2AAOLCD2029BTCD Micro System with Bluetooth

Bluetooth CD Micro Model : CD-2029BT Note: Please read and follow these inst ructions before using your unit. • TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. • THIS APPLIANCE SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING WATER AND THAT NO OBJECT FILLED WITH LIQU IDS SUCH AS VASES SHALL BE PLACED ON APPARATUS. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. RISK OF ELECTRIC SHOCK DO NOT OPEN Warning: To reduce the rise of electric shock, do not remove cover (or back) no user-serviceable parts inside. Refer servicing to qualified service personnel. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as r adiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polari zed or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consul t an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. - EN 1 - WARNING 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning stor ms or when unused for long periods of time. 14. Refer all servicing to qualified service per sonnel. Servicing is required when the apparatus has been damaged in any way, such as power-s upply cord or plug is damaged, liquid has been spilled or objects have fallen into t he apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. Grounding or Polarization – This product may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. Alternate Warnings - This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will onl y fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug. 17) Ventilation – Slots and openings in the cabi net are provided for ventilation and to ensure reliable operation of the product and to pr otect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This produc t should not be placed in a built-in installation such as a bookcase or rack unless proper v entilation is provided or the manufacturer’s instructions have been adhered to. 17) The MAINS plug or an appliance coupler is used as the disconnect dev ice, the disconnect device shall remain readily operable. 18) 回 : CLASS II apparatus with double insulati on, and no protective earth provided. - EN 2 - FCC NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are de signed to provide reasonable pr otection against harmful interference in a residential installation. This equi pment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer ence to radio or television recept ion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit di fferent from that to which the receiver is needed. – Consult the dealer or an experi enced radio/TV technician for help. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - EN 3 - LOCATION OF CONTROLS 1. Speakers 16. CD Door OPEN Button 2. POWER/AL. OFF Button 17. CD Door 3. PLAY/PAUSE Button 18. Display 4. FUNC./CL. ADJ. Button 19. Remote Sensor 5. SKIP − /TUNE − Button 20. CD Compartment Back Light 6. SKIP + /TUNE + Button 21. FM Wire Antenna 7. MEM − /AL 1 Button 22. R-SP Jack 8. MEM + /AL 2 Button 23. L-SP Jack 9. P-MODE/MONO Button 24. …

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company Wing Hing Electronics Industrial Ltd. hereby declares: The product model(s) SRCD1079BT-PL is identical in the same PCB layout, interior structure and electrical circuits with the model CD-2029BT which tested in Global United Technology Services Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Simon Chu Position: Manager Date: 2013-10-29

CD2029 BT Rating Label Size : W 59 x H 29 mm Date : 1-11-2013 Color : Black background with White text SRCD1079BT-PL FCC ID: 2AAOLCD2029BT CD Micro System with Bluetooth FREQUENCY RANGE : FM 88 - 108 MHz POWER SOURCE : DC: 3V (AAA x2 FOR CLOCK) DC: 7.5V 1.6A CD-2029BT WINEC FCC ID: 2AAOLCD2029BT CD Micro System with Bluetooth FREQUENCY RANGE : FM 88 - 108 MHz POWER SOURCE : DC: 3V (AAA x2 FOR CLOCK) DC: 7.5V 1.6A MANUFACTURED :MM/YYYY MADE IN CHINA WING HING MANUFACTURED :MM/YYYY MADE IN CHINA WING HING FCC Label Size : W 48 x H 14 mm Date : 1-11-2013 Color : Black background with White text

Label location

RF Exposure evaluation According to 447498 1 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength =94.99dBuV/m @3m Ant gain =2dBi So pt={ [10 (94.99/20) /10 6 x3] 2 /30x1.58 }x1000 mW So ( 0.6 mW/5mm)x √2.48 = 0.19 <3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE13090161301 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS International Electrical Approvals or testing done by GTS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by GTS International Electrical Approvals in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” Page FCC REPORT Applicant: Wing Hing Electronics Industrial Ltd. Address of Applicant: Room 1902-03, 19/F., Enterprise Square One, Tower 3, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong. Equipment Under Test (EUT) Product Name: CD Micro System with Bluetooth Model No.: CD-2029BT, SRCD1079BT-PL FCC ID: 2AAOLCD2029BT Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2012 Date of sample receipt: October 08, 2013 Date of Test: October 08-21, 2013 Date of report issued: October 22, 2013 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE13090161301 Global United Technology Services Co., Ltd. Project No.: GTSE130901613RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 32 2 Version Version No. Date Description 00 October 22, 2013 Original Prepared By: Date: October 22, 2013 Project Engineer Check By: Date: October 22, 2013 Reviewer Report No.: GTSE13090161301 Global United Technology Services Co., Ltd. Project No.: GTSE130901613RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 32 3 Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT:.................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DB OCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS ..........................................…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
