FCC ID : 2AAQFSBT5100 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the followi ng table shall be used to evaluat e the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission form ula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result Channel Freq. (GHz) modulation conducted power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2.402 GFSK -0.30 0 ± 1 1 1 0.00025 1 2.441 GFSK -1.87 -1 ± 1 0 1 0.00020 1 2.480 GFSK -3.14 -3 ± 1 -2 1 0.00013 1 2.402 π /4-DQPSK -3.61 -3 ± 1 -2 1 0.00013 1 2.441 π /4-DQPSK -4.88 -4 ± 1 -3 1 0.00010 1 2.480 π /4-DQPSK -6.16 -6 ± 1 -5 1 0.00006 1 2.402 8-DPS K -5.31 -5 ± 1 -4 1 0.00008 1 2.441 8-DPSK -6.55 -6 ± 1 -5 1 0.00006 1 2.480 8-DPSK -7.89 -7 ± 1 -6 1 0.00005 1

TRF No.:FCC 15.247/A Page 1 of 61 Report No.: ES150824002E-1 Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For 5.1CH Bluetooth speaker system MODEL No.: SBT5100,PBT5100,BS501,BS501B,AR5100 FCC ID: 2AAQFSBT5100 REPORT NO.: ES150824002E-1 ISSUE DATE: November 11, 2015 Prepared for China Electronics Shenzhen Company. 33F,Tower A,Electronic Science and Technology Building,2070 Shennan Zhonglu,Futian District Shenzhen Prepared by Emtek (Shenzhen) Co., Ltd. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.:FCC 15.247/A Page 2 of 61 Report No.: ES150824002E-1 Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION .......................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................................ 4 3 SUMMARY OF TEST RESULT .............................................................................................................................. 5 4 TEST METHODOLOGY ........................................................................................................................................ 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED ..................................................................................................... 6 4.3 DESCRIPTION OF TEST MODES ............................................................................................................. 7 5 FACILITIES AND ACCREDITATIONS ................................................................................................................. 8 5.1 FACILITIES ................................................................................................................................................. 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS .............................................................................. 8 6 TEST SYSTEM UNCERTAINTY ........................................................................................................................... 9 7 SETUP OF EQUIPMENT UNDER TEST ............................................................................................................. 10 7.1 RADIO FREQUENCY TEST SETUP 1 ..................................................................................................... 10 7.2 RADIO FREQUENCY TEST SETUP 2 ..................................................................................................... 10 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................................. 11 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ..................................................................................... 12 8.1 STA N D A R D APPLICABLE .............................................................................................................................. 12 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ........................................................................... 12 8.3 EQUAL HOPPING FREQUENCY USE .............................................................................................................. 13 8.4 FREQUENCY HOPPING SYSTEM .................................................................................................................... 13 9 TEST REQUIREMENTS ....................................................................................................................................... 14 9.1 20DB BANDWIDTH ................................................................................................................................. 14 9.2 CARRIER FREQUENCY SEPARATION .................................................................................................. 20 9.3 NUMBER OF HOPPING FREQUENCIES ............................................................................................... 26 9.4 AV E R A G E TIME OF OCCUPANCY (DWELL TIME) ............................................................................. 28 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................................ 31 9.6 CONDUCTED SUPRIOUS EMISSION .................................................................................................... 37 9.7 RADIATED SPURIOUS EMISSION ......................................................................................................... 44 9.8 CONDUCTED EMISSION TEST .............................................................................................................. 58 9.9 ANTENNA APPLICATION ....................................................................................................................... 61 TRF No.:FCC 15.247/A Page 3 of 61 Report No.: ES150824002E-1 Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: China Electronics Shenzhen Company 33F,Tower A,Electronic Science and Technology Building,2070 Shennan Zhonglu,Futian District Shenzhen Manufacturer: China Electronics Shenzhen Company 33F,Tower A,Electronic Science and Technology Building,2070 Shennan Zhonglu,Futian District Shenzhen Product Description: 5.1CH Bluetooth speaker system Model Number: SBT5100,PBT5100,BS501,BS501B,AR5100 Trademark: Sharper Image, ART+SOUND, Polaroid File Number: ES150824002E-1 Date of Test: August 24, 2015 to November 11, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J,June 11,2014 FCC 47 CFR Part 15, Subpart C,May 9,2014 PASS The above equipment was tested by Emtek (Shenzhen) Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C…
