2AASG-MS3590Barcode Scanner

MS3590 Programmable Mobile Scanner User Manual Version: MS3590_UM_EN_V1.0.3 i ii Notice Before operating this mobile scanner, please make sure you carefully read the following information to ensure that your scanner is able to perform at the level for which it is designed. 1. All software, including firmware, furnished to the user is on a licensed basis. 2. The right is reserved to make changes to any software or product to improve reliability, function, or design. 3. The contents of this manual are subject to change without notice. 4. The manufacturer assumes no responsibility for any loss or claims by third parties which may arise from the use of this manual. 5. Do not throw or drop the scanner or otherwise subject it to strong impact, which can damage the scanner, interrupt program execution, corrupt memory contents, or otherwise interfere with proper operation. 6. A standard packing includes a mobile scanner, a USB cable and a CD (containing software and electrical manuals). Accessory includes a Bluetooth USB adapter BA2110 which supports reliable wireless data transmission and an AC/DC adaptor for battery charge. 7. Please charge the battery before the first time of use. 8. The term “scanner” as used in this manual denotes the MS3590 mobile scanner unless otherwise noted. iii iv Contents Notice ........................................................................................................................................................................ ii 1 Specifications ........................................................................................................................................................ 1 1-1 Technical specifications .............................................................................................................................. 1 1-2 Default settings for each barcode .............................................................................................................. 3 1-3 Dimensions ................................................................................................................................................... 4 1-5 Parts of the scanner ..................................................................................................................................... 5 1-6 Parts of the Bluetooth USB adapter BA2110 ........................................................................................... 6 1-7 Keys introduce .............................................................................................................................................. 7 2 Introduction to installation ................................................................................................................................... 8 2-1 Installing a USB HID keyboard wired scanner ......................................................................................... 8 2-2 Installing a USB virtual COM wired scanner ............................................................................................ 8 2-3 Attaching the neck/wrist strap .................................................................................................................... 9 2-4 Replacing the Lithium-ion battery .............................................................................................................. 9 3 Getting started .................................................................................................................................................... 10 3-1 Power on/off scanner ................................................................................................................................. 10 3-2 Charge battery ............................................................................................................................................ 10 3-3 Enter/Exit sleep mode ............................................................................................................................... 10 3-4 Power on/off Bluetooth .............................................................................................................................. 10 4 Introduction to LCD display ................................................................................................................................ 11 4-1 LCD display icons ...................................................................................................................................... 11 4-2 LCD display menu ...................................................................................................................................... 12 5 Operations of the scanner ................................................................................................................................. 16 5-1 Scan ............................................................................................................................................................. 16 5-1-1 Scan Mode ........................................................................................................................................... 16 5-1-2 Input Data Manually ........................................................................................................................... 16 5-1-3 Quantity Enter ..................................................................................................................................... 17 5-1-4 Add Time .............................................................................................................................................. 17 5-1-5 Add Date .............................................................................................................................................. 18 5-1-6 Set Separator ...................................................................................................................................... 18 5-1-7 Database Query ........................................................…

Text truncated - open the document above for the full version.

Shenzhen Minde Electronics Technology LTD Confidentiality Letter Date: 2014-07-22 Subject: Confidentiality Request for FCC ID: 2AASG-MS3590 Pursuant to FCC 47 CRF 0.457(d) and 0.459, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term User’s Manual _____ Shenzhen Minde Electronics Technology LTD_____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: __ Guowen Zhou_/ Marketing Manager__ ________________________ (Signature/Title) (Print name)

FCC ID : 2AASG-MS3590 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 D01 General RF Exposure Guidance v05, section 4.3.1 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. GFSK Mode Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Calculation Value(mW) Threshold Value(mW) 2402 -0.82 0.83 0.26 3.0 2441 -1.15 0.77 0.24 3.0 2480 -1.28 0.74 0.23 3.0 ∏/4-DQPSK Mode Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Calculation Value(mW) Threshold Value(mW) 2402 -3.43 0.45 0.14 3.0 2441 -3.89 0.41 0.13 3.0 2480 -3.94 0.40 0.13 3.0 8DPSK Mode Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) Calculation Value(mW) Threshold Value(mW) 2402 -3.18 0.48 0.15 3.0 2441 -3.59 0.44 0.14 3.0 2480 -3.72 0.42 0.13 3.0 Threshold at which no SAR required is ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

Page 1 of 93 FCC ID: 2AASG-MS3590 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20140803 APPLICATION CERTIFICATION On Behalf of Shenzhen MinDe Electronics Technology Ltd. Barcode Scanner Model No.: MS3590, MS35XX(XX stand for 00-99, AA-ZZ) FCC ID: 2AASG-MS3590 Prepared for : Shenzhen MinDe Electronics Technology Ltd. Address : 5th Floor, Section 1,25th Block,No.5,Keji Xi Road,Keji Yuan, Nanshan District, Shenzhen, P.R. China Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20140803 Date of Test : May 16-July 18,2014 Date of Report : July 21,2014 Page 2 of 93 FCC ID: 2AASG-MS3590 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20140803 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 5 1.1. Description of Device (EUT)....................................................................................................................5 1.2. Description of Test Facility ......................................................................................................................6 1.3. Measurement Uncertainty.........................................................................................................................6 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 7 3. OPERATION OF EUT DURING TESTING ................................................................................. 8 3.1. Operating Mode ........................................................................................................................................8 3.2. Configuration and peripherals ..................................................................................................................8 4. TEST PROCEDURES AND RESULTS ......................................................................................... 9 5. 20DB BANDWIDTH TEST............................................................................................................10 5.1. Block Diagram of Test Setup..................................................................................................................10 5.2. The Requirement For Section 15.247(a)(1) ............................................................................................10 5.3. EUT Configuration on Measurement .....................................................................................................10 5.4. Operating Condition of EUT ..................................................................................................................10 5.5. Test Procedure ........................................................................................................................................11 5.6. Test Result ..............................................................................................................................................11 6. CARRIER FREQUENCY SEPARATION TEST........................................................................ 17 6.1. Block Diagram of Test Setup..................................................................................................................17 6.2. The Requirement For Section 15.247(a)(1) ............................................................................................17 6.3. EUT Configuration on Measurement .....................................................................................................17 6.4. Operating Condition of EUT ..................................................................................................................17 6.5. Test Procedure ........................................................................................................................................18 6.6. Test Result ..............................................................................................................................................18 7. NUMBER OF HOPPING FREQUENCY TEST ......................................................................... 24 7.1. Block Diagram of Test Setup..................................................................................................................24 7.2. The Requirement For Section 15.247(a)(1)(iii) ......................................................................................24 7.3. EUT Configuration on Measurement .....................................................................................................24 7.4. Operating Condition of EUT ..................................................................................................................24 7.5. Test Procedure ........................................................................................................................................25 7.6. Test Result ..............................................................................................................................................25 8. DWELL TIME TEST ..................................................................................................................... 27 8.1. Block Diagram of Test Setup..................................................................................................................27 8.2. The Requirement For Section 15.247(a)(1)(iii) ......................................................................................27 8.3. EUT Configuration on Measurement .....................................................................................................27 8.4. Operating Condition of EUT ..................................................................................................................27 8.5. Test Procedure ........................................................................…

Text truncated - open the document above for the full version.
