2AAP6M7029Internet Tablet

User’s Manual Internet Tablet DA-741QHD Read this manual before installation and use. We would like you to have a safe and enjoyable experience. Please read the following instructions and notices before using the tablet. Avoid using the tablet in extremely hot, cold, dusty, damp or wet environments. The tablet is not moisture/water-resistant. Avoid using the tablet around sources of water.Avoid dropping or forcibly placing the tablet onto a hard surface. This may damage the screen or internal electronic components. Do not use alcohol, thinner or benzene to clean the surface of the tablet. Use only cleaning products designed for computer tablet devices Do not use the tablet while walking or driving. Excessive use of earphones at high volume may lead to hearing impairment. Limit earphone usage, and adjust the volume to a moderate level when doing so. The images in this manual may vary slightly from the actual product. Charge the tablet batery under any the following circumstances: 1.The battery level icon indicates low power, by showing a drained, red battery icon. 2.The tablet powers-off automatically, and conti nues to do even after restarting. 3.On-screen keys do not work. Do not suddenly disconnect the tablet when formatting, uploading or downloading data. This can lead to program errors(e.g.,system or screen “freezing”.) Static discharge in the cable, while it is con- nected to a computer, may corrupt files or damage the memory of the tablet. Dismantling the tablet will void the manu- facture’s warranty. If experiencing problems, review the Troubleshooting section of this manual.The tablet functions, hardware, software, and warranty information may be improved or modified by the manufacturer or their respec- tive owners, and is subject to change without notice. 2 Important Safety lnstructions and Notices Features 7"1024X600 Capacitive touch-screen, with multi-point touch func tion. Wi-Fi .Play all formats of music, video and picture file, Supports res olution up to 1080P. TF card for data storage and transfer. Energy-saving brightness control and sleep functions. Supports multiple languages. USB 2.0 high-speed transfer. APK program installation using the Applnstaller. Supports firmware upgrades. G-Sensor function: Detects the environment, orientation and pos ition of the tablet, to provide input for various applications. Camera: Front (facing user)0.3MP; Rear 2.0MP The DAGE DA-741QHD 7"Tablet AC Adapter User’s Manual USB Cable 3 Features/What’s In the Box What’s in the Box Important Safety lnstructions and Notices 4 1 10 11 8 234567 9 5 1 Camera 0 . 3Mcamera on front of tablet ( facing the user .) 2 MIC Key 34 567 810 Reset Button 11 Speaker Microphone. Press to reset the tablet. This requires a paper-clip or other small, narrow-tipped item to insert and trigger the reset. (Be careful not to apply excessive pressure to the button located inside the ta blet.) Power/Lock KeyEarphone Jack use with a standard 3.5mm stereo headphone jack. Micro USB PortHDMI 1080P HDMI Output. Connect to a computer via mini USB cable to transfer data (I.e. music, video, photo, data files.) Powers ON/OFF when held for about 3 seconds. Locks and unlocks the tablet in Stand-by Mode. ESC Key Tap to return to the previous screen / page . If the keyboard is in use , close the keyboard . Camera 2.0 MP camera on back of tablet. 9 TF Card Slot Slot for a TransFlash card. Speaker Powering ON/OFF To power ON/OFF the tablet, press and hold the Power button for about 3 sec onds. When turning the tablet ON, you will go to the initial Startup screen and have the option of unlocking it and going to the Home screen, or directly to the Camera app, When turning OFF the tablet, a window will open, verifying your action. 6 Basic Operations Touching and Typing The DA-741QHD tablet screen is designed for you to touch it to move, select and manipulate information. To select an item on the screen, simply tap it Stand-by Mode if you do not want to power-off the tablet, you can opt to deactivate just the LCD screen. This will keep the tablet in Stand-by mode. To deactivate the screen, quickly press and release the Power button. The screen will go black. To reactivate, simply press and release the Power button again. (You may have to unlock the tablet in order to use it, depending on your security settings.) once with your fingertip or stylus. Some items may require you to”double-tap”. To type into on text field(i.e.,when inputting your name, or a web address),tap the text field. The on-screen keyboard will appear, and allow you to type the information you wish to enter. Other common finger gestures include: Touch and Hold: Touching and keeping your finger on an on-screen item, until a light glow appears around it, may activate a separate menu or other options for that item. This is often used for deleting an item from the tablet. Drag: To move an object, or activate functionality, Touch and Hold an item until it glows, then “drag”it to another location on the screen without lifting your finger or stylus. 7 Swipe/Slide: A motion often used to move through menus, pictures or multiple options. This is done with a light tap or flick of the finger/stylus into the direcion you want the item, menu or screen to move toward. Double-Tap: Some items will require two taps in order to activate, zoom-in, zoom-out. Pinch: In some apps (such as Maps, Brower, and Gallery), you can zoom in and out by placing two fingers on the screen at once, and pinching them together (to zoom out) or spreading them apart(to zoom in.) Changing the screen orientation First, maks sure the “Auto-rotate screen”option is selected in the Settings menu(Settings> Accessibility). With this option selected, the screen will automatically rotate based on the vertical/ horizontal orientation it is being held in. To“lock” an orientation, simple deselect the“Auto-rotate screen” option. Resetting the Tablet if the tablet is unresponsive to either touch input or function keys, us e a…

Text truncated - open the document above for the full version.

SHENZHEN ZOWEE TECHNOLOGY CO.,LTD SHENZHEN ZOWEE TECHNOLOGY CO.,LTD FCC ID: 2AAP6M7029 DATE: Oct 21, 2013 We , SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. declares that our product can only operate frequency band from 2412MHz to 2462 MHz in USA and doesn’t provide any controls or software to allow the operation outside of the USA frequency band (rom 2412MHz to 2462 MHz) when we sell this product in USA. Sincerely yours, SHENZHEN ZOWEE TECHNOLOGY CO.,LTD QiaoYing/ Manager Fax: +86-755-26511004 Tel: +86-755-26697888 E-mail: [email protected]

SHENZHEN ZOWEE TECHNOLOGY CO.,LTD SHENZHEN ZOWEE TECHNOLOGY CO.,LTD FCC ID: 2AAP6M7029 DATE: Oct 22, 2013 We , SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. declares that our all of modifications for this product meet FCC rules when the product imanufactured and placed on the market. Sincerely yours, SHENZHEN ZOWEE TECHNOLOGY CO.,LTD QiaoYing/ Manager Fax: +86-755-26511004 Tel: +86-755-26697888 E-mail: [email protected]

SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Attestation for FCC Declaration of Conformity FCC ID: 2AAP6M7029 DATE: Oct 21, 2013 Please be notified that we, the undersigned, SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. declare that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. Testing in regards to this report was done by Interocean EMC Technology Corp. located atNo.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County 244, Taiwan, R.O.C.., which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827 Sincerely yours, SHENZHEN ZOWEE TECHNOLOGY CO.,LTD QiaoYing/ Manager Fax: +86-755-26511004 Tel: +86-755-26697888 E-mail: [email protected]

SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Product Similarity Declaration FCC ID: 2AAP6M7029 DATE: Oct 21, 2013 To Whom It May Concern, We , SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. hereby declare that our (Tablet PC) Model Number: DA07QHD-BLK,DA07QHD-BLU,DA07QHD-PNK,DA07QHD-RED, DA07QHD-PUR,M7029,Q728,Q728-BLK,Q728-BLU,Q728-PNK,Q728-RED,Q728-PUR, GS-728,D728,M728,DA-741QHD,DA-745HD,AP-7S728,TM-7S728,AP-7S778,TM-7S778, AP-7S768,TM-7S768,AP-9S728,TM-9S728, NB07 are same as DA07QHD (PCB,Schemartic,Hardware erc), DA07QHD, DA07QHD-BLK,DA07QHD-BLU, DA07QHD-PNK,DA07QHD-RED,DA07QHD-PUR,M7029,Q728,Q728-BLK, Q728-BLU,Q728-PNK,Q728-RED,Q728-PUR,GS-728,D728,M728,DA-741QHD, DA-745HD,AP-7S728,TM-7S728,AP-7S778,TM-7S778,AP-7S768,TM-7S768,AP-9S728,TM-9S 728, NB07 are Only product Color and trade mark are different,and are named differently due to marketing purposes Please contact me if you have any question. Sincerely yours, SHENZHEN ZOWEE TECHNOLOGY CO.,LTD QiaoYing/ Manager Fax: +86-755-26511004 Tel: +86-755-26697888 E-mail: [email protected]

External photos of the EUT

FCC ID:2AAP6M7029 INPUT:DC 5V/2A TMAX Digital 7” Internet Tablet Made in China FCC ID:2AAP6M7029 INPUT:DC 5V/2A Nobis 7” Internet Tablet Made in China FCC ID:2AAP6M7029 INPUT:DC 5V/2A Double Power 7” Internet Tablet Made in China FCC ID:2AAP6M7029 INPUT:DC 5V/2A 7” Internet Tablet Made in China FCC ID:2AAP6M7029 INPUT:DC 5V/2A APEX Digital 7” Internet Tablet Made in China Label Location

Internal photos of the EUT

TEST REPORT Report Reference No. ..................... : FCC ID. ............................................. : TRE1310001302 R/C: 77672 2AAP6M7029 Compiled by ( position+printed name+signature) .. : File administrators Jerome Luo Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Nov 11, 2013 Representative Laboratory Name . : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : No.149, Gongye 7th Road, Shekou Nanshan, Shenzhen, CHINA Applicant’s name ............................ : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address............................................. : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Test specification: Standard ........................................... : ANSI C95.1–1999 47CFR §2.1093 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Internet Tablet Trade Mark ....................................... : DOPO,D.AGE,TAMX.APEX, Model/Type reference ....................... : DA07QHD Listed Models .................................. : DA07QHD-BLK,DA07QHD-BLU,DA07QHD-PNK,DA07QHD-RED, DA07QHD-PUR,M7029,Q728,Q728-BLK,Q728-BLU,Q728-PNK, Q728-RED,Q728-PUR,GS-728,D728,M728,DA-741QHD, DA-745HD,AP-7S728,TM-7S728,AP-7S778,TM-7S778, AP-7S768,TM-7S768,AP-9S728,TM-9S728, NB07 Manufacturer .................................. : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Operation Frequency ........................ : From 2412MHz to 2462MHz Rating ............................................... : DC 3.70V/DC 5.0V adapter from AC120V/60Hz Software version .............................. : Android 4.2.2 Result ................................................ : PASS Report No.: TRE1310001302 Page 2 of 56 Issued:2013-11-11 T E S T R E P O R T Test Report No. : TRE1310001302 Nov 11, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : Internet Tablet Model /Type : DA07QHD Listed Models : DA07QHD-BLK,DA07QHD-BLU,DA07QHD-PNK, DA07QHD-RED,DA07QHD-PUR,M7029,Q728, Q728-BLK,Q728-BLU,Q728-PNK,Q728-RED, Q728-PUR,GS-728,D728,M728,DA-741QHD, DA-745HD,AP-7S728,TM-7S728,AP-7S778,TM-7S778, AP-7S768,TM-7S768,AP-9S728,TM-9S728, NB07 Applicant : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Manufacturer : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1310001302 Page 3 of 56 Issued:2013-11-11 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Statement of Compliance 5 2.4. Equipment under Test 5 2.5. Short description of the Equipment under Test (EUT) 6 2.6. EUT configuration 6 2.7. Note 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. SAR Limits 8 3.5. Equipments Used during the Test 8 4. SAR MEASUREMENTS SYSTEM CONFIGURATION 9 4.1. SAR Measurement Set-up 9 4.2. DASY5 E-field Probe System 10 4.3. Phantoms 11 4.4. Device Holder 11 4.5. Scanning Procedure 12 4.6. Data Storage and Evaluation 12 4.7. Tissue Dielectric Parameters for Head and Body Phantoms 14 4.8. Tissue equivalent liquid properties 14 4.9. System Check 15 4.10. SAR measurement procedure 16 5. TEST CONDITIONS AND RESULTS 20 5.1. Conducted Power Results 20 5.2. Simultaneous TX SAR Considerations 20 5.3. SAR Measurement Results 23 5.4. SAR Measurement Variability 23 5.5. Measurement Uncertainty (300MHz-3GHz) 24 5.6. System Check Results 26 5.7. SAR Test Graph Results 27 6. CALIBRATION CERTIFICATE 29 6.1. Probe Calibration Ceriticate 29 6.2. D2450V2 Dipole Calibration Ceriticate 40 6.3. DAE4 Calibration Ceriticate 48 7. TEST SETUP PHOTOS 53 8. EXTERNAL PHOTOS OF THE EUT 54 Report No.: TRE1310001302 Page 4 of 56 Issued:2013-11-11 1. TEST STANDARDS The tests were performed according to following standards: IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. KDB 447498 D01 Mobile Portable RF Exposure v05r01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01: SAR Measurement Requirements for 100 MHz to 6 GHz KDB865664 D02 SAR Reporting v01: RF Exposure Compliance Reporting and Documentation Considerations KDB248227: SAR m…

Text truncated - open the document above for the full version.

FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. .............................................: TRE1310001301 R/C: 77672 2AAP6M7029 Compiled by ( position+printed name+signature) .. : File administrators Eric Wang Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Nov 14, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................ : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address ............................................ : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Test specification: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Internet Tablet Trade Mark ....................................... : DOPO,D.AGE,TAMX.APEX, Nobis Model/Type reference ....................... : DA07QHD Listed Models .................................. : DA07QHD-BLK,DA07QHD-BLU,DA07QHD-PNK,DA07QHD-RED, DA07QHD-PUR,M7029,Q728,Q728-BLK,Q728-BLU,Q728-PNK, Q728-RED,Q728-PUR,GS-728,D728,M728,DA-741QHD, DA-745HD,AP-7S728,TM-7S728,AP-7S778,TM-7S778, AP-7S768,TM-7S768,AP-9S728,TM-9S728, NB07 Manufacturer .................................. : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Operation Frequency ........................ : From 2412MHz to 2462MHz Rating ............................................... : DC 3.70V/DC 5.0V adapter from AC120V/60Hz Software version .............................. : Android 4.2.2 Result................................................ : PASS Report No.: TRE1310001301 Page 2 of 102 Issued:2013-11-14 T E S T R E P O R T Test Report No. : TRE1310001301 Nov 14, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : Internet Tablet Model /Type : DA07QHD Listed Models : DA07QHD-BLK,DA07QHD-BLU,DA07QHD-PNK, DA07QHD-RED,DA07QHD-PUR,M7029,Q728, Q728-BLK,Q728-BLU,Q728-PNK,Q728-RED, Q728-PUR,GS-728,D728,M728,DA-741QHD, DA-745HD,AP-7S728,TM-7S728,AP-7S778,TM-7S778, AP-7S768,TM-7S768,AP-9S728,TM-9S728, NB07 Applicant : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Manufacturer SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1310001301 Page 3 of 102 Issued:2013-11-14 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Description of the test mode 5 2.5. Short description of the Equipment under Test (EUT) 6 2.6. EUT operation mode 6 2.7. EUT configuration 6 2.8. Related Submittal(s) / Grant (s) 6 2.9. Modifications 6 2.10. NOTE 6 3. TEST ENVIRONMENT ............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Test Description 8 3.6. Statement of the measurement uncertainty 9 3.7. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 11 4.1. AC Power Conducted Emission 11 4.2. Radiated Emission 14 4.3. Maximum Peak Output Power 23 4.4. Power Spectral Density 32 4.5. Band Edge Compliance of RF Emission 41 4.6. Spurious RF Conducted Emission 52 4.7. 6dB Bandwidth 83 4.8. Antenna Requirement 92 5. TEST SETUP PHOTOS OF THE EUT .......................................... 93 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 95 Report No.: TRE1310001301 Page 4 of 102 Issued:2013-11-14 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10 : American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: TRE1310001301 Page 5 of 102 Issued:2013-11-14 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Sep 11, 2013 Testing commenced on : Sep 13, 2013 Testing concluded on : Nov 14,2013 2.2. Product Description The SHENZHEN ZOWEE TECHNOLOGY CO.,LTD’s Model: DA07QHD or the “EUT” as referred to in this report; more general information as follows, for m…

Text truncated - open the document above for the full version.

Test setup photos of the EUT_DTS

Test setup photos of the EUT_SAR 0mm Body-worn Rear Side Setup Photo 0mm Body-worn Bottom Side Setup Photo
