2AANZHYWCLPDesk Lamp

DGL Group LTD.

Click to zoom

Application Details

Equipment Class: DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant: May 31, 2022
Application Purpose: Original Equipment
Date of Application: May 31, 2022
Equipment Note: Desk Lamp
Frequency Range: 0.11010000 - 0.20500000
Company: DGL Group LTD.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

External Photos

FCCID:2AANZHYWCLP

ID Label/Location Info

LabelLocationOnEUT Label ProductName:DeskLamp ModelNo.:HY-WCLP FCCID:2AANZHYWCLP ThisdevicecomplieswithPart15oftheFCCRules.Operationis subjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2) Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

Internal Photos

FCCID:2AANZHYWCLP ANT

Operational Description

version01 DGLGroupLTD. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:HY-WCLP,HY-WCLP-WHT,HY-WCLP-BLK,HY-WCLP-XXX FCCID:2AANZHYWCLP fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna:N/A Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:DGLGroupLTD. Address:2045LincolnHighway,Edison,NewJersey08817,UnitedStates City:Edison ZIP/Postalcode:08817 Country:UnitedStates Place:NewJerseyDate:5/31/2022 Signature:
