2AASXMT-740TABLET PC

- 1 - MT-740 User manual User manual catalog ............................................................................................................ - 1 - 1 Outer appearance and button introduction ...................................................................... - 2 - 2 Turn on/off ....................................................................................................................... - 3 - 3 Unlock/lock the touch screen ........................................................................................ - 4 - 4 Home Screen .................................................................................................................. - 4 - 5 The virtual keyboard and input method ............................................................................ - 4 - 6 WIFI internet ..................................................................................................................... - 5 - 7 Network download the APK application and the game installation .................................. - 5 - 8 Charge description ............................................................................................................ - 5 - 9 protect the machine and accessories ................................................................................. - 5 - - 2 - 1 Outer appearance and button introduction - 3 - 1.1Hardware configurations Size（L*W*H） 192*120*10.8mm Weight 420g CPU Action ATM7029 1.2GHZ Quad core Storage 4GB DDR 1G DDR3 TF Card slot T-flash 128M-32G Cameras Front 0.3M / Rear 2M Display 7”TFT capacitive multi touch Resolution 1024*600 Working time 2-8 Hours USB USB 2.0 Speaker One Stereo speakers G-sensor Yes I/O port 1* USB 2.0 OTG support 3G、U disk、mouse、keyboard、USB 1* T card can extend support to 32GB 1*3.5mm stereo earphone 1* DC5V power input 1* HDMI HD output Wifi Built in WiFi 802.11b/g/n 1.2Software configuration Operation system Android4.1 The browser Google browser Video AVI、WMV、MOV、MKV、RM、RMVB、 MP4、M4V、DivX、Xvid、FLV、 3GP、DAT、VOB、MPG、MPEG、 AVS、ASF、TP、TRP、TS、M2TS、 MTS Music MP3/WMA/CBR/VBROGG/APE/FLA C/WAV/AAC/AudibleRA/AC3/ DTS/MIDI/AMR/AIFF/MPC Picture MJPEG, JPEG,JPG,BMP,GIF,PNG Email Email MIC Built in MIC 2 Open/close MID 1、 Open：long press the power button for 3-5seconds； 2、 Close：long press the power button for 3-5 seconds, choose turn off-yes。 - 4 - 3 Unlock or lock the touch screen 1、 Lock：short press the power button the screen will enter the black screen and lock； 2、 Unlock：short press the power button the screen lights up, then the ring to "lock" direction of the slide to unlock 4 Menu options 1、 In the main screen touch“”to enter application program interface list； 2、 short press“Return” Return to the previous menu ； 3、 short press“HOME” Return to the main menu ； 4、 view the recently taskbar，touch it soon entry directly. “ ”。 5 The virtual keyboard and input method 1、 Click on any input box； 2、 the bottom of the pop-up virtual keyboard； 3、 press the input box 3 seconds to switch the input method options； 4、 Note: Baidu input method can use Chinese handwriting input method, using different input method of the virtual keyboard is slightly different, the following explains only Google Pinyin input method 5、 Touch to switch number and character； 6、 Touch to select the size of letters； - 5 - 7、 click on the "English" or "Chinese" input switching in English； 8、 after the completion of the input and click "go" for sure。 6 WIFI Surf the Internet WI-FI access network the following steps： 1. into the "wireless network" and click the “WI-FI”； 2. click on the "WI-FI settings"； 3. Click on the WI-FI to connect to the network； 4. if necessary, in the password entry dialog pop-up and click "connect"。 7 Network download the APK application and the game installation 1、 WIFI/3G the network must be connected correctly； 2、 open any webpage search or download the suffix ".Apk" application / game, choose to install the APK application / game, there will be "Install" option, click "Install", suggesting "downloading -- finished downloading, installing -- the installation is complete," this can open this application, can also be Click on the "uninstall", uninstall this program。 8 Charge description Charger A. output voltage：5V B. output current：2000mA~2500mA Note: the charger specifications must meet the above specifications, or any failure or accident, the company is regarded as a man-made damage！ 9 protect the machine and accessories This machine is a complex electronic equipment, and can be used as a miniature computer. These tips can help to extend the service life of the machine. * the best equipment in a safe place, away from the water source to protect the machine and accessories; * use only original manufacturer in the production of machine parts, the parts without permission is likely to damage the machine, the machine service life shorten; * avoid by weight, fall from a height, not forced to run the machine。 The machine configuration and software in order to prevail in kind - 6 - FCC Statment This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particula…

Text truncated - open the document above for the full version.

MEERA INTERNATIONAL LIMITED 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong MEERA INTERNATIONAL LIMITED FCC ID: 2AASXMT-740 DATE: Dec 03, 2013 We , MEERA INTERNATIONAL LIMITED doesn’t provide any controls or software to allow the operation outside of the USA frequency band (2412-2462MHz) when we sell this product in USA. Sincerely, Client’s signature : Client’s name / title:Prakash Kalwani / General Manager Company Name: MEERA INTERNATIONAL LIMITED Address: 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong E-mail: [email protected] Fax: + 86 20 3886 9426 Tel: + 86 20 3886 9429

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 MEERA INTERNATIONAL LIMITED 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong Dec 03,2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AASXMT-740 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram- Long-term confidential - Schematics- Long-term confidential - Operational Description- Long-term confidential The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title:Prakash Kalwani / General Manager Company Name: MEERA INTERNATIONAL LIMITED Address: 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong E-mail: [email protected] Fax: + 86 20 3886 9426 Tel: + 86 20 3886 9429

MEERA INTERNATIONAL LIMITED 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong Product Similarity Declaration FCC ID: 2AASXMT-740 DATE: Dec 03, 2013 To Whom It May Concern, We, MEERA INTERNATIONAL LIMITED, hereby declare that our product (TABLET PC) Model Number: MT-720,MT-725,NTB-720,NTB-740 and NTB-725 are electrically identical with the Model MT740. MT-720,MT-725,NTB-720,NTB-740 and NTB-725 are named differently due to marketing purposes Please contact me if you have any question. Sincerely, Client’s signature : Client’s name / title:Prakash Kalwani / General Manager Company Name: MEERA INTERNATIONAL LIMITED Address: 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong E-mail: [email protected] Fax: + 86 20 3886 9426 Tel: + 86 20 3886 9429

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 MEERA INTERNATIONAL LIMITED 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong Dec 03, 2013 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ MEERA INTERNATIONAL LIMITED __hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AASXMT-740 Product Name: TABLET PC Model: MT-740,MT-720,MT-725,NTB-720,NTB-740,NTB-725 We affirm that between SIEMIC and ____ MEERA INTERNATIONAL LIMITED ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature : Client’s name / title:Prakash Kalwani / General Manager Company Name: MEERA INTERNATIONAL LIMITED Address: 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong E-mail: [email protected] Fax: + 86 20 3886 9426 Tel: + 86 20 3886 9429

External photos of the EUT

Label Label Location

Internal photos of the EUT WLAN Antenna v

FCC TEST REPORT 47 CFR FCC Part 15 Subpart B Report Reference No. ..................... : FCC ID. .............................................: TRE1311014502 R/C: 98242 2AASXMT-740 Compiled by ( position+printed name+signature) .. : File administrators Eric Wang Supervised by ( position+printed name+signature) .. : Test Engineer Yuchao Wang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Dec 10, 2013 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................ : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : MEERA INTERNATIONAL LIMITED Address ............................................ : 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong Test specification ...........................: Standard ........................................... : 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : TABLET PC Trade Mark ....................................... : / Model/Type reference ....................... : MT-740 Listed Models .................................. : MT-740,MT-720,MT-725,NTB-720,NTB-740,NTB-725 Manufacturer .................................. : SHENZHEN LUCKYSTARS TECHNOLOGY CO., LTD Rating ............................................... : DC 3.70V/DC 5.0V adapter from AC120V/60Hz Android Version ................................ : Android 4.2.2 Result................................................ : PASS Report No.: TRE1311014502 Page 2 of 24 Issued:2013-12-10 T E S T R E P O R T Test Report No. : TRE1311014502 Dec 10, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : TABLET PC Model /Type : MT-740 Listed Models : MT-740,MT-720,MT-725,NTB-720,NTB-740,NTB-725 Applicant : MEERA INTERNATIONAL LIMITED Address : 301 Kam On Building, 176A Queen’s Road Central, Central, Hong Kong Manufacturer SHENZHEN LUCKYSTARS TECHNOLOGY CO., LTD Address : 21st Fl., Fuchun Orient Bldg., 7006# Shennan Ave., Futian CBD, Shenzhen 518040, P.R.C Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1311014502 Page 3 of 24 Issued:2013-12-10 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Internal Identification of AE used during the test 5 2.7. Modifications 6 2.8. EUT configuration 6 2.9. Configuration of Tested System 6 2.10. NOTE 7 3. TEST ENVIRONMENT ............................................................... 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Statement of the measurement uncertainty 9 3.5. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 12 5. TEST SETUP PHOTOS OF THE EUT .......................................... 16 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 17 Report No.: TRE1311014502 Page 4 of 24 Issued:2013-12-10 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz Report No.: TRE1311014502 Page 5 of 24 Issued:2013-12-10 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Nov 29, 2013 Testing commenced on : Dec 05, 2013 Testing concluded on : Dec 05,2013 2.2. Product Description The MEERA INTERNATIONAL LIMITED’s Model: MT-740 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT TABLET PC Model Number MT-740,MT-720,MT-725,NTB-720,NTB-740,NTB-725 FCC ID 2AASXMT-740 WLAN Supported 802.11b/802.11g/802.11n Antenna Type Internal WLAN FCC Operation frequency IEEE 802.11b: 2412MHz—2462MHz IEEE 802.11g: 2412MHz—2462MHz IEEE 802.11n HT20: 2412MHz—2462MHz IEEE 802.11n HT40: 2422MHz—2452MHz WLAN Modulation IEEE 802.11b: DSSS(CCK,DQPSK,DBPSK) IEEE 802.11g: OFDM(64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20: OFDM (64QAM, 16QAM, QPSK,BPSK) IEEE 802.11n HT40: OFDM (64QAM, 16QAM, QPSK,BPSK) Android Version Android 4.2.2 2.3. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC z Other (specified in blank below) DC 3.70V/DC 5.0V Adapter from AC 120V/60Hz 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: FCC ID:2AASXMT-740 filing to comply with the FCC Part 15, Subpa…
