2AAQ6TC05GPS Tracker

New Product Requirement Asiatelco Technologies Co. Proprietary/Confidential User manual Contents 1 Introduction .............................................................................................................................. 2 2 ID and Tooling Design ................................................................................................................ 4 3 Hardware Requirements ........................................................................................................... 5 3.1 Basic Hardware Requirements ......................................................................................... 5 3.2 Basic RF Performance Requirements ................................................................................ 7 3.3 Certification and Safety Requirements ............................................................................. 9 4 Software Requirements ........................................................................................................... 10 4.1 Basic Software Requirements ......................................................................................... 10 4.2 Remote Update ............................................................................................................... 10 4.2.1 Auto Execute .............................................................................................................. 10 4.3 Power Modes .................................................................................................................. 10 4.4 AT Command .................................................................................................................. 11 4.5 Report ............................................................................................................................. 13 4.6 Reset ............................................................................................................................... 13 4.6.1 Context Preservation .................................................................................................. 13 4.7 Startup Banner ............................................................................................................... 13 5 Test Plan .................................................................................................................................. 14 5.1 Hardware Test ................................................................................................................. 14 5.2 Software Test .................................................................................................................. 14 6 Package Requirement .............................................................................................................. 16 6.1 Package Content ............................................................................................................. 16 7 Required Project Schedule ...................................................................................................... 16 New Product Requirement Asiatelco Technologies Co. Proprietary/Confidential 1 Introduction The MC891G is a self-contained vehicle tracking device that combines GPS location with CDMA connectivity. Logically, the ION appears to a user or a server application as a single endpoint device. It can be queried, updated and configured either through a serial connection, or an over the air CDMA IP connection, or through SMS messaging. The MC891G presents itself over these connections as an enhanced cellular modem with attached functional elements. These elements include: GPS location engine 2 General Purpose Bidirectional I/ O (GPIO) pins 1 Relay drive pin output Se ria l UART po rt Input voltage monitor (optional) Tim e r s Watchdog lockup protection (Dedicated watchdog circuit is optional) Fa ct o r y load option for motion detection Access to these elements and general purpose interfaces is done through an extended AT command set as defined herein. Application scene: T his product will be designed based on the VIA CBP8.2 CDMA 1X 800M&1900M Baseband chipset, which includes GPS functionality, ARM CPU and CDMA protocol. This baseband external connection 256M serial flash, CDMA 800M/1900M/GPS RF Transceiver, and RF Front end circuit. The device will use one dual band antenna（CDMA800&CDMA1900）and one dedicate GPS antenna. Internet Server (IP) Server (SMS) IP CDMA Network OTA ION-X GPS Car New Product Requirement Asiatelco Technologies Co. Proprietary/Confidential Marketing Information Item Description Potential market America Product Design Requirement Cost: Low end Expected sample Date QTY of Samples New Product Requirement Asiatelco Technologies Co. Proprietary/Confidential 2 ID and Tooling Design The product appearance is shown as follows: New Product Requirement Asiatelco Technologies Co. Proprietary/Confidential 3 Hardware Requirements 3.1 Basic Hardware Requirements Items Requirement Baseband Chipset VIA CBP8.2C/CBP8.2D RF Transceiver FCI7790 Memory Serial Flash 256Mb PSRAM 128Mb/6 4 M b (optional) Air Interface CDMA 2000 1x, GPS Frequency CDMA2000 1x: 800MHz,1900MHz Antenna Internal Antenna(800M&1900M) GPS Antenna Dedicate high performance ceramic antenna UIM requirement No-UIM mode, UIM card connector optional Interface UART TX UART RX 12V DC Input（1A current） Relay Drive (12V Output ,500mA current) GPIO1 GPIO2 Battery Monitor internal analog input scaled (Optional) Build in battery manager Required Dedicate T imers No Watchdog Required(Dedicate Watchdog is Optional) Motion Detect Optional（GPS/Sensor） LED 2 LED required 2 LEDs(one is RED，one is Green) Battery Build in battery（80MAH Lion） Working Time 4hours Power switch No Power Cable color 8 colors Power Cable connector type 8 pin Power Consumption < 5Watts The MC891G provides support for specialized hardware features through extended AT commands. The features supported include the following. GPS The major functionality of the GPS module is to compute t…

Text truncated - open the document above for the full version.

Montage Systems, Inc. 65 Enterprise, Aliso Viejo, CA 92656 DATE :2015-7-22 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank.Yan of Global United Technology Services Co., Ltd. Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Montage Systems, Inc. and 65 Enterprise, Aliso Viejo, CA 92656 Dated this / Day of 7/22/2015 / Agency agreement expiration date: 7/22/2016 B y: Eric Collins Printed Title: President On behalf of : Montage Systems, Inc. Telephone: 949-330-8099

Size：32.8 x 21.5mm

FCC ID:2AAQ6TC05 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation The RF exposure evaluation as below: C hannel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result CDMA2000 BC0 297.852 0.09391 0.55 PASS CDMA2000 BC1 258.821 0.08161 1.0 PASS Rem ark: antenna gain=2.0 dBi

Report No.: GTSE15070126401 1 Cover Page FCC Report Applicant: Montage Systems, Inc. Address of Applicant: 65 Enterprise, Aliso Viejo, CA, United States, 92656 Equipment Under Test (EUT) Product Name: GPS Tracker Model No.: S3000, S3000-S, S3000-V, S3000-S-G, S3000-V-G, S3000-S-BG, S3000-V-BG, S3000-S-BA, S3000-V-BA, S3000-VB-G, S3000-SB-G, S3000-SB, SC2000-SB, S3000-VB FCC ID: 2AAQ6TC05 Applicable standards: FCC CFR Title 47 Part 2:2014 FCC CFR Title 47 Part22 Subpart H:2014 FCC CFR Title 47 Part24 Subpart E:2014 Date of sample receipt: July 14, 2015 Date of Test: July 15-17, 2015 Date of report issued: July 20, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE15070126401 Project No.: GTSE150701264RF Page 2 of 36 2 Version Version No. Date Description 00 July 20, 2015 Original Prepared By: Date: July 20, 2015 Project Engineer Check By: Date: July 20, 2015 Reviewer Report No.: GTSE15070126401 Project No.: GTSE150701264RF Page 3 of 36 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION.......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................... 6 5.4 TEST METHODOLOGY.......................................................................................................................... 6 5.5 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 SYSTEM TEST CONFIGURATION ......................................................................................................... 8 7.1 EUT CONFIGURATION......................................................................................................................... 8 7.2 EUT EXERCISE.................................................................................................................................. 8 7.3 CONFIGURATION OF TESTED SYSTEM.................................................................................................. 8 7.4 DESCRIPTION OF TEST MODES............................................................................................................ 8 7.5 CONDUCTED PEAK OUTPUT POWER.................................................................................................. 10 7.6 OCCUPY BANDWIDTH........................................................................................................................ 11 7.7 MODULATION CHARACTERISTIC............................................................................................... 15 7.8 OUT OF BAND EMISSION AT ANTENNA TERMINALS................................................................................ 15 7.9 ERP, EIRP MEASUREMENT.............................................................................................................. 19 7.10 FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT.................................................................. 23 7.11 FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT................................................................ 27 7.12 FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT........................................................................ 29 8 TEST SETUP PHOTO ............................................................................................................................ 31 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................32 Report No.: GTSE15070126401 Project No.: GTSE150701264RF Page 4 of 36 4 Test Summary Test Item Section in CFR 47 Result RF Output Power Part 2.1046 Part 22.913 (a)(2) Part 24.232 (c) Pass Modulation Characteristics Part 2.1047 Pass 99% & -26 dB Occupied Bandwidth Part 2.1049 Part 22.917 Part 24.238 Pass Spurious Emissions at Antenna Terminal Part 2.1051 Part 22.917 (a) Part 24.238 (a) Pass Field Strength of Spurious Radiation Part 2.1053 Part 22.917 (a) Part 24.238 (a) Pass Out of band emission, Band Edge Part 22.917 (a) Part 24.238 (a) Pass Frequency stability vs. temperature Part 2.1055(a)(1)(b) Pass Frequency stability vs. voltage Part 2.1055(d)(1)(2) Pass Pass: The EUT complies with the essential requirements in the standard. 4.1 Measurement Uncertainty Test Item Frequency Range Measurement Uncertainty Notes Radiated Emission 9kHz ~ 30MHz  4.34dB (1) Radiated Emission 30MHz ~ 1000MHz  4.24dB (1) Radiated Emission 1GHz ~ 26.5GHz  4.68dB (1) AC Power Line Conducted Emission 0.15MHz ~ 30MHz  3.45dB (1) Note (1): The measurement uncertainty is for coverage factor of k=2 and a level of confidence of 95%. Report No.: GTSE15070126401 Project No.: GTSE150701264RF Page 5 of 36 5 General Information 5.1 Client Information Applicant: Montage Systems, Inc. Address of Applicant: 65 Enterprise, Aliso V…

Text truncated - open the document above for the full version.

Radiated Emission
