RF Exposure Statement To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 China Electronics Shenzhen Company. 2015-09-10 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, China Electronics Shenzhen Company. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product name: 5.1CH Bluetooth speaker system Model Number: AR5100 FCC ID: 2AAQFAR5100 Sincerely, signature Xie xu ning / Engineer E-mail: [email protected] Phone: 0086-755-83783780 Fax: 0086-755-83783961 Address: 33F,Tower A,Electronic Science and Technology Building,2070 Shennan Zhonglu,Futian District Shenzhen
Label Location Proposed Label Location on EUT
FCC ID : 2AAQFAR5100 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the followi ng table shall be used to evaluat e the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission form ula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Channel Freq. (GHz) modulation conducted power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2.402 GFSK -0.65 0 ± 1 1 1 0.0026 1 2.441 GFSK -1.87 -1 ± 1 0 1 0.0020 1 2.480 GFSK -3.14 -3 ± 1 -2 1 0.0012 1 2.402 π /4-DQPSK -3.61 -3 ± 1 -2 1 0.0012 1 2.441 π /4-DQPSK -4.88 -4 ± 1 -3 1 0.0010 1 2.480 π /4-DQPSK -6.16 -6 ± 1 -5 1 0.0006 1 2.402 8-DPS K -5.31 -5 ± 1 -4 1 0.0008 1 2.441 8-DPSK -6.55 -6 ± 1 -5 1 0.0006 1 2.480 8-DPSK -7.89 -7 ± 1 -6 1 0.0006 1
