MODES ................................................................................................................... 9 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 10 5.1. CONFIGURATION OF TESTED SYSTEM ............................................................................................... 10 5.2. EQUIPMENT USED IN TESTED SYSTEM .............................................................................................. 10 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 10 6. TEST FACILITY .............................................................................................................................................. 11 7. PEAK OUTPUT POWER ................................................................................................................................ 12 7.1. MEASUREMENT PROCEDURE .............................................................................................................. 12 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 12 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................................. 13 8. BANDWIDTH .................................................................................................................................................. 15 8.1. MEASUREMENT PROCEDURE .............................................................................................................. 15 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 15 8.3. LIMITS AND MEASUREMENT RESULTS ............................................................................................... 15 9. CONDUCTED SPURIOUS EMISSION........................................................................................................... 19 9.1. MEASUREMENT PROCEDURE .............................................................................................................. 19 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 19 9.3. MEASUREMENT EQUIPMENT USED .................................................................................................... 19 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................................. 19 10. MAXIMUM CONDUCTED OUTPUT POWER SPECTRAL DENSITY ........................................................ 26 Report No.: AGC01559220303FE02 Page 4 of 44 10.1. MEASUREMENT PROCEDURE ............................................................................................................ 26 10.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................. 26 10.3. MEASUREMENT EQUIPMENT USED .................................................................................................. 26 10.4. LIMITS AND MEASUREMENT RESULT................................................................................................ 26 11. RADIATED EMISSION ................................................................................................................................. 28 11.1. MEASUREMENT PROCEDURE ............................................................................................................ 28 11.2. TEST SETUP .......................................................................................................................................... 29 11.3. LIMITS AND MEASUREMENT RESULT.........................…

Text truncated - open the document above for the full version.

Report No.: AGC01559220303AP01 Page 1 of 2 TEST SETUP PHOTOS RADIATED EMISSION TEST SETUP BELOW 1GHz RADIATED EMISSION TEST SETUP ABOVE 1GHz Report No.: AGC01559220303AP01 Page 2 of 2 AC POWER LINE CONDUCTED TEST SETUP RF CONDUCTED TEST SETUP ****************************************End of Report*************************************
