2AAQS-ISP2454BLuetooth 6.0 BLE Module

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 10/17/2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AAQS-ISP2454 [Insight SiP] (“the applicant”) certifi es that the equipment for which authorization is sough t is not “covered” equipment prohibited from receiving an equipment authorization pursuan t to section 2.903 of the FCC rules. [Insight SiP] (“the applicant”) certifi es that the equipment for which authorization is sough t do es not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, Contact Name: Christopher Barratt Title: President Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 10/17/2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AAQS-ISP2454 [Insight SiP] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Contact Name: Christopher Barratt Title:President

Certification designating a U.S. Agent for service of process: As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. In either scenario, the designation of the U.S. agent for service of process should be provided as an attachment to the equipment authorization application. The applicant must provide a written certification, which must: i. Be signed by both the applicant and designated agent for service of process, if the agent is different from the applicant. ii. Acknowledge the applicant’s consent and the designated agent’s obligation to accept service of process. iii. Provide a physical U.S. address and email for the designated agent. iv. Acknowledge the applicant’s acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Unofficial information provided by FCC personnel on February 14, 2023, via the monthly call with the TCB Council: The Agent for Process of Service:  cannot be a TCB or affiliated with a TCB (e.g. could not be a person who works for a TCB or a company that owns or is owned by the TCB)  cannot be a [FCC recognised] Lab or affiliated with a test lab (e.g. could not be a person who works for a Lab or a company that owns or is owned by the Lab)  Agent can be Individual Entity or a Company Entity  Agent Entity must be located in US, US address/phone  Entity acting as Agent must have FRN (best practice, put FRN on Agent Letter)  Agent letter does not have to be FCC ID specific, can be general Agent for Grantee For devices being marketed or for which marketing has ceased for less than 1 year, if the Agent for Process of Service changes, then for every TC Number the TCB must request the FCC to put application into Audit Mode and Agent Letter needs to be updated (superseded). NOTE: The U.S. Agent for Service of Process should not be confused with the authorized agent used for signing the 731 form, other cover letters within the application, and/or the agent who may interface with the TCB. U.S. Agent Designation for Service of Process ATTENTIO N: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) I nformation Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 E mai l: [email protected] FRN # : 0027533835 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Desig nated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: November 20, 2025 Signed by (Printed Name/Title): Nathan G rinager / Co-President The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Insight SiP Service Type: original application FCC ID: 2AAQS-ISP2454 Grantee FRN: 0022876635 Module type: single-modular transmitter Contact Name: Christopher Barrat Street Address: 400 ave Roumanille, Greenside Baya access Bat 7 Ent1, Sophia antipolis, France City/Province/Zip: 06906 (Zip code) Telephone No: +33 493 00 88 80 Email: [email protected] Applicant Signature: Date: 10/21/2025 Signed by (Printed Name/Title): Christopher Barratt / President *By signing this letter, the client declares and agrees that the service provided by Approve-IT, Inc. will only be applicable for the module model described above. The client also declares and accepts that the service won’t be applicable in any way to any host devices that could contain the module for which the service has been contracted.

GREEN SIDE / BAT 7 / 400, AV. ROUMANILLE / BP 309 / 06906 SOPHIA-ANTIPOLIS / FRANCE MODULAR APPROVAL LETTER Date: 07/30/2025 FCC ID: 2AAQS-ISP2454 Modular Approval Requirement Answers (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The module has a metal shield over the radio elements (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. All data is buffered (iii) The modular transmitter must have its own power supply regulation. The module includes its own LDOs and regulators (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The antenna is permanently attached to the module inside the substrate (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). This is the case (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. The module has the FCC identification number marked on the product (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The user manual contains such explanations (viii) Radio frequency devices operating under the provisions of this part are subject to the radio frequency radiation exposure requirements specified in §§ 1.1307(b), 1.1310, 2.1091, and 2.1093 of this chapter, as appropriate. Applications for equipment authorization of modular transmitters under this section must contain a statement confirming compliance with these requirements. The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Technical information showing the basis for this statement must be submitted to the Commission upon request. The module complies with the RF exposure requirements Sincerely, Contact Name: Christopher Barratt Title: President Insight SIP

GREEN SIDE / BAT 7 / 400, AV. ROUMANILLE / BP 309 / 06906 SOPHIA-ANTIPOLIS / FRANCE Date: 07/30/2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Request of Confidentiality FCC ID: 2AAQS-ISP2454 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Insight SiP hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Insight SiP temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 Internal Photos SHORT-TERM 6 External Photos 7 Test-Setup Photos 8 User Manual 9 - The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Please note that we request that the internal photo are kept confidential permanently since the component placement is a trade secret that is owned by Insight Sip. This information is not available to the public since the module is over-molded with an epoxy mold compound that is difficult to remove. The components are not sold under NDA as this is not necessary to achieve the level of protection that we consider necessary. Sincerely, Contact Name: Christopher Barratt Title: President Insight SIP

GREEN SIDE / BAT 7 / 400, AV. ROUMANILLE / BP 309 / 06906 SOPHIA-ANTIPOLIS / FRANCE Date: 07/30/2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of Dt&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AAQS-ISP2454 including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of Dt&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Insight SiP. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Contact Name: Christopher Barratt Title: President Insight SiP

FCC ID: 2AAQS‐ISP2454 IC: 11306A‐ISP2454 Since the device is very small, the FCC ID, ISED certification number, and HVIN will be placed in the user manual and on the product packaging. M/N: ISP2454FC ID: 2AAQS-ISP2454IC: 11306A-ISP2454“This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions. (1)This device may not cause harmful interference (2)This device must accept any interference received, including interference that may cause undesired operation. top side of the packaging box M/N: ISP2454FC ID: 2AAQS-ISP2454IC: 11306A-ISP2454This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions. (1)This device may not cause harmful interference (2)This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: RF feature Mode Transmitting Frequency(MHz) Test separation distance (mm) ANT Gain (dBi) Max. power with tune-up tolerance (dBm) Note 1 Max. power with tune-up tolerance (mW) Power thresholds SAR test exclusion thresholds BLE GFSK(1Mbps) 2480.00 5.0 1.00 7.40 5.4954 1.73 3.00 Thread O-QPSK (250kbps) 2480.00 5.0 1.00 7.40 5.4954 1.73 3.00 Note1. Conclusion : Note. The calculation result was rounded to two decimal place f or comparison. 2AAQS-ISP2454 Please refer to the operation description for Max tune-up power . Standalone SAR test exclusion considerations SAR evaluation for general popul ation exposure conditions by me asurement or numerical simulation is not required KDB 447498 D01 clause 4.3.1 Step 1) SAR test exclusion thresho lds for 100MHz to 6GHz at test separation distances ≤ 50 mm [ ( max. power of channel, inclu ding tune-up tolerance, mW ) / ( min. test separation distance, mm ) ] · [ √f(GHz) ] ≤ 3.0 for 1g SAR and ≤ 7.5 for 10g extremity SAR Sample Calculation = [ ( 5.4954mW / 5mm ) ] X [ √2.48GHz ] = 1.73

FCC ID: 2AAQS-ISP2454 Report No.: DRTFCC2510-0070 IC: 11306A-ISP2454 This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-238(07)250909 Pages: 2 / 43 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2510-0070 Oct, 17. 2025 Initial issue DongHyun Kang JaeJin Lee FCC ID: 2AAQS-ISP2454 Report No.: DRTFCC2510-0070 IC: 11306A-ISP2454 This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-238(07)250909 Pages: 3 / 43 Table of Contents 1. General Information .................................................................................... 4 1.1. Description of EUT .......................................................................................................... 4 1.2. Support Equipment ......................................................................................................... 4 1.3. Testing Laboratory .......................................................................................................... 5 1.4. Testing Environment ....................................................................................................... 5 1.5. Measurement Uncertainty............................................................................................... 5 1.6. Test Equipment List ........................................................................................................ 6 2. Test Methodology ........................................................................................ 7 2.1. EUT Configuration ........................................................................................................... 7 2.2. EUT Exercise .................................................................................................................... 7 2.3. General Test Procedures ................................................................................................ 7 2.4. Instrument Calibration .................................................................................................... 7 2.5. Description of Test Modes.............................................................................................. 8 3. Antenna Requirements ............................................................................... 8 4. Summary of Test Results ........................................................................... 9 5. Test Result ................................................................................................. 10 5.1. Maximum Peak Conducted Output Power .................................................................. 10 5.1.1. Test Setup .................................................................................................................. 10 5.1.2. Test Procedures ........................................................................................................ 10 5.1.3. Test Results ............................................................................................................... 11 5.2. 6 dB Bandwidth ............................................................................................................. 14 5.2.1. Test Setup .................................................................................................................. 14 5.2.2. Test Procedures ........................................................................................................ 14 5.2.3. Test Results ............................................................................................................... 14 5.3. Power Spectral Density ................................................................................................. 17 5.3.1. Test Setup .................................................................................................................. 17 5.3.2. Test Procedures ........................................................................................................ 17 5.3.3. Test Results ............................................................................................................... 17 5.4. Unwanted Emissions (Conducted) .............................................................................. 20 5.4.1. Test Setup .................................................................................................................. 20 5.4.2. Test Procedures ........................................................................................................ 20 5.4.3. Test Results ............................................................................................................... 21 5.5. Unwanted Emissions (Radiated) .................................................................................. 28 5.5.1. Test Setup .................................................................................................................. 30 5.5.2. Test Procedures ........................................................................................................ 30 5.5.3. Test Results ............................................................................................................... 32 5.6. AC Power-Line Conducted Emissions ........................................................................ 33 5.6.1. Test Setup .................................................................................................................. 33 5.6.2. Test Procedures ........................................................................................................ 33 5.6.3. Test Results ............................................................................................................... 33 5.7. Occupied Bandwidth ..................................................................................................... 36 5.7.1. Test Setup .................................................................................................................. 36 5.7.2. Test Proce…

Text truncated - open the document above for the full version.

FCC ID: 2AAQS-ISP2454 Report No.: DRTFCC2510-0069 IC: 11306A-ISP2454 This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-238(07)250909 Pages: 2 / 65 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2510-0069 Oct, 17. 2025 Initial issue DongHyun Kang JaeJin Lee FCC ID: 2AAQS-ISP2454 Report No.: DRTFCC2510-0069 IC: 11306A-ISP2454 This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-238(07)250909 Pages: 3 / 65 Table of Contents 1. General Information .................................................................................... 4 1.1. Description of EUT .......................................................................................................... 4 1. 1.2. Support Equipment ................................................................................................... 4 1.3. Testing Laboratory .......................................................................................................... 5 1.4. Testing Environment ....................................................................................................... 5 1.5. Measurement Uncertainty............................................................................................... 5 1.6. Test Equipment List ........................................................................................................ 6 2. Test Methodology ........................................................................................ 7 2.1. EUT Configuration ........................................................................................................... 7 2.2. EUT Exercise .................................................................................................................... 7 2.3. General Test Procedures ................................................................................................ 7 2.4. Instrument Calibration .................................................................................................... 7 2.5. Description of Test Modes.............................................................................................. 8 3. Antenna Requirements ............................................................................... 8 4. Summary of Test Results ........................................................................... 9 5. Test Result ................................................................................................. 10 5.1. Maximum Peak Conducted Output Power .................................................................. 10 5.1.1. Test Setup .................................................................................................................. 10 5.1.2. Test Procedures ........................................................................................................ 10 5.1.3. Test Results ............................................................................................................... 11 5.2. 6 dB Bandwidth ............................................................................................................. 16 5.2.1. Test Setup .................................................................................................................. 16 5.2.2. Test Procedures ........................................................................................................ 16 5.2.3. Test Results ............................................................................................................... 17 5.3. Power Spectral Density ................................................................................................. 22 5.3.1. Test Setup .................................................................................................................. 22 5.3.2. Test Procedures ........................................................................................................ 22 5.3.3. Test Results ............................................................................................................... 23 5.4. Unwanted Emissions (Conducted) .............................................................................. 28 5.4.1. Test Setup .................................................................................................................. 28 5.4.2. Test Procedures ........................................................................................................ 28 5.4.3. Test Results ............................................................................................................... 29 5.5. Unwanted Emissions (Radiated) .................................................................................. 43 5.5.1. Test Setup .................................................................................................................. 45 5.5.2. Test Procedures ........................................................................................................ 45 5.5.3. Test Results ............................................................................................................... 47 5.6. AC Power-Line Conducted Emissions ........................................................................ 49 5.6.1. Test Setup .................................................................................................................. 49 5.6.2. Test Procedures ........................................................................................................ 49 5.6.3. Test Results ............................................................................................................... 49 5.7. Occupied Bandwidth ..................................................................................................... 52 5.7.1. Test Setup .................................................................................................................. 52 5.7.2. Test Procedur…

Text truncated - open the document above for the full version.

ISP2454 Technical Specification www.insightsip.com Document reference ISP2454-TS Page 1/2 1.Antenna report 1.Antenna Keep-Out Zone For optimal antenna performance, it is recommended to respect a metal exclusion zone to the edge of the board: no metal, no traces, and no components on any application PCB layer except mechanical LGA pads. 2.Typical Antenna Return Loss Module mounted on a USB dongle ground plane ISP2454 Technical Specification www.insightsip.com Document reference ISP2454-TS Page 2/2 3.Radiation Pattern in 3 planes Module mounted on a USB dongle ground plane The measurement of maximum gain is 1 dBi in the BLE band from 2.4 GHz to 2.5 GHz.
