2AAP6M7047Internet Tablet

User’s Manual Internet Tablet NB7022 S Read this manual before installation and use. We would like you to have a safe and enjoyable experience. Please read the following instructions and notices before using the tablet. Avoid using the tablet in extremely hot, cold, dusty, damp or wet environments. The tablet is not moisture/water-resistant. Avoid using the tablet around sources of water. Avoid dropping or forcibly placing the tablet onto a hard surface. This may damage the screen or internal electronic components. Do not use alcohol, thinner or benzene to clean the surface of the tablet. Use only cleaning products designed for computer tablet devices Do not use the tablet while walking or driving. Excessive use of earphones at high volume may lead to hearing impairment. Limit earphone usage, and adjust the volume to a moderate level when doing so. The images in this manual may vary slightly from the actual product. Charge the tablet battery under any the following circumstances: 1.The battery level icon indicates low power, by showing a drained, red battery icon. 2.The tablet powers-off automatically, and continues to do even after restarting. 3.On-screen keys do not work. Do not suddenly disconnect the tablet when formatting, uploading or downloading data. This can lead to program errors(e.g.,system or screen “freezing”.) Static discharge in the cable, while it is con- nected to a computer, may corrupt files or damage the memory of the tablet. Dismantling the tablet will void the manu- facture’s warranty. If experiencing problems, review the Troubleshooting section of this manual. The tablet functions, hardware, software, and warranty information may be improved or modified by the manufacturer or their respec- tive owners, and is subject to change without notice. 2 Important Safety lnstructions and Notices Features 7 1024 WiFi b/g/n . Play many formats of music, video and picture formats, Supports resolution up to 1080P. Micro SD card slot for data storage and transfer. Energy-saving brightness control and sleep functions. Supports multiple languages. USB 2.0 high-speed transfer. APK program installation using the Applnstaller. Supports firmware upgrades. G-Sensor function: Detects the environment, orientation and position of the tablet, to provide input for various applications. Camera: Front (facing user)0.3MP; Rear 2.0MP The Nobis NB7022 S 7" tablet AC Adapter x1 User ’s Manual USB Cable " X600 capacitive touch screen. x1 x1 OTG(”On-the-Go”) Cable x1 3 Features/What’s In the Box What’s in the Box Important Safety lnstructions and Notices 4 1 23 4 5 6 7 8 9 10 5 1 Front Camera 2 3 4 Micro USB Port 5 6 7 Earphone Jack Use with a standard 3.5mm stereo headphone jack. Power/Lock Key Powers ON/OFF when held for about 3 seconds. Locks and unlocks the tablet in Stand-by Mode. Micro SD card slotSlot for Micro SD card. Speaker Speaker Connect to a computer via mini USB cable to transfer data (l.e.music, video,photo,data files.) 0.3MP camera on front of tablet (facing the user.) 8 9 Reset ButtonPress to reset the tablet. This requires a paper-clip or other small. narrow-tipped item to insert and trigger the reset. (Be careful not to apply excessive pressure to the button located inside the tablet.) Volume-/+Key Increases/ Decreases audio volume in either speakers or earphones. MIC Jack Microphone 10 Rear Camera 2.0MP camera on back tablet. Powering ON/OFF To power ON/OFF the tablet, press and hold the Power button for about 3 seconds. When turning the tablet ON, you will go to the initial Startup screen and have the option of unlocking it and going to the Home screen, or directly to the Camera app, When turning OFF the tablet, a window will open, verifying your action. 6 Basic Operations Touching and Typing The NB7022 S tablet screen is designed for you to touch it to move, select and manipulate information. To select an item on the screen, simply tap it Stand-by Mode If you do not want to power-off the tablet, you can opt to deactivate just the LCD screen. This will keep the tablet in Stand-by mode. To deactivate the screen, quickly press and release the Power button. The screen will go black. To reactivate, simply press and release the Power button again. (You may have to unlock the tablet in order to use it, depending on your security settings.) once with your fingertip or stylus. Some items may require you to”double-tap”. To type into on text field(i.e.,when inputting your name, or a web address),tap the text field. The on-screen keyboard will appear, and allow you to type the information you wish to enter. Other common finger gestures include: Touch and Hold: Touching and keeping your finger on an on-screen item, until a light glow appears around it, may activate a separate menu or other options for that item. This is often used for deleting an item from the tablet. Drag: To move an object, or activate functionality, Touch and Hold an item until it glows, then “drag”it to another location on the screen without lifting your finger or stylus. 7 Swipe/Slide: A motion often used to move through menus, pictures or multiple options. This is done with a light tap or flick of the finger/stylus into the direcion you want the item, menu or screen to move toward. Double-Tap: Some items will require two taps in order to activate, zoom-in, zoom-out. Pinch: In some apps (such as Maps, Brower, and Gallery), you can zoom in and out by placing two fingers on the screen at once, and pinching them together (to zoom out) or spreading them apart(to zoom in.) Changing the screen orientation First, makes sure the “Auto-rotate screen”option is selected in the Settings menu(Settings> Accessibility). With this option selected, the screen will automatically rotate based on the vertical/ horizontal orientation it is being held in. To“lock” an orientation, simple deselect the“Auto-rotate screen” option. Resetting the Tablet if the tablet is unresponsive to either touch input or function keys, use a paperclip or simi…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA 2014-5-27 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AAP6M7047 Product Name: Internet Tablet Trade mark: DOPO, D.AGE,TMAX, APEX, Nobis Model: M7407, NB7022 S, NB7024 S, NB7026 S, NB7035, TM724, TM723, TM729, TM735, DPA31Q, DPA35P, DPA56S, DPA31S, M7043, M7050, M7055 We affirm that between SIEMIC and SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Mr.Qiao ying / Manager Company Name: SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. Address: Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA E-mail: [email protected] Fax: 0755-26511004 Tel: 0755-26997888-6638

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA May 27,2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAP6M7047 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram- Long-term confidential - Schematics- Long-term confidential - Operational Description- Long-term confidential The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Mr.qiaoying /Manager Company Name: SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address: Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA E-mail: [email protected] Fax: 0755-26511004 Tel: 0755-26997888-6638

Date: 2014-5-27 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AAP6M7047 To Whom It May Concern: This letter is to ascertain that SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Product Internet Tablet has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title: Mr.qiaoying /Manager Contact information / address Address: Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA E-mail: [email protected] Fax: 0755-26511004 Tel: 0755-26997888-6638

Differences Declaration To whom concern, We company SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. hereby declares: The product model(s) NB7022 S, NB7024 S, NB7026 S, NB7035, TM724, TM723, TM729, TM735, DPA31Q, DPA35P, DPA56S, DPA31S, M7043, M7050, M7055 is identical in the same PCB layout, interior structure and electrical circuits with the model M7047 which tested in Shenzhen Huatongwei International Inspection Co., Ltd, the only differences are the model name for commercial purpose. Sincerely yours, Name:zuo Yongqian Position: Manager CompanyAdress: Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Te l / F a x : +86-755-26997888-6638/+86-755-26511004 E-Mail: [email protected]

Report No : TRE1404007301 Page 60 of 65 6. External and Internal Photos of the EUT External photos of the EUT Report No : TRE1404007301 Page 61 of 65 Report No : TRE1404007301 Page 62 of 65

1:1 108mm 1 8 8 m m M i c r o S D M7047后壳丝印 丝印颜色：白色 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. BC FCC ID:2AAP6M7047 INPUT:DC 5V/2A Made in China Production date: May/2014 Model No:M7047

Report No : TRE1404007301 Page 63 of 65 Internal photos of the EUT Report No : TRE1404007301 Page 64 of 65 Report No : TRE1404007301 Page 65 of 65 .......................End of Report.........................

TEST REPORT Report Reference No. ..................... : TRE1404007302 R/C..........:46475 Compiled by ( position+printed name+signature) .. : File administrators Vivi Zhou Supervised by ( position+printed name+signature) .. : Test Engineer Jerome Luo Approved by ( position+printed name+signature) .. : Manager Hans Hu Date of issue ..................................... : May 24, 2014 Representative Laboratory Name . : Shenzhen Huatongwei International Inspection Co., Ltd Address............................................. : No.149, Gongye 7th Road, Shekou Nanshan, Shenzhen, CHINA Applicant’s name ............................ : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. Address............................................. : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Test specification: Standard ........................................... : ANSI C95.1–1999 47CFR §2.1093 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Internet Tablet Trade Mark ....................................... : DOPO, D.AGE,TMAX,APEX, Nobis Manufacturer .................................... : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. Model/Type reference ....................... : M7047 Listed Models .................................. : NB7022 S, NB7024 S, NB7026 S, NB7035, TM724, TM723, TM729, TM735, DPA31Q, DPA35P, DPA56S, DPA31S, M7043, M7050, M7055 Rating ............................................... : DC 3.70V/DC 5.0V adapter from AC120V/60Hz Result ................................................ : Positive Report No.: TRE1404007302 Page 2 of 55 T E S T R E P O R T Test Report No. : TRE1404007302 May 24, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Internet Tablet Model /Type : M7047 Listed Models : NB7022 S, NB7024 S, NB7026 S, NB7035, TM724, TM723, TM729, TM735, DPA31Q, DPA35P, DPA56S, DPA31S, M7043, M7050, M7055 Applicant : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Manufacturer : SHENZHEN ZOWEE TECHNOLOGY CO.,LTD Address : Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1404007302 Page 3 of 55 Contents 1. TEST STANDARDS 4 2. SUMMARY 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Statement of Compliance 6 2.4. Equipment under Test 6 2.5. Short description of the Equipment under Test (EUT) 6 2.6. EUT configuration 6 3. TEST ENVIRONMENT 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. SAR Limits 8 3.5. Equipments Used during the Test 8 4. SAR MEASUREMENTS SYSTEM CONFIGURATION 9 4.1. SAR Measurement Set-up 9 4.2. DASY5 E-field Probe System 10 4.3. Phantoms 11 4.4. Device Holder 11 4.5. Scanning Procedure 12 4.6. Data Storage and Evaluation 12 4.7. Tissue Dielectric Parameters for Head and Body Phantoms 14 4.8. Tissue equivalent liquid properties 15 4.9. System Check 15 4.10. SAR measurement procedure 16 5. TEST CONDITIONS AND RESULTS 20 5.1. Conducted Power Results 20 5.2. Simultaneous TX SAR Considerations 20 5.3. SAR Measurement Results 23 5.4. SAR Measurement Variability 24 5.5. Measurement Uncertainty (300MHz-3GHz) 24 5.6. System Check Results 26 5.7. SAR Test Graph Results 27 6. CALIBRATION CERTIFICATE 29 6.1. Probe Calibration Ceriticate 29 6.2. D2450V2 Dipole Calibration Ceriticate 40 6.3. DAE4 Calibration Ceriticate 48 7. TEST SETUP PHOTOS 51 8. EXTERNAL PHOTOS OF THE EUT 53 Report No.: TRE1404007302 Page 4 of 55 1. TEST STANDARDS The tests were performed according to following standards: IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. KDB 447498 D01 Mobile Portable RF Exposure v05r02: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 616217 D04 SAR for laptop and tablets v01: SAR Evaluation Considerations for Laptop, Notebook, Netbook and Tablet Computers KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01r03: SAR Measurement Requirements for 100 MHz to 6 GHz KDB865664 D02 SAR Reporting v01: RF Exposure Compliance Reporting and Documentation Considerations KDB248227: SAR measurement procedures for 802.112abg transmitters FCC Part 2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices Report No.: TRE1404007302 Page 5 of 55 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : May 20,2014 Testing commenced on : May 22,2014 Testing concluded on : May 24,2014…

Text truncated - open the document above for the full version.

The test r It is not pe Report R FCC ID ... Applican Address .. Manufactu Address.. Test item Trade Ma Model/Typ List Mode Standard Date of re Date of te Date of is Result .... Compiled ( position + Supervise ( position+ Approved ( position + Testing L Address .. Shenzhen This publi Huatongw Shenzhen for damag context. report merely ermitted to c Reference No .................... t’s name ..... .................... urer.............. .................... m description ark ................ pe reference el .................. d ................... eceipt of test esting............ sue............ .............. ...... by +printed nam ed by +printed nam by +printed nam Laboratory N .................... n Huatongw cation may b wei Internatio n Huatongwe ges resulting y correspond opy extracts o. ................. .................... .................... .................... .................... .................... n ................. .................... e ................... .................... .................... sample...... ...............: ..................: .................. me+signature me+signature me+signature Name .......... .................... wei Internatio be reproduce onal Inspectio ei Internation from the rea ds to the test of these te s TES ... : TRE1 ... : 2AAP ... : SHEN .... : Scie n Pings .....: SHEN ......: Scie n Pings ... : Intern .... : DOPO .... : M704 .... : NB7 0 TM73 M705 ... : FCC .: Apr 1 Apr 1 Apr 2 ......: PASS e) .. : File a e) .. : Proje e) .. : RF M ... : Shen .... : Keji N onal Inspec ed in whole o on Co., Ltd is nal Inspection ader's interpr sample. st result witho ST RE 1404007301 P6M7047 NZHEN ZOW nce &Techno shan, Xili, Na NZHEN ZOW nce &Techno shan, Xili, Na net Tablet O, D.AGE,TM 47 022 S, NB70 35, DPA31Q 55 CFR Title 4 7 0, 2014 2, 2014- M a 22, 2014 S administrator ect Engineer Manager Han nzhen Huato Nan No.12 R ction Co., Ltd or in part for s acknowledg n Co., Ltd tak retation of th out the writte EPOR WEE TECHN ology Industr anshan Distr WEE TECHN ology Industr anshan Distr MAX,APEX, 24 S, NB70 2 , DPA35P, D 7 Part 15 Su ay20, 2014 rs Vivi Zhou Eric Wang ns Hu ongwei Inter Road, Hi-tech d. All rights non-commer ged as copy kes no respo e reproduce en permission RT R/C... NOLOGY CO rial Park of P ict, Shenzh e NOLOGY CO rial Park of P ict, Shenzh e Nobis 26 S, NB703 DPA56S, DPA ubpart C Sec rnational Ins h Park, Shenz reserved. rcial purpose right owner a onsibility for a d material du n of the test l ..........: 9821 O.,LTD. rivately Ow n en, PR CHINA O.,LTD. rivately Ow n en, PR CHINA 5, TM724, T A31S, M704 ction 15.247 spection Co zhen, China es as long as and source o and will not a ue to its plac laboratory. 14 ned Enterpris A ned Enterpris A TM723, TM72 43, M7050, 7 o., Ltd s the Shenzh of the materia assume liabil cement and ses, ses, 29, hen al. lity Report No : TRE1404007301 Page 2 of 65 Contents 1. TEST STANDARDS AND TEST DESCRIPTION ....................................... 3 1.1. Test Standards 3 1.2. Test Description 3 2. SUMMARY ............................................................................... 4 2.1. Client Information 4 2.2. Product Description 4 2.3. EUT operation mode 5 2.4. EUT configuration 5 2.5. Modifications 5 3. TEST ENVIRONMENT .................................................................. 6 3.1. Address of the test laboratory 6 3.2. Test Facility 6 3.3. Environmental conditions 7 3.4. Statement of the measurement uncertainty 7 3.5. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ................................................... 9 4.1. Antenna requirement 9 4.2. Conducted Emission (AC Main) 10 4.3. Conducted Peak Output Power 13 4.4. Power Spectral Density 18 4.5. 6dB bandwidth 23 4.6. Band Edge 28 4.7. Spurious Emission (conducted) 40 4.8. Spurious Emission (radiated) 53 5. TEST SETUP PHOTOS OF THE EUT ........................................... 58 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT .................................... 60 Report No : TRE1404007301 Page 3 of 65 1. TEST STANDARDS AND TEST DESCRIPTION 1.1. Test Standards The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10 : American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 1.2. Test Description Test Item Section in CFR 47 Result Antenna requirement 15.203/15.247 (c) Pass Line Conducted Emission (AC Main) 15.207 Pass Conducted Peak Output Power 15.247 (b)(3) Pass Power Spectral Density 15.247 (e) Pass 6dB Bandwidth 15.247 (a)(2) Pass Band Edge 15.247(d) Pass Spurious Emission 15.205/15.209 Pass Remark: The measurement uncertainty is not included in the test result. Report No : TRE1404007301 Page 4 of 65 2. SUMMARY 2.1. Client Information Applicant: SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. Address: Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA Manufacturer: SHENZHEN ZOWEE TECHNOLOGY CO.,LTD. Address: Science &Technology Industrial Park of Privately Owned Enterprises, Pingshan, Xili, Nanshan District, Shenzhen, PR CHINA 2.2. Product Description Name of EUT Internet Tablet Trade Mark: DOPO, D.AGE, TMAX, APEX, Nobis Model No.: M7047 List Model: NB7022 S, NB7024 S, NB7026 S, NB7035, TM724, TM723, TM729, TM735, DPA31Q, DPA35P, DPA56S, DPA31S, M7043, M7050, M7055 Power supply: DC 3.7V From Internal Battery Adapter information: Mode:JK050200-S04USA INPUT:100-240V 50/60Hz 0.5A OUTPUT:5V 2000mA WIFI Supported type: 802.11b/802.11g/802.11n(H20)/802.11n(H40) Modulation: 802.11b: DSSS 802.11g/802.11n(H20)/802.11n(H40):OFDM Operation frequency: 802.11b/802.11g/802.11n(H20): 2412MHz~2462MHz 802.11n(H40): 2422MHz~2452MHz Bit Rate: 802.11b: 1/…

Text truncated - open the document above for the full version.

Report No : TRE1404007301 Page 58 of 65 5. Test Setup Photos of the EUT Radiated Emission (Below 30MHz) Radiated Emission (30MHz-1GHz) Radiated Emission (above 1GHz) Report No : TRE1404007301 Page 59 of 65 Conducted Emission (AC Mains)
